PORTABLE LAMP WARMER
Model LW-2
The Hatco Portable Lamp Warmer will
hold your food products at serving
temperatures. The specially designed
powdercoated stand keeps food holding
pans above the countertop, providing
an effective insulation to prolong
serving times.
FLEXIBILITY
This lamp warmer holds full size and
half size pans of appetizers, chicken
wings, or other hot foods. Ideal for
restaurants, cafeterias, concession
stands, convenience stores, and delis,
this warmer has an adjustable stand
that varies the height 141/4" to 201/2"
(368-521 mm) from the bottom of the
lamp shroud to the countertop.
Blend the Lamp Warmer with the décor
by choosing one of six powdercoated
Designer colors: warm red, black, gray
granite, white granite, navy blue, and
hunter green.
QUALITY
The following features assure the finest
performance for years to come:
• The LW-2 has a 6' (1829 mm) cord and
plug with in-line power switch located
outside of the heat zone.
• Vented lamp shades with heavy-
duty sockets.
• The Hatco Lamp Warmer comes with
two 250-watt clear uncoated heat
bulbs. Uncoated red, coated red, and
coated clear bulbs are available.
Model LW-2
with accessory
food pans

OPTIONS (NOT FOR RETROFIT)
❑Designer Colors: Warm Red, Black, Gray Granite, White Granite,
Navy Blue, Hunter Green
ITEM#
SPECIFICATIONS
123/8" (314 mm)
SIDE VIEW
24" to 30"
(610-762 mm)
141/2" to 201/2"
(368-521 mm)
101/2" to 161/2"
(267-419 mm)
FRONT VIEW
203/4" (527 mm)
22" (559 mm)
4"
(102 mm)
DIMENSIONS
123/8"W x 22"D x 24"-30"H (314 x 559 x 610-762 mm).
VOLTAGE
120 volts, single phase (uses NEMA 5-15P).
Export voltages available.
CORD LOCATION
Back of adjustable stand near top.
PLUG CONFIGURATIONS
PRODUCT SPECS
Lamp Warmer
The Lamp Warmer shall be a Hatco Model ....as manufactured
by the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Lamp Warmer shall be rated at ....watts, ....volts, and be
....inches (millimeters) in overall width. It shall consist of a
powdercoated stand, two vented lamp shades with two
uncoated 250-watt heat bulbs, an adjustable stand that varies
the height 141⁄2" to 201⁄2" (368-521 mm) from the bottom of the
lamp shroud to the countertop, and a 6' (1829 mm) cord and
plug with an in-line power switch.
Accessories shall include 250-watt coated clear, coated red,
uncoated red bulbs, five pleat hardcoated fry box ribbon, and
an eight pleat hardcoated fry bag ribbon.
ACCESSORIES
❑250 Watt Clear Bulb, Coated
❑250 Watt Red Bulb, Uncoated, 120V only
❑250 Watt Red Bulb, Coated, 120V only
❑5 Pleat Hardcoated French Fry Box Ribbon
❑8 Pleat Hardcoated French Fry Bag Ribbon
PORTABLE LAMP WARMER
Model LW-2
Model▲Watts Amps Shipping Weight
LW-2 500 4.2 13 lbs. (6 kg)
▲When no color is specified, color will be gray granite.
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. LW-1006(S) Printed in U.S.A.
BS-1363CEE 7/7 SchukoNEMA 5-15P
