Haworth Jive Table with Swivel Base User manual

Jive
Assembly Instructions
Congratulations on your
purchase of a new Jive
Table with Swivel Base!
Ready to create a dedicated workspace just for you?
We know you want to get up and running as soon as possible, but
before you dive right into setting up your table, be sure to:
1. Grab a friend to help you with the lifting. They can also help you
hold parts in place during assembly to make things a little easier.
2. Make sure you have all your parts and hardware, and gather the
necessary tools and safety equipment.
3. Follow all the steps carefully before using your table.
That’s it! Once you’ve got your table assembled, you’ll be ready to
get down to business with a fresh, new space that’s dedicated to
helping you stay productive.
For assembly assistance, visit haworth.com, call 800 426 8562, or email [email protected]

9/16”
B
S-66
Scale 1 : 1
0 11/2
1/4 1/4
(S-66) #12 x 1” Pan Head Screw
30D x 60W
30D x 72W
24D x 60W
#2
C
D
#2
A
Tools Required
Assembly Overview
Jive Table with Swivel Base Assembly Instructions
Customer Service: 800 426 8562 E.C.O. No 245-691 Part No 6100-0170 Rev 1 Page 2 of 6

(A) Table Top
(B) Swivel Base Legs - Magnet
(S-66) Pan Head Screws - Qty. 24
(D) Casters
(C) Swivel Base Legs - Swing Arm
Customer Service: 800 426 8562 E.C.O. No 245-691 Part No 6100-0170 Rev 1 Page 3 of 6
Jive Table with Swivel Base Assembly Instructions

C
Magnetic and Swing Arm locations (topside view)
24 Qty.
1
S-66
A
Attach swivel base legs (B and C) to table top (A) as shown
C B
B C
B
NOTE: Swivel base swing arm legs (C)
must be installed on opposite corners
of the table.
Customer Service: 800 426 8562 E.C.O. No 245-691 Part No 6100-0170 Rev 1 Page 4 of 6
Jive Table with Swivel Base Assembly Instructions
(S-66) #12 x 1” Pan Head Screw

2Insert casters (D) and tighten with wrench as shown
With a helper, flip table onto its feet
3
FLIP TABLE
ONTO FEET
C
B
Non-Locking
Locking
D
9/16”
Wrench
FLIP TABLE
ONTO FEET
Jive Table with Swivel Base Assembly Instructions
Customer Service: 800 426 8562 E.C.O. No 245-691 Part No 6100-0170 Rev 1 Page 5 of 6

4Align tables so base legs with magnets (B) and base legs with swing arms (C) are adjacent to one another
C
B
C
B
Pivot each swing arm (on C) to attach to the adjacent magnet (on B)
TABLE CONNECTION AND ALIGNMENT
5
C
B
Customer Service: 800 426 8562 E.C.O. No 245-691 Part No 6100-0170 Rev 1 Page 6 of 6
Jive Table with Swivel Base Assembly Instructions
