Haws 1920FR Guide

05/19 Model 1920FR Page 1 of 7
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0510000491 (4)
Model 1920FR
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS, Sparks,
Nevada. HAWS will not be liable for any damages caused by defective materials or
poor workmanship, except for replacements, as provided above. Buyer agrees that
HAWS shall not be liable for general, special, or consequential damages claimed to
arise under the contract of sale. The drinking fountain manufactured by HAWS is
warranted to function if installation and maintenance instructions provided are
adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

05/19 Model 1920FR Page 2 of 7
REQUIRED TOOLS: Tubing cutter, 3/32” and 5/32” hex key set, adjustable wrench or
socket.
LOCATION OF UNIT: The Model 1920FR bottle filler water dispenser can be installed in
various applications. Possible installations include indoor over an existing drinking fountain,
outdoors over an existing fountain, or as a stand-alone wall-mounted bottle filler. When
installing this unit, local, state or federal codes should be adhered to.
SUPPLY LINE: The minimum recommended line size is 3/8"O.D. copper or plastic tubing
with 30-90 psi (2-6 ATM) pressure. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet is 3/8“O.D. push-in type fitting.
MAINTENANCE: Refer to 6521FR operation and maintenance sheet for more information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes
O.D.
Tolerance
Insertion Depth
1/4”
±.005”
11/16”
3/8”
±.005”
3/4”
1/2”
±.005”
7/8”
BOTTLER FILLER BRACKET:
If installing the bottler filler in new construction, use Model 6700 or 6700.4L Mounting Plate.
Follow the installation instructions supplied with the 6700 or 6700.4L for mounting dimensions.
Reference Page 5-7 of this document for 1920FR button height when mounted over different
Haws drinking fountains.
If installing as a retrofit in old construction, it is recommended to use Model 6700 or 6700.4
Mounting Plate behind the finished wall. If that is not possible, it is recommended to install wood
stud cross-braces behind the wall and mount the 1920FR directly to the wood support. If that is
not possible, Model 6700R Retrofit Plate may be used. Follow the installation instructions
supplied with the 6700R.
If installing as a standalone bottle filler, use the mounting hole location diagram on Page 5 and
bolt the 1920FR securely to the wall.
WATER LINE:
Refer to 6521FR Manual for water line connection instructions. Refer to 6518FR Manual for
water line connection instruction in pedestal installation. NOTE: The 1920FR is shipped with laminar
flow screens in the dispensing nozzle. In cold temperatures remove laminar screens to prevent water
from freezing and clogging the supply line.

05/19 Model 1920FR Page 3 of 7
TROUBLESHOOTING 1920FR
PROBLEM
REPAIR CHECKLIST
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve is wide
open (customer supplied). Turn
counterclockwise.
b.
Verify minimum 30 psi flowing supply pressure.
c.
Adjust valve to increase flow. See 6518FR/
6521FR Valve Manual.
d.
Clean screens (inside nozzle body). Unscrew
nozzle insert and very gently activate water
supply to pop out qty. 3 screens (be careful not to
lose screens). Remove any debris clogging the
screen openings and place back into nozzle body.
Reassemble nozzle insert.
For more information about Haws products, see our website: www.hawsco.com
© 2019 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
MJ
06/08/16
4
0510000491
1920FR
1:14
11
IR 07/10/19
5081
DP
4 OF 7
PARTS BREAKDOWN
5400
2019
FV
1
1PUSH BUTTON ASSY 5881PBA

APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: H[email protected]OM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
DS 05/25/16
4
0510000491.D
1920FR
N/A
13
IR 07/10/19
5081
DP
5 of 7
INSTALLATION
5400
2019
FV
NOTES:
1THIS BOTTLE FILLER REQUIRES THE USE OF MODEL 6521FR FREEZE RESISTANT VALVE
ASSEMBLY (SOLD SEPERATELY)
2VALVE ASSEMBLY MUST BE INSTALLED IN A WARM AREA. PROVISIONS SHOULD BE MADE
TO ALLOW ACCESS TO THE ACCESS PANEL.
3. WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.
FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS MARKED (*) MUST BE ADJUSTED
ACCORDINGLY.
1920 MOUNTING HOLE LOCATIONS

APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
MJ
02/13/17
4
0510000491.D
1920FR
N/A
23
IR 07/10/19
5081
DP
6 of 7
INSTALLATION
5400
2019
FV
NOTES:
1THIS BOTTLE FILLER REQUIRES THE USE OF MODEL 6521FR FREEZE RESISTANT VALVE
ASSEMBLY (SOLD SEPERATELY)
2VALVE ASSEMBLY MUST BE INSTALLED IN A WARM AREA. PROVISIONS SHOULD BE MADE
TO ALLOW ACCESS TO THE ACCESS PANEL.
3. SEE SEPERATE INSTALLATION DRAWINGS FOR FOUNTAINS, MOUNTING PLATES, BACKPANELS,
4. WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.
FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS MARKED (*) MUST BE ADJUSTED
ACCORDINGLY.
6521FR FREEZE
RESISTANT VALVE
ASSEMBLY (FOR
FOUNTAIN, SHOWN
FOR REF. ONLY)
6521 VALVE ASSEMBLY
ACCESS PANEL 2
6521FR FREEZE RESISTANT
VALVE ASSEMBLY (FOR BF) 1 2
CONNECT AIR LINE TO BOTTLE
FILLER PUSH BUTTTON, TRIM TO FIT.
7/8" OD INSULATING TUBING (MUST COVER
ENTIRE SUPPLY TUBING, FROM THE
NOZZLE TO MODEL 6521FR ASSEMBLY,
TRIM TO FIT.
3/8" OD POLYPROPYLENE TUBING
(CONNECT TO NOZZLE WITH SUPPLIED
PUSH IN ELBOW, TRIM TO FIT.
1-1/4" NPT
WASTE (NOT
SUPPLIED)
1/2" NPT SUPPLY
(NOT SUPPLIED)
(47-5/8")
(1210mm)
BUTTON
HEIGHT
27"
686mm
FOR ADA
COMPLIANCE
BP15
6469
438mm
17-1/4"
34-1/2"
876mm
37-1/2"
952mm
39-1/2"
1003mm
(4")
(102mm)
DEPTH
OF BOX
6700 MOUNTING PLATE
(BEHIND FINISH WALL)
- OR -
6700R RETROFIT PLATE
(ON TOP OF FINISH WALL)
INSTALLATION ABOVE HAWS 1109FR, 1109FRBP
BP3
AND DRIP TRAY. HOLD ROUGH-IN DIMENSIONS±1/8" (3.2mm)

APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
MJ
02/13/17
4
0510000491.D
1920FR
N/A
33
IR 07/10/19
5081
DP
7 of 7
INSTALLATION
5400
2019
FV
NOTES:
1THIS BOTTLE FILLER REQUIRES THE USE OF MODEL 6521FR FREEZE RESISTANT VALVE
ASSEMBLY (SOLD SEPERATELY)
2VALVE ASSEMBLY MUST BE INSTALLED IN A WARM AREA. PROVISIONS SHOULD BE MADE
TO ALLOW ACCESS TO THE ACCESS PANEL.
3. SEE SEPERATE INSTALLATION DRAWINGS FOR FOUNTAINS, MOUNTING PLATES, BACKPANELS,
4. WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.
FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS MARKED (*) MUST BE ADJUSTED
ACCORDINGLY.
INSTALLATION ABOVE HAWS 1119FR
AND DRIP TRAY. HOLD ROUGH-IN DIMENSIONS±1/8" (3.2mm)
27"
686mm
(47-5/8")
(1210mm)
BUTTON
HEIGHT
FOR ADA
COMPLIANCE
6469
6700.4L MOUNTING PLATE
(BEHIND FINISH WALL)
- OR -
6700R RETROFIT PLATE
(ON TOP OF FINISH WALL)
34-1/2"
876mm
37-1/2"
952mm
39-1/2"
1003mm
BP32
1920FR
17-1/4"
438mm
WITH SUPPLIED PUSH IN ELBOW,
TUBING (CONNECT TO NOZZLE
3/8" OD POLYPROPYLENE 7/8" OD INSULATING TUBING (MUST COVER
ENTIRE SUPPLY TUBING, FROM THE
NOZZLE TO MODEL 6521FR ASSEMBLY,
TRIM TO FIT.
CONNECT AIR LINE TO BOTTLE
FILLER PUSH BUTTTON, TRIM TO FIT.
TRIM TO FIT. 1/2" NPT SUPPLY
(NOT SUPPLIED)
1-1/4" NPT
WASTE (NOT
SUPPLIED)
6521 VALVE ASSEMBLY
ACCESS PANEL 2
6521FR FREEZE RESISTANT
VALVE ASSEMBLY (FOR BF) 1 2
