Haws 3300FR Guide

03/20 Model 3300FR Page 1 of 4
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0002077342 (14)
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS, Sparks,
Nevada. HAWS will not be liable for any damages caused by defective materials or
poor workmanship, except for replacements, as provided above. Buyer agrees that
HAWS shall not be liable for general, special, or consequential damages claimed to
arise under the contract of sale. The drinking fountain manufactured by HAWS is
warranted to function if installation and maintenance instructions provided are
adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
Model 3300FR
Drinking Fountain
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/20 Model 3300FR Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64” hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open-
end wrench.
LOCATION OF UNIT: The Model 3300FR Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions shown, meet current ADA requirements.
When installing this unit, local, state or federal codes should be adhered to. If height other
than shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Waste outlet is female 1-1/2” Slip PVC.
MAINTENANCE: Periodically clean the strainer. Refer to 6518.2FR Valve Operation and
Maintenance Sheet for information.
TROUBLESHOOTING
3300FR with 6518.2FR
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve
is wide open. Turn counterclockwise.
b.
Verify minimum 30 psi flowing supply
pressure.
c.
Clean inlet strainer.
d.
Adjust valve to increase flow. See
6518.2FR Valve Manual.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2020 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1 VALVE, DUAL, FREEZE RESISTANT
2
3STRAINER ASSY
4BUBBLER HEAD PUSH BTN ASS'Y
2
4
3
PARTS BREAKDOWN
A
5703M
5881PBA
6518.2FR
6466
VALVE BOX
(NOT SUPPLIED)
1
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
D. OLLOM
11/25/95
14
0002077342
3300FR
1:14
11
FV 04/02/20
DP
3 OF 4
PARTS BREAKDOWN
5527
2020
FV
1
ENSURE TUBE IS DISCONNECTED FROM
"PUSH-IN" TYPE CONNECTOR ON PRESSURE
REGULATOR PRIOR TO REMOVAL. APPLY A
DROP OF LOCTITE 222MS ON NOZZLE
THREADS PRIOR TO REASSEMBLING BACK
ONTO BUBBLER HEAD. REATTACH TUBE TO
"PUSH-IN" TYPE CONNECTOR ENSURING IT IS
FULLY BOTTOMED OUT.
1NOTE:
DETAIL A
ROTATED 90° INTO VIEW
DETAIL OF ITEM 3
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
1
**
** REQUIRED - SOLD SEPARATELY

41-3/4"
1060mm
GROUND LEVEL
30" SQUARE
CONCRETE SLAB
(NOT SUPPLIED)
ACCESS PLATES
457mm
30"
762mm
18"
35-3/4"
686mm
27"
908mm
1 1/2"
SLIP PVC
(NOT SUPPLIED)
WASTE
(TO SPOUT
OUTLET)
(TO SPOUT
OUTLET)
4X 1/2"-13 UNC
CONCRETE ANCHORS
BURY DEPTHS OF 48"[1219mm] AND 72"
[1829mm]. WASTE TO BE 1-1/4" IPS
MINIMUM TO A POROUS GRAVEL FILL OR
MAIN SEWER LINE LOCATED BELOW
152mm
Ø
FROST LINE (NOT SUPPLIED).
127mm
5"
6"
4X MOUNTING HOLES
FOR 1/2" ANCHOR BOLTS
241mm
9-1/2"
MOUNTING DETAIL
IN CONCRETE SLAB
TEMPLATE FOR
PEDESTAL
9-1/2"
241mm
MTG. BOLTS
4X 1/2"-13 UNC
(SUPPLIED)
VALVE BOX
DISCONNECT COUPLING
TO REPLACE BUBBLER
HEAD (2X)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CJL
09/29/92
14
0002077342.D
3300FR
1:13
11
FV 04/02/20
DP
4 OF 4
INSTALLATION
5527
2020
FV
6518.2FR VALVE ASSY
(SUPPLIED)
(NOT SUPPLIED)
REQUIRED - SOLD SEPARATELY
