Haws 3500FR Guide

03/20 Model 3500FR Page 1 of 4
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0002077455 (14)
Model 3500FR
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material
or poor workmanship for a period of one year from date of shipment. HAWS
liability under this warranty shall be discharged by furnishing without charge F.O.B.
HAWS Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The drinking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instructions provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/20 Model 3500FR Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 9/16”, 1/2", 7/16” socket wrench or open end wrench, 5/32” hex key
wrench pinned tamper proof (supplied).
LOCATION OF UNIT: The Model 3500FR Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions shown, meet current ADA requirements. When
installing this unit, local, state or federal codes should be adhered to. If height other than
shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 PSI (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Waste outlet is female 1-1/2” slip PVC female.
MAINTENANCE: Refer to 6518.2FR Operation and Maintenance Sheet for more
information.
TROUBLESHOOTING 3500FR with 6518.2FR
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve
is wide open.
b.
Verify minimum 30PSI flowing supply
pressure.
c.
Adjust valve to increase flow. See
6518FR Manual.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2020 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
4 ANCHORS
MODEL MTG.3501
MOUNTING SYSTEM
(OPTIONAL)
MODEL MTG.3500
MOUNTING PLATE
(OPTIONAL)
A
5703M
BUBBLER HEAD 6452
STRAINER
ASSEMBLY
5881PBA
PUSH BUTTON
ASSEMBLY
P/N 0002049640
DOOR KEY, TEE
P/N 0002981127
KEY, 5/32" HEX PINNED
VALVE BOX
(NOT SUPPLIED)
4 BOLTS
4 WASHERS
MOUNTING PLATE
WITH ANCHORS
4 BOLTS
4 WASHERS
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]M
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
F. VASQUEZ
3/17/99
14
0002077455
3500FR
1:12
11
FV 04/02/20
DP
3 OF 4
PARTS BREAKDOWN
5527
2020
FV
1
ENSURE TUBE IS DISCONNECTED FROM "PUSH-IN"
TYPE CONNECTOR ON PRESSURE REGULATOR
PRIOR TO REMOVAL. APPLY A DROP OF LOCTITE
222MS ON NOZZLE THREADS PRIOR TO
REASSEMBLING BACK ONTO BUBBLER HEAD.
REATTACH TUBE TO "PUSH-IN" TYPE CONNECTOR
ENSURING IT IS FULLY BOTTOMED OUT.
1
NOTE:
DETAIL A
ROTATED 90° INTO VIEW
DETAIL OF 5703M
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
1
6518.2FR VALVE
REQUIRED -
SOLD SEPARATELY

41-1/2"
1054mm
GROUND LEVEL
[1829mm]. WASTE TO BE 1-1/4" IPS
MAIN SEWER LINE LOCATED BELOW
MINIMUM TO A POROUS GRAVEL FILL OR
FROST LINE (NOT SUPPLIED).
(TO SPOUT OUTLET)
MODEL MTG.3501
(OPTIONAL)
OR
MODEL MTG.3500
(OPTIONAL)
(BY OTHERS)
1-1/2" WASTE
4X 1/2"-13 UNC
CONCRETE ANCHORS
BURY DEPTHS OF 48"[1219mm] AND 72"
152mm
6"
Ø
6"
152mm
864mm
686mm
30" SQUARE CONCRETE
SLAB (NOT SUPPLIED)
TUBING FOR
AIR ACTUATION
27"
OUTLET)
(TO SPOUT
35-1/2"
902mm
34"
PEDESTAL MOUNTING
DETAIL
3/8" SUPPLY TUBING
W/FOAM INSULATION
14"
356mm
11-1/2"
292mm
18"
457mm
28-1/2"
724mm
NOTE: DOOR SPECIFIED BY CUSTOMER
AND SHIPPED SEPARATELY.
11-1/2"
292mm
14"
356mm
4X
19mm
3/4"
Ø
DISCONNECT COUPLING
TO REPLACE BUBBLER
HEAD (2X)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [e-mail]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
F. VASQUEZ
6/29/99
14
0002077455.D
3500FR
1:16
11
FV 04/02/20
DP
4 OF 4
INSTALLATION
5527
2020
FV
6518.2FR VALVE ASSY
VALVE BOX
(NOT SUPPLIED)
NOTES:
MOUNTING HARDWARE NOT SUPPLIED. SEE PARTS BREAKDOWN
DRAWING FOR HARDWARE SUPPLIED WITH EACH OPTIONAL KIT.
1
1
REQUIRED - SOLD SEPARATELY
