Haws 1119.14 Guide

03/17 Model 1119.14 Page 1 of 4
No. 2076717(19)
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
Model 1119.14
Drinking Fountain
LIMITED WARRANTY
HAWS
warrants that this specific product is guaranteed against defective material
or poor workmanship for a period of one year from date of shipment. HAWS
liability under this warranty sh
all be discharged by furnishing without charge F.O.B.
HAWS Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws w
ithin a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The drinking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instruction
s provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/17 Model 1119.14 Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64“ hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open end
wrench.
LOCATION OF UNIT: The Model 1119.14 Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions that are shown meet current ADA requirements.
When installing this unit, local, state or federal codes should be adhered to. If height other
than shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2" IPS with 30-90 psi (2-6 ATM)
pressure. Where sediment or mineral content is a problem, an inlet filter is recommended.
PLUMBING CONNECTIONS: Inlet is 3/8” push-in type fitting. Waste outlet is female
1-1/4” IPS.
MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Manual for more
information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all plastic push-in type fitting connections, only connect NSF-61 copper or
plastic tubing. Stainless steel or glass tubing is not recommended. The
following assembly instructions must be followed to ensure a watertight
connection:
a. Cut tubing square and clean.
b. Mark from end of tube the length of insertion (See table below).
c. Push tube into the fitting until it bottoms out.
d. To remove, depress collet and pull tubing out.
Tube Sizes
O.D.
Tolerance Insertion Depth
1/4”
±.005”
11/16”
3/8”
±.005”
3/4”
1/2”
±.005”
7/8”
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop
valve is wide open. Turn counter-
clockwise.
1b.
Verify minimum 30 psi flowing
supply pressure.
1c.
Clean strainer. See 5874 Series
Valve Manual
1d.
Adjust valve to increase flow. Use
front adjust screw or see 5874
Series Valve Manual.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

8
5
10
9
(OPTIONAL)
PARTS BREAKDOWN
2
A
5REF
3
4
1
1
1
STRAINER, WASTE ASSY1
BACK PANEL
2
BUBBLER HEAD ASSY, PCP
3PUSH BUTTON ASSY, FLANGED, PCP
4
BUTTON, PUSH, FLANGED, PCP W/ VALVE
5PLATE, BOTTOM6
8
9
5703M
PBA6
5874PBF
PBM1105
0004023580
6462
ITEM DESCRIPTION 1119.14
* DENOTES OPTIONAL PART.
VALVE REPAIR KIT VRK5874
TRAP 0005982900
10
*PLATE, MOUNTING 6700.4
PLATE, BOTTOM PBM1109
7
6
7
1
ROTATED 90° INTO VIEW
DETAIL A
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
2
NOTES:
1 5874PBF (ITEM 2) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 3) AND PBA6 FLANGED PUSH BUTTON (ITEM 4).
2 ENSURE TUBE IS DISCONNECTED FROM PUSH BUTTON VALVE
BODY PRIOR TO REMOVAL. APPLY ONE DROP OF LOCTITE
222MS TO NOZZLE THREADS PRIOR TO FASTENING BACK ONTO
BUBBLER HEAD. RE-ATTACH TUBE TO VALVE.
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
f.
06/06/98
19
0002076717
1119.14
.
1:1
11
FV 07/06/17
.
VWC
3 OF 4
PARTS BREAKDOWN
5124
2017
VWC

TO FLOOR
406mm
254mm
10"
305mm
12"
(OPTIONAL, HAWS 6700.4)
MOUNTING PLATE
406mm
813mm
32"
914mm
36"
16" 16"
203mm
8"
702mm
*27-5/8"
BACK PANEL
305mm
1/2" IPS SUPPLY
2-1/8"
54mm
413mm
16-1/4"
(BY OTHERS)
12"
305mm
12"
406mm
16"
70mm
2-3/4" 2-3/4"
70mm
3/8" O.D SUPPLY
SUPPLY STOP AND
686mm
*27"
(BY OTHERS)
1029mm
*40-1/2"
781mm
*30-3/4"
WASTE
927mm
*36-1/2"
WASTE
12.7mm470mm
324mm
12-1/4"
18"
29mm
SUPPLY
1-1/8"
(BACK PANEL)
1/2"
203mm
8"
8"
203mm
6"
152mm
1-1/4" IPS
TRAP
(SUPPLIED)
WALL FACE
FLOOR LINE
(OPTIONAL)
MOUNTING PLATE
*29-5/8"
SUPPLY
752mm
3/8" MOUNTING BOLTS
(BY OTHERS)
C
WASTE
(BY OTHERS)
WASTE
3-1/4"
83mm
MOUNTING DETAIL
3-1/4"
83mm
BACK VIEW
TO FLOOR
*27-7/16"
697mm
WASTE
76mm
3"
C
SLOTS
5-1/8"
130mm 11mm
.44
MOUNTING
Ø
*33-1/16"
839mm
TO FLOOR
876mm
*34-1/2"
(TO SPOUT OUTLET)
(TO SPOUT OUTLET)
SUPPLY
SUPPLY
SUPPLY
*35-3/8"
905mm
NOTES:
3
1. HOLD ROUGH-IN DIMENSIONS ± 1/4" (6.4mm).
2. WHEN INSTALLING THIS UNIT LOCAL, STATE OR FEDERAL CODES SHOULD BE
ADHERED TO. FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS
MARKED (*) MUST BE ADJUSTED ACCORDINGLY.
3 REFER TO 5874 SERIES OPERATION AND MAINTENANCE MANUAL FOR PUSH
BUTTON AND VALVE INSTALLATION/MAINTENANCE INSTRUCTIONS.
1-1/8"
29mm
L
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
F.VASQUEZ
04/01/04
19
0002076717.D
1119.14
1:14
11
FV 07/06/17
VWC
4 OF 4
INSTALLATION
