Haws 1430HO User manual

model 1430HO
Vandal-Resistant Enameled Iron Motion-Activated Fountain
FEATURES & BENEFITS
CONSTRUCTION
Heavy-duty cast iron bowl with a glossy white enamel nish is
designed for the toughest of applications, and at the same time is
gentle to all users with its soft rounded corners. Unit also ships with
vandal-resistant bottom plates to provide added peace of mind.
BUBBLER HEADS
Polished chrome-plated brass bubbler heads with integral 11/16" dia.
basin shank and stainless anti-rotation roll pin for vandal resistance
strength. Shielded, angled stream opening provides a steady, sanitary
source of drinking water at .45 gpm.
FOUNTAIN VALVES
Fountain incorporates touchless sensor operated stainless steel
solenoid valves controlled by a transformer for hands-free operation.
A pressure regulator is used to adjust the bubbler flow according to
incoming water pressures.
VANDAL RESISTANT
The bubbler heads, drain strainer and bottom plate are locked in
place, discouraging unwanted vandal tampering.
INTEGRATED TRAP
All cast brass 1-1/4" NPT adjustable traps completely concealed
inside bottom plates for easy installation and lack of unwanted access.
OPTIONS
Bottle Filler: Model 1920WHO, touchless bottle ller can be a
stand-alone station, or mounted above Haws 1430 series
touchless drinking fountain models.
Remote Drinking Fountain Water chiller: Model HCR8, 8 gph (30.3
L) remote water chiller provides instantaneous cooling to meet a
continuous demand for chilled water.
For more information, visit www.hawsco.com or call [phone].
SPECIFICATIONS
Model 1430HO vandal-resistant wall mounted motion activated drinking
fountain shall include a white enameled- iron basin mounted with twin
galvanized cast-iron wall brackets, touchless sensor operated stainless
steel solenoid valves with 30-second obstruction time-out controlled by
a transformer, 100% lead-free waterways, dual polished chrome plated
brass vandal-resistant bubbler heads, polished chrome plated brass
vandal-resistant waste strainer, vandal-resistant bottom plate, and
chrome- plated 1-1/2″ NPT trap.
FOR INDOOR USE ONLY
APPLICATIONS
Perfect for either public or private settings, our gleaming white
enameled-iron series is one of the sturdiest wall mounted fountains
Haws produces. This unit is the perfect t for high trafc areas where
there is a greater need for multiple drinking stations. Elegant gloss nish
and color consistency throughout the enameled-iron maintain the
fountains overall appeal so it always remains looking as new as it did
when it was installed. Specically, this type of wall mounted drinking
fountain may be placed in settings such as: parks, schools, and other
indoor/outdoor environments where the temperature remains above
freezing. Haws manufactures drinking fountains, faucets and electric
water coolers to be lead-free by all known denitions including
NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition
65, and the Federal Safe Drinking Water Act. Product is compliant to
California Health and Safety Code 116875 (AB 1953-2006), and
NSF/ANSI/CAN 61: Q ≤ 1.
1455 Kleppe Lane :: Sparks, NV 89431 :: p. 775.359.4712 :: f. 775.359.7424 :: e. [e-mail] :: www.hawsco.com :: 31 May, 2023
DISCLAIMER: Continued product improvements make specications subject to change without notice. Check www.hawsco.com for the latest product information and updates.

NOT SUPPLIED) HARDWARE (QTY 8, 3/8-16 MOUNTING
(NOT SUPPLIED)
89mm
3-1/2"
SCREWDRIVER STOP 3/8" O.D. TUBING &
MOUNTING DETAIL
200mm
7-7/8"
40-1/2"
1029m
200mm
7-7/8"
1-1/2" IPS
(SUPPLIED)
1067mm
42"
SUPPLY
WASTE 889mm
35"
*
940mm
37"
*
*
FLOOR LINE
WALL
TRAP
1-1/2" IPS
WASTE (NOT
SUPPLIED)
6-1/4"
4"
159mm
SQR
32mm
SQR
102mm
76mm
3"
330mm
13"
1-1/4"
1. ROUGH-IN DIMENSIONS MAY VARY ±1/4" (6.4mm).
2. WHEN INSTALLING THIS UNIT LOCAL, STATE OR FEDERAL CODES
SHOULD BE ADHERED TO. FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS MARKED (*) MUST BE ADJUSTED ACCORDINGLY.
3. REFER TO 5874 SERIES OPERATION AND MAINTENANCE MANUAL FOR
PUSH BUTTON AND VALVE INSTALLATION/MAINTENANCE INSTRUCTONS. (NOTES CONTINUED ON SHEET 2 OF 2)
NOTES:
3
REAR VIEW
FLOOR LINE
SUPPLY
*37"
940mm
BRACKET
MTG HOLES
5-1/2"
140mm
(TO SPOUT OUTLET)
SUPPLIED)
SUPPLY (NOT
1/2" IPS
MOUNTING BRACKET
PN 0001121140
(QTY 2, SUPPLIED) (SEE STEP 6 OF
OPERATIONS MANUAL FOR
ATTACHMENT DETAILS)
APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CJL
11-01-91
18
0002076850.D
1430
TWO BUBBLER FOUNTAIN
1:11
12
FV
07/06/17
.
VWC
INSTALLATION
5188
2017
JP

WHITE POLYPRO TUBING
21"
TEE FITTING
WHITE POLYPRO TUBING
13"
CLEAR POLY TUBING
15" (ATTACHED TO
BUBBLER HEAD)
CLEAR POLY TUBING
15" (ATTACHED TO
(BUBBLER HEAD)
ELBOW FITTING
ELBOW FITTING
NOTES: (CONTINUED)
4. CONNECT WHITE "POLYPROPYLENE" TUBING ON
PRESSURE SIDE (INLET) OF VALVE.
5. CONNECT CLEAR "POLYETHYLENE" TUBING ON
FREE FLOW SIDE (VALVE TO BUBBLER HEAD) ONLY.
VALVE OUTLET
VALVE OUTLET
TUBING ROUTING DETAIL
BOTTOM VIEW
3/8" OD TUBE SUPPLY
3 8"
APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CLJ
11-01-91
18
0002076850.D
1430
TWO BUBBLER FOUNTAIN
1:11
22
FV
07/06/17
.
VWC
INSTALLATION
5188
2017
JP

APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
BJM
02/10/21
4
0580001156.D
2RKHO.P / 2RKHO.H
DUAL HANDS-OFF RETRO-FIT KIT
N/A
14
BJM
10/26/21
5649
FV
INSTALLATION
5749
2021
BJM
NOTES:
1. 2RKHO.P AND 2RKHO.H RETROFIT KITS ALLOW INDOOR FOUNTAINS TO BE CONVERTED FROM A
HAWS 5874 PUSH BUTTON VALVE TO HANDS-OFF (TOUCHLESS) OPERATION. FOUNTAINS (NOT SUPPLIED) MAY BE MOUNTED ON THE EXTERNAL WALL OF A BUILDING PROVIDED THE TRANSFORMER SHALL BE MOUNTED INSIDE THE WALL AND PROTECTED FROM WATER AS SHOWN IN THIS INSTALLATION PER NEC/CEC AND LOCAL CODE. AVOID
2RKHO.P: INDOOR HO RETRO-FIT KIT (INCLUDES 2X HO SENSOR WITH MOUNTING HARDWARE, 2X
SOLENOID VALVE, 2X REGULATOR, WIRE SPLITTER, AND 100-240V PLUG-IN TRANSFORMER - SEE SHEET 2).
2. RETROFIT KIT MODEL:
2RKHO.H: INDOOR HO RETRO-FIT KIT (INCLUDES 2X HO SENSOR WITH MOUNTING HARDWARE, 2X
3. 2RKHO.P REQUIRES 100-240VAC POWER CONNECTION. 2RKHO.H REQUIRES 100-277V
4. TRANSFORMERS MUST BE MOUNTED SUCH THAT THEY ARE PROTECTED FROM WATER.
5. 2RKHO.P TRANSFORMER IS COMPATIBLE WITH TYPE A AND TYPE B NORTH AMERICAN
ELECTRICAL OUTLETS. FOR OTHER RECEPTACLE TYPES, AN ADAPTER (NOT SUPPLIED) MUST BE PROVIDED BY OTHERS.
SOLENOID VALVE, 2X REGULATOR, WIRE SPLITTER, AND 100-277V HARDWIRE TRANSFORMER - SEE SHEET 3).
POWER CONNECTION.
(NOTES CONTINUED ON SHEET 4)
DIRECT CONTACT WITH SUNLIGHT ON THE SENSOR LENS.
EXAMPLE 1011 FOUNTAIN INSTALLATION
AA
SOLENOID VALVE
(NOTE FLOW DIRECTION ARROW)
PRESSURE REGULATOR
(NOTE "IN" AND "OUT"
FLOW DIRECTION)
HO SENSOR
POWER CONNECTION HARNESS
(SEE ELECTRICAL SCHEMATIC - SUPPLIED
WITH TRANSFORMER KIT - SHOWN FOR
REFERENCE)
EXAMPLE 1920 BOTTLE FILLER INSTALLATION
MOUNTING HARDWARE
Y-STRAINER
(NOTE FLOW DIRECTION ARROW)
3/8" O.D. TUBING SPLITTER (EXISTING)
VIEW A - A
TO SECOND FOUNTAIN/BOTTLE FILLER
(BOTTOM PLATE OMITTED FOR CLARITY)
3/8" O.D. TUBING
(EXISTING)
3/8" O.D. TUBING
TO SECOND SENSOR
TO WIRE SPLITTER. SEE SHEET 4 FOR WIRING DIAGRAM
3/8" O.D. TUBING SUPPLY INLET

APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
BJM
02/10/21
4
0580001156.D
2RKHO.P / 2RKHO.H
DUAL HANDS-OFF RETRO-FIT KIT
N/A
24
BJM
10/26/21
5649
FV
INSTALLATION
5749
2021
BJM
2RKHO.P KIT - MAIN PARTS
SOLENOID VALVE ASSEMBLY (2X)
VRKHO5
3/8" PUSH-IN TUBING
CONNECTOR
HO SENSOR ASSEMBLY (2X)
VRKHO6
BRASS NUT
VALVE REGULATOR (2X)
5867
RUBBER O-RING
3/8" PUSH-IN TUBING
CONNECTOR
3/8" PUSH-IN TUBING
CONNECTOR
FLANGE WASHER
PLUG-IN TRANSFORMER
VRKHO7
3/8" PUSH-IN TUBING
CONNECTOR
Y-STRAINER
6433
3/8" PUSH-IN TUBING
CONNECTOR
3/8" PUSH-IN TUBING
CONNECTOR
DUAL POWER SPLITTER
CUP WASHER

APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
BJM
02/10/21
4
0580001156.D
2RKHO.P / 2RKHO.H
DUAL HANDS-OFF RETRO-FIT KIT
N/A
34
BJM
10/26/21
5649
FV
INSTALLATION
5749
2021
BJM
2RKHO.H KIT - MAIN PARTS
SOLENOID VALVE ASSEMBLY (2X)
VRKHO5
3/8" PUSH-IN TUBING
CONNECTOR
HO SENSOR ASSEMBLY (2X)
VRKHO6
VALVE REGULATOR (2X)
5867
RUBBER O-RING
3/8" PUSH-IN TUBING
CONNECTOR
3/8" PUSH-IN TUBING
CONNECTOR
FLANGE WASHER
3/8" PUSH-IN TUBING
CONNECTOR
Y-STRAINER
6433
3/8" PUSH-IN TUBING
CONNECTOR
3/8" PUSH-IN TUBING
CONNECTOR
DUAL POWER SPLITTER
HARDWIRE TRANSFORMER
VRKHO8
CUP WASHER
BRASS NUT

APPROVED: DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
BJM
02/10/21
4
0580001156.D
2RKHO.P / 2RKHO.H
DUAL HANDS-OFF RETRO-FIT KIT
N/A
44
BJM
10/26/21
5649
FV
INSTALLATION
5749
2021
BJM
CABLE WIRING SCHEMATIC
SENSOR
SOLENOID
VALVE
TRANSFORMER
AC(L) AC(N)
HARDWIRE
NOTES (CONTINUED FROM SHEET 1):
6. 2RKHO.H TRANSFORMER WIRE RANGE: 24-12 AWG
2RKHO.H TRANSFORMER TIGHTENING TORQUE: MAX 0.4 N*m
SENSOR
SOLENOID
VALVE
DUAL
SPLITTER
TRANSFORMER
PLUG-IN
2RKHO.P TRANSFORMER
2RKHO.H TRANSFORMER
WIRE THE HARDWIRE TRANSFORMER TO
APPROPRIATE POWER PER NEC/CEC AND LOCAL
CODE. IF NEEDED, ENCLOSE TRANSFORMER IN
OUTLET BOX (NOT SUPPLIED).
PLUG THE 9V TRANSFORMER INTO
A DUPLEX RECEPTACLE
