Haws 3377 Guide

03/17 Model 3377/3377G Page 1 of 4
1455Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 3377/3377G
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2077364 (13)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material
or poor workmanship for a period of one year from date of shipment. HAWS
liability under this warranty shall be discharged by furnishing without charge F.O.B.
HAWS Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, pre
paid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS,
Sparks, Nevada. HAWS will not be liable for
any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer
agrees that HAWS shall not be liable for general, special, or consequential
damages claimed to arise under the contract of sale. The drinking fountain
manufactured by HAWS is warranted to function if installation and maintenance
instructions provided are adhered to. The units also must be used for the purpose
for which they were intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/17 Model 3377/3377G Page 2 of 4
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 3/32“ and 5/32” hex key wrench, 9/16”, 1/2", 7/16” socket wrench or
open end wrench.
LOCATION OF UNIT: The Model 3377/3377G Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions shown, meet current ADA requirements. When
installing this unit, local, state or federal codes should be adhered to. If height other than
shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet is 1/4" IPS male fitting. Waste outlet is 1-1/4” Slip Joint.
MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Manual for
information.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve is
wide open.
b.
Verify minimum 30 psi flowing supply
pressure.
c.
Clean inlet strainer. See 5874 Series
Valve Manual.
d.
Adjust valve to increase flow. Use front
adjust screw or see 5874 Series Valve
Manual.
e.
Clean screens (inside nozzle body).
Unscrew nozzle insert and very gently
activate water supply to pop out qty. 3
screens (be careful not to lose
screens). Remove any debris clogging
the screen openings and place back
into nozzle body. Reassemble nozzle
insert.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1STRAINER ASSY 6463
2
BUTTON, PUSH, FLANGED W/ VALVE
HEAD W/LAMINAR INSERT
4
3
BOTTOM PLATE
VALVE REPAIR KIT
6
5
PARTS BREAKDOWN
1
2
4
3
6
7
HLF HLF
BIB FAUCET (OPTIONAL)
7OPTIONAL
8
DRIVER, NOZZLE .25 HEX
A
STYLE B
(TUBING CONNECTS TO
INSERT ASSY)
FOUNTAIN COULD HAVE EITHER STYLE
STYLE A
(TUBING CONNECTS
TO ELBOW)
ROTATED 90° INTO VIEW
DETAIL A
5705 LAMIN (OPTIONAL)
FOR REMOVAL
OF NOZZLE
WITH TUBE
(STYLE A OR STYLE B) 5705
0002082253
6250LF
PBM1000
VRK5874
5874PBF
6463
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]M
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
RTM
10-20-98
13
0002077364
3377/3377G
.
1:5
11
FV 07/07/17
.
VWC
3 OF 4
PARTS BREAKDOWN
5189
2017
JP
8
BUTTON, ASSY, PUSH, FLANGED, 5874 PBA6
5
NOTES:
1 5874PB (ITEM 3) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 4) AND PBA6 FLANGED PUSH BUTTON (ITEM 5).
1
1
1

3mm
1/8"
10mm
3/8"
829mm
32-5/8"
1/2" NPT INLET
TO
STRAINER
INLET
OPTIONAL HOSE BIB DETAIL
27"
686mm
864mm
34"
5"
127mm
127mm
5"
127mm
5"
5"
127mm
305mm
12"
305mm
12"
1-1/2"
38mm
1-1/2"
38mm
3/4"
19mm
Ø
30mm
1-3/16"
THRU
C-BORE
4X
Ø
4X
MOUNTING PLATE
DETAIL
ELBOW ONTO BOWL. AFTER
BUTTON TO INSTALL WASTE
WASTE ELBOW IS INSTALLED,
REINSTALL VALVE & ADJUST
REMOVE VALVE FROM PUSH
FLOW
WASTE SUPPLY
WASTE BENDS
1-1/4"
Ø 3/8" SUPPLY TUBING
(SUPPLIED)
& WASHERS 4X
3/8-16 HEX BOLTS
4X (SUPPLIED)
& WASHERS W/ 4" ANCHORS.
1/2-13UNC HEX BOLTS
1/2" IPS SUPPLY
(NOT SUPPLIED)
1-1/4 IPS WASTE
(NOT SUPPLIED)
ACCESS PLATE
19-1/2"±1"
495mm±25mm
ABOVE FINISHED
GRADE
(NOT SUPPLIED)
6250LF
BIB FAUCET
STEEL
559mm
22" (SUPPLIED)
Ø14-1/8"
359mm
SCREWDRIVER STOP
30" SQUARE
CONCRETE SLAB
6"
152mm
ANCHORS
(SUPPLIED) (NOT SUPPLIED)
6250LF
BIB FAUCET
(OPTIONAL)
HLF
HLF
1 REFER TO 5874 SERIES OPERATION AND MAINTENANCE MANUAL FOR
PUSH BUTTON AND VALVE INSTALLATION/MAINTENANCE INSTRUCTIONS.
NOTES:
1
(OPTIONAL)
1/2" NPT
(NOT SUPPLIED)
STOP, COMPRESSION
TUBING (NOT SUPPLIED)
FITTINGS, & 3/8" O.D.
(SUPPLIED)
1/2" TEE
1/2" NPT SCREWDRIVER
FITTINGS
COMPRESSION
1/2" TUBING &
FOUNTAIN
(NOT SUPPLIED)
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
RTM
05/97
13
0002077364.D
3377/3377G
.
1:15
11
FV 07/07/17
.
VWC
4 OF 4
INSTALLATION
5189
2017
JP
