Hayward ColorLogic User manual

Hayward Pool Products
620 Division Street, Elizabeth NJ 07207
Phone [phone]
www.hayward.com
ColorLogic Pool Lamp
Color LED Replacement Lamp
Owner's Manual
BPCUS11120
Contents
Introduction...........................2
Installation............................2
Operation..............................5
092759 RevA draft3
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

IMPORTANT SAFETY INSTRUCTIONS
SAFETY WARNING: Do not open. Lamp has no user serviceable parts inside. Improper installation
may result in death or serious injury to bathers or service personnel or others by way of electric
shock. Disconnect electrical power before installing or servicing this equipment. Read and follow all
instructions. This product to be installed by qualified personnel only.
Model Input (Volts, Amps, Watts)
BPCUS11120 120 VAC 60 Hz, 0.24A, 28.5W
IMPORTANT WIRING CHECKLIST
Do not skip any steps in this or any section of the manual.
The above safety warnings and the complete installation instructions in this manual have
been read and followed.
The cord length has not been extended beyond the guidelines in this manual.
The cord jacket is not damaged, cut or spliced except as noted below.
Extensions or splices to the cord are only made in a safety listed Pool/Spa junction box
or junction box transformer system.
The light fixture strain relief is firmly secured.
The luminaire is firmly secured to the pool wall and cannot be removed without removal
of the strain relief.
The luminaire has been installed by qualified personnel in compliance with the National
Electrical Code (NEC) or Canadian Electric Code (CE Code) and any applicable local
codes and/or regulations.
Bonding wire is secure and properly attached to bonding system.
Ground is secure and properly attached.
Power is shut off.
LEAVE THESE INSTRUCTIONS WITH PROPERTY OWNER
1
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Introduction
The Hayward®BPCUS11120 is a UL Listed Color LED replacement lamp designed for use in com-
patible light fixtures listed below. Using up to 86% less energy and lasting up to 10x longer than
conventional 300 watt incandescent and halogen lamps, the BPCUS11120 makes an efficient and
long lasting replacement for your existing pool light. When used in standalone mode, lamp colors are
controlled by turning on/off power repeatedly. When used with a Hayward automation control, colors
can be programmed with schedules and easily changed and saved with a button.
Pool & Spa Light Housing Compatibility
Replacement LED in-ground pool lamps must be installed in a compatible Nationally Recognized Test-
ing Laboratory (NRTL) approved pool light fixture or housing. Compatible NRTL light fixtures include:
• Hayward®Astrolite™ SP058 Series
• Pentair®Amerlite 784 Series
• Swimquip 05086 Series
Hayward Pool Control Compatibiltiy
The Hayward®BPCUS11120 is compatible with the following Hayward Pool controls:
• OmniLogic
• OmniHub
• Pro Logic
• ColorLogic Light Controller
Installation
Before You Begin
Before attempting to install, confirm that you have a compatible light fixture. Disconnect power to
the pool light at the main panel before attempting to service the lamp. Refer to the original manu-
facturer’s pool light installation manual before proceeding. This service should be performed by a
qualified individual.
Because the BPCUS11120 must be kept dry, be sure to have a new replacement gasket for your
light fixture before starting the installation. Do not re-use the existing gasket as a leak inside the
fixture could cause serious injury or death due to electrical shock.
Safety precautions and Installation notes
• Do not open, service or tamper with any internal component of the BPCUS11120 LED under-
water pool lamp.
• Do not directly expose or immerse the lamp in water before installation.
• During removal of the old lamp and installation of the BPCUS11120, keep the inside of the
light housing dry.
• Handle the lamp with care. Be careful not to drop the unit or permanent damage can occur.
• The BPCUS11120 can not be used with dimmers or dimming systems.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2

Installation Steps
1. Remove existing light fixture from niche
With power off at the circuit breaker, carefully remove the existing light fixture from the pool
light niche and place it on the pool deck. There should be enough power cord length to reach
the deck. If the power cord is too short to reach the pool deck surface, the light fixture should
be reinstalled with the proper length cord by a qualified individual before attempting to install
the new lamp.
2. Remove glass lens
Refer to the manufacturer’s owner’s manual for lamp removal instructions. Typically, screws
and/or a clamp fastens the cover plate and lens to the housing. Loosen fasteners and carefully
remove the lens and gasket from the light fixture.
3. Inspect fixture and remove old lamp
While the fixture is out of the pool and the lens is off, inspect the housing for wear or damage.
Do not install the BPCUS11120 into a fixture that may be prone to failure. Inspect the rubber
seal where the power cord enters the housing for leaks or deterioration. Check the surface
where the lens and gasket seats for warping or dents. Replace the tensioning clamp or other
fasteners if worn or damaged. After inspection, unscrew the old lamp and remove.
4. Clean lens and install the BPCUS11120
Make sure the inside of the light housing is completely dry. Take this opportunity to clean both
sides of the glass lens. Remove any gasket residue from the lens.Wipe completely dry. Carefully
screw the BPCUS11120 into the lamp socket.
cover plate and lens
gasket
light fixture removed from niche
power cord
BPCUS11120 LED
replacement lamp
3
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

5. Install lens
Failure to install a new lens gasket could result in a leak that can damage the BPCUS11120
and cause serious injury or death due to electrical shock. Before installing the lens, clean any
old gasket residue from the light fixture. The surface must be clean for the new gasket to seat
properly. Install your new replacement gasket onto the glass lens. Set the lens and cover plate
on the light housing and secure by tightening the screws and/or clamp, allowing the gasket to
seal evenly.
6. Test light fixture in water
Submerge the assembled light fixture in the water and visually check that air bubbles are not
escaping from the gasket area or at the power cord entrance. If bubbles appear, immediately
remove the light fixture from the water and re-seat the gasket and lens. Continue the installation
only if there are no air leaks.
7. Install light fixture into niche
If there are no leaks, complete the installation by wrapping the cord around the light fixture in
the same manner as when it was removed. Secure the light fixture to the niche using the original
or equivalent fasteners.
8. Inspect
Turn power on to the lamp at the main panel. With the light on, check for air bubbles exiting
the light housing. Leave the lamp on for 30 minutes and continue to inspect. If there are no air
bubbles, the housing is watertight and installation is complete.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
4
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
4

Operation
BPCUS11120 Lamp modes
The Hayward BPCUS11120 lamp is designed to operate in one of two modes; Universal ColorLogic
or Omni Direct.
Universal ColorLogic mode (default): The lamp is shipped in this mode. Use this mode for new
installations and for installations with other Universal ColorLogic lights.
Omni Direct mode: Omni Direct mode offers unique colors as well as speed and brightness control.
It must be configured and controlled by a Hayward OmniLogic or OmniHub pool controller only. Refer
to the controller’s manual for more information.
How to change modes:
1. Turn on lights and then turn off for between 11-15 seconds.
2. Turn on lights and then turn off for between 11-15 seconds.
3. Turn on lights and then turn off for between 11-15 seconds.
4. The light should blink one of two colors indicating which mode it is currently in. Refer to the table
below to determine which mode the BPCUS11120 lamp is in. Note that new lights are shipped
from the factory in Universal ColorLogic mode (blinking red).
MODE COLOR
Universal ColorLogic Red
Omni Direct Purple
5. To change modes, turn the light off and then back on. Continue this method until you arrive at
the desired mode. Note that Universal ColorLogic modes (blinking red) are repeated 4 times so
it may take a few cycles to arrive at Omni Direct mode (blinking purple).
6. When the light is in the desired mode, remove power from the lights for at least one minute.
7. The light will restart in the new mode the next time it is turned on.
Operating the BPCUS11120 lamp
The BPCUS11120 lamp is controlled through power-cycling: a method of changing light programs
which requires no special controller or interface. To activate the light, simply turn on the switch. To
deactivate the light, turn off the switch. To advance to the next light program (fixed color or color
show), turn the switch off, then back on within 10 seconds.
When the light has been off for over 60 seconds, and is first turned on, it will come on to white for 15
seconds for quick clear view of your pool, then go to the last fixed color or color show it was running.
Light Synchronization
If your pool or spa has multiple BPCUS11120 lamps, they may be operated independently, or they
can be easily synchronized so they will all display the same colors and shows at the same time. For
5
USE ONLY HAYWARD GENUINE REPLACEMENT PARTSUSE ONLY HAYWARD GENUINE REPLACEMENT PARTS

light synchronization, all lights must be wired to the same switch. Once installed, all lights should
be automatically synchronized, however, if they get out of sync, they can be re-synchronized easily.
To re-synchronize your lights, turn the switch on, then back off, then wait between 11-15 seconds
and turn the switch back on. When the lights come back on, they should enter program #1, and be
synchronized.
Programs
When in Universal ColorLogic mode (default), the BPCUS11120 lamp has the capability to display
17 different programs; 10 fixed colors and 7 color-changing shows. These programs are advanced
using power-cycling (quickly powering the lights on, then off, then back on). The programs are listed
below:
1. Show-Voodoo Lounge
2. Fixed-Deep Blue Sea
3. Fixed-Royal Blue
4. Fixed-Afternoon Skies
5. Fixed-Aqua Green
6. Fixed-Emerald
7. Fixed-Cloud White
8. Fixed-Warm Red
9. Fixed-Flamingo
10. Fixed-Vivid Violet
11. Fixed-Sangria
12. Show-Twilight
13. Show-Tranquility
14. Show-Gemstone
15. Show-USA
16. Show-Mardi Gras
17. Show-Cool Cabaret
Refer to the included color card as a quick reference to the available programs.
Omni Direct
The BPCUS11120 lamp must be configured and controlled by a Hayward OmniLogic or OmniHub
pool control to use Omni Direct mode. This mode offers some unique colors as well as speed and
brightness control. The programs are listed below.
1. Show-Voodoo Lounge
2. Fixed-Deep Blue Sea
3. Fixed-Royal Blue
4. Fixed-Afternoon Skies
5. Fixed-Aqua Green
6. Fixed-Emerald
7. Fixed-Cloud White
8. Fixed-Warm Red
9. Fixed-Flamingo
10. Fixed-Vivid Violet
11. Fixed-Sangria
12. Show-Twilight
13. Show-Tranquility
14. Show-Gemstone
15. Show-USA
16. Show-Mardi Gras
17. Show-Cool Cabaret
18. Fixed-Yellow
19. Fixed-Orange
20. Fixed-Gold
21. Fixed-Mint
22. Fixed-Teal
23. Fixed-Burnt Orange
24. Fixed-Pure White
25. Fixed-Crisp White
26. Fixed-Warm White
27. Fixed-Bright Yellow
Refer to the OmniLogic or OmniHub manuals for Omni Direct configuration and operation informa-
tion.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
6
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

WARNING - Read and follow all instructions in this owner’s manual and on the equipment. Failure
to follow instructions can cause severe injury and/or death.
WARNING – Suction Entrapment Hazard Suction in suction outlets and/or suction outlet
covers which are, damaged, broken, cracked, missing, or unsecured can cause severe injury and/
or death due to the following entrapment hazards:
Hair Entrapment- Hair can become entangled in suction outlet cover.
Limb Entrapment- A limb inserted into an opening of a suction outlet sump or suction outlet cover
that is damaged, broken, cracked, missing, or not securely attached can result in a mechanical bind
or swelling of the limb.
Body Suction Entrapment- A negative pressure applied to a large portion of the body or limbs can
result in an entrapment.
Evisceration/ Disembowelment - A negative pressure applied directly to the intestines through
an unprotected suction outlet sump or suction outlet cover which is, damaged, broken, cracked,
missing, or unsecured can result in evisceration/ disembowelment.
Mechanical Entrapment- There is potential for jewelry, swimsuit, hair decorations, finger, toe or
knuckle to be caught in an opening of a suction outlet cover resulting in mechanical entrapment.
WARNING - To Reduce the risk of Entrapment Hazards:
• When outlets are small enough to be blocked by a person, a minimum of two functioning
suction outlets per pump must be installed. Suction outlets in the same plane (i.e. floor or
wall), must be installed a minimum of three feet (3’) [1 meter] apart, as measured from near
point to near point.
• Dual suction fittings shall be placed in such locations and distances to avoid “dual blockage”
by a user.
• Dual suction fittings shall not be located on seating areas or on the backrest for such seating
areas.
• The maximum system flow rate shall not exceed the flow rating of as listed on Table 1.
• Never use Pool or Spa if any suction outlet component is damaged, broken, cracked, missing,
or not securely attached.
• Replace damaged, broken, cracked, missing, or not securely attached suction outlet compo-
nents immediately.
• In addition two or more suction outlets per pump installed in accordance with latest ASME,
APSP Standards and CPSC guidelines, follow all National, State, and Local codes applicable.
• Installation of a vacuum release or vent system, which relieves entrapping suction, is recom-
mended.
WARNING – Failure to remove pressure test plugs and/or plugs used in winterization of the pool/
spa from the suction outlets can result in an increase potential for suction entrapment as described
above.
WARNING – Failure to keep suction outlet components clear of debris, such as leaves, dirt, hair,
paper and other material can result in an increase potential for suction entrapment as described
above.
WARNING – Suction outlet components have a finite life, the cover/grate should be inspected
frequently and replaced at least every ten years or if found to be damaged, broken, cracked, miss-
ing, or not securely attached.
CAUTION – Components such as the filtration system, pumps and heater must be positioned so
as to prevent their being used as means of access to the pool by young children. To reduce risk of
injury, do not permit children to use or climb on this product. Closely supervise children at all times.
Components such as the filtration system, pumps, and heaters must be positioned to prevent chil-
dren from using them as a means of access to the pool.
WARNING – Hazardous Pressure Pool and spa water circulation systems operate under
hazardous pressure during start up, normal operation, and after pump shut off. Stand clear of
circulation system equipment during pump start up. Failure to follow safety and operation instruc-
tions could result in violent separation of the pump housing and cover, and/or filter housing and
clamp due to pressure in the system, which could cause property damage, severe personal injury,
7
USE ONLY HAYWARD GENUINE REPLACEMENT PARTSUSE ONLY HAYWARD GENUINE REPLACEMENT PARTS

or death. Before servicing pool and spa water circulation system, all system and pump controls
must be in off position and filter manual air relief valve must be in open position. Before starting
system pump, all system valves must be set in a position to allow system water to return back to
the pool. Do not change filter control valve position while system pump is running. Before starting
system pump, fully open filter manual air relief valve. Do not close filter manual air relief valve until
a steady stream of water (not air or air and water) is discharged.
WARNING – Separation Hazard Failure to follow safety and operation instructions could
result in violent separation of pump and/or filter components. Strainer cover must be properly
secured to pump housing with strainer cover lock ring. Before servicing pool and spa circulation
system, filters manual air relief valve must be in open position. Do not operate pool and spa circu-
lation system if a system component is not assembled properly, damaged, or missing. Do not oper-
ate pool and spa circulation system unless filter manual air relief valve body is in locked position in
filter upper body. Never operate or test the circulation system at more than 50 PSI. Do not purge
the system with compressed air. Purging the system with compressed air can cause components
to explode, with risk of severe injury or death to anyone nearby. Use only a low pressure (below 5
PSI), high volume blower when air purging the pump, filter, or piping.
WARNING – Risk of Electric Shock All electrical wiring MUST be in conformance with ap-
plicable local codes, regulations, and the National Electric Code (NEC). Hazardous voltage can
shock, burn, and cause death or serious property damage. To reduce the risk of electric shock, do
NOT use an extension cord to connect unit to electric supply. Provide a properly located electrical
receptacle. Before working on any electrical equipment, turn off power supply to the equip-
ment. To reduce the risk of electric shock replace damaged wiring immediately. Locate conduit
to prevent abuse from lawn mowers, hedge trimmers and other equipment. Do NOT ground to a
gas supply line.
WARNING – Risk of Electric Shock Failure to ground all electrical equipment can cause seri-
ous or fatal electrical shock hazard. Electrical ground all electrical equipment before connecting
to electrical power supply.
WARNING – Risk of Electric Shock Failure to bond all electrical equipment to pool structure
will increase risk for electrocution and could result in injury or death. To reduce the risk of electric
shock, see installation instructions and consult a professional electrician on how to bond all elec-
trical equipment. Also, contact a licensed electrician for information on local electrical codes for
bonding requirements.
Notes to electrician: Use a solid copper conductor, size 8 or larger. Run a continuous wire from
external bonding lug to reinforcing rod or mesh. Connect a No. 8 AWG (8.4 mm2) [No. 6 AWG
(13.3 mm2) for Canada] solid copper bonding wire to the pressure wire connector provided on the
electrical equipment and to all metal parts of swimming pool, spa, or hot tub, and metal piping (ex-
cept gas piping), and conduit within 5 ft. (1.5 m) of inside walls of swimming pool, spa, or hot tub.
IMPORTANT - Reference NEC codes for all wiring standards including, but not limited to, ground-
ing, bonding and other general wiring procedures.
WARNING – Risk of Electric Shock The electrical equipment must be connected only to a
supply circuit that is protected by a ground-fault circuit-interrupter (GFCI). Such a GFCI should
be provided by the installer and should be tested on a routine basis. To test the GFCI, push the
test button. The GFCI should interrupt power. Push reset button. Power should be restored. If
the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the
electrical equipment without the test button being pushed, a ground current is flowing, indicating
the possibility of an electrical shock. Do not use this electrical equipment. Disconnect the electri-
cal equipment and have the problem corrected by a qualified service representative before using.
CAUTION – HAYWARD®pumps are intended for use with permanently-installed pools and may be
used with hot tubs and spas if so marked. Do not use with storable pools. A permanently-installed
pool is constructed in or on the ground or in a building such that it cannot be readily disassembled
for storage. A storable pool is constructed so that it is capable of being readily disassembled for
storage and reassembled to its original integrity.
SAVE THESE INSTRUCTIONS
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
8
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
9
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
10
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

For further information or consumer
technical support, visit our website at
www.hayward.com
Hayward is a registered trademark and ColorLogic is a trademark
of Hayward Industries, Inc. © 2019 Hayward Industries, Inc.
All other trademarks not owned by Hayward are the property of their respective owners.
Hayward is not in any way affiliated with or endorsed by those third parties.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTSUSE ONLY HAYWARD GENUINE REPLACEMENT PARTS
