PR Lighting PR-8836 User manual

1
XRLED 3000-W Wash/Framing
PR-8836
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1. SAFETYAND WARNINGS……………………………………………………………………………………
2. INSTRUCTIONS………………………………………………………………………………………………
3.APPEARANCE…………………………………………………………………………………………………
4.INSTALLATION…………………………………………………………………………………………………
5. SETUPAND CONFIGURATION ………………………………………………………………………………
6. OPERATION MENU…………………………………………………………………………………………
7. DMX PROTOCOL………………………………………………………………………………………………
8.SIGNS ONTHE TOUCH SCREEN ……………………………………………………………………………
9.ERROR MESSAGES ……………………………………………………………………………………………
10.TECHNICAL DATA ……………………………………………………………………………………………
11.CIRCUIT DIAGRAM …………………………………………………………………………………………
12.COMPONENT ORDER CODES………………………………………………………………………………
3
4
5
5
8
10
12
20
20
21
24
26
The following items are supplied with the projector and please check:
Name
Quantity
Unit
Remark
G clamp
2
Pcs
XLR connector
1
Set
Male and female
Safety cord
2
Pcs
User manual
0
Pc
QR Code
Ω clamp
2
Pcs
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the
course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult your dealer and
do not use the unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
Any future technical changes are not subject to further notice.
Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from
the delivery date but the light source is not within the warranty.

3
1. SAFETYAND WARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
The following safety signs are used in the user manual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
●When unpacking, check if there is transportation damage before using the projector. Should there be any
damage caused by transportation, consult your dealer and do not use it.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projector as he/she likes.
●Please be noted that the damage caused by changing the projector at will is not warranted.
●Do not hesitate to contact the dealer or the manufacturer if any questions or advice.
●The projector is for indoor use only, IP20.
●Use only in dry locations. Keep this unit away from rain and moisture, excessive heat, humidity and dust. Do not
allow contact with water or any other liquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
being operated.
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operation must strictly follow the procedures in the manual.
●The projector is not for a user for any replacements and the user shouldn't open the projector for repair and
maintenance.
●Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned..
●Do not connect this device to any type of dimmer pack.
●If the lamp, lens and screen protective cover of the a lighting fixture have obvious damage, i.e., to the extent that
it hurts the performance like cracking or deformation. Please stop use it and replace them with the original parts,
otherwise its performance will be compromised.
●For the location of a lighting fixture, it shouldn’t be seen in the distance of less than 4 meters.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector while covers(housing)are off .
●Keep the lamp clean and do not touch it with bare hands.
●While operating it, wear protective items.
●Any electrical connection must be carried out by a qualified person .
●Before installation, please confirm the voltage supplied matches what is required for the projector.
●Each projector must be properly earthed and installed as per related electrical standards.
●Do not use power cord with its insulator damaged and connect the power cord with other cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully or
by pulling the power cable.
●All power cords must conform to related safety and regulations.

4
●While being operated, the projector should not be under rains or in humidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electrical parts’ life will be shortened .
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord
supplied through the safety cord holes for safety support.
●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from power
mains.
●.After stable operation under normal ambient temperature ,the temperature of the external surface of the housing
of the LED lighting fixture (the surface of the heat sink) is 65℃after the stable running.
●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not mean
the projector has some defects.
●While projector running, do not touch the metal housing with bare hand, otherwise get burned.
●Do not mount the projector directly on inflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector
and illuminated items is 10m.
●A projector should be installed with good ventilation and the minimum distance between the projector and
walls is 50cm.At the same time, please ensure the fans and air inlets and outlets are workable.
●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature
internally causing damages to the projector. Before power-off, please useTilt channel to move the head and make
it facing downward.
●The product meets The General Technical Requirements and Standards for Recycle and Use Of
Expired Appliance and Electronic Products.
●When the product meets disposal standards and needs to be disposed, a client needs to dispose and recycle it.
2. INSTRUCTIONS
●CLEANINGAND MAINTENANCE
If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the
projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the
projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,
restart the projector.
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very necessary to
ensure a reliable use of it. Cooling fans need to be cleaned every 15days. Internal lens, reflector and hot mirror need to be cleaned
periodically to optimize light output.
Cleaning frequency is to be decided by operations and its environment. Use soft cloth and normal detergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean
and do not touch optical parts with bare hands.
●Before any maintenance and cleaning, please ensure the project is off the power.
●Only qualified person is allowed to do maintenance.
●During maintenance and before maintenance, the projector must be off power.

5
●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
●Do not use any solvent with chemical elements to clean color filters or hot mirror.
●LUBRICATION
To ensure smooth movement of gobos and zoom and focus lens, it’s advised rotators’ bearings and 2 sliding bars for zoom and
focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised..
●TROUBLESHOOTING
PROBLEM
ACTION
The projector can’t be switched on
Check if the fuse is burned
Check if the power cord is connected well
Check if the switching power supply is bad or not connected well. A
professional technician is required for the repair
Check if the control board is connected well. .A professional technician
is required for the repair
The projector can be switched on , but the LED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technician is required for the repair
The projector can be switched on normally, but
not controlled by the DMX controller
Make sure that the fixture’s start address is right
Replace or repair the XLR signal cable.
The beam is not bright and its brightness
decreases sharply
Make sure the fans are working well or fans and their shields are not blocked
bydust.
Makesure that the internaloptics is clean.
The project image appears to have a halo
Carefully clean the LED lamp, optical lenses and other components.
Heavily Defective Beam
Check if lens are in good condition(not cracked)
Clean dust or grease on the lens.
3. APPEARANCE
4. INSTALLATION
●RIGGING
During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the
projector without unlock Pan and Tilt
BASE
ARM
HEAD

6
Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to
each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of
the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
Always ensure that the structure that you are going to mount the projector is secure and is strong enough to support the weight of the
fixture.
WARNING:
●The projector MUST be lifted or carried by the HANDLES instead of clamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●POWER CONNECTIONS
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
CLAMP
SAFETY
CORD
WARMING
Please run safety cord through
the safety hole circled in the
diagram for safety
Note:
1. the distance between the foot of
the base and the front lens cover(the
head facing downward)
2. the distance between mounting
truss and the front lens cover( the
head facing downward)
3. The maximum diameter of the
rotating head ( minimum spacing
between fixtures)

7
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector be connected with power separately so that they may be individually switched on and off.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordance with the standards concerned.
●If any questions about the electrical installation, do not continue but consult a qualified electrician.
●DMX CONTROLCONNECTION
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the
projector) or 5 pin XLR plugs and sockets. The XLR's are connected as shown in the figure above.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol
DMX512 (1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminator as shown in the figure below.
●DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged
into the output socket on the last projector in the chain. The connections are illustrated below

8
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain.
PIN 3
PIN 2
5. SETUPAND CONFIGURATION
●FRONT PANEL OPERATION
The configuration and start address can be set conveniently via push button and color touch screen.
To view or change its setup, touch any white area of the screen or push the key OK for more than 3 seconds to unlock the
display(While only on battery, push OK key). After the unlocking, push ► key to enter into function menus. Each main menu has its
submenus and each submenu has a specific function. For details, please see the “OPERATION MENU” with following
the 6th point..
1. In the page of function setup, push any key of ◄, ►, ▲ and ▼ or icon for the function desired.
2. At 2nd ,3rd and 4th level menus, key ◄ means ESCAPE, key ► won’t function, key OK means ENTER. Push key OK to
save any changes o enter into submenus. Push key ▲or ▼ to change numbers(plus or minus) or tap any item required
for changes.
Push the left key or shortcut key X to go back to the upper level menu. If none pushed, the system will go back to initial display
automatically.
Shortcut keys: after the interface of FUNCTION MENU, the upper part is with menus for many functions. On the right, there are 4
shortcut keys, which are ←,→,lamp control or English/Chinese menus.
●DMX STARTADDRESS
Each projector must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller. The projector has 3 DMX modes. There are short mode ,standard mode and extended mode. For example standard mode
has 35 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 036, No. 3 projector’s address 071, No. 4
projector’s address 106, and so on.
Launch the projector. Press key OK more than 3 seconds to unlock the display.After the unlocking, push key ► to enter into menus.
After selecting the sign of DMX setting, push OK key or tap the screen directly and select DMX address at 2nd level menus.
Push key▲ or▼ or tap sign < or > to set the number desired.
Push OK key to confirm.
Push key◄ and it will return to the upper menu
.
The projector has wireless control function with wireless receiver module and antenna for remote control.
The setup of it is below:

9
1. Enter into the projector’s menu. Select the menu “Config Settigns” via the keys of ▲ and ▼
2. Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY). The DMX wireless control
function is activated.
Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press
“Enter” for the menu of Unlink Wireless under the upper level menu of Config Settigns.
●STAND-ALONE MODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVE MODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’and Slaves’operation mode can
be set accordingly.
After Powered on, the group will run in Master/Slave Mode
●TO SET UP COLOR TEMPERATUREAND COLOR MACRO
A projector has 7 color temperature macros and 89 standard color macros. Color temperatures are for respective
2700K,3000K,3500K,4000K,4500K,5000K and 5700K. Under the DMX channel of CMY macro, color macro and its color
temperature macro can be selected.
●TO SET UPDIMMER CURVE AND LED REFRESH FREQUENCY
Aprojector has 4 gamma dimmer curves: gamma 2.0, gamma 2.2, gamma 2.4 and gamma 2.6.
It has 8 LED refresh frequency: LED refresh frequency 1200Hz, LED refresh frequency 2400Hz, LED refresh frequency 4800Hz,
LED refresh frequency 10000Hz, LED refresh frequency 12000Hz, LED refresh frequency 15000Hz, LED refresh frequency
20000Hz and LED refresh frequency 25000Hz.
It has fast, medium and slow dimmer speeds.
Its setups are as follows:
1. Hold the OK button for more than 3s to unlock the control panel and then push ► button to enter into the menus and select
“Option Settings”.
2. Select “Dimmer Settings” and select any mode of gamma curve /LED frequency /dimmer speed for adjustment.

10
●FAN SPEED MODES
It has standard and theater modes. Theater mode is quiet mode.
Its setups are as follows:
1. Hold the OK button for more than 3s to unlock the control panel and then push ► button to enter into the menus and select
“Option Settings”.
2. Select either of Standard and theater modes after the menu of Fan Settings.
●BRIGHTNESS CALIBRATION
For brightness calibration function, a controller can be used on the projectors in a DMX chain or a projector be done individually.
After running for some time, the projectors need to be recalibrated in brightness for conformity with the help of LED brightness
calibration channel via controller. The function has the following characteristics:
1. LED brightness calibration channel has 50 levels for adjustment with each level meaning power consumption decreases by 1%.
2. Calibration can be done on projectors in a DMX chain or a single one.After calibration done on a lot of projectors in a DMX chain,
it can be done individually also if needed.
3. To avoid erroneous operation, after the fader of a DMX controller is at proper place for LED BRIGHTNESS CALIBRATION
channel, the fader for channel of LED BRIGHTNESS CALIBRATION CONFIRMATION channel should be at right DMX value
range to save parameters. The calibration is completed after the desired parameters are stored into the projectors.
●CRI MODE
It hasHIGH CRI MODE and select it via DMX controller to activate it. The mode ensures high CRI optical effect.
6. OPERATION MENU
1st LEVEL
2nd LEVEL
3rd LEVEL
4th LEVEL
5th LEVEL
Address
DMX Address
1-482（Short Mode）
1-478（ Standard Mode）
1-464（Extended Mode）
IP Address
Default IPAddress
2.X.X.X /10.X.X.X
Custom IPAddress
X.X.X.X
Sub Net Mask
X.X.X.X
ArtNet Universe
0-255
sACN Universe
1-63999
Reset
Total Reset
Really Reset?
Confirm/Cancel
Pan&Tilt Reset
Really Reset?
Confirm/Cancel
Colour System Reset
Really Reset?
Confirm/Cancel
Zoom Focus Reset
Really Reset?
Confirm/Cancel
Other Reset
Really Reset?
Confirm/Cancel
Config Settings
DMX Channel Mode
Short 31CH
Standard 35CH
Extended 49CH
View Selected Mode
Strobe
Signal Select
XLR Only
XLR First
Wireless Only
Wireless First
Wireless In/XLR Out
ArtNet Only
ArtNet In/XLR Out
sACN Only
sACN In/XLR Out

11
Loss of DMX
Normal time out
Hold LastValue
Display Config
Display Mode
OffAfter Delay
OnAlways
Display Invert
Invert OFF
Invert ON
InvertAuto
Language Setting
English
Chinese
Touch Calibration
0-999
Temperature Unit
Celsius Degree
Fahrenheit Degree
Un-Link Wireless
Really Un-Link?
Confirm/Cancel
Factory Defaults
Restore Defaults?
Confirm/Cancel
Option Settings
Pan/Tilt Settings
Pan DMX Invert
OFF/ ON
Tilt DMX Invert
OFF/ ON
Pan Tilt Swap
OFF/ ON
XYFeedback
OFF/ ON
Pan/Tilt Mode
speed/Time
Invert Settings
Zoom Invert
OFF/ ON
CYM Invert
OFF/ ON
CTO Invert
OFF/ ON
Dimmer Settings
Gamma Curve
Gamma 2.0/2.2/2.4/2.6
LED Refresh Rate
1200/2400/4800/10000/1200
0/15000/20000/25000Hz
Dimmer Speed
Fast/Medium/Slow Speed
Fan Settings
Standard/Theatre
Defaults
Restore Defaults?
Confirm/Cancel
Information
View DMX Values
Lamp Hours
Reset Lamp Hours
Total Hours
Temperature
Display Board XX℃/F
Pan and Tilt Board XX℃/F
Driver Board 1 XX℃/F
Driver Board 2 XX℃/F
Driver Board 3 XX℃/F
Blade Board XX℃/F
Fan Board XX℃/F
Led Sensor XX℃/F
SoftwareVersion
Display Board
Sys= XXX
Boot =XXX
Pan and Tilt Board
Sys= XXX
Boot =XXX
Driver Board 1
Sys= XXX
Boot =XXX
Driver Board 2
Sys= XXX
Boot =XXX

12
Driver Board 3
Sys= XXX
Boot =XXX
Blade Board
Sys= XXX
Boot =XXX
Fan Board
Sys= XXX
Boot =XXX
Electronic SN
Electronic SN=
************
RDM Device Label
XRLED 3000-W W/Framing
ANSI E1.20 RDM
Fan Status
Fan Speed Status
Base Fan 1 XXX XXX
Base Fan 2 XXX XXX
Color Wheel Fan XXX XXX
Framing M. F1 XXX XXX
Framing M. F2 XXX XXX
LED Fan 1 XXX XXX
LED Fan 2 XXX XXX
LED Fan 3 XXX XXX
LED Fan 4 XXX XXX
LED Driver Fan1XXX XXX
LED Driver Fan2XXX XXX
Service
Manual Effect Control
Strobe XXX
Dimmer XXX
Factory Test
…
Operation Mode
DMX Mode
Change Operation Mode?
Confirm/Cancel
Master Mode
Preset Memory
Change Operation Mode?
Confirm/Cancel
User Memory 1
Change Operation Mode?
User Memory 2
Change Operation Mode?
Stand-Alone Mode
Preset Memory
Change Operation Mode?
User Memory 1
Change Operation Mode?
User Memory 2
Change Operation Mode?
Static Scene
Change Operation Mode?
User Memories
Edit User Memory
Edit User Memory 1
Edit User Memory 2
Scene XX
（
1~200 Scenes）
Strobe XXX
Dimmer XXX
….
Delay Time XXX
Delay Unit MS/S/MIN
Link to Step XXX
Edit Static Scene
Strobe XXX
Dimmer XXX
Init User Memory
Reset User Memory 1
Reset User Memory?
Input Password123
Reset User Memory 2
Reset User Memory?
Input Password123
Reset Static Scene
Reset Static Scene?
Input Password123
7. DMX PROTOCOL
Short
mode
Standard
mode
Extended
mode
Function Description
Decimal
Low
Decimal High
1
1
1
Strobe
Close
0
Pulse strobe speed from slow to fast
1
127
Strobe speed slow to fast
128
255
2
2
2
Dimmer
Close
0
0
Non-linear dimmer from dark to bright (0-100%)
1
255

13
3
3
Dimmer Fine
Dimmer in 16 bit
0
255
3
4
4
CYM Macro
The following functions will disable CMY ,CTO
No Function
0
7
Colour Temperature 2700K
8
9
Colour Temperature 3000K
10
11
Colour Temperature 3500K
12
13
Colour Temperature 4000K
14
15
Colour Temperature 4500K
16
17
Colour Temperature 5000K
18
19
Colour Temperature 5700K
20
21
Colour Macro 1
22
23
Colour Macro 2
24
25
Colour Macro 3
26
27
Colour Macro 4
28
29
Colour Macro 5
30
31
Colour Macro 6
32
33
Colour Macro 7
34
35
Colour Macro 8
36
37
Colour Macro 9
38
39
Colour Macro 10
40
41
Colour Macro 11
42
43
Colour Macro 12
44
45
Colour Macro 13
46
47
Colour Macro 14
48
49
Colour Macro 15
50
51
Colour Macro 16
52
53
Colour Macro 17
54
55
Colour Macro 18
56
57
Colour Macro 19
58
59
Colour Macro 20
60
61
Colour Macro 21
62
63
Colour Macro 22
64
65
Colour Macro 23
66
67
LEE 004 (Medium Bastard Amber)
68
69
LEE 010 (Medium Yellow)
70
71
LEE 019 (Fire)
72
73
LEE 026 (Bright Red)
74
75
LEE 058 (Lavender)
76
77
LEE 068 (Sky Blue)
78
79
LEE 071 (Tokyo Blue)
80
81
LEE 079 (Just Blue)
82
83

14
LEE 088 (Lime Green)
84
85
LEE 090 (Dark Yellow Green)
86
87
LEE 100 (Spring Yellow)
88
89
LEE 101 (Yellow)
90
91
LEE 102 (Light Amber)
92
93
LEE 103 (Straw)
94
95
Lee 104 (Deep Amber)
96
97
LEE 105 (Orange)
98
99
LEE 106 (Primary Red)
100
101
LEE 111 (Dark Pink）
102
103
LEE 115 (Peacock Blue)
104
105
LEE 116 (Medium Blue-Green)
106
107
LEE 117 (Steel Blue)
108
109
LEE 118 (Light Blue)
110
111
LEE 119(Deep Blue)
112
113
LEE 120 (Dark Blue)
114
115
LEE 121 (LEE Green)
116
117
LEE 128 (Bright Pink)
118
119
LEE 131 (Marine Blue)
120
121
LEE 132 (Medium Blue)
122
123
LEE 134 (Golden Amber)
124
125
LEE 135 (Deep Golden Amber)
126
127
LEE 136 (Pale Lavender)
128
129
LEE 137 (Special Lavender)
130
131
LEE 138 (Pale Green)
132
133
LEE 139 (Primary Green)
134
135
LEE 141 (Bright Blue)
136
137
LEE 147 (Apricot)
138
139
LEE 148 (Bright Rose)
140
141
LEE 152 (Pale Gold)
142
143
LEE 154 (Pale Rose)
144
145
LEE 157 (Pink)
146
147
LEE 158 (Deep Orange)
148
149
LEE 162 (Bastard Amber)
150
151
LEE 164 (Flame Red)
152
153
LEE 165 (Daylight Blue)
154
155
LEE 169 (Lilac Tint)
156
157
LEE 170 (Deep Lavender)
158
159
LEE 172 (Lagoon Blue)
160
161
LEE 179 (Chrome Orange)
162
163
LEE 180 (Dark Lavender)
164
165
LEE 181 (Congo Blue)
166
167
LEE 197 (Alice Blue)
168
169

15
LEE 201 (Full C.T. Blue)
170
171
LEE 202 (Half C.T. Blue)
172
173
LEE 203 (Quarter C.T. Blue)
174
175
LEE 204 (Full C.T. Orange)
176
177
LEE 205 (Half C.T. Orange)
178
179
LEE 206 (Quarter C.T. Orange)
180
181
LEE 247 (LEE Minus Green)
182
183
LEE 248 (Half Minus Green)
184
185
LEE 281 (Three Quarter C.T. Blue)
186
187
LEE 285 (Three Quarter C.T. Orange)
188
189
LEE 352 (Glacier Blue)
190
191
LEE 353 (Lighter Blue)
192
193
LEE 715 (Cabana Blue)
194
195
LEE 778 (Millennium Gold)
196
197
LEE 793 (Vanity Fair)
198
199
CMY colour mixing from slow to fast
200
255
4
5
5
Cyan
Cyan (Linear 0-100%)
0
255
6
Cyan Fine
Cyan in 16 Bit precision
0
255
5
6
7
Yellow
Yellow (Linear 0-100%)
0
255
8
Yellow Fine
Yellow in 16 Bit precision
0
255
6
7
9
Magenta
Magenta (Linear 0-100%)
0
255
10
Magenta Fine
Magenta in 16 Bit precision
0
255
7
8
11
CTO
Linear adjust from high to low
0
255
12
CTO Fine
CTO in 16 Bit precision
0
255
8
9
13
Colour Wheel 1
Continual positioning
index 0-360°
0
63
positioning
Open
64
67
Open/Color1(Red)
68
71
Color1(Red)
72
75
Color1(Red)/Color 2(Green)
76
79
Color 2(Green)
80
83
Color 2(Green)/Color 3(Blue)
84
87
Color 3(Blue)
88
91

16
Color 3(Blue)/ Color 4(Orange)
92
95
Color 4(Orange)
96
99
Color 4(Orange) /Color 5(Pink)
100
103
Color 5(Pink)
104
107
Color 5（Pink）/Color 6（Light cyan）
108
111
Color 6(Light cyan)
112
115
Color6(Light cyan)/ Open
116
119
Open
120
127
Clockwise rainbow effect rotation speed from slow to fast
128
191
Anti-clockwise rainbow effect rotation speed from slow to fast
192
255
10
14
Color Wheel 1 Fine
Color Continual positioning in 16 Bit precision
0
255
9
11
15
Colour Wheel 2
Continual positioning
index 0-360°
0
63
positioning
Open
64
67
Open/Color1(Dark Red)
68
71
Color1(Dark Red)
72
75
Color1(Dark Red)/Color 2(Amber)
76
79
Color 2(Amber)
80
83
Color 2(Amber)/Color 3(Tea red)
84
87
Color 3(Tea red)
88
91
Color 3(Tea red)/ Color 4(Apple Green)
92
95
Color 4(Apple Green)
96
99
Color 4(Apple Green ) /Color 5(Dark magenta)
100
103
Color 5(Dark magenta)
104
107
Color 5（Dark magenta）/Color 6（UV）
108
111
Color 6(UV)
112
115
Color 6(UV)/ Open
116
119
Open
120
127
Clockwise rainbow effect rotation speed from slow to fast
128
191
Anti-clockwise rainbow effect rotation speed from slow to fast
192
255
12
16
Color Wheel 2 Fine
Color Continual positioning in 16 Bit precision
0
255
10
13
17
Framing blade 1 left
Framing blade 1 left linearly closing from big to small
0
255
18
Framing blade 1 left in 16 bit
Framing blade 1 left fine adjustment
0
255
11
14
19
Framing blade 1 right
Framing blade 1 right linearly closing from big to small
0
255
20
Framing blade 1 right in 16 bit
Framing blade 1 right fine adjustment
0
255

17
12
15
21
Framing blade 2 left
Framing blade2 left linearly closing from big to small
0
255
22
Framing blade 2 left in 16 bit
Framing blade 2 left fine adjustment
0
255
13
16
23
Framing blade 2 right
Framing blade 2 right linearly closing from big to small
0
255
24
Framing blade 2 right in 16 bit
Framing blade 2 right fine adjustment
0
255
14
17
25
Framing blade 3 left
Framing blade 3left linearly closing from big to small
0
255
26
Framing blade 3 left in 16 bit
Framing blade 3 left fine adjustment
0
255
15
18
27
Framing blade 3 right
Framing blade 3 right linearly closing from big to small
0
255
28
Framing blade 3right in 16 bit
Framing blade 3right fine adjustment
0
255
16
19
29
Framing blade 4 left
Framing blade 4left linearly closing from big to small
0
255
30
Framing blade 4left in 16 bit
Framing blade 4 left fine adjustment
0
255
17
20
31
Framing blade 4 right
Framing blade 4 right linearly closing from big to small
0
255
32
Framing blade 4right in 16 bit
Framing blade 4right fine adjustment
0
255
18
21
33
Framing module rotation
Framing module indexing(0-360degrees)
0
127
Stop
128
Framing module clockwise rotation from slow to fast
129
188
Stop
189
195
Framing module anti-clockwise rotation from slow to fast
196
255
22
34
Framing module rotation in 16 bit
Framing module fine rotation
0
255
19
23
35
Focus
Linearly focusing
0
255
36
Focus Fine
Focus in 16 precision
0
255
20
24
37
Zoom
Linearly zooming
0
255
38
Zoom Fine
Zoom in 16 Bit precision
0
255
21
25
39
Pan
Pan movement
0
255
22
26
40
Pan Fine

18
Pan movement in 16 bit precision
0
255
23
27
41
Tilt
Tilt movement
0
255
24
28
42
Tilt fine
Tilt movement 16 bit precision
0
255
25
29
43
Pan/Tilt speed
Fast Speed Mode
0
1
Pan &Tilt speed from fast to slow
2
255
26
30
44
CRI MODE
Normal mode
0
127
High CRI mode
128
255
27
31
45
Power/Special functions
No function:
0
4
Reserved
5
19
To activate following functions, stay in DMX value for at least 5 s
Graphic display On
20
24
Graphic display Off
25
29
Reserved
30
44
Reserved
45
46
Fan standard mode
47
48
Fan theater mode
49
50
Reserved
51
52
Fast speed dimmer
53
54
Mid speed dimmer
55
56
Slow speed dimmer
57
58
Gamma curve 2.0
59
60
Gamma curve 2.2
61
62
Gamma curve 2.4
63
64
Gamma curve 2.6
65
66
LED refresh rate 1200Hz
67
68
LED refresh rate 2400Hz
69
70
LED refresh rate 4800Hz
71
72
LED refresh rate 10000Hz
73
74
LED refresh rate 12000Hz
75
76
LED refresh rate 1500Hz
77
78
LED refresh rate 20000Hz
79
80
LED refresh rate 25000Hz
81
82
Reserved
83
89
Pan/Tilt speed mode
90
94
Pan/Tilt time mode
95
99
Reserved
100
129
Reserved
130
139

19
Pan/Tilt reset
140
149
Colour system reset
150
159
Gobo wheels reset
160
169
Reserved
170
179
Zoom/focus reset
180
189
Others(Framing module) reset
190
199
Total reset
200
209
Reserved
210
229
Reserved
240
255
28
32
46
LED brightness calibration
No
0
127
LED brightness 50%-100%, linear calibration
128
255
29
33
47
LED brightness calibration confirmation
Ready to store calibrated value
0
200
Store calibrated value in the fixture(stay in the DMX range for
more than 5s)
201
209
No
210
255
30
34
48
Reserved
0
255
31
35
49
Reserved
0
255
Remarks:
1. Fan error can shut off light source.
2. "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means
both Pan and Tilt will arrive at designated pointat the same time. It's advised Time Mode be used if the projector runs circles or in
oblique lines.
3. LED brightness standard with adjusting range between 50% and 100%. After completion, the desired parameters will be
stored into the fixtures without repeated operations.
1).Procedures:
Step1: DMX value range for Channel LED brightness calibration is between 128 and 255 with according brightness range
between 50% and 100%.
Step2:DMX value range for Channel LED brightness calibration confirmation is between 0 and 200. If the fader is moved
between 201 and 209 and stays there for more than 5s, the desired brightness value will be stored into fixtures.
Step 3:Move the faders for DMX channels LED brightness calibration and LED brightness calibration confirmation
respectively to zero.
1).If 100% brightness needed, move the fader for channel LED brightness calibration at 255 for Step 1 and repeat Step 2 and 3.
2).Under the menu, confirm Defaults/Restore default, LED brightness will go back to 100%.

20
8. SIGNS OF THE TOUCH SCREEN
Config Settings
Option Settings
Address
Information
Error Messages
Service
Reset
Operation Mode
User Memories
9.ERROR MESSAGES
The system can detect some errors during the reset, if displayed, touch to view the error.
The error messages are as follows:
Name
Type
Correction
Pan
Timeout/magnet Sensor/Encoder
Check if wiring, positioning parts and motors are normal
Tilt
Timeout/magnet Sensor/Encoder
Check if wiring, positioning parts and motors are normal
Cyan
Timeout
Check if wiring, positioning parts and motors are normal
Yellow
Timeout
Check if wiring, positioning parts and motors are normal
Magenta
Timeout
Check if wiring, positioning parts and motors are normal
CTO
Timeout
Check if wiring, positioning parts and motors are normal
Color Wheel1
Timeout
Check if wiring, positioning parts and motors are normal
Color Wheel2
Timeout
Check if wiring, positioning parts and motors are normal
Dimmer
Timeout
Check if wiring, positioning parts and motors are normal
Focus
Timeout
Check if wiring, positioning parts and motors are normal
Zoom
Timeout
Check if wiring, positioning parts and motors are normal
Pan Board
Error
Check signal wire
Tilt Board
Error
Check signal wire
Driver Board 1
Error
Check signal wire
Driver Board 2
Error
Check signal wire
Driver Board 3
Error
Check signal wire
Driver Board 3
Error
Check signal wire
Blade board
Error
Check signal wire
Fan board
Error
Check signal wire
Lamp Off[Fan
Error]
Error
Check if all fans are normal
Time IC
Error
Contact the manufacturer
