1 Measuring Amplifiers on Eurocards ME50S6
The Eurocards ME50S6 are 4.8KHz carrier frequency measuring amplifiers
for strain gauge transducers.
All plug-in cards are delivered without housing or rack frame and without
power supply unit so that an individual setting in an existing 19” rack mounting
system is possible. Owing to the narrow width of the plug-in cards (4 divs =
20.32mm) up to 21 cards can be inserted into a 19” rack. The dimensions and
connecting details correspond to the IEC standards 48D and 297.
All controls necessary for easy operation are accessible from the front.
Individual adjustments are described in chapter four; ex-works settings are
specified on the back of the Eurocard.
Notes for the diagram on the right
S21:
calibration −measuring −zero
S22/23:
zero balancing (coarse)
S24/1+2:
MR1 fine balancing internal/ex-
ternal
S24/3:
switch for measuring frequency
range 60 Hz to 2 Hz
S24/4:
MR changeover from MR1 to
MR2
S25:
alteration to bridge supply vol-
tage
S26/27:
setting of measuring range
(coarse)
P21/22:
fine balancing of MR
P23:
zero balancing (fine)
1c
7c
8c
9c
26c
21c
24c
21a
25a
25c
30c
30a
32c
32a
28a
28c
31a+c
6c
7a
15c
4a
5a
15a
16a
19c
18c
19a
20a
11c
St 21
chassis
MR1
fine balancing
external
zero balancing
external
zero
calibr.
MR1−2
+14.5...15.5V
−14.5...15.5V
+
−
option DC/DC-con-
verter
Ub +14.5...+15.5V
Ub −14.5...−15.5V
Ua ±10V >5kOhm
option Ia ±20mA
2.33V synchr.-vol-
tage
or synchr. input
5kOhm
50kOhm
wh
rd
gy
bk
bu
gn
G

4.8kHz
S25
5V/1V
S26/27 S22/23
P23
S21
Cal. 1mV/V
zero

0..250Hz
0..40Hz
S24/4
S24/1+2
S24/3
P21/22
Fig. 1.1: Block diagram

9
ME50S6
HBMA0260-1.1 en
2 Electrical Connection
2.1 Transducer Connection
Strain gauge transducers are connected by means of 6-wire circuits.
measuring signal(−) pin 30a. . . . . . .
sensing line to 32a(−) pin 32c. . . . .
bridge supply voltage(−) pin 32a. . .
measuring signal (+) pin 30c. . . . . .
bridge supply voltage (+) pin 28a. .
sensing line to 28a (+) pin 28c. . . .
screen pins 31a+c. . . . . . . . . . . . . . . . . .
(alternatively 29a+c)
contact rd
bk
wh
bu
gn
ye
gy
Fig. 2.1: Bridge connection
The required bridge supply voltage is 5 V(symmetrical about ground) as set
ex-works. It can be reduced to 1.0 V by switch S25.
UBBridge resistance Switch S25
5 V
(ex-works setting) RB≥110...4000 Ω
1 V RB≥60...4000 Ω
The safety barriers SD01 must be wired into the connecting lines (see chapter
5.4) for transducers in EEx(i) design.

10 ME50S6
HBM A0260-1.1 en
2.2 Supply Voltage
+14.5...+15.5 V (max.70 mA) . . . . . . . . . . . . . .
−14.5...−15.5 V (max.65 mA) . . . . . . . . . . . . . .
operating voltage zero . . . . . . . . . . . . . . . . . . .
The ripple on the supply voltage should not exceed 0.1 V peak-to-peak. The
supply connections are internally protected against reverse polarity. Single
sided connection of the supply voltage should be avoided. The supply voltage
should be kept as low as possible within the permissible range of
"15.6..."25 V in order to maintain the dissipation at a low value.
If a stabilized voltage is not available, the measuring amplifier can be oper-
ated by means of a stabilized power supply or a DC-DC converter (see chap-
ter 5.1 and 5.2).
2.3 Output
Output voltage: "10 V; RL≥5 kΩ . . . . . . . . . .
Operating voltage zero . . . . . . . . . . . . . . . . . . .
The output is provided for the connection of a display and/or recorders. A cur-
rent output can be generated optionally (see chapter 5.3).
2.4 Supply Voltage for Additional Units
Stabilised voltages are available for supplying additional units:
+14.5V...+15.5 V; <50 mA . . . . . . . . . . . . . . . .
−14.5V...−15.5 V; <50 mA . . . . . . . . . . . . . . . .
operating voltage zero . . . . . . . . . . . . . . . . . . .
pin15a
pin16a
pin19c
+
pin18c
pin20a
±
+
pin6c
pin7a
pin15c
−
−

11
ME50S6
HBMA0260-1.1 en
2.5 Pin Assignment
64-pin right angle plug
1c housing
2c not occupied
3c not occupied
4c not occupied
5c not occupied
6c output Uadd.=+14.5...+15.5 V; <50 mA
7c MR1 external fine balance (R=5 kOhm)
8c MR1 external fine balance. tap
9c MR1 external fine balance (R=5 kOhm)
10c not occupied
11c not occupied
12c input synchronization
13c not occupied
14c not occupied
15c operating voltage zero
16c not occupied
17c not occupied
18c output UA="10 V; R>5 kOhm
19c operating voltage zero
20c not occupied
21c external zero balancing tap
22c not occupied
23c not occupied
24c external zero balancing (R=50 kOhm)
25c external switching from MR1 to MR2
26c external zero balancing (R=50 kOhm)
27c not occupied
28c sensing line F(gn)
29c operating voltage zero
30c measuring signal A(wh)
31c operating voltage zero (ye)
32c sensing line G(gy) St 21
1a not occupied
2a not occupied
3a not occupied
4a DC-DC converter positive pole
5a DC-DC converter negative pole
6a not occupied
7a output
Uadd.=−14.5...−15.5 V; <50 mA
8a not occupied
9a not occupied
10a not occupied
11a not occupied
12a not occupied
13a internally connected
14a internally connected
15a supply voltage
+14.5...+15.5 V (standard)
16a supply voltage
−14.5...−15.5 V (standard)
17a not occupied
18a not occupied
19a current output with EM002
20a operating voltage zero
21a zero function, external
22a not occupied
23a not occupied
24a not occupied
25a calibration function, external
26a not occupied
27a not occupied
28a bridge supply voltage C(bu)
29a operating voltage zero
30a measuring signal D(rd)
31a operating voltage zero (ye)
32a bridge supply voltage B(bl)

12 ME50S6
HBM A0260-1.1 en
3 Putting into Operation
If the manufacturer’s settings, such as the coarse measuring range, are re-
tained the operation is limited to the following points:
3.1 Select Measuring Range
With the ex-works setting measuring range 1 ("1 mV/V) is always switched
on. Measuring range 2 (calibration at "0.2 mV/V) can be selected either in-
ternally via DIP switch 24/4 or externally by connecting a single-pole change-
over switch to pin 25c (see chapter 4.2).
3.2 Bridge Zero Balancing
The bridge zero balancing is carried out by means of the screwdriver poten-
tiometers P23 (fine) and switches S22 (coarse) and S23 (polarity). (See also
chapter 4.4).
3.3 MR Fine Adjustment
The fine adjustment of the measuring range is made seperately for both
ranges by means of the screwdriver potentiometers P21 (measuring range 1)
and P22 (measuring range 2). The potentiometers, which are accessible from
the front, permit corrections of approx. 35 % (related to the set measuring
range). As far as measuring range 1 is concerned, the fine adjustment is also
possible via an external potentiometer (for this see chapter 4.3).
Attention: P22 must not be altered in order not to detune the manufacturer’s
calibration of MR2 ("0.2 mV/V). (for this see chapter 4.5).

13
ME50S6
HBMA0260-1.1 en
P21
P22
ME50
S21
P23
S22
S23
Fig. 3.1: Front view ME50S6

14 ME50S6
HBM A0260-1.1 en
4 Individual Settings
Various ex-works settings on the measuring amplifier card can be altered.
Adaptations, which are of no problem, can be carried out by means of the DIP
switch on the board or also by externally wired switching elements. If re-
quested with the order, they can be carried out by the manufacturer.
4.1 Operational Setting
Zero Measure Calibrate
Switch S21 or connect pin 21a to pin 15c
or connect pin 25a to pin 15c
The measuring signal is switched off in the ”Zero” function, so that the output
signal indicates the adjusted balance value as ”Zero value”. This function en-
ables amplifiers to be replaced in measurement systems without the need for
rebalancing the bridge with zero load on the transducer. All that is required is
that the amplifier balance values are noted and then this value is set, if neces-
sary, with P23, S22 and S23.
4.2 Setting the Measuring Range
Measuring range 1 is get ex-works. Measuring range 2 can be activated by
switching DIP switch S24/4 or by external switching.
Measuring Range S 24/4 Externally
MR 1 = "1 mV/V
(ex-works setting) −
MR 2 = "0.2 mV/V from MR1 to MR2;
connect 25c and 15c
Any alteration to the measuring ranges between "0.2 mV/V and "4 mV/V
with UB= 5 V (resp. "1.0 mV/V... "20 mV/V with UB= 1.0 V) can be made
by means of the DIP switches S26 and S27. For fine balancing see 3.3.

15
ME50S6
HBMA0260-1.1 en
UB=5 V MR1:S26 ; MR2:S27 ex-works sett.
Meas.range(mV/V) 1 2 3 4 5 6 7 8
0.17 0.24. . . x o o o o o x o MR 2 "0.2mV/V
0.22 0.32. . . x o o o o o o x
0.30 0.42. . . o x o o o o x o
0.39 0.55. . . o x o o o o o x
0.52 0.73. . . o o x o o o x o
0.68 0.97. . . o o x o o o o x
0.90 1.28. . . o o o x o o x o MR 1 "1mV/V
1.18 1.69. . . o o o x o o o x
1.56 2.23. . . o o o o x o x o
2.07 2.94. . . o o o o x o o x
2.73 3.88. . . o o o o o x x o
3.61 5.13. . . o o o o o x o x
o = open, x = closed
4.3 External Fine Balancing of the MR1
An external Potentiometer (5 kΩ) can be connected for fine adjustment of the
range.
This will enable about 35 % correction of the selected range.
Connections:
potentiometer pin 9c. . . . . . . . . . . . . . . . . . . . . .
wiper pin 8c. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
potentiometer finish pin 7c. . . . . . . . . . . . . . . . .
4.4 Bridge Fine Balancing
a) Coarse Balancing
The 16-stage switch S22 is used for the coarse balancing carried out from the
front panel; the polarity of the balancing direction can be chosen via switch
S23. The overall balancing range is approximatly "2 mV/V.
b) Fine Balancing
The potentiometer P23 is used for the fine balancing ("0.08 mV/V).
R=5 kΩ

16 ME50S6
HBM A0260-1.1 en
c) External Zero Balancing
A potentiometer of 50 kΩ, which can be connected externally, can be used for
settings within a balancing range of "0.12 mV/V set by the manufacturer.
Pin assignment:
potentiometer pin 26c. . . . . . . . . . . . . . . .
wiper pin 21c. . . . . . . . . . . . . . . . . . . . . . .
potentiometer finish pin 24c. . . . . . . . . . .
4.5 Calibration Signal
The measuring amplifier ME50S6 operates on a 6-wire technique, i.e. the cal-
ibration and zero compensation signals are formed from the bridge supply
voltage fed back; thus they are independent of transducer, connecting cable
and pin resistances. If necessary, the sensitivity of the measuring amplifier
can be adjusted by means of an internal calibration signal of +1 mV/V with
measurimg ramges > 1mV/V. Here the switch S21 must be kept in the calibra-
tion position and the appropriate value must be be set simultaneously by
means of the potentiometers P21 resp. P22. When using the ex-works cal-
ibration measuring range 2 the setting of P22 must be altered. (see chapter
3.3).
4.6 Measuring Frequency Range / Cut-off Frequency fco
The Butterworth low pass of the amplifier has been set to 0...250 Hz (−1 dB)
by the manufacturer. It can be readjusted by switching the DIP switch S24/3 to
0...40 Hz (−1 dB).
Measuring frequency range S 24/3
0...250 Hz (−1 dB)
(ex-works setting)
0...40 Hz (−1 dB);
R=50 kΩ

17
ME50S6
HBMA0260-1.1 en
4.7 Synchronization
When synchronizing several units of the type ME50S6 one of them has to be
switched as master; its carrier frequency is used for reference. Pins 12c and
15c of all amplifiers concerned must be joined for synchronization. The master
amplifier is selected by switch S28.
Synchronization S S28
Slave amplifier (ex-works setting)
Master amplifier

18 ME50S6
HBM A0260-1.1 en
5 Options
5.1 Stabilized Power Supply
The module KM001 can be used to connect the measuring amplifier to a sym-
metrical supply voltage "15.6...25.0 V. When installing the module KM001,
attention must be paid to the marking. The jumpers BR3 and BR4 have to be
configured according to the table below.
Pin assignment:
positive pole pin 15a. . . . . . .
negative pole pin 16a. . . . . .
supply zero pin 19c. . . . . . . .
5.2 DC-DC Converter
The manufacturer can mount a DC-DC converter onto the board for the op-
eration of a simple operating voltage with simultaneous electrical isolation be-
tween operating voltage and measuring circuit. The voltage converter can be
delivered for operation +9...+35 V (for unstabilized voltage).
Pin assignment:
positive pole pin 4a. . . . . . .
negative pole pin 5a. . . . . .
When using the modules KM001 resp. a DC-DC converter attention has to
be paid to the jumpers BR3 and BR4 which are re-configured.
ex-works setting:
1 2 3
BR3
BR4
I
I
With module KM001 resp. DC-DC converter
1 2 3
BR3
BR4
I
I

19
ME50S6
HBMA0260-1.1 en
5.3 Current Output Module
The module EM002 can be installed to obtain a current output.
The pin assignment is as follows:
output current pin 19a. . . . . .
supply zero pin 20a. . . . . . . .
The power range is switched by the DIP switch 24/5.
Output current source S24/5
+4...+20 mA
+20 mA (ex-works setting)
When using an EM002, current and voltage outputs are not aligned to each
other. The required fine calibration can be carried out from the front panel (as
described in chapter 3)
5.4 Safety Barriers for use in Hazardous Areas
For transducer operation in potentially explosive atmospheres the safety barri-
ers SD01A are used conforming to the protection classes (EEx ia IIC) accord-
ing to EN 50 014 and EN 50 020.
5.5 Additional Units
The following additional cards are available for the measuring amplifier
ME50S6:
−automatic zeroing unit NE02
−peak / last value memory SE03
−limit switch GE04

20 ME50S6
HBM A0260-1.1 en
6 General Notes
6.1 Disturbances
Certain regulations concerning electrical installation have to be observed in
plants with strongly disturbed supply mains systems. The most important
points are listed up in the HBM leaflet ” Hints for connection/disturbances”. An
extensive summary is given in the installation regulations VDI/VDE 3551. The
extent of certain measures to be taken depends on the specific applications.
