Heath Zenith Lighted Wireless Push Button Accessory User manual

Lighted Wireless
Push Button Accessory
The Heath®/Zenith Wireless Push Button Accessory works with existing
Heath®/Zenith jumper or dip switch systems.
• Battery powered push button - No wires to run.
• 128 selectable codes allow more than one chime system in the same
house.
• LED lighted push bar (see Lighted Push Bar Feature).
© 2007 HeathCo LLC 598-1137-02
(Style may vary from illustration)
Lighted Push Bar Feature
This Heath®/Zenith wireless push button contains a LED (Light Emitting
Diode) that will illuminate in dark conditions so the push button will be
more visible for your guests.This (patent pending) technology and built-in
photocontrol will allow the light intensity of the push button LED to in-
crease as the outdoor light conditions around the push button decreases.
The actual time and intensity that the LED is visible will depend on the
specific mounting environment of the push button. In nominal conditions
the batteries will typically last 2 years.

-2- 598-1137-02
1. Install two lithium type CR2032 3 volt bat-
teries (included). Remove back of case by
pushing in tab on bottom with a small screw-
driver. Make sure battery is oriented properly
(see page 5).
2. Set the push button jumpers to match the
chime receiver code. See “Code and Tune Setting” section.
3. Test range. Temporarily position push button where you want it
mounted. Press push button to verify chime and push button work
properly. If chime does not sound, see Troubleshooting.
4. Mount push button. Use either screws or double sided tape to mount
push button.
• To mount with screws, remove back of case by pushing in tab on
bottom with a small screwdriver. Attach back of case to door jamb
or wall. Snap front of push button on.
• When attaching push button using double sided tape, make sure
the surface of the door jamb or wall is clean.

-3-
598-1137-02
Code and Tune Settings
Code Settings
Note: Most installations will not require you to change any
jumpers on your chime and push button.
WARNING: Disconnect chime unit from power source before
opening code access door. Close door and replace screw
before reconnecting to power.
The push button and chime communicate by using a code that can be
changed by removing and/or adding jumpers on both the push button and
chime. The code is factory set; however, there are 128 selectable codes
that allow you to expand your system and prevent outside interference.
Other wireless products may cause interference and the system may not
function properly. Follow the instructions below for setting a new code.
1. Unplug wireless chime (if applicable).
2. Open the cases and locate the jumpers on both the push button and
chime (See illustration on page 5).
3. The push button and chime both have eight different jumper locations.
The jumper positions 1 through 7 are used for setting the code.
4. To change the code, add and/or remove jumpers as needed. It is
recommended to only change one jumper at a time and then check
to see if system is functioning properly. Note: Jumpers in positions
1 through 7 must be exactly the same for both the push button and
chime for this system to function.

-4- 598-1137-02
Tune Settings
Your Heath®/Zenith wireless chime has different selectable tunes: Ding
(one note), Ding-Dong (two note), or Westminster (eight note) (Available
on selected Heath®/Zenith chimes). The factory setting is for the Ding-
Dong tune (or Westminster, when available). This tune can be changed
by following the instructions below.
• Ding (one note tune)
Push button: Add a jumper to location 8.
• Ding-Dong (two note tune)
Push button: Remove jumper from location 8.
Chime: Remove jumper from location 8.
• Westminster (Eight note tune) (Available on selected Heath®/Zenith
chimes)
Push button: Remove jumper from location 8.
Chime: Add a jumper to location 8.
Note: All models have both front and back door tune capabilities.You may
purchase any Heath®/Zenith wireless push button for a second entrance.
We recommend the back door use the Ding tune and the front door
use the Ding-Dong tune (or Westminster tune, available on selected
Heath®/Zenith chimes). Models that include two push buttons will come
factory set for front and back doors. Decals on the rear of the push button
will indicate its setting.

-5-
598-1137-02
C
R
2
0
3
2
+
1
2
3
4
5
6
7
8
12345678
Inside Push
Button
Replacing Push Button Batteries
Install two lithium type CR2032 3 volt batteries.
Insert Batteries (+) Positive Side Up.
* Code Settings 1-7
Must Match Both
Push Button and
Chime
Remove screw to
open access door
Tune Setting (Not used on
all models)
Back of
Chime
Tune Setting
Note: Some models might require the use of
tweezers to remove and replace the jumpers.

-6- 598-1137-02
Troubleshooting
Chime does not sound:
• Make sure push button and chime codes are the same (See pages 3,
4, and 5).
• Check orientation of push button battery (See page 5).
• Check charge of push button and chime batteries (if applicable), replace
if necessary.
Batteries seem OK, but the chime does not work when installed:
• Do not mount chime or push button on metal or near metal studs.This
reduces the transmitter range. Use 1/4" to 1/2" (6 to 13 mm) wood
shims to move chime or push button off metal surface.
• Concrete floors may reduce range. Move chime away from floor.
• Try locating chime closer to push button.
Push button light (LED) is “ON” or “OFF” all the time (see page 1).
The range of the wireless chime can vary with location, temperature and
battery condition.

-7-
598-1137-02
Regulatory Information
This device complies with Part 15 of the FCC Rules and RSS-210 of
Industry Canada. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
The user is cautioned that changes or modifications not expressly ap-
proved by the party responsible for regulatory compliance could void the
user’s authority to operate the equipment.
Technical Service
Please call 1-800-858-8501 (English speaking only)
for assistance before returning product to store.
If you experience a problem, follow this guide.You may also want to visit
our Web site at: www.hzsupport.com. If the problem persists, call* for
assistance at 1-800-858-8501, 7:30 AM to 4:30 PM CST (M-F).You may
also write* to:
HeathCo LLC
P.O. Box 90004, Bowling Green, KY 42102-9004
ATTN: Technical Service
* If contacting Technical Service, please have the following information
available: Model Number, Date of Purchase, and Place of Purchase.
No Service Parts Available for this Product

-8- 598-1137-02
FIVE YEAR LIMITED WARRANTY
This is a “Limited Warranty” which gives you specific legal rights. You may also
have other rights which vary from state to state or province to province.
For a period of five years from the date of purchase, any malfunction caused by
factory defective parts or workmanship will be corrected at no charge to you.
Not Covered - Repair service, adjustment and calibration due to misuse,
abuse or negligence, light bulbs, batteries, and other expendable items are not
covered by this warranty.Unauthorized service or modification of the product or
of any furnished component will void this warranty in its entirety.This warranty
does not include reimbursement for inconvenience, installation, setup time,
loss of use, unauthorized service, or return shipping charges.
This warranty covers only HeathCo LLC assembled products and is not
extended to other equipment and components that a customer uses in con-
junction with our products.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY, REPRESENTATION
OR CONDITION OF MERCHANT ABILITY OR THAT THE PRODUCTS ARE FIT
FOR ANY PARTICULAR PURPOSE OR USE, AND SPECIFICALLY IN LIEU OF
ALL SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
REPAIR OR REPLACEMENT SHALL BETHE SOLE REMEDY OF THE CUS-
TOMER ANDTHERE SHALL BE NO LIABILITY ONTHE PART OF HEATHCO
LLC FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, INCLUDING BUT NOT LIMITED TO ANY LOSS OF BUSINESS
OR PROFITS, WHETHER OR NOT FORESEEABLE. Some states or prov-
inces do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you. Please
keep your dated sales receipt, it is required for all warranty requests.
HeathCo LLC reserves the right to discontinue and to change speci-
fications at any time without notice without incurring any obligation to
incorporate new features in previously sold products.

-9-
598-1137-02
Accesorio de pulsador
inalámbrico
El accesorio de pulsador inalámbrico Heath®/Zenith funciona con el
puente Heath®/Zenith o con los sistemas de interruptores.
• Pulsador alimentado con pila – No se necesitan alambres.
• Los 128 códigos elegibles permiten más de un sistema de campanas
en la misma casa.
• Barra de empuje iluminada con LED (Vea Característica barra de
empuje iluminada).
(El estilo puede variar de la ilustración)
Característica barra de empuje iluminada
Este pulsador inalámbrico Heath®/Zenith tiene un LED (Diodo Emisor de
Luz) que se iluminará en condiciones de oscuridad para que el pulsador
sea más visible por sus invitados. Esta tecnología (patente en trámite)
y el fotocontrol incorporado permitirán a la intensidad de luz del LED
del pulsador aumentar a medida que las condiciones exteriores de luz
alrededor del pulsador disminuyan. El tiempo y la intensidad real que el
LED es visible dependerán del entorno específico en el que se instaló
el pulsador. En condiciones nominales las baterías durarán típicamente
dos años.
© 2007 HeathCo LLC 598-1137-02 S

-10- 598-1137-02
1. Instale las dos baterías(pilas) de litio tipo
CR2032 de 3 voltios del pulsador (inclui-
das). Extraer la parte posterior de la caja
presionando la aleta en el botón con un destor-
nillador pequeño. Asegurarse que la pila esté
orientada correctamente (ver la página 13).
2. Fije los puentes del pulsador de acuerdo al código del receptor
de campana. Vea la sección de “Programaciones del código y del
tono”.
3. Pruebe el alcance. Ponga provisionalmente el pulsador en la posición
donde lo quiera instalar. Presione el pulsador para verificar que la
campanay el pulsador funcionen apropiadamente. Si la campana no
suena, vea Análisis de Averías.
4. Instale el pulsador. Use ya sean tornillos o cinta adhesiva por ambas
caras para instalar el pulsador.
• Para montar con tornillos, quite la parte de atrás de la caja em-
pujando hacia adentro la lengüeta de abajo con un destornillador
pequeño y girando la cuchilla. Coloque la parte de atrás de la caja
contra la jamba o la pared. Encaje a presión la parte frontal del
pulsador.
• Cuando fije el pulsador usando cinta adhesiva por ambas caras,
asegúrese que la superficie de la pared o la del batiente de la puerta
estén limpias.
