Heatilator SRV2384-070 User manual

1
Heatilator • SRV2384-070, SRV2385-070 Log Instructions • 2384-935 Rev. C • 1/20
Figure 3. Log #4 in Position
11
11
Log Set Assembly: SRV2384-070, SRV2385-070
Models: NNXT3933IF-B, NNXT3933ILF-B, NNXT4236IF-B, NNXT4236ILF-B
NNXT33-IFT, NNXT33L-IFT, NNXT36-IFT, NNXT36L-IFT
LOG PLACEMENT INSTRUCTIONS
See Table 1 for corresponding log set and individual logs
for each size Novus model.
Figure 1. Log Set Shown as Shipped
Figure 2. Locations of Flat Spots for Log #4
22
22
11
2233
CAUTION: Logs are fragile, handle with care.
FLAT SPOTS FOR LOG #4FLAT SPOTS FOR LOG #4
LOG #4: Place Log #4 into position by setting the left end of Log #4 into the at spot on Log #2 and then resting the right
end, or nose, of Log #4 on the at spot on Log #1. Figure 2 shows locations of at spots. Figure 3 shows Log #4 installed.
44
SIZE 3933 / 33 4236 / 36
ASSEMBLY SRV2384-070 SRV2385-070
LOG 1 SRV2384-071 SRV2384-071
LOG 2 SRV2380-072 SRV2381-072
LOG 3 SRV2384-073 SRV2385-073
LOG 4 SRV2380-074 SRV2380-074
LOG 5 SRV2384-075 SRV2385-075
LOG 6 SRV2384-076 SRV2385-076
Table 1.
The log set is shipped from the factory with three logs
already in place on the hearth pan. See Figure 1.

2Heatilator • SRV2384-070, SRV2385-070 Log Instructions • 2384-935 Rev. C • 1/20
Log #5: Place Log #5 into position. The forked end of
Log #5 is positioned on the log pins as shown in Figure 5.
The back end of Log #5 will rest on Log #4, but does not
touch Log #1.
LOG PINSLOG PINS
Figure 4. Log Pin Locations
Figure 5. Log #5 in Position
Figure 7. Log Set Installed
44
55
11
11
2233
33
66
FLAT SPOTS FOR LOG #6FLAT SPOTS FOR LOG #6
Figure 6. Locations of Flat Spots for Log #6
Log #6: Place Log #6 into position by setting the large
end on the at spot in Log #3 and then resting the small
end on the at spot on Log #1.
DOES NOT TOUCH LOG #1DOES NOT TOUCH LOG #1
1155
LOG PINSLOG PINS
