Heidolph Hei-MIX Titramax 100 User manual

Leading Safety Standards Superior Ease of Use Reduced Cost of Ownership
Temperature
Controlled Shaking
Platform Shaker Hei-MIX Titramax 100/101/1000,
Vibramax 100/110 and Rotamax 120.
Operating manual must be read before initial start-up.
Please follow the safety instructions provided.
Please keep for future reference.
Plattformschüttler Hei-MIX Titramax 100/101/1000,
Vibramax 100/110 und Rotamax 120
Betriebsanleitung vor Erstinbetriebnahme unbedingt lesen.
Sicherheitshinweise beachten.
Für künftige Verwendung aufbewahren.
Operating Manual Page 2
Original-Betriebsanleitung Seite 30

Contents
Inhaltsverzeichnis
About this Document 4
Version and variants ...........................................................................................4
About this manual ..............................................................................................4
Symbols and keywords........................................................................................5
Safety Instructions 6
General safety instructions...................................................................................6
EU Declaration of Conformity.........................................................................6
Intended use...............................................................................................6
Installation / electrical safety .......................................................................7
Qualications of employees...........................................................................7
Obligations of the operator ..................................................................................7
Installation site ...........................................................................................7
Modications to the device............................................................................8
Employee safety..........................................................................................8
California Residents .....................................................................................8
Safety during use ...............................................................................................9
Disposal ............................................................................................................9
Device Description 10
Device overview ...............................................................................................10
Vibramax 100 overall view ..........................................................................10
Vibramax 110 overall view ..........................................................................10
Titramax 100/101/1000 overall view ............................................................11
Rotamax 120 overall view...........................................................................11
Control panel ............................................................................................11
Start-Up 12
Setting up device .............................................................................................12
Connect/disconnect power cord ..........................................................................12
Switch unit on and o .......................................................................................13
Operation 14
Mounting vessels..............................................................................................14
Secure vessels on shaker plate....................................................................14
Shaking mode..................................................................................................16
Continuous mode.......................................................................................17
Timer mode ..............................................................................................17

Contents
Cleaning and Maintenance 18
Cleaning..........................................................................................................18
Maintenance ....................................................................................................18
Troubleshooting 19
Possible errors and how to resolve ......................................................................19
Assembly 20
Electrical connections........................................................................................20
Disassembly and Storage 21
Dismantling, transportation and storage ..............................................................21
Dismantling ..............................................................................................21
Transportation and storage .........................................................................21
Accessories and Spare Parts 22
Scope of delivery..............................................................................................22
Accessories......................................................................................................22
Attachments 23
Technical data ..................................................................................................23
Performance range / admissible load ............................................................24
China RoHS Declaration of Conformity.................................................................25
Service 27
Contact / Technical Service ................................................................................27
Warranty.........................................................................................................28
Conrmation of condition...................................................................................29

About this Document
4
About this Document
Copyright
This operating manual is protected by copyright and is exclusively intended for the
internal use of the purchaser.
Handing over this operating manual to third parties, reproducing it in any type or form
– in part or in full – and utilizing and/or communicating its contents is prohibited without
prior written approval from the manufacturer.
Any violations will result in an obligation to provide compensation for damages. Other
claims remain unaected.
Version and variants
Version
This manual describes the function, operation and maintenance of the Hei-MIX Titramax
100/101/1000, Vibramax 100/101 and Rotamax 120 platform shakers.
Version Alteration date
1.2 04/2020
Variants
The device is available in dierent variants. Certain features or functions are only
available in specic product variants. These variants are described in this operating
manual.
About this manual
This operating manual is an integral part of the device described here.
➜Carefully read through this operating manual and observe all of the
safety instructions and warnings notices.
➜Ensure that every user has carefully read the operating manual
before using the device for the rst time.
➜Store this operating manual so that it is accessible to all users at
all times.
➜Pass the operating manual on to any subsequent owner.
The current version of this operating manual can also be found at:
https://heidolph-instruments.com/en/service/downloads/operation-
manuals#Shakers & Mixers (Hei-MIX Titra- Vibra- Rota- 100)
In addition, also observe the local regulations at the installation site.

5
About this Document
Symbols and keywords
Standardized symbols and signal words are used in this operating manual to warn against
any dangers and provide important instructions. These instructions must be strictly
observed to avoid accidents and damage.
The following terms and basic symbols are used:
Symbol Additional signal words / explanation
Warning
signs The yellow triangle indicates hazardous situations. It is used in
combination with the following signal words:
DANGER:
Indicates a hazardous situation which, if not avoided, will result in
serious injury or death.
WARNING:
Indicates a hazardous situation which, if not avoided, may result in
serious injury or death.
CAUTION:
Indicates a hazardous situation which, if not avoided, may result in
property damage and minor or moderate injury.
Prohibitory
signs Prohibited:
The red circle indicates a situation that should be avoided under all
circumstances and which, if not avoided, may result in serious injury
or death.
Mandatory
signs Must be observed:
The blue circle indicates important information. Please observe this
information to avoid any property damage.
Other symbols used:
Symbol Description
➜Handling instruction, action required
✓Result of action
▪
▪
▪
List of information
a.
b.
c.
List of variants

Safety Instructions
6
Safety Instructions
General safety instructions
EU Declaration of Conformity
This device complies with the following EC-Directives*:
▪2006/42/EC Machinery Directive
▪2014/30/EU Electromagnetic Compatibility Directive
*Also see the attachment “EU Declaration of Conformity”.
The device has been manufactured according to state-of-the-art technology and in
compliance with recognized safety regulations. However, risks may still arise during
installation, operation and maintenance.
➜Please ensure that the operating manual is available at all times.
The device may only be used under the following conditions:
➜Only operate the device if it is in a technically perfect condition.
➜Only operate the device if you are properly aware of the risks and required safety
measures.
➜Only operate the device in accordance with the instructions given in this operating
manual.
➜If any information is ambiguous or missing, ask your superior or contact the
manufacturer.
➜Do not operate anything on the device without authorization.
➜Only use the device in accordance with its intended use.
Intended use
The device may only be operated by authorized personnel.
The device is suitable for the
following uses:
▪Shaking
▪Mixing
▪Emulsifying
▪Suspending
▪Separating
▪Dissolving
▪Staining
The device may be operated
in research laboratories,
other laboratories and
production facilities in the
following sectors:
▪Chemistry
▪Pharmacy
▪Biology
▪Environmental analytics
▪Basic research
▪Similar research laboratories
Unintended use/Reasonable foreseeable misuse
Any use which deviates from the device‘s intended use is considered to be improper. The
manufacturer is not liable for damage that occurs as a result. The risk is borne by the
operator alone.
When used in medical and food sectors the operator alone is responsible for compliance
with the applicable regulations and standards.

7
Safety Instructions
Installation / electrical safety
▪The device may only be connected up if the available power supply voltage corre-
sponds to the information stated on the rating plate for the device.
▪The power supply connection must be easily accessibly at all times.
▪An RCD circuit breaker (residual current circuit breaker) must be tted to the
electrical system in the building so that the device is disconnected from the power
circuit in the event of a fault.
▪Repairs may only be performed by electricians authorised by Heidolph Instruments.
▪Never operate the device with a damaged power cord.
▪Always turn the device OFF and disconnect the power cord before carrying out any
maintenance or repair work.
Qualications of employees
▪The device may only be operated by trained personnel.
▪The device may only be operated by persons who have been instructed and super-
vised in its proper use by trained specialist personnel.
▪The device may only be operated by specialist personnel who are above the legal
minimum age.
▪Other persons may only work on the device under the constant supervision of experi-
enced and trained specialist personnel.
▪This operating manual must be read and understood by all persons working with the
device.
▪Personnel must receive safety training that ensures responsible and safe working
practices.
Obligations of the operator
Installation site
▪The device must be installed in a suitable location.
▪The device must be installed on a rm and stable surface.
▪Ensure that the device and all of its components are easily accessible at all times.
▪Maintain a sucient safety clearance to, in particular, any moving and/or hot
equipment components.
▪It is not permitted to place or store any objects such as accessories, tools or
chemicals within this clearance area during operation.
▪All screw connections must be securely tightened.
▪It is not permitted to operate the device near to highly ammable or explosive
substances.
▪Operate the device in conjunction with an extractor hood, if working with potential
harmful media (see DIN EN 14175 and DIN 12924).

Safety Instructions
8
▪The device is designed for indoor use in dry spaces only and under the following
ambient conditions:
Ambient temperature 5 - 31 °C at 80 % relative humidity
32 - 40 °C decreasing linearly to a
maximum 50 % relative humidity
Installation altitude 0 - 2,000 m above sea level
Contamination level 2
Overvoltage category II
Permissible supply deviations ± 10 %
▪If the device is operated in corrosive atmospheres, the service life of the device will
decrease based on the concentration, duration and frequency of the exposure to the
corrosive atmosphere e.g. concentrated hydrochloric acid (HCI).
Modications to the device
▪It is not permitted to make any unauthorised modications or changes to the device.
▪Do not attach or install any parts that have not been approved by the manufacturer.
▪Unauthorised modications or changes will void the EC Declaration of Conformity for
the device and operation of the device will no longer be permitted.
▪The manufacturer is not liable for any damage, dangers or injuries that result from
unauthorised modications and changes or due to the non-observance of the instruc-
tions in this manual.
Employee safety
➜Ensure that the device is only operated by qualied specialist personnel and trained
employees.
➜Observe the following instructions to avoid any personal injuries and property
damage:
- Laboratory regulations
- Accident prevention regulations
- Hazardous Substance Act
- Other generally accepted occupational health and safety regulations
- Local regulations
California Residents
➜Important information for California residents regarding Prop 65. Please visit
www.P65Warnings.ca.gov for more information.

9
Safety Instructions
Safety during use
➜Wear the appropriate protective clothing when working on the device (protective
glasses and, if necessary, safety gloves).
➜Do not use the device in potentially explosive areas. The device is not protected
against explosion. There is no explosion or ATEX protection available.
➜Do not carry out work with naked ames in the vicinity of the device (risk of
explosion).
➜Do not operate any devices in the vicinity which may exhibit electromagnetic elds in
the frequency range 9 x 103 Hz to 3 x 1011 Hz.
➜Do not operate or assemble devices in the vicinity which are emission or radiation
sources (electromagnetic radiation) for the frequency range 3*1011 Hz to 3*1015 Hz
(in the optical spectral range wavelengths from 1,000μ to 0.1μ).
➜Do not operate or assemble appliances in the vicinity of the device which constitute
emission or radiation sources for ionizing radiation or in the ultrasonic range.
➜Do not operate the device where adiabatic compression or shock waves might occur
(shock wave combustion).
➜Do not use substances, where the energy input due to mixing might pose a hazard.
➜Avoid putting pressure on the display when you are not operating the device.
➜Do not spill liquids over the device or any parts of it.
➜Remove any accidentally spilled liquids immediately.
➜Eliminate errors immediately.
➜Do not use abrasive material to clean the surface. Only wipe with damp cloth.
➜Always switch the device OFF after use.
Disposal
➜Check the device components for hazardous substances and
solvents.
➜Clean all components before disposal.
➜Dispose of the device in accordance with the relevant national
regulations.
➜Dispose of the packaging material in accordance with the
appropriate national regulations.

Device Description
10
Device Description
Device overview
Vibramax 100 overall view
Platform shaking:
circular vibration
orbit 3,0 mm
Control panel
Clamping rollers
(optional)
Attachment
(optional)
Vibramax 110 overall view
Platform shaking:
circular vibration
orbit 1,5 mm
Control panel
Test tube attachment
(optional)

Device Description
11
Titramax 100/101/1000 overall view
Platform shaking:
circular vibration
orbit 1,5 / 3 mm
Control panel
Microtiter plates
(optional)
Titramax 100: Orbit 1,5 mm
Titramax 1000: Orbit 1,5 mm
Titramax 101: Orbit 3,0 mm
Rotamax 120 overall view
Platform shaking:
rotating orbit 20 mm
Control panel
Example:
petridishes
Control panel
Rotating knob:
set speed „rpm”
ON/OFF
switch
Select mode switch:
timer/continuous
Rotating knob:
set time

Start-Up
12
Start-Up
Setting up device
Warning:
Risk of slipping device!
As a result of vibrations generated during operation the device might
slide o the table top.
The surface must be smooth and clean and should be properly leveled.
➜Locate the shaker on a stable, horizontal surface.
➜Clean surface and feet with a damp cloth and ethanol regularly.
Connect/disconnect power cord
Connect power cord
The power cord comes with a three-wire
plug and a recess on the bottom side.
Power cordUnit plug
The socket is located on the back side of
the unit.
✓The device is switched OFF.
➜Connect plug to the socket with the
recess facing down.
➜Push plug up against socket until
securely attached.
➜Connect plug to power socket.
Unit socket
Disconnect power cord
➜Disconnect plug from power socket rst.
➜Then disconnect plug from socket on unit.

Start-Up
13
Switch unit on and o
The ON/OFF switch is situated on the front
panel.
Switch unit on
➜Press the On/O switch on the upper
side.
✓The green control light switches on.
✓The unit is switched on.
Switch unit o
➜Press the On/O switch on the lower
side.
✓The green control light switches o.
✓The unit is switched o. ON/OFF switch:
device switched on
ON/OFF switch:
device switched o

Operation
14
Operation
Mounting vessels
Secure vessels on shaker plate
Use optional attachment to secure vessels on shaker plate:
➜To secure vessels on shaker plate, use optional adaptors (see chapter „Spare parts
and accessories” and chapter „Assembly”).
➜At low shaking speed, low-prole vessels like petri dishes may be placed directly on
the non-skid rubber plate.
A single ask should be arranged in the middle of the shaker plate.
Several asks should be distributed equally on the plate.
TITRAMAX 100 / TITRAMAX 101 / TITRAMAX 1000
➜Place microtiter plates directly in
indentations in the rubber mat.
✓Microtiter plates are positively locked
in these indentations.
✓The rubber mat can be removed easily
for cleaning or replacement.
VIBRAMAX 100 / ROTAMAX 120 / attachment with clamping rollers
Vessels of dierent sizes can be secured
by an optional attachment with clamping
rollers. Vessels clamped at the same time
by two clamping rollers must have the
same diameter.
➜Secure attachment on the shaker plate
with the wing bolts supplied.
➜Place vessels on the anti-skid rubber
mat.
➜Clamp vessels on both sides with the
clamping rollers.

Operation
15
VIBRAMAX 110 / attachment for test tubes
➜Place a single test tube on the rubber
mat by hand and softly push tube
downwards.
Caution:
Possible risk of exertion
There is a possible risk of
exertion due to physical force
required to holding test tube in
place.
Do not use the device any longer
than recommended in the direc-
tive 2002-44 EC on vibration
strain.
Several test tubes may be shaken at the
same time, using the optional test tube
attachments.
➜Secure attachment on the shaker table
with the wing bolts supplied.
➜Plug test tubes into “collets”.
✓The test tubes will be secured by the
collets.

Operation
16
Shaking mode
Warning:
Risk of injury!
Returning power after a power cut o will restart shaking mode. There
is a risk of injury in the vicinity of moving parts of device.
Before working with the device or in the vicinity ensure all controls are
switched to “0” or “OFF” mode, when device is not moving.
Caution:
Risk of breakage and spillage
If the vessels are not attached securely they may fall out and spill the
sample.
Prior to switching the unit on ensure that all vessels are securely
fastened.
Warning:
Risk of poisoning
Open vessels and too high vibration frequencies may result in samples
splashing.
▪Close all vessels tight especially if sample is dangerous or toxic.
▪Adjust vibration frequency step by step until you have reached the
required rpm settings..
▪Wear safety glasses and especially with dangerous and toxic samples
appropriate protective clothing.
Warning:
Risk of injury!
High speeds in combination with high loads and/or a tall assembly may
lead to an unstable device. As result the device may start moving and
slide o the table top.
When working with with high loads and/or a tall assembly, increase the
speed with care and watch for the devices stability. Ensure the device
is installed in such a way as it can not collide with the surrounding
environment or slip o its work surface.
At high loads (load bearing capacity of shaker plate) and high
frequency of shaking, always make reference to load graph as
applicable for your item (see chapter “Technical data”, section
”Performance range, permissable load”).
When using shakers inside conditioning cabinets, make reference
to ambient conditions (see chapter “Safety, Operating company’s
obligations”, section “Installation site”).

Operation
17
When using shakers inside conditioning cabinets, make reference
to ambient conditions (see chapter “Safety, Operating company’s
obligations”, section “Installation site”).
You can choose from two shaking options:
▪Continuous mode: The unit starts and stops shaking as soon as you switch it on or o.
▪Timer mode: The time for shaking can be set between 0 and 120 minutes. The unit
stops shaking when the time has elapsed.
Continuous mode
✓Select mode switch is positioned to
continuous mode „0”.
➜Turn item on with ON/OFF switch.
➜Set speed with rotating knob „Speed”.
✓Actual speed appears in the 3-digit
digital display.
➜Reduce speed with rotating knob.
➜Turn item o with ON/OFF switch.
Rotating knob
„Speed”
Rotating knob
„Timer”
Select mode switch
Timer mode
➜Select mode „Timer” with select mode
switch.
➜Set time with rotating knob „Timer”.
➜Set speed with rotating knob „Speed”.
➜Turn item on with ON/OFF switch.
✓When time has elapsed an acoustic
signal will be audible and shaking
action will stop.
➜Reduce speed with rotating knob.
➜Turn item o with ON/OFF switch.
Select mode switch:
“continuous”
Select mode switch:
“timer”

18
Cleaning and Maintenance
Cleaning and Maintenance
Cleaning
All surfaces of the unit allow for cleaning with a damp cloth and if required a mild soap
lotion.
Warning:
Risk of electric shock!
If the device is still connected to power during cleaning, you might get
in contact with live parts due to accidentally entering liquids.
Prior to cleaning:
▪ensure that the device is switched OFF
▪ensure that the plug is pulled from the electric socket.
Caution:
Damage to the device
Accidentally entering liquids will cause the device to fail .
Only wipe with a damp cloth. Never use a soaked cloth.
Attention:
Risk of damage to the surfaces
All of the surfaces may be damaged by improper cleaning.
Never use:
▪Chlorine bleach or any cleaning agent containing chlorine
▪Solvent-bearing agents (e.g. acetone)
▪Ammonia
▪Abrasive cleaning agents such as scouring agents, cleaning wool or
agents with metallic particles
As a result of vibrations generated during operation the device might
slide o the table top.
To ensure a stable position clean surface and feet with a damp cloth
and ethanol regularly.
Maintenance
The unit is maintenance-free. Any necessary repair must be performed by an authorized
Heidolph distributor.
Please contact Heidolph Instruments or your local Heidolph Instruments distributor.

Troubleshootimg
19
Troubleshooting
Possible errors and how to resolve
Malfunctions Possible reason Troubleshooting
On-/O switch does not
enlighten
No power ▪Check size and shape of
plug and compatibility to
your electrical socket
▪Check circuit breakers
Light diode defective Contact your local Heidolph
Instruments distributor
Unit stops shaking Pre-set timer elapsed Restart timer, if necessary
Thermal motor circuit
breaker triggered by motor
overload.
Wait 20 minutes, decrease
overall load
▪Mechanical parts broken
▪Electronic failure
Contact your local Heidolph
Instruments distributor
If you experience a malfunction which can not be resolved, please contact your authorized
Heidolph Instruments distributor immediately.

Assembly
20
Assembly
Electrical connections
▪Fuses must only be replaced by a professional electrician.
▪Repairs to the device must only be carried out by a qualied electrician
approved by Heidolph Instruments. Improper repairs could result in serious
dangers. Please contact your specialist dealer if the device needs to be repaired.
Warning:
Risk of electric shock
The device must be connected to an earthed power socket.
The rated voltage for the device and the supply voltage must be the
same. The rated voltage for the device can be found on the rating plate
on the rear of the device.
The device is supplied with a grounded power cord. In case the original
plug is replaced, the new plug must have a protective conductor!
If the device is still connected to power while changing the fuse, you
might get in contact with live parts.
Prior to replacing the fuse ensure that the unit is switched o and pull
the plug from the electric socket. Only use original spare fuses from
Heidolph Instruments.
After changing a fuse check the device for safe operating condition
according to IEC 61010-1.
Fuse
Rating plate
Colour code for electrical connections:
Europe North America
GREEN/YEL-
LOW
PE: Protective
conductor (Earth) GREEN PE: Protective conductor (Earth)
BLUE N: Neutral conductor WHITE N: Neutral conductor
BROWN P: Phase BLACK P: Phase
The device is connected to the mains with the power cord supplied. The power connection
is located on the rear of the housing.
For countries where a dierent plug than the standard plug supplied is used:
▪The plug supplied may only be changed by a professional electrician.
▪If you wish to use an adapter, ensure that it is grounded and approved in accordance
with the local regulations.
▪Wiring, adapter and plug must at least meet the electrical power stated on the rating
plate.
