Heidolph Hei-FLOW Value 01 User manual

Leading Safety Standards Superior Ease of Use Reduced Cost of Ownership
Peristaltic Pumps Hei-FLOW Value, Hei-FLOW Advantage,
Hei-FLOW Precision
Operating manual must be read before initial start-up.
Please follow the safety instructions provided.
Please keep for future reference.
Peristaltikpumpe Hei-FLOW Value, Hei-FLOW Advantage,
Hei-FLOW Precision
Betriebsanleitung vor Erstinbetriebnahme unbedingt lesen.
Sicherheitshinweise beachten.
Für künftige Verwendung aufbewahren.
Operating Manual Page 2
Original-Betriebsanleitung Seite 50
Precise
Dosing and Dispensing

Contents
Contents
Interfaces........................................................................................................21
Analog Interface .......................................................................................22
Digital Interface .......................................................................................23
Digital interface commands.........................................................................24
Cleaning and Maintenance 26
Cleaning..........................................................................................................26
Maintenance ....................................................................................................26
Troubleshooting 27
Possible errors and how to resolve ......................................................................27
Assembly 28
Electrical connections........................................................................................28
Mount pump heads ...........................................................................................29
Single-channel pump heads SP standard and SP vario ....................................29
Single-channel pump head SP quick .............................................................30
Multi-channel pump heads ..........................................................................31
Mount tubes: Single-channel pump heads............................................................33
Tubes: pump head SP standard ...................................................................33
Tubes: pump head SP vario.........................................................................34
Tubes: pump head SP quick ........................................................................35
Mount tubes: Multi-channel pump heads..............................................................36
Cassettes and tubes: „Cassette small”..........................................................37
Cassettes and tubes: „Cassette medium” ..........................................................39
Cassettes and tubes: „Cassette large”...............................................................40
Mount several pump .........................................................................................40
Disassembly and Storage 41
Dismantling, transportation and storage ..............................................................41
Dismantling ..............................................................................................41
Transportation and storage .........................................................................41
Accessories and Spare Parts 42
Scope of delivery..............................................................................................42
Accessories......................................................................................................42
Attachments 43
Technical data ..................................................................................................43
Table tubes ...............................................................................................44
Performance range pump heads...................................................................46
Service 47
Contact / Technical Service ................................................................................47
Warranty.........................................................................................................48
Conrmation of condition of unit.........................................................................49
Inhaltsverzeichnis
About this Document 4
Version and Variants ...........................................................................................4
About this manual ..............................................................................................4
Terms and signs used..........................................................................................5
Safety Instructions 6
General safety instructions...................................................................................6
EU Declaration of Conformity.........................................................................6
Intended use...............................................................................................6
Installation / Electrical safety .......................................................................7
Personnel qualication..................................................................................7
Operating company’s obligations...........................................................................7
Installation site ...........................................................................................7
Changes to the unit .....................................................................................8
Safety for the personnel ...............................................................................8
Safety during use ...............................................................................................8
Disposal ............................................................................................................8
Device Description 9
Device overview .................................................................................................9
Hei-FLOW Value: overall view ........................................................................9
Hei-FLOW Advantage: overall view.................................................................9
Hei-FLOW Precision: overall view .................................................................10
Hei-FLOW Precision: control panel................................................................10
Start-Up 11
Setting up device .............................................................................................11
Switch main switch on and off ............................................................................11
Switch unit on ..........................................................................................11
Switch unit off...........................................................................................11
Connect/disconnect power cord ..........................................................................12
Operation 13
Switch rotation on and off..................................................................................13
Change direction of rotation...............................................................................15
Additional functions Hei-FLOW Precision ..............................................................16
Set pump head..........................................................................................17
Set tube ...................................................................................................17
Set ow....................................................................................................18
Set volume ...............................................................................................18
Calibrate pump..........................................................................................19
Set intermittent dosing...............................................................................20
Set back stroke .........................................................................................21
Operating Manual

About this Document
4 5
About this Document
About this Document
Version and Variants
Version
This manual describes the function, operation and maintenance of the Hei-FLOW Value,
Hei-FLOW Advantage and Hei-FLOW Precision peristaltic pumps.
Version Alteration date
1.1 02.2017
Variants
The units are available in different congurations. Certain features and functions apply to
specic congurations only. The varieties are documented in this manual.
About this manual
This operating manual is a component of the device described here.
➜Please read this manual carefully and obey all safety and warning
notices.
➜Ensure that every operator reads this manual.
➜Ensure that this manual is accessible for every operator.
➜Pass on the operating manual to the subsequent owner.
For the current version of this operating manual in pdf format, please
go to:
http://www.heidolph.com/Support/Operation Manuals/Peristaltic
Pumps/All models and pump heads/ Hei-FLOW Value,
Hei-FLOW Advantage and Hei-FLOW Precision.
In addition, please observe the regional regulations.
Terms and signs used
In this manual you will nd standardized terms and signs to warn you of possible dangers
or give important hints. Please take special notice to these signs to avoid personal injury
or damage to the unit.
The following terms and type of signs (basic drawing elements) are used:
Symbol Additional term / Description
Warning signs The yellow triangle indicates hazardous situations. It is used in
combination with the following terms:
DANGER:
Indicates a hazardous situation which, if not avoided, will result in
irreversible injury or death.
WARNING:
Indicates a hazardous situation which, if not avoided, could result in
serious injury or material damage.
CAUTION:
Indicates a hazardous situation which, if not avoided, may result in a
minor injury or material damage.
Prohibitory
signs Do not do:
The red circle indicates a situation that should be avoided under all
circumstances to avoid injury or damage.
Mandatory
signs
Must do:
The blue circle indicates important information. Please obey to avoid
property damage.
Other signs used
Symbol Description
➜Handling instruction, action required
✓Result of action
▪
▪
▪
List of information
a.
b.
c.
List of variants

Safety Instructions
6 7
Safety Instructions
Safety Instructions
General safety instructions
EU Declaration of Conformity
This device complies with the following EC-Directives*:
▪2006/42/EC Machinery Directive
▪2014/30/EU Electromagnetic Compatibility Directive
*Also see attachment „EU Declaration of Conformity”.
The device has been constructed according to state-of-the-art technology and recog-
nized safety regulations. However, risks may still arise during installation, operation and
maintenance.
➜Please ensure the operating manual is available at all times.
The device may only be used under the following circumstances:
➜Only operate the device, if it is in full working order.
➜Ensure all operators of the device possess the necessary safety and risk awareness.
➜Operate the device according to the instructions stipulated in this manual only.
➜If there is something you do not understand, or certain information is missing, ask
your manager or contact the manufacturer.
➜Do not do anything on the device without authorization.
➜Only use the device according to its intended use.
Intended use
The device is intended for use by trained and authorized personnel only.
The device is suitable for
the following use:
Hei-FLOW Value
Hei-FLOW Advantage
Dispensing of uids
Hei-FLOW Precision Dispensing and dosing of uids
Operation of the device is suitable in one of the
following locations:
In any research facility
Improper use
Any use which deviates from the device‘s intended use is considered to be improper. The
manufacturer does not accept liability for any damages resulting from non-permitted
uses. The risk is carried by the operator alone.
Installation / Electrical safety
▪The device may only be connected when the mains voltage corresponds to the infor-
mation on the rating plate of the unit.
▪The mains connection must be accessible at all times.
▪Repairs on live parts may only be performed by a qualied electrician.
▪Never operate the unit with a damaged power cord.
▪Always turn the unit OFF and disconnect mains power before performing any
maintenance or service.
Personnel qualication
▪The device may only be operated by qualied persons.
▪The device may only be operated by individuals who have been instructed in its
proper use by qualied persons.
▪The device may only be operated and maintained by persons who are of legal age.
▪Other personnel may only work with the unit under continuous supervision of an
experienced qualied operator.
▪This manual must be read and understood by all persons working with the device.
▪The personnel must receive special safety instructions in order to guarantee respon-
sible and safe work procedures.
Operating company’s obligations
Installation site
▪The device must be positioned in a suitable location.
▪The device must be installed sufciently stable on a temperature resistant surface.
▪All screw connections must be securely tightened.
▪Do not install the device in the vicinity of highly inammable or explosive substances.
▪Installation and operation of the device is only permitted in facilities which are tted
with the appropriate laboratory equipment (e.g. with air extraction units).
▪We recommend operation in fume hood enclosures depending on the agents used.
▪The device may only be operated in enclosed spaces and under the following environ-
mental conditions:
Ambient temperature 5 - 31 °C at 80 % relative humidity
32 - 40 °C decrease linearly
till max. 50 % relative humidity
Installation altitude 0 - 2,000 m (6,500 feet) height above sea level
Degree of pollution 2
Overvoltage category II

Device Description
9
Safety Instructions
8
Changes to the unit
▪No unauthorized changes may be made to the unit.
▪No parts may be used which have not been approved by the manufacturer.
▪Unauthorized changes result in the EC Declaration of Conformity loosing its validity,
and the unit may no longer be operated.
▪The manufacturer is not liable for any damage, danger or injuries that result from
unauthorized changes or from operating the unit other than as described in this
manual.
Safety for the personnel
➜Ensure that only qualied personnel operates the device.
➜Observe the following regulations:
- Laboratory guidelines
- Accident prevention regulation
- Ordinance on Hazardous Substances
- Other generally accepted rules of safety engineering and occupational health
- Local regulations
Safety during use
➜Wear the appropriate protective clothing when working on the device (clothing,
protective glasses and, if necessary, safety gloves).
➜Do not use the device in potentially explosive areas. The device is not protected
against explosion. There is no explosion or ATEX protection available.
➜Do not operate or assemble devices in the vicinity which are emission or radiation
sources (electromagnetic waves) for the frequency range (3*1011 Hz to 3*1015 Hz).
➜Do not operate the device where adiabatic compression or shock waves might occur
(shock wave combustion).
➜Avoid putting pressure on the display when you are not operating the device.
➜Eliminate errors immediately.
➜Do not use abrasive material to clean the glass surface. Only wipe with damp cloths.
➜Always switch the device off after use.
Disposal
➜Check the device components for hazardous substances and solvents.
➜Clean all components before disposal.
➜Dispose of the device according to the appropriate national legal regulations.
➜Dispose of the packaging material in accordance with the appropriate national legal
regulations.
Device Description
Device overview
Hei-FLOW Value: overall view
Analog knob
rotation
Example:
Pump head SP standard
Rotation switch:
switch rotation on/off
Direction switch:
change rotation direction
ON/OFF switch
(device back side)
Hei-FLOW Advantage: overall view
Analog knob
rotation
Example:
Pump head SP vario
ON/OFF switch
(device back side)
Direction key:
change rotation direction
Max key:
for lling and draining
Rotation key:
switch rotation on/off

Start-Up Start-Up
10 11
Start-Up
Setting up device
Warning:
Risk of slipping device!
In operation the device might slide off the table top.
The surface must be smooth and clean and should be properly
leveled.
➜Locate the unit on a stable, horizontal surface.
➜Clean surface and feet with a damp cloth and ethanol regularly.
Switch main switch on and off
The ON/OFF switch is situated on the back
side of the unit.
✓ON/OFF switch is in „power off”
position.
Switch unit on
➜Press ON/OFF switch.
✓ON/OFF switch is in „power on” position.
Hei-FLOW Advantage
✓The indicator light of actual direction illuminates.
Hei-FLOW Precision
✓The settings are displayed in following order:
▪set pump head (e. g. „Pu 1”)
▪gear ratio (e. g. „5”)
▪set inner tubing diameter (e. g. „3,1”)
▪possible back hub (z. B. „r on”)
✓The indicator light of actual direction illuminates.
✓Unit is switched on.
Switch unit off
➜Press ON/OFF switch.
✓ON/OFF switch is in „power off” position.
Hei-FLOW Advantage, Hei-FLOW Precision
✓All indicator lights power off.
✓Unit is switched off.
Hei-FLOW Precision: overall view
Control panel
Example:
Pump head SP quick
ON/OFF switch
(device back side)
Hei-FLOW Precision: control panel
Rotation key
Direction key:
change rotation
direction
Control indicator
parameter
Control indicator
rotation
Calibrating
key
Control indicator
direction
Select key parameter
Max key: for
lling and draining Arrow key: increase, decrease value
Set parameter

Operation
13
Start-Up
12
Connect/disconnect power cord
The three-wire socket is rmly connected
to the unit.
The connection is at the rear side of the
unit.
✓The ON/OFF switch is in the “Off
“position.
➜Connect the power cord with a
grounded socket.
➜Disconnect the plug if the unit is not
in use.
Operation
Switch rotation on and off
Switch rotation on and off: Hei-FLOW Value
Set speed
Speed is set via rotation knob.
✓Unit is switched on.
✓Required direction of rotation is
activated.
➜Turn knob to set speed.
Start rotation
➜Press rotation switch on the right side.
✓Control light of rotation switch
illuminates.
✓Pumping starts.
Stop rotation
➜Press rotation switch on the left side.
✓Control light of rotation switch powers
off.
✓Pumping stops
Rotation on Rotation off
Rotation switch
Switch rotation on and off: Hei-FLOW Advantage, Hei-FLOW Precision
Caution:
Possible damage of device
If device sockets are not covered, uids can get in contact with
Interface connectors. Penetrating uids can lead to malfunctions of
interface connection and could initiate a short circuit.
Sockets at the backside of device must be covered at all times.
Close sockets with attached sealing cap or connect interface cable.

Operation Operation
14 15
Set speed: Hei-FLOW Advantage
Speed is set via rotation knob.
✓Unit is switched on.
✓Required direction of rotation is
activated.
➜Turn knob to set speed.
Set speed: Hei-FLOW Precision
▪Hei-FLOW Precision 01: 5 - 120 rpm
▪Hei-FLOW Precision 06: 24 - 600 rpm
Speed is set via selection key „Speed
rpm”.
✓Unit is switched on.
✓Required direction of rotation is
activated.
➜Press selection key repeatedly, till
control light „Speed rpm” illuminates.
➜Increase speed via arrow key up .
➜Decrease speed via arrow key down
.
✓Set speed will be displayed as rpm.
Selection key
Control light speed
Arrow keys
Switch rotation on
➜Press rotation key.
✓Control light of rotation key will
illuminate.
✓Pumping starts.
Switch rotation off
➜Press rotation key.
✓Control light of rotation key will power
off.
✓Pumping stops.
Pumping active
Rotation key
Pumping inactive
Feed rate depends on media, inner diameter and material of tubing
and speed.
To determine speed see chapter „Technical data, Performance
range”.
Charge and discharge tubes
With the key „max” charging and discharging of the tubes can be sped up without
changing any settings.
✓Unit is switched on.
✓Rotation is switched off.
✓Required direction of rotation is
activated.
➜Press key „max” and hold pressed.
✓Pump is running with maximum speed.
Hei-FLOW Precision:
✓The display shows „Full”.
✓Release key „max”.
✓Pumping stops.
A power cut will stop the pump. All settings will be saved.
With power return the device is switched on automatically. Rotation
must be started manually.
Change direction of rotation
Direction of rotation can only be changed if rotation is switched off.
A warning signal will be audible when trying to change direction
during operation.
Change direction: Hei-FLOW Value
✓Rotation is switched off.
➜Press direction switch on the right side.
✓Pump will operate clockwise.
➜Press direction switch on the left side.
✓Pump will operate counter-clockwise.
counter-clockwise
Direction switch
Direction
clockwise

Operation Operation
16 17
Change direction: Hei-FLOW Advantage, Hei-FLOW Precision
✓Left control light of direction key is
illuminated.
✓Rotation is switched off.
➜Press direction key.
✓Right control light of direction key
illuminates.
✓Pump will operate clockwise.
➜Press direction key.
✓Left control light of direction key
illuminates.
✓Pump will operate counter-clockwise.
Clockwise
Counter-clockwise
Additional functions Hei-FLOW Precision
On top of the standard functions you can set parameters that allow consistent process
quality.
Following parameters can be set:
▪„Speed rpm”
sets speed of pumping;
ow per minute “Flow ml/min” will be adjusted automatically
▪„Tube mm” (inner diameter)
allows minimum and maximum ow per minute
must be set correctly for any other parameter to be adjusted correctly
▪„Flow ml/min”
sets the ow per minute;
speed “Speed rpm” will be adjusted automatically
▪„Vol ml”
sets the volume to be pumped in total;
pump will be stopped automatically when volume is reached
▪„Pause sec/min/h”
intermittent dosing allows a permanent repetition of dispensing a dened volume
Correct operation of all functions requires the correct setting of pump
head and inner tube diameter in use.
When purchasing a package with pump head, the pump head is set
correctly by the factory.
Set pump head
Factory pre-setting is SP quick (Pu 1).
Display Pump head Hei-FLOW
Precision 01 Hei-FLOW Precision 06
Pu 0 Multi-channel C 8 ✓-
Pu 1 Single-channel SP quick ✓ ✓
Pu 2 Single-channel SP standard / SP vario ✓ ✓
Pu 3 not assigned - ✓-
Pu 4 not assigned - ✓-
Pu 8 Multi-channel C 12 ✓-
Pu 9 Multi-channel C 4 ✓-
➜Switch unit off at main switch.
➜Press „Cal” key and hold pressed.
➜Switch unit on at main switch.
✓Display shows actual setting of pump
head.
➜Release „Cal” key.
➜Select required pump head via arrow
keys or .
➜Conrm selection by pressing „Select”
key.
Set tube
Possible inner diameters of tubes:
(also see chapter „Technical data, Selection table tubes”)
0.8 1.7 3.1 4.8 6.4 7.9
✓Unit is switched on.
➜Press „Select” key repeatedly, till
indicator light „Tube mm” illuminates.
➜Select required inner diameter of tube
in use via arrow keys or .
➜Conrm selection by pressing „Select”
key.
A blinking indicator light „Vol ml” during setting of tube diameter
shows that the device adjusts volume to required minimum of new
diameter.

Operation Operation
18 19
Set ow
By setting the ow you dene how many ml per minute should be dispensed.
Depending on the tube size different ranges of ow.
(Please refer to chapter “Technical data, Table tubes”
When using „Cassette small” with small tubes and inner Ø
from 0,2 mm - 0,9 mm volume will be displayed as μl instead of ml.
✓Unit is switched on.
✓Pump head and inner diameter of tube is set correctly.
➜Press „Select” key repeatedly, till
indicator light „Flow ml/min” illuminates.
✓Display shows actual setting of ow ml
per minute.
➜Select required ow ml per minute via
arrow keys or .
➜Conrm selection by pressing „Select”
key.
✓The corresponding speed will be
adjusted automatically.
Set volume
By setting the volume you dene how many milliliters in total should be dispensed.
Depending on the tube size used the volume can be set from 0,1 to 9,999 ml.
When using „Cassette small” and tubes with an inner Ø between
0,2 mm and 0,9 mm the volume will be displayed as μl instead off ml.
Model Hei-FLOW Precision 06 is limited to a maximum speed of
300 rpm.
✓Unit is switched on.
✓Pump head and inner diameter of tube is set correctly.
➜Press „Select” key repeatedly till
indicator light „Vol ml” illuminates.
➜Select required volume ml via arrow
keys or .
➜Conrm selection by pressing „Select”
key.
✓Pump will automatically stop when
volume is reached.
Speed and tube diameter result in a minimal volume. Lower volume
can only be performed by using smaller tubes.
Large tubes and to little ow will result in an error feedback (see
chapter “Troubleshooting, Possible errors and how to resolve”).
Calibrate pump
Tubes have individual manufacturing tolerances. If high dosing accuracy is required the
pump has to be calibrated for the tube in use by ow and/or by volume.
✓Unit is switched on.
✓Media to be dispensed is connected to pump.
✓Pump head and inner diameter of tube are set correctly.
Calibrate pump with ow
✓Indicator light „Flow ml/min” is illuminated.
✓Required ow ml per minute is set.
➜Press „Cal” key.
✓Display starts blinking.
➜Press rotation key.
✓The pump dispenses for exactly 1 minute.
➜Measure dispensed volume.
➜Set measured ow via arrow keys or .
➜Press „Cal” key for a minimum of 3 seconds to conrm.
✓Pump is calibrated for ow ml per minute.
Verify set ow after calibrating. If applicable adjust ow.

Operation Operation
20 21
Set back stroke
To avoid dripping when dosing a short backstroke can be programmed.
➜Switch unit off at main switch.
➜Press „Cal” key and hold pressed.
➜Switch unit on at main switch.
✓Display shows actual setting of pump
head.
➜Release „Cal” key.
➜Press „Select” key repeatedly till Display
shows „r on” or „r off” .
✓„r on” switches back stroke on,
„r off„ switches back stroke off.
➜Conrm selection by pressing „Select”
key.
Interfaces
Caution:
Possible damage of device
If device sockets are not covered, uids can get in contact with
Interface connectors. Penetrating uids can lead to malfunctions of
interface connection and could initiate a short circuit.
Sockets at the backside of device must be covered at all times.
Use plug connectors protection class IP 67 only. Ensure professional
connection.
Calibrate pump with volume
✓Indicator light „Vol ml” is illuminated.
✓Required volume is set.
✓Speed is set via setting ow ml/min.
➜Press rotation key.
➜Measure dispensed volume.
➜Press „Cal” key.
➜Set measured volume via arrow keys or .
➜Press „Cal” key for a minimum of 3 seconds to conrm.
✓Pump is calibrated for volume.
If the calibrated values show a deviation > 30% most probably pump
head or tube diameter are not set correctly. Or the tube mounting
needs to be adjusted.
In this case cancel calibration via „Select” key. Verify your settings.
Set intermittent dosing
Pauses can be set from 0.1 seconds to 750 hours.
Time unit Display Explanation
Seconds 0.1 - 599.9 600 sec. = 10 minutes
Minutes 10 - 599‘600 min. = 10 hours
Hours 10 - 750h 750 h. = 31.25 days
✓Unit is switched on.
✓Pump head and inner diameter of tube
are set correctly.
✓Volume is set.
➜Press „Select” key repeatedly till
indicator light „Pause sec/min/h”
illuminates.
➜Select required break time between
pumping motion via arrow keys or
.
➜Press „Select” key repeatedly till indicator lights „Vol ml” and „Pause sec/min/h”
illuminate simultaneously.
✓Intermittent dosing is set for all following processes.
✓The display shows alternating dispensed volume or running break time. The corre-
sponding indicator light blinks.
✓As soon as break time is over the pump starts moving.
✓As soon as set volume is dispensed the pump will stop.

Operation Operation
22 23
Analog Interface
(Hei-FLOW Advantage and Hei-FLOW Precision only)
To operate pump externally an analog
interface is located at the backside of
device.
Via this interface the speed can be set.
The socket is protected against splash
water with a screw cap.
Screw cap
Pin assignment of analog interface socket
▪PIN 1 = +5 V
▪PIN 2 = Start /Stop
▪PIN 3 = 0-10 V
▪PIN 4 = Direction of rotation
▪PIN 5 = 0 V (GND)
▪PIN 6 = 4-20 mA
51
2
34
6
Analog interface socket
Control
voltage Control current
Hei-FLOW Advantage 01
Hei-FLOW Precision 01
Hei-FLOW Advantage 06
Hei-FLOW Precision 06
0 - 0.9 V 0 - 4.9 mA 0 rpm 0 rpm
1 V 5 mA 5 rpm 24 rpm
10 V 20 mA 120 rpm 600 rpm
▪TTL-level 0 V = clockwise rotation, TTL-level 5 V = counter-clockwise rotation
▪TTL signal 5 V switches pump on and off.
This function is available all the time (also in internal mode).
▪For triggering direction of rotation and ON/OFF function, a 5 volts pin is available in
the interface connector which allows potential-free switching.
▪The analog interface is recognized at a level of 0.2 volts or a 4 mAmps current.
▪Hei-FLOW Precision: This mode is conrmed by “EA” in the display. As long as the
pump drive is controlled via analog interface, the display is inactive and “Start/Stop”
key will be the only active key on the device.
Digital Interface
(Hei-FLOW Precision only)
You can connect the device to a PC.
In addition to an analog interface a
RS 232 digital interface is located at the
backside of device.
Digital interface socket Pin assignment Socket cable to PC
1
5
6
4
2
3
8
7
PIN 1 Pin 1
PIN 2 Pin 6
PIN 3 Pin 2
PIN 4 Pin 7
PIN 5 Pin 3
PIN 6 Pin 8
Pin 7 Pin 4
Pin 8 Pin 5
1
9
As long as the RS 232 interface is active, all pump control elements
and display will remain active.

Operation Operation
24 25
Digital interface commands
Query
to pump1) Feedback from pump Explanation
LEDx? ▪LED=0000\r\n
▪LED=0001\r\n
Select parameter: x=0-7
▪LED off
▪LED on
LED0?=Volume ml
LED1?=Flow ml/min
LED2?=Tube mm (inner diameter)
LED3?=Speed rpm
LED4?=Rotation
LED5?=Direction of rotation right
LED6?=Direction of rotation left
LED7?=Pause sec/min/h (intermittent pause)
DSP? DSP=xxx\r\n Display query: show actual value
TAx! - Select function key: x=1-7
TA1!=Cal (calibrate)
TA2!=Start/Stop (rotation key)
TA3!=Change direction of rotation
TA4!=Max (maximum speed)
TA5!=Up (arrow key)
TA6!=Down (arrow key)
TA7!=Select (select key)
SPx=xxxx! - Set intermittent pause: x=0;2;3
SP0=0001 - 5999 seconds/10 e.g. 100 milliseconds
SP2=0010 - 0599 minutes
SP3=0010 - 0750 hours
SMM=xxxx!2) -Flow ml respectively μl (tube dependent):
xxxx=000.0 - 9999
SDZ=xxxx! - Set rotation rpm:
xxxx=0000 - 9999 (min/max gear dependent)
SDM=xxxx!2) -Volume dosing ml e.g. μl (tube dependent):
xxxx=000.1 - 9999 (not allowed for calibrating)
SSD=xxxx!2) -Set inner tube Ø : x=4digit gure
xxxx=0000 (see following section
“Interface commands: set tube”)
-OK\r\n Command successful
-ERROR\r\n Command failed
-PO/r/n Dosing completed
1) Interface parameter RS 232: 9600 Baud, No Parity, 8 Bit, 1 Stopbit
2) Also see chapter „Technical data, Table tube selection” for tube dependent parameters
▪Do not send commands as package,
minimum pause 0.1 seconds
▪xxxx substitutes a 1 - 4 digit gure
Interface commands: set tube
Command Inner tube Ø
SSD=0000! 0.8 mm
SSD=0001! 1.0 mm
SSD=0002! 1.7 mm
SSD=0003! 2.0 mm
SSD=0004! 3.0 mm
SSD=0005! 3.1 mm
SSD=0006! 4.0 mm
SSD=0007! 4.8 mm
SSD=0008! 5.0 mm
SSD=0009! 6.0 mm
SSD=0010! 6.3 mm
SSD=0011! 7.0 mm
SSD=0012! 7.9 mm
SSD=0013! 8.0 mm
SSD=0014! 9.0 mm

Troubleshootimg
2726
Cleaning and Maintenance
Cleaning and Maintenance
Cleaning
All surfaces of the unit allow for cleaning with a damp cloth and if required a mild soap
lotion.
Attention:
Damage to the surfaces
All surfaces can be damaged by improper cleaning.
Never use:
▪Chlorine bleach or any cleaning agent including chlorine
▪Ammonia
▪Abrasive cleaning agents such as cleaning rags, scrubbing agents
or any other agents which include metal components
To ensure a stable position clean surface and feet with a damp cloth
and ethanol regularly.
Maintenance
The unit is maintenance-free. Any necessary repair must be performed by an authorized
Heidolph distributor.
Please contact Heidolph Instruments or your local Heidolph Instruments distributor.
Tubes
Tubes are wear parts. Service life of tubes depends on material, rotational speed and
properties of the substance to be fed, e.g. temperature, viscosity, chemical composition,
and pressure.
Service life of tubes used in pumps varies between approx. 50 and 500 hours in use.
➜Check tubes regularly.
➜Replace tubes in the event of visible wear.
Multi-channel pump head
➜Check plastic sleeve over metal bar regularly.
➜Replace plastic sleeve in the event of visible wear or latest after approx. 500 hours in
use.
Troubleshooting
Possible errors and how to resolve
General
Errors Possible reason Troubleshooting
Unit will not
switch on
Indicators do
not illuminate
No power supply Check size and shape of plug and
compatibility to your electrical socket
Fuse defective Please contact your local Heidolph
Instruments distributor
▪Regulation defective
▪Motor defective
▪Indicator light defective
Please contact your local Heidolph
Instruments distributor
Tube moves Tube not mounted
correctly
Adjust tube mounting (see chapter
„Assembly, Mount tubes”)
Pump is running
but does not
dispense
Wrong tube wall thickness Use adequate tube
(see chapter „Assembly, Mount tubes”)
Gear not working:
coupling of pump head not
aligned
Push pump head to drive as far as it
will go
(see chapter „Assembly, Mount pump
heads”)
Tube bed open
(pump head SP quick
only)
Close tube bed
(see chapter „Assembly, Mount tubes”)
Tube not set correctly
(Hei-FLOW Precision only)
Set correct tube diameter
(see chapter “Hei-FLOW Precision,
additional functions”, section “Set
tube”)
Motor too hot:
overheat protection
activated
Wait a few minutes and let motor cool
down;
pump switches on automatically
Hei-FLOW Advantage, Hei-FLOW Precision
Error message Possible reason Troubleshooting
Control light
rotation key is
blinking
Power cut Start rotation
Hei-FLOW Precision
Error message Possible reason Troubleshooting
---- Invalid values while
calibrating volume
▪Set rotation rpm according to table
(see chapter “Technical data,
Performance range pump heads”)
▪Calibrate volume anew
(see chapter “Technical data, Table
tubes”)
If you experience a malfunction which can not be resolved, please contact your
authorized Heidolph distributor immediately.

Assembly Assembly
28 29
Assembly
Electrical connections
▪Repairs of any kind are allowed by qualied professional electricians only.
Any improper repair can result in a dangerous situation. Contact your local Heidolph
Instruments distributor for any repair you may have.
Warning:
Electric shock!
This unit must only be connected to a grounded electrical socket.
The unit and voltage must match. The type label on the back side of
the unit provides all voltage specics.
When shipped the unit is grounded. In case the original plug is
changed, the new plug must have a protective conductor!
Rating plate
ON/OFF switch
Color code for electrical connections:
Europe North
America
GREEN/
YELLOW
PE: Protective
conductor (Earth) GREEN PE: Protective conductor (Earth)
BLUE N: Neutral conductor WHITE N: Neutral conductor
1,411 mm P: Phase BLACK P: Phase
The unit is connected with the power cord supplied to the electrical socket. It plugs into
the housing on the rear side of the unit.
For countries utilizing a plug other than the standard one supplied:
▪The plug supplied may only be changed by a professional electrician.
▪If utilizing an adaptor ensure that it is grounded and approved by the local regula-
tions.
Mount pump heads
Warning:
Risk of nger crushing!
When mounting pump heads you can crush your ngers if rotation is
switched on accidentally.
Always switch device off via main switch while mounting pump
heads.
Single-channel pump heads SP standard and SP vario
Components:
▪1x Pump head
▪1x Flange
▪1x Guide aid
▪2x Knurled screws
▪2x Short tube sections
▪1x Allen key
Pump head Flange
Knurled screws Allen key
Guide aids Tube
sections
➜Insert guide aid into ange.
➜Position ange with guide aid in front
of pump head in a way that guide will
be pushed into coupling.
✓Allen screw shows upwards.
➜Tighten ange on both sides with
knurled screws onto pump head.
➜Remove guide aid.
Knurled screws Allen screw
Guide aids Coupling
➜Remove protection shield from front of
pump head.
Warning:
Risk of nger crushing!
When pump head is not
covered, you can crush your
ngers on rotating parts.
Always mount protection shield
before switching on and
operating device.
Protection shield
Knurled screws

Assembly Assembly
30 31
➜Push pump head with coupling heading
into ange, till ange and pump head
are aligned.
➜Eventually turn rotor till couplings
interlock.
➜Position pump head so it ts to your
set-up of vessels and xate with allen
screws.
➜Mount protective shield.
Rotor
Single-channel pump head SP quick
➜Move clamping lever from right to left.
✓Tube bed of pump head is open.
Clamping lever Tube bed open
➜Insert coupling of pump head into
coupling of pump drive.
➜Eventually turn rotor till couplings
interlock.
Coupling pump drive
Coupling pump head
➜Hand-tighten pump head with the
2 knurled screws (tighten up with a
screwdriver or coin if necessary).
Knurled screws
Multi-channel pump heads
Components
Adaptor:
▪1x Adaptor
▪2x Cross headed screws
Adaptor
Back side ScrewsFront side
Pump head C 4, C 8
▪1x Pump head
▪1x Spare plastic sleeve for metal bar
▪4x Allen screws
▪1x Allen key
▪2x Spare feet
Pump head C 8
Allen screw
Allen keyPlastic sleeve
Spare feet
Pump head C 12
▪1x Pump head
▪4x Allen screws
▪1x Allen key
▪2x Spare feet
Pump head C 12
Allen screw
Allen key
Spare feet

Assembly Assembly
32 33
➜Insert coupling of adaptor into coupling
of pump drive.
➜Insert supplied screws through holes
of adaptor.
➜Tighten screws with a cross headed
screw driver.
Caution:
Possible damage of device
(Pump head C 4, C 8 only)
Without plastic sleeve mounted
on metal bar the pump head can
be damaged.
Ensure plastic sleeve is mounted
on metal bar for operation.
➜Align metal bar (with plastic sleeve) to
mounting slot of adaptor.
➜Push pump head onto adaptor in a way
that metal bar glides into mounting
slot of adaptor.
Screws
Mounting slotMetal bar (with plastic sleeve)
➜Level pump head via adjusting foot for
support.
➜Insert allen screws into 4 holes and
tighten with supplied allen key onto
adaptor.
Holes for allen screws
Adjusting foot
➜Tighten screw nut at adjusting foot of
pump head.
Adjusting foot Screw nut
Mount tubes: Single-channel pump heads
Warning:
Risk of crushing!
While mounting and demounting tubes you can crush your ngers, if
rotation starts accidentally.
Always switch device OFF at main switch before mounting tubes.
Only use tubes with appropriate wall thickness. Using an inadequate
tube can damage tube or pump might not operate.
To extend life-cycle of tubes pre-tension tube after mounting. Pull
slightly and simultaneously at both ends of tube.
Pre-tension guarantee the rollers running centered over tube.
You will nd corresponding tube sizes to variants of pump heads in chapter „Technical
data, Table tubes” as well as in our general catalogue.
Tubes: pump head SP standard
✓Protection shield is removed.
➜Loosen clamping screw to take off
clamp.
➜Mount tube in a curve of 180° into
tube bed.
➜Turn rotor by hand to engage tube
between rollers and tread.
➜Turn rotor repeatedly till tube is
crushed by total width of rollers.
➜Secure clamp with clamping screws.
➜Mount protection shield and secure
with knurled screws.
➜Check correct mounting by running a
short test.
Clamping screw
Rotor Clamp
Rollers

Assembly Assembly
34 35
Tubes: pump head SP vario
Additional components:
1x Aid pin
Aid pin
Pump head SP vario allows operating
tubes of different wall thickness.
✓Remove protection shield.
➜Remove clamping screw to remove
clamp.
Clamping screw
Rotor Clamp
Protection shield
➜Turn vario wheel via aid pin to
maximum wall thickness.
➜Mount tube in a curve of 180° into
tube bed.
➜Turn rotor by hand till tube lies
between roller and tread.
➜Turn vario wheel via aid pin to
minimum wall thickness till you
sense a noticeable resistance.
➜Tighten xiing screw to hold vario
wheelin this position. Vario
wheel
Rotor Fixing
screw
Aid pin
maximum minimum
➜Turn rotor repeatedly to ensure tube is crushed by rollers in whole width.
➜Attach clamp with clamping screws.
➜Mount protection shield and secure with knurled screws.
➜Check correct mounting by running a short test.
The right pressure is reached if uid is dispensed during operation but
stops passing through when pump is stopped.
Small tubes, inner diameter 0.8 mm and 1.7 mm
Tubes with an inner diameter of
0.8 mm and 1.7 mm are delivered
with 2 additional tube cuttings.
Push both tube cuttings onto the
dispenser tube.
➜Place tube in pump head with cuttings
positioned in clamping sleeve.
✓The cuttings ensure save clamping of
the small tube.
Aid pin Tube inner Ø 0.8 mm / 1.7mm
Tube cuttings
Tubes: pump head SP quick
Pump head SP quick features a quick-clamp
mechanic for clamping tubes.
➜Move clamping lever to the left to open
tube bed.
➜Turn both clamping screws counter-
clockwise as far as they will go for
maximum tube size.
Clamping screws
Clamping lever
Tube bed open
➜Place tube into open tube bed.
➜Move clamping lever cautiously to the
right to close tube bed.
✓When sensing signicant resistance
during closing either clamping screws
are not open or tube is too large.
➜Turn both clamping screws clockwise to
clamp tube.
➜Check correct mounting by running a
short test.
Tube bed closed

Assembly Assembly
36 37
✓Tube may not move during operation.
➜To adjust clamping stop rotation, switch off device and open tube bed.
➜Turn clamping screws clockwise or counterclockwise to increase or decrease clamping
pressure.
➜Close tube bed and repeat the test run.
Caution:
Possible tube damage
Do not force closing of tube bed. Overtightening leads to damaged
tube.
Open clamping screws completely before closing tube bed. Adjust
clamping gradually.
Check correct mounting by repeated test runs if necessary.
Mount tubes: Multi-channel pump heads
Multi-channel pump heads require cassettes to mount tubes. You will nd the right sizes
of cassettes in our general catalogue or at the end of this manual.
Warning:
Risk of crushing!
While mounting and demounting cassettes you can crush your
ngers, if rotation starts accidentally.
Always switch device OFF at main switch before mounting cassettes.
Caution:
Possible damage of device
Multi-channel pump heads require a certain combination of cassettes
and tubes. Other combinations lead to premature wear or to
malfunctions.
Only use combinations of cassettes and tubes tting your Multi-
channel pump head as laid out in this manual (see chapter
„Technical data, Table tubes”).
All cassettes operate in both directions. However, we recommend to
mount cassettes alternating. This way the clamping can be adjusted
more easily.
Cassettes and tubes: „Cassette small”
„Cassette small” is suitable for multi-channel pump heads C 4 and
C 12 only!
Caution:
Possible damage of device
Stopper on tubes with small inner diameter of 0.8 and 1-7 prevent
tubes from moving. Operating tubes without stoppers will lead to
malfunction and exclusion from warranty!
Always use stopper tubes when operating these small tubes.
„Cassette small” is suitable for two-stopper tubes only!
Mount tube
➜Turn adjustment knob for tube
pressure counterclockwise till tube bed
is opened to maximum.
✓Wedges are pushed out.
➜Insert two-stopper tube into cassette
from below.
➜Stoppers are placed outside of
cassette.
➜Pull tube into cassette till stoppers are
hold by the side frame.
Adjustment knob
Stopper
Wedges
Clamping side
Mount cassette
➜Click cassette hook onto support rod
while holding onto tube.
➜Move cassette downwards to click in
opposite hook.
✓Tube is positioned between rollers and
cassette.
➜Push cassette to pump drive.
Hooks
Support rods

Assembly Assembly
38 39
Adjust tube pressure
➜Turn adjustment knob clockwise till
inner side of wedge aligns with mark
on adjustment scale between gures
1 and 2.
✓Tube pressure is set.
➜Repeat with next cassette.
Demount cassette
➜Push cassette downwards and pull at
clamping side to open hook.
➜Move cassette upwards while holding
onto clamping side to release hook.
➜Unhook other side of cassette.
Inner side of wedge
Adjustment scaleClamping side
If tube pressure was already adjusted for tube size in previous
operations, adjustment of pressure does not have to be repeated.
Optimize tube pressure
Certain applications require adjustment of tube pressure, for instance to:
▪vary ow for certain tube size
▪reduce variation in ow caused by system pressure
▪extend life time of tubes
➜Switch rotation on.
➜Turn adjustment knob counterclockwise to move wedges outwards to higher scale.
✓Tube pressure is reduced to insufcient.
➜Slowly adjust by turning knob clockwise till ow and pressure t your requirements.
Secure cassettes
Multi-channel pump heads can be operated with reduced number of cassettes. Reduced
number of cassettes have to be secured to prevent moving.
Both support rods are equipped with an
O-ring to prevent cassettes from moving.
➜Push O-rings on both sides away from
pump head.
➜Mount required number of cassettes.
➜Push 0-Ringe on both sides against
front cassette.
✓Cassettes are secured.
O-Ring
Front cassette
Support rod
Tube extension
Optional PTFE tube couplings are available for extension. Bulk hose goods can be
connected with these couplings.
Components:
▪2x Sleeve nuts
▪1x Screw joint
▪2x3 Pcs. O-rings
▪2x Ferrules
Sleeve nuts
O-ringsScrew joint
Tube sizes:
0.2; 0.5; 0.9 and 1.4
➜Insert tubes into sleeve nuts.
➜Push 3 O-rings over each tube.
➜Screw sleeve nuts hand-tight onto
screw joints.
Tube size 2.8
➜Trim tube ends diagonally.
➜Insert tubes into sleeve nuts.
➜Trim tube ends horizontally.
➜Push ferrules with at side onto tube.
➜Insert tubes with ferrule tip into screw
joints at both sides.
➜Screw sleeve nuts hand-tight onto
screw joints.
Ferrule
Cassettes and tubes: „Cassette medium”
„Cassette medium” is suitable for multi-channel pump head C 8
only!
➜Mount suitable tubes to cassettes.
(see chapter „Technical data, Table tubes”).
➜Mount Cassettes as described under “Cassette small”.
➜Pull slightly at both ends of tube to prevent an eventual loop.
➜Set tube pressure via adjustment knob between gures 3 and 4 of scale.
