1x 700009741 Schraubensatz: 1x 700009741 Screw kit:
230617/020218/260121
1
1x 700009739 Rohradapter links
1x 700009740 Rohradapter rechts
1x 700009739 tube adapter left
1x 700009740 tube adapter right
Easyrack
Bei Bestellung eines Aluracks zusätzlich:
1 799.901HB Alurack
1 799.902HB TC-Bügel für Alurack
1 799.903HB Abdeckplatte für Rack
Bei Bestellung eines Easyracks zusätzlich:
1 700008650 Easyrack
1 700008647 Abdeckblende links
1 700008648 Abdeckblende rechts
When ordering a Alurack:
1 799.901HB alurack
1 799.902HB bow for Alurack
1 799.903HB plastic cover for rack
When ordering a Easyrack:
1 700008650 Easyrack
1 700008647 plastic cover left
1 700008648 plastic cover right
4x filister head screw M8x30
4x allen screw M6x12
4x allen screw M6x20
4x washer Ø6,4
4x body washer Ø8,4xØ23
4x self lock nut M6
2x alu spacer Ø25xØ9x10mm
2x alu spacer Ø20xØ9x12mm
4x special washer 20x20x Ø6,4
4x Linsenkopfschraube M8x30
4x Zylinderschraube ISK M6x12
4x Zylinderschraube ISK M6x20
4x U-Scheiben Ø6,4
4x Karosseriescheiben Ø8,4xØ23
4x selbstsichernde Muttern M6
2x Aludistanz Ø25xØ9x10mm
2x Aludistanz Ø20xØ9x12mm
4x Viereck-Scheiben 20x20x Ø6,4
Alurack
HONDA X-ADV
(2017-2020)
Easyrack
Artikel Nr.: / Item-no.:
661999 01 01
schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652999 01 01
schwarz/black
INHALT
CONTENTS
Preparing of the Alurack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is needed in use with a Hepco & Becker topcase only.
Vorbereitung des Aluracks:
Den beiliegenden TC-Bügel mit den Zylinderkopf-
schrauben M6 x 12 hinten unter dem Alurack
verschrauben.
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker
Topcases erforderlich.
2
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined
action, you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the
screws should be tightened to the torque specified. This guarantees, that the product is mounted without tension.
Observe the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
VORBEREITUNG
PREPARING
4x
Ratsche/Ratchet
Verlängerung/extension
Set
2x 2x
Sitzbank hochklappen. Die Original Haltegriffe
entfernen, diese sowie deren Schrauben entfallen.
Die Aludistanzen ø25xø9x10mm vorne und die
Aludistanzen ø20xø9x12mm hinten mit etwas
beidseitigem Klebeband auf den nun freien
Gewindebohrungen fixieren.
Fold the seat up. Dismantle the original grab rails -
rail and screws are obsolete. Fix the alu spacer
ø25xø9x10mm at the front and the spacer
ø20xø9x12mm at the back with some double-sided
adhesive tape on the now free tapped holes.
HONDA X-ADV
(2017-2020)
Easyrack
Artikel Nr.: / Item-no.:
661999 01 01
schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652999 01 01
schwarz/black
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
3
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
Fahrtrichtung
driving direction
2x
Montage der Rohradapter
rechts/links vorne:
Die Montage erfolgt mit den Linsenkopf-
schrauben M8x30 und
Karosseriescheibe Ø8,4xØ23 an den
nun freien Gewinde-bohrungen.
Montage der Rohradapter
rechts/links hinten:
Die Montage erfolgt mit den Linsenkopf-
schrauben M8x30 und
Karosseriescheibe Ø8,4xØ23 an den
nun freien Gewinde-bohrungen.
2x
2x 2x
2
HONDA X-ADV
(2017-2020)
Easyrack
Artikel Nr.: / Item-no.:
661999 01 01
schwarz/black
Alurack
Artikel Nr.: / Item-no.:
652999 01 01
schwarz/black
Fastening of the tube adapters
right/left front:
With filister head screws M8x30 and
body washers Ø8,4xØ23 in the now
free threads.
Fastening of the tube adapters
right/left rear:
With filister head screws M8x30 and
body washers Ø8,4xØ23 in the free
threads.
4
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
HINWEIS:
Rack soweit hinten montieren, dass
sich die Sitzbank noch aufklappen lässt.
NOTICE:
Mount Rack so far back that the seat
can still be opened.
Alurack:
Easyrack:
3
Fastening of the Alurack/Easyracks:
On the tube adapters.
Use allen screws M6 x 20 and special
washer 20x20xø6,4. Secure with washers
ø6,4 and self-lock nuts M6. Mount the
plastic cover.
Montage des Aluracks/Easyracks:
Das Rack wird mit den Zylinderschrauben
M6x20,den Viereck-Scheiben 20x20xø6,4,
den U-Scheiben ø6,4 und den
selbst-sichernden Muttern M6 auf den
Rohradaptern verschraubt. Anschließend die
Kunststoffabdeckung montieren.
4x 4x
4x
4x
Als weiteres Zubehör lieferbar / Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Weiteres Zubehör auf unserer Homepage. More accessories: see our homepage.
660999 01 01 Minirack
501999 00 01 Motorschutzbügel, schwarz / Engine guard, black
4212999 00 01 Griffschutz / Handle protection
