Herman Miller Verus Task Chair Installation instructions

Power Driver
Tools Required
HermanMiller
VerusTM Task Chair Disassembly Instructions
How to disassemble your chair.
T-
Trox Bit
T-
Trox Bit
T-
Trox Bit Allen Wrench
Step 1
. Slide your ngers between the J-Bar and the cover, gently pry each
corner.
Step 2
. Take out the  bolt screws from the J-bar by using T- torx power drive.
Step 3
. Take out the mesh back frame from J-bar.
Rubber Mallet
1Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair

Step 7
. Take out the seat assembly by sliding it forward.
Step 4
. Take out the  screws from mesh back frame by using T- trox power drive.
Step 5
. Remove the lambar with sacral by pulling it upwards.
Step 6
. Loosen the cap screws to remove the arms by using allen wrench.
2Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair

3Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
. Take out the old J-bar from tilt assembly by removing the
 bolt screws using T- torx power drive.
. Take out the tilt assembly from cylinder by pulling it hard.
Step 8 Step 9
. Take out the cylinder from the base by using rubber mallet.
Step 10 Step 11
. Hold base and pull hard to remove caster from base.

4Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
Tools Required
HermanMiller
VerusTM Task Stool Disassembly Instructions
How to disassemble your stool.
Step 1
. Slide your ngers between the J-Bar and the cover, gently pry each
corner.
Step 2
. Take out the  bolt screws from the J-bar by using T- torx power drive.
Step 3
. Take out the mesh back frame from J-bar.
Power Driver T-
Trox Bit
T-
Trox Bit
T-
Trox Bit Allen Wrench Rubber Mallet

5Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
Step 7
. Take out the seat assembly by sliding it forward.
Step 4
. Take out the  screws from mesh back frame by using T- trox power drive.
Step 5
. Remove the lambar with sacral by pulling it upwards.
Step 6
. Loosen the cap screws to remove the arms by using allen wrench.

6Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
. Take out the old J-bar from tilt assembly by removing the
 bolt screws using T- torx power drive.
. Take out the tilt assembly from cylinder by pulling it hard.
Step 8 Step 9
. Take out the footring from the cylinder by pulling it hard. . Take out the cylinder from the base by using rubber mallet.
Step 10 Step 11

7Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
Step 12
. Hold base and pull hard to remove caster from base.

8Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
Tools Required
HermanMiller
VerusTM Side Chair Disassembly Instructions
How to disassemble your chair.
Step 1
. To remove the caster, grasp the caster with hand and pullout.
Step 2
. Remove the seat by taking out the  screws in the bottom.
Step 3
. Remove the seat.
Power Driver T-
Trox Bit
T-
Trox Bit
T-
Trox Bit Allen Wrench Rubber Mallet

9Disassembly Instructions1BHVBS rev AHermanMiller for VerusTM task chair
Step 4
. Remove the  nuts holding the arms using / inch socket.
Step 5
. Remove the arm. Repeat for opposite side.
Step 5
. Using a rubber mallet, gently tap the top end of the arm from underneath
and take out the arm.
Step 6
. Using a rubber mallet, tap up evenly on both sides until the back comes
out of the track.
