Herman Miller Canvas Channel StructuralFoot Installation instructions

Tools Required
Parts Included
HermanMiller
Canvas Channel Structural
Foot Installation and Disassembly
for Recycling Instructions
How to assemble your structural foot
Assembly Instructions:Pre - Assembly Instructions:
Step 2Step 1
Shared Structural Foot -
Open Base
Angle Bracket Hex Head
Machine Screw
(Black - /” Long)
Hardware Pack
Hex Head
Cap Screw
(Silver -  / Long)
Tapping
Screw
Hex Nut Shim
. Place Foot under frame. Place Angle Bracket on top of
bottom rail of frame. Insert Hex Head Machine Screws from
bottom up thru frame. Install Hex Nuts onto Screws. Align Foot
Cover with End Trim before Tightening. Torque screws to  in-lbs.
End-Of-Frame Structural Foot
/” Socket# Phillips Bit
/”
Wrench
/”
Wrench
Torque
Wrench
Safety
Glass
Angle Bracket
Angle Bracket
Hex Head
Machine Screw
Foot Mounting
Plate
Adapter
Foot Base
Shim
Hex Head
Machine Screw
End of Frame Foot
(Open Base)
Foot Mounting
Plate
Foot Mounting
Plate
End of Frame Foot
(To the Floor)
Frame
Hex Nut
Hex Nut
6” From End Structural Foot -
Open Base
End of Frame Structural Foot -
Open Base
Shared Structural Foot -
To The Floor
6” From End Structural Foot -
To The Floor
End of Frame Structural Foot -
To The Floor
Ratchet
. Ensure the foot base and foot mounting plate are aligned as shown in the
parts section.
. If not rotate foot base to align as shown.
. Tighten Adapter against the foot base to ensure proper assembly.
Power
Driver
1HermanMiller for Canvas Channel Structural Foot Installation Instructions Assembly Instructions1BKTM3 rev C

2HermanMiller for Canvas Channel Structural Foot Installation Instructions Assembly Instructions1BKTM3 rev C
Step 4
Step 5 Step 6
Shared Structrual Foot - Open Base
Shared Structrual Foot - To The Floor
. Place Foot under frames. Place Angle Brackets on top of bottom
rail of frames. Insert Hex Head Machine Screws from bottom up thru
frames. Install Hex Nuts onto Screws. Install Frame to Frame Connector
Kit FZ. See instruction sheet BKRBS for details.
. Place Foot under frames. Place Angle Brackets on top of bottom
rail of frames. Insert Hex Head Machine Screws from bottom up thru
frames. Install Hex Nuts onto Screws. Install Frame to Frame Connector
Kit FZ. See instruction sheet BKRBS for details.
Angle Bracket
Angle Bracket
Hex Head
Machine Screw
Hex Head
Machine Screw
Shared Structural Foot
(Open Base)
Shared Structural Foot
(Open Base)
Frame to Frame
Connector Kit
Foot Base
Adapter
Insert Cover
Foot Base
Frame to Frame
Connector Kit
Frame
Frame
Hex Nut
Hex Nut
Step 3
. Place Foot under frame. Place Angle Bracket on top of
bottom rail of frame. Insert Hex Head Machine Screws from
bottom up thru frame. Install Hex Nuts onto Screws. Align Foot
Cover with End Trim before Tightening. Torque screws to  in-lbs.
Note: When installing with single sided gallery panel (FZ.XXXXXXXL/R) and
utilizing 6” inset structural foot at frame to frame joint, place the ” inset foot
on the frame connected to the gallery panel.
6” From End Structural Foot
Hex Head
Machine Screw
Hex Head
Machine Screw
Tapping Screw
Tapping Screw
6” From End Foot
(To the Floor)
Hex Nut
Hex Nut
6” From End Foot
(Open Base)
Angle Bracket
Angle Bracket
Foot Mounting
Plate
Foot Mounting
Plate
Foot
Mounting
Plate
Foot Mounting
Plate
. Loosen the adapter
. To adjust an open base type structural foot, li the inset cover to access the
adapter
. To increase the product height: Rotate foot base clock wise to a desirable
height and tighten the adapter against the foot base
. To decrease the height: Rotate foot base anti-clock wise to a desirable
height and tighten the adapter against the foot base to lock the height
. Aer adjusting the foot assembly height ensure the foot base is positioned
perpendicular to frame (as shown below)
Frame Height Adjustment Instructions

3HermanMiller for Canvas Channel Structural Foot Installation Instructions Assembly Instructions1BKTM3 rev C
Disassembly for Recycling:
Materials Identication and Segregation:
Where possible, plastic components are marked with ASTM recycling codes.
Use these codes to identify material type for recycling.
Non marked components should be treated as mixed plastic.
Ferrous metals can be identied using a small magnet for recycling.
Non-ferrous metals should be separated and recycled separately.
. Apply shim to the bottom of the structural foot base to reduce foot
wobble.
. Shims can be attached on to each other to create thicker shim.
. Make desired thickness and attach it to the bottom face of the foot
base by peeling adhesive liner from the shim.
.Ensure Shim is completely hidden within the boundary of foot base. To disassemble product, reverse the above installation steps.
Step 6
Frame Height Adjustment Instructions
Shim
Adhesive
Shim
Adapter
Foot Base
