HermanMiller Assembly Instructions1
How to assemble
your Nelson Thin Edge Bed.
HermanMiller
Nelson Thin Edge Bed
(Twin, Full, Queen) Installation
Instructions
For more information about our products and services or to see a list of dealers, please visit us at
www.hermanmiller.com/product-instructions or call 888 - 443 - 4357.
© 2016 Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. 1BFXZ8 - C.
4mm Allen
Wrench (1)
Safety Instructions & Warning
Start with bed frame facing down.
Note: Will require at least 2 people. Attach center steel or wood legs (except on Twin) using 4 Short Bolts per leg.
Step 1 Step 2
• Read all instructions before using products
• Failure to fully tighten screws may cause injury
• Periodically check fasteners to ensure tightness
• The right is reserved to make changes at any time without notice
• Will require at least 2 people
• Extra bolts have been included
Parts Included
Wood Bed Frame (1) Top Rail (2)
Short Bolt (32)
Steel Leg (2) Wood Leg (6)
Headboard (1)
OR
H-Legs (2)
Short Bolt
Medium Bolt (10)

HermanMiller Assembly Instructions2
Attach outer legs using 4 Short Bolts per leg.
Attach wooden top rails to both ends using Medium Bolts. Ensure medallion is
facing outward.
Flip bed frame over so it is right side up being careful not to put
weight on legs while flipping.
Step 3
Step 5
Step 4
Step 6
Steel Leg Option
Wood Leg Option
Medium Bolt
Short Bolt
Branding Medallion
Attach headboard to bed frame at the end with medallion
on top rail. Use 4 Short Bolts for each headboard support plate.

HermanMiller Assembly Instructions3
How to assemble
your Nelson Thin Edge Bed.
HermanMiller
Nelson Thin Edge Bed
(King,Cal King)
Installation Instructions
For more information about our products and services or to see a list of dealers, please visit us at
www.hermanmiller.com/product-instructions or call 888 - 443 - 4357.
© 2015 Herman Miller, Inc., Zeeland, Michigan Printed in U.S.A. Part No. 1BFXZ8 - C.
4mm Allen
Wrench (1)
Parts Included
Safety Instructions & Warning
• Read all instructions before using products
• Failure to fully tighten screws may cause injury
• Periodically check fasteners to ensure tightness
• The right is reserved to make changes at any time without notice
• Will require at least 2 people
Wood Bed Frame (LH) (1) Wood Bed Frame (RH) (1) Top Rail (2)
Short Bolt
(46)
Large
Spanner Plate
Small
Spanner Plate
Medium Bolt
(12)
Long Bolt
(2)
Long Bolt
Barrel Nut
(2)
Barrel Nut
Start with bed frames facing upward. Ensure frames are properly aligned.
Note: Will require at least 2 people.
Use 2 Long Bolts and Barrel Nuts to connect frames together to assemble the platform.
Tighten with allen wrench.
Step 1 Step 2
Steel Leg
(2)
Wood Leg
(6)
Headboard (1)
OR
H-Legs (2)

HermanMiller Assembly Instructions4
Carefully flip connected frames over in orientation shown below ensuring both frames
do not bend relative to each other.
Step 3
Attach large spanner plate at foot end of bed with 6 Short Bolts.
Flip frame over so it is right side up being careful not to put weight on legs
while flipping.
Attach wooden top rails to both ends using 6 Medium Bolts each. Use top rail with no
medallion on end with large spanner plate. Use top rail with medallion on other end.
Ensure medallion is facing outward.
Step 4
Step 6
Step 7
Attach center and outer legs using 4 Short Bolts per leg.
Step 5
Wood Leg Option
Steel Leg Option
Short Bolt
Large Spanner Plate
Medium Bolt
Branding
Medallion

HermanMiller Assembly Instructions5
Attach outer headboard support plates to frame using 4 short bolts for each.
Step 8 Step 9
Brand Medallion
Small Spanner Plate
Short Bolt
Attach inner headboard support plates and small spanner plate using 8 short bolts in
total. The spanner plate sits on top of the headboard support plates as shown below.
