Hettich Quadro V6 User manual

Technik für Möbel 13
Advice
`Dimensions in millimeters (inch approximations as noted). Subject to technical modifications without notice.
Drawer slides for wooden drawers
`Quadro
`Technical information
Mounting specifications – (Quadro V6 / Quadro 4D V6, face frame application)
Cabinet front edge
Min. setback for inset or roll out tray =
Decorative drawer front thickness + 3.5 mm (1/8“).
Trial recommended! See details below for adjustment possiblities.
Blocking behind frame
Minimum/maximum cabinet depth (see below)
(Rear attachment options see page 12)
Face frame application with
overlay decorative front
Face frame application with
inset decorative front
Front gap 1.5 mm (1/16“)
Setback 2 mm (3/32“)
10 mm (3/8“)
37 mm (1 7/16“)
Inset application increases minimum cabinet depth!
Drawer box length
mm (inch)
Min-Max cabinet depth with
metal rear attachment
mm (inch)
Min-Max cabinet depth with
plastic rear attachment (TennTex C-307)
mm (inch)
229 mm (9") Quadro V6 250 - 300 mm (9 7/8“ - 11 3/4“) 270 - 297 mm (10 5/8“ - 11 11/16“)
305 mm (12") 326 - 376 mm (12 7/8“ - 14 3/4“) 346 - 373 mm (13 5/8“ - 14 11/16“)
381 mm (15") 402 - 452 mm (15 7/8“ - 17 3/4“) 422 - 449 mm (16 5/8“ - 17 11/16“)
457 mm (18") 479 - 529 mm (18 7/8“ - 20 3/4“) 498 - 525 mm (19 5/8“ - 20 11/16“)
533 mm (21") 555 - 605 mm (21 7/8“ - 23 3/4“) 574 - 601 mm (22 5/8“ - 23 11/16“)
610 mm (24") 631 mm (24 7/8“) no rear attachment, must be blocked out
Minimum / maximum cabinet depth (Quadro V6 / Quadro 4D V6, face frame application)

www.hettich.com
14
14
9 9 9
32
24
36
68
2 2
1 1
3 3
8
26
9
9 9 14
32
24
36
3
1
2
Drawer slides for wooden drawers
`Quadro
`Technical information
Adjustment possibilities - cabinet profile details
Advice
`Dimensions in millimeters (inch approximations as noted). Subject to technical modifications without notice.
Drawer adjustments: 1 mm (1/32”) (down)
3 mm (1/8”) (up)
9 mm (3/8”) (range in/out)
Trial recommended!
Adjustment influences minimum cabinet depth.
Detail A* Detail B*
Drawer adjustments: 1.5 mm (1/16”) (in)
2.5 mm (3/32”) (out)
4 mm (5/32”) (range in/out)
1
2
33
2
1
Mounting specifications – (Quadro V6 / Quadro 4D V6, face frame application)
Item A
mm (inch)
B
mm (inch )
C
mm (inch)
Minimum cabinet depth
(blocking or frameless cabinet)
mm (inch)
Quadro V6 9” 133 (5 1/4) 229 (9) 96 (3 25/32) 250 (9 7/8)
Quadro V6 12” 165 (6 1/2) 261 (10 1/4) 128 (5 1/32) 326 (12 7/8)
Quadro V6 15” 165 (6 1/2) 357 (14 1/16) 128 (5 1/32) 402 (15 7/8)
Quadro V6 18” 261 (10 1/4) 453 (17 13/16) 224 (8 13/16) 479 (18 7/8)
Quadro V6 21” 261 (10 1/4) 517 (20 3/8) 224 (8 13/16) 555 (21 7/8)
Quadro V6 24” 261 (10 1/4) 453 (17 13/16) 224 (8 13/16) 631 (24 7/8)
37 mm (1 7/16“)
10 mm (3/8“)
Setback 2 mm (3/32“)
A
B
32 mm
28 mm (1 3/32“)
Front gap 1.5 mm (1/16“)
C
Cabinet front edge

Technik für Möbel 15
Drawer slides for wooden drawers
`Quadro
`Technical information
Advice
`Dimensions in millimeters (inch approximations as noted). Subject to technical modifications without notice.
Catch for wooden drawers (Quadro V6 full extension)
10 mm
3/8“
80 mm
(3 3/16") 48 mm
(1 7/8")
26 mm
(1 1/32")
ø 3,5 x 20 mm
#6 x 3/4“
30 mm
(1 3/16")
30 mm
(1 3/16")
≤
30°
Catch and tilt adjuster for wooden drawers (Quadro 4D V6 full extension)
≤
30°
80 mm
(3 3/16")
26 mm
(1 1/32")
48 mm
(1 7/8")
7,5 mm
(5/16")
ø 3,5 x 20 mm
#6 x 3/4“
ø 4 x 12 mm
#6 x 1/2"
35 mm
(1 3/8")
35 mm
(1 3/8")
19 mm
(3/4")
25 mm
(1")
21 mm
(13/16")
15 mm
(19/32")
35 mm
(1 3/8")

www.hettich.com
16
Drawer slides for wooden drawers
`Quadro
`Technical information
Quadro 4D V6 full extension runner: adjustment of the drawer front panel
+
+
+ 2 mm X
+
-
+
-
+
-
+
-
±2 mm
Push to open: + 4 mm
± 1,5 mm
± 1,5 mm
A <15 mm: X =
A =15 mm: X <
A =16 mm: X = ± 1,0 mm
A
Advice
`Dimensions in millimeters (inch approximations as noted). Subject to technical modifications without notice.

Technik für Möbel 17
1
2
32
1
2.
1.
21
+ 2 mm
3
12 3
Assembly / Disassembly
Quadro V6 full extension runner: adjustment of the drawer front panel
Disassembly drawer Quadro 4D V6Drawer installation Disassembly drawer Quadro V6
Drawer slides for wooden drawers
`Quadro
`Technical information
Advice
`Dimensions in millimeters (inch approximations as noted). Subject to technical modifications without notice.
