Hettich ROTO SILENTA 630 RS User manual

Rev. 02 / 05.2022 Andreas Hettich GmbH & Co. KG AB5005EN_SA
ROTO SILENTA 630 RS
EN
Operating Instructions.................................................... 5

2/61 Rev. 02 / 05.2022 AB5005EN_SA
A
Fig. 1
LOCK1
STOP
120:30
400020022
PC
Fig. 2

AB5005EN_SA Rev.02 / 05.2022 3/61
Standards and regulations which apply to this device
The device is a high-end technical product. It is subject to extensive testing and certification procedures according to
the following standards and regulations in their respectively valid version:
Electrical and mechanical safety for design and final testing:
Standard series: IEC 61010 (conform to standards of DIN EN 61010)
• IEC 61010-1 “Safety requirements for electrical equipment for measurement, control, and laboratory use -
Part 1: General requirements” (Pollution Degree 2, Excess-voltage category II)
• IEC 61010-2-010 “Safety requirements for electrical equipment for measurement, control and laboratory use
- Part 2-010: Particular requirements for laboratory equipment for the heating of materials” (applied to
heated centrifuges only)
• IEC 61010-2-011 „Safety requirements for electrical equipment for measurement, control and laboratory use
- Part 2-011: Particular requirements for refrigerating equipment” (only valid for centrifuges with cooling)
• IEC 61010-2-020 “Safety requirements for electrical equipment for measurement, control, and laboratory
use - Part 2-020: Particular requirements for laboratory centrifuges”
• IEC 61010-2-101 ”Safety requirements for electrical equipment for measurement, control and laboratory use
- Part 2-101: Particular requirements for in vitro diagnostic (IVD) medical equipment“
Electromagnetic Compatibility:
• EN 61326-1 “Electrical equipment for measurement, control and laboratory use - EMC requirements - Part 1:
General requirements“
Risk management:
• DIN EN ISO 14971 “Application of risk management to medical devices”
Restriction of Hazardous Substances (RoHS II):
• EN 50581 "Technical documentation for assessing electric and electronic devices with regard to the
restriction of hazardous substances"
European directives applied for conformity assessment procedures:
• Medical device directive 93/42/EEC (class 2a medical products)
EC conformity assessment procedure according to Annex II
"EC DECLARATION OF CONFORMITY (complete quality assurance system)".
The certificate, Annex II, is issued by the following notified body:
mdc medical device certification GmbH – Notified Body CE 0483
tel: [phone]
fax: [phone]
e-mail: [email protected]
website: www.mdc-ce.de
mail: Kriegerstraße 6, D-70191 Stuttgart; Germany
• Directive 2011/65/EU for the restriction of use of certain hazardous substances in electric and electronic
devices. Carrying out the EC conformity assessment process is the sole responsibility of the manufacturer,
without the involvement of a notified body.
Applied medical device regulations outside Europe:
• USA: QSR, 21CFR 820 “CFR Title 21 - Food and Drugs: TITLE 21- FOOD AND DRUGS, CHAPTER I -
FOOD AND DRUG ADMINISTRATION DEPARTMENT OF HEALTH AND HUMAN SERVICES,
SUBCHAPTER H - MEDICAL DEVICES, Part 820 QUALITY SYSTEM REGULATONS“
• Canada: CMDR, SOR/98-282 “Medical Devices Regulations”
Certified quality management system according to
• ISO 9001 “Quality management systems – Requirements”
• ISO13485 “Medical devices - Quality management systems - Requirements for regulatory purposes”
Environmental management system according to
• ISO 14001 “Environmental management systems - Requirements with guidance for use”

4/61 Rev. 02 / 05.2022 AB5005EN_SA
Andreas Hettich GmbH & Co. KG
Föhrenstraße 12, D-78532 Tuttlingen / Germany
Phone [phone] / 705-0
Fax [phone]
[email protected], serv[email protected]m
www.hettichlab.com
0483
© 2003 by Andreas Hettich GmbH & Co. KG
All rights reserved. No part of this publication may be reproduced without the prior written permission of the copyright
owner.
Änderungen vorbehalten! , Modifications reserved! , Sous réserve de modifications ! , Con riserva di modifiche!
AB5005EN_SA / Rev. 02

EN
AB5005EN_SA Rev.02 / 05.2022 5/61
Contents
1Intended use .................................................................................................................................................................................. 7
2Remaining risks.............................................................................................................................................................................. 7
3Technical specifications ................................................................................................................................................................. 8
4Notes on safety ............................................................................................................................................................................ 10
5Symbol meanings ........................................................................................................................................................................ 12
6Delivery checklist ......................................................................................................................................................................... 13
7Unpacking the centrifuge and installation .................................................................................................................................... 13
8Transport and storage.................................................................................................................................................................. 13
8.1 Transport.............................................................................................................................................................................. 13
8.2 Storage ................................................................................................................................................................................ 13
9Initial operation............................................................................................................................................................................. 14
10 Opening and closing the lid...................................................................................................................................................... 15
10.1 Opening the lid................................................................................................................................................................. 15
10.2 Closing the lid .................................................................................................................................................................. 15
11 Installation and removal of the rotor......................................................................................................................................... 15
12 Inserting and removing hangers into/from the rotor ................................................................................................................. 16
13 Inserting and removing the adapters into/from the hangers .................................................................................................... 16
14 Loading the rotor...................................................................................................................................................................... 17
15 Closing biosafety systems........................................................................................................................................................ 18
16 HettLiner packing instructions.................................................................................................................................................. 19
16.1 Packing before centrifugation .......................................................................................................................................... 19
16.2 Unpacking after centrifugation ......................................................................................................................................... 20
17 Control and display devices ..................................................................................................................................................... 21
17.1 Status symbols ................................................................................................................................................................ 21
17.2 Control knob .................................................................................................................................................................... 21
17.3 Keys and set-up options .................................................................................................................................................. 21
18 Entering centrifugation parameters.......................................................................................................................................... 22
18.1 Running time.................................................................................................................................................................... 22
18.1.1 Time selection.......................................................................................................................................................... 22
18.1.2 Continuous running.................................................................................................................................................. 22
18.2 Speed (RPM) ................................................................................................................................................................... 22
18.3 Relative centrifugal force (RCF/RZB) .............................................................................................................................. 22
18.4 Run-up and run-down parameters................................................................................................................................... 22
18.4.1 Run-up step ............................................................................................................................................................. 22
18.4.2 Run-up time ............................................................................................................................................................. 22
18.4.3 Braking step............................................................................................................................................................. 23
18.4.4 Run-down time......................................................................................................................................................... 23
18.4.5 Brake de-energisation speed................................................................................................................................... 23
18.5 Radius/Temperature ........................................................................................................................................................ 23
18.5.1 Radius...................................................................................................................................................................... 23
18.5.2 Temperature ............................................................................................................................................................ 23
18.6 Automatic buffer............................................................................................................................................................... 23
19 Programming............................................................................................................................................................................ 23
19.1 Entering / modifying programs......................................................................................................................................... 23
19.2 Calling up programs......................................................................................................................................................... 23
20 Centrifugation........................................................................................................................................................................... 24

EN
6/61 Rev. 02 / 05.2022 AB5005EN_SA
20.1 Centrifugation with time selection .................................................................................................................................... 24
20.2 Continuous running.......................................................................................................................................................... 24
21 Changing settings during the centrifugation run....................................................................................................................... 24
22 Integral RCF (∫RCF) ................................................................................................................................................................. 24
23 Displaying the maximum speed of the rotor............................................................................................................................. 24
24 Displaying the maximum RCF of the rotor ............................................................................................................................... 25
25 Emergency stop ....................................................................................................................................................................... 25
26 Audible signal........................................................................................................................................................................... 25
27 Interrogating the operating hours ............................................................................................................................................. 25
28 Setting the date and time ......................................................................................................................................................... 25
29 Centrifugation data displayed after switching on...................................................................................................................... 25
30 Immediate display of the centrifugation data after switching on............................................................................................... 26
31 Key-operated switch................................................................................................................................................................. 26
32 Program linking (for centrifuges with program linking only). .................................................................................................... 26
32.1 Linking programs ............................................................................................................................................................. 26
32.2 Changing program links ................................................................................................................................................... 26
32.3 Centrifugation run with program linking ........................................................................................................................... 27
32.4 Deleting program linking .................................................................................................................................................. 27
33 Cooling (only in centrifuges with cooling)................................................................................................................................. 27
33.1 Standby-cooling ............................................................................................................................................................... 27
33.2 Pre-cooling the rotor ........................................................................................................................................................ 27
34 Heating (only on centrifuges with heating/cooling option)........................................................................................................ 27
35 Relative centrifugal force (RCF)............................................................................................................................................... 28
36 Centrifugation of materials or mixtures of materials with a density higher than 1.2 kg/dm3..................................................... 28
37 Rotor recognition...................................................................................................................................................................... 28
38 Emergency release .................................................................................................................................................................. 29
39 Maintenance and servicing ...................................................................................................................................................... 29
39.1 Centrifuge (housing, lid and centrifuging chamber) ......................................................................................................... 29
39.1.1 Surface cleaning and care ....................................................................................................................................... 29
39.1.2 Surface disinfection.................................................................................................................................................. 29
39.1.3 Removal of radioactive contaminants...................................................................................................................... 30
39.2 Rotors and Attachments .................................................................................................................................................. 30
39.2.1 Cleaning and care.................................................................................................................................................... 30
39.2.2 Disinfection .............................................................................................................................................................. 30
39.2.3 Removal of radioactive contaminants...................................................................................................................... 31
39.2.4 Trunnions................................................................................................................................................................. 31
39.2.5 Rotors and accessories with limited service lives.................................................................................................... 31
39.3 Autoclaving ...................................................................................................................................................................... 31
39.4 Centrifuge containers....................................................................................................................................................... 31
40 Faults........................................................................................................................................................................................ 32
41 Returning Devices.................................................................................................................................................................... 33
42 Disposal.................................................................................................................................................................................... 33
43 Anhang / Appendix................................................................................................................................................................... 34
43.1 Rotoren und Zubehör / Rotors and accessories .............................................................................................................. 34

EN
AB5005EN_SA Rev.02 / 05.2022 7/61
1 Intended use
This device is a laboratory centrifuge which is suitable for medical and in-vitro diagnostic applications.
The therapeutic purpose with the corresponding centrifuge vessels is the separation of blood by means of
centrifugation for the purpose of transfusions or autotransfusion of the blood components.
The centrifuge is also suitable for preparing human bodily fluids by means of centrifugation for in-vitro diagnostic
purposes.
Furthermore, the centrifuge is generally also suitable for separating substances or substance mixtures of non-human
origin having a density of max. 1.2 kg/dm³.
The centrifuge may only be used by skilled personnel in closed laboratories.
The centrifuge is only meant for the above-named purposes.
Another use or one which goes beyond this, is considered to be non-intended. The company Andreas Hettich GmbH
& Co. KG is not liable for damage resulting from this.
Observing all information in the operating instructions and complying with the measures described therein is also a
part of the intended use.
2 Remaining risks
The device is built according to the state-of-the-art and the recognized safety regulations.
If used and handled improperly, there could be life-threatening danger to the user or third parties, or the device could
be impaired or there could be other property damage.
The device is only to be used for its intended purpose and only when it is in safe working condition.
Malfunctions which could affect safety must be corrected immediately.

EN
8/61 Rev. 02 / 05.2022 AB5005EN_SA
3 Technical specifications
Manufacturer Andreas Hettich GmbH & Co. KG
D-78532 Tuttlingen
Model ROTO SILENTA 630 RS
Type 5005,
5005-50 5005-80 5005-90
Mains voltage (±10%) 400 V 3~ +N
Mains frequency 50 - 60 Hz
Connected load 9700 VA 9400 VA 6600 VA
Current consumption 14 A 13.5 A 9.5 A
Cooling medium R452A
Max. capacity 12000 ml
Allowed density 1.2 kg/dm3
Speed (RPM) 6000
Force (RCF) 6520
Kinetic energy 215000 Nm
Obligatory inspection
(DGUV Regel 100 – 500)
Yes
Ambient conditions (EN / IEC 61010-1)
− Set-up site Indoors only
− Altitude Up to 2000 m above sea level
− Ambient temperature 5°C to 40°C
− Humidity Maximum relative humidity 80% for temperatures up to 31°C, linearly
decreasing to 50% relative humidity at 40°C.
− Excess-voltage category
(IEC 60364-4-443) ΙΙ
− Pollution degree 2
Device protection class Ι
Not suitable for use in explosion-endangered areas.
EMC
− Emitted interference,
Interference immunity
EN / IEC 61326-1, Class B
Noise level (dependent on rotor) ≤62 dB(A) ≤56 dB(A)
Dimensions
− Width 813 mm
− Depth 1015 mm 1050 mm
− Height 973 mm
Weight approx. 355 kg approx. 367 kg approx. 306 kg

EN
AB5005EN_SA Rev.02 / 05.2022 9/61
Manufacturer Andreas Hettich GmbH & Co. KG
D-78532 Tuttlingen
Model ROTO SILENTA 630 RS
Type 5005-08
Mains voltage 208–220 V +6/-10% 3~ (+N) +PE
Mains frequency 50 - 60 Hz
Connected load 9000 VA
Current consumption 25 A
Cooling medium R452A
Max. capacity 12000 ml
Allowed density 1.2 kg/dm3
Speed (RPM) 6000
Force (RCF) 6498
Kinetic energy 215000 Nm
Obligatory inspection
(DGUV Regel 100 – 500)
yes
Ambient conditions (EN / IEC 61010-1)
− Set-up site Indoors only
− Altitude Up to 2000 m above sea level
− Ambient temperature 5°C to 30°C 5°C to 40°C
− Humidity Maximum relative humidity 80% for temperatures up to 31°C, linearly
decreasing to 50% relative humidity at 40°C.
− Excess-voltage category
(IEC 60364-4-443) ΙΙ
− Pollution degree 2
Device protection class Ι
Not suitable for use in explosion-endangered areas.
EMC
− Emitted interference,
Interference immunity
EN / IEC 61326-1, Class B
Noise level (dependent on rotor) ≤62 dB(A)
Dimensions
− Width 813 mm
− Depth 1015 mm
− Height 973 mm
Weight approx. 401 kg

EN
10/61 Rev. 02 / 05.2022 AB5005EN_SA
4 Notes on safety
No claim of warranty will be considered by the manufacturer unless ALL instructions in this manual
have been followed.
• The centrifuge should be installed on a good, stable base.
• Before using the centrifuge absolutely check the rotor for firm placement.
• When the centrifuge is running, according to EN / IEC 61010-2-020, no persons, dangerous
substances or objects may be within the safety margin of 300 mm around the centrifuge.
• Rotors, suspensions and accessories that possess traces of corrosion or mechanical damage or
if their term of use has expired may not be used any longer.
• The centrifuge may no longer be put into operation when the centrifuging chamber has safety-
related damages.
• With swing-out rotors the trunnions must be regularly lubricated (Hettich Lubricating Grease No.
4051) in order to ensure consistent swinging out of the hangers.
• For centrifuges without temperature control, when the room temperature is increased and/or if the
device is frequently used, the centrifuging chamber could be heated up. Therefore, it can't be
ruled out that the sample material might be changed due to the temperature.
• Before the initial operation of your centrifuge you should read and pay attention to the operating
instructions. Only personnel that has read and understood the operating instructions are allowed to
operate the device.
• Along with the operating instructions and the legal regulations on accident prevention, you should also follow the
recognised professional regulations for working in a safe and professional manner. These operating instructions
should be read in conjunction with any other instructions concerning accident prevention and environmental
protection based on the national regulations of the country where the device is to be used.
• This centrifuge is a state-of-the-art piece of equipment which is extremely safe to operate. However, it can lead to
danger for users or others if used by untrained staff, in an inappropriate way or for a purpose other than that it
was designed for.
• The centrifuge must not be moved or knocked during operation.
• In case of fault or emergency release, never touch the rotor before it has stopped turning.
• To avoid damage due to condensate, when changing from a cold to a warm room the centrifuge must either heat
up for at least 3 hours in the warm room before being connected to the mains, or run hot for 30 minutes in the
cold room.
• Only the rotors and accessories approved by the manufacturer for this device may be used (see chapter
"Anhang/Appendix, Rotoren und Zubehör/Rotors and accessories"). Before centrifuge vessels are used which are
not listed in the chapter "Appendix, Rotors and accessories", the user must make sure they can be used by
asking the manufacturer.
• The centrifuge rotor may only be loaded in accordance with the chapter "Loading the rotor".
• When centrifuging with maxim revolutions per minute the density of the materials or the material mixtures may not
exceed 1.2 kg/dm3.
• The centrifuge may only be operated when the balance is within the bounds of acceptability.
• The centrifuge may not be operated in explosion-endangered areas.
• The centrifuge must not be used with:
− inflammable or explosive materials
− materials that react with one another producing a lot of energy.

EN
AB5005EN_SA Rev.02 / 05.2022 11/61
• When centrifuging hazardous substances or mixtures, which are toxic, radioactive or contaminated with
pathogenic microorganisms, suitable measures must be taken by the user.
Fundamentally, centrifuge containers with special screw closures must be used for hazardous substances. For
materials of risk groups 3 and 4, in addition to sealable centrifuge containers, a bio-safety system must be used
(see the "Laboratory Bio-safety Manual" from the World Health Organization).
In a bio-safety system, a bio-seal (sealing ring) prevents droplets and aerosols from escaping.
If the hanger of a bio-safety system is used without the lid, the sealing ring must be removed from the hanger to
prevent damage to the sealing ring during the centrifugation run.
Damaged bio-safety systems are no longer microbiologically sealed.
If a bio-safety system is not used, a centrifuge is not microbiologically sealed for the purposes of the standard EN
/ IEC 61010-2-020.
When closing a bio-safety system, follow the instructions in the chapter "Closing biosafety systems".
For the available bio-safety systems, see the chapter "Appendix, Rotors and accessories". If in doubt, you can
get the information you need from the manufacturer.
• The centrifuge must not be operated with highly corrosive substances which could impair the mechanical integrity
of rotors, hangers and accessories.
• Repairs must only be carried out by personnel authorised to do so by the manufacturer.
• Only original spare parts and original accessories licensed by the Andreas Hettich GmbH & Co. KG company are
allowed to be utilised.
• The following safety regulations apply:
EN / IEC 61010-1 and EN / IEC 61010-2-020 as well as their national deviations.
• The safe operation and reliability of the centrifuge can only be guaranteed if:
− the centrifuge is operated in accordance with the operating instructions,
− the electrical installation on the site where the centrifuge is installed conforms to the demands of EN / IEC
stipulations.
• Meeting the country-specific requirements concerning occupational safety with regard to the use of laboratory
centrifuges at the workplaces provided for this purpose by the user is the responsibility of the user.

EN
12/61 Rev. 02 / 05.2022 AB5005EN_SA
5 Symbol meanings
Symbol on the device:
Attention, general hazard area.
Symbol on the device:
Observe operating instructions.
This symbol indicates that the user must observe the operating instructions provided.
Symbol in this document:
Attention, general hazard area.
This symbol refers to safety relevant warnings and indicates possibly dangerous situations.
The non-adherence to these warnings can lead to material damage and injury to personal.
Symbol on the device and in this document:
Beware of biohazard.
Symbol on the device and in this document:
Beware of hot surface.
Nonobservance of this warning can lead to material damage and personal injury.
Symbol on the device:
Equipotential: Connector (PE connector) for potential equalization (only for centrifuge with PE
connector).
Symbol on the device:
Switch positions of the key-operated switch.
Symbol in this document:
This symbol refers to important circumstances.
Symbol on the device and in this document:
Symbol for the separate collection of electric and electronic devices according to the guideline
2002/96/EG (WEEE). The device belongs to Group 8 (medical devices).
Applies in the countries of the European Union, as well as in Norway and Switzerland.
Symbol on the shipping carton label:
This way up.
Symbol on the shipping carton label:
The shipping packaging must be transported and
handled within the indicated humidity range (10% - 80%).
Symbol on the shipping carton label:
The shipping packaging must be stored, transported and
handled within the temperature range shown (-20°C - +60°C).
Symbol on the shipping carton label:
The shipping packaging must be kept away from rain and
kept in a dry environment.
Symbol on the shipping carton label:
Fragile, handle with care.

EN
AB5005EN_SA Rev.02 / 05.2022 13/61
Symbol on the shipping carton label:
Stack limit. Maximum number of identical packages which may be stacked on the bottom package,
whereby “n“ stands for the number of permissible packages. The bottom package is not included in “n”.
6 Delivery checklist
4 Vibration absorber
1 Double open-end wrench 17/19 mm
1 Hexagonal pin-type spanner
1 Lubricating grease for trunnions
1 Operating instructions
3 Program-data sheet
1 Information on how to remove the packing
1 Installation information sheet
The rotor(s) and associated accessories are included in the delivery in the quantity ordered.
7 Unpacking the centrifuge and installation
Unpack and install the centrifuge in accordance with the instruction leaflets AH5005XX and AH5005-01XX provided.
8 Transport and storage
8.1 Transport
When the device and accessories are transported, the following ambient conditions must be complied with:
• Ambient temperature: -20°C to +60°C
• Relative humidity: 10% to 80%, non-condensing
8.2 Storage
The device and the accessories may only be stored in closed and dry rooms.
When the device and accessories are stored, the following ambient conditions must be complied with:
• Ambient temperature: -20°C to +60°C
• Relative humidity: 10% to 80%, non-condensing

EN
14/61 Rev. 02 / 05.2022 AB5005EN_SA
9 Initial operation
• A type B residual current circuit breaker must be used if the device is additionally protected with a residual current
circuit breaker in the building installation. If a different type is used, the residual current circuit breaker may switch
off the device even though there is no fault at the device.
• Types 5005-90 and 5005-08 are permanently connected devices. With permanently connected devices, a switch
must be fitted in the building installation to disconnect the mains supply to the device, in accordance with the
laboratory equipment standard EN / IEC 61010-1. The switch must be located near the device, be readily
accessible to the user and be marked as the means of isolation for this device. It must be possible to secure the
switch to prevent it being switched on again.
• Types 5005-80, 5005-90 and 5005-08, may only be installed by authorized skilled personnel.
These devices must be installed according to the enclosed set-up and installation instructions,
AH5005-02EN.
• Position the centrifuge in a stable and level manner in a suitable place. During set-up, the required safety
margin of 300 mm around the centrifuge is to be kept according to EN / IEC 61010-2-020.
When the centrifuge is running, according to EN / IEC 61010-2-020, no persons, dangerous
substances or objects may be within the safety margin of 300 mm around the centrifuge.
• Ventilation openings may not be blocked.
A distance of 300 mm must be maintained from the ventilation slots and openings of the centrifuge.
• Centrifuge with PE connector:
If required, connect the PE connector at the back of the device with an additional medical potential equalization
system.
• Check whether the mains voltage tallies with the statement on the type plate.
• For types 5005, 5005-50 and 5005-80:
Connect the centrifuge with the power cord to a standard mains socket. For connection ratings refer to Chapter
"Technical specification".
• Switch on the mains switch in the building installation.
• Switch on the switch on the front panel. Switch position "Ι".
The following display follows:
1. Type of centrifuge, 2. The last rotor code detected by the rotor identification and the maximum speed of the
rotor (n-max-Rotor), 3.The programme version, 4. OPEN OEFFNEN.
• Open the lid.
The centrifuge data of the last used program or program 1 will be displayed.

EN
AB5005EN_SA Rev.02 / 05.2022 15/61
10 Opening and closing the lid
10.1 Opening the lid
The lid can only be opened when the centrifuge is switched on and the rotor is at rest. If it cannot be
opened under these circumstances, see the section on “Emergency release”.
• Press the button on the front panel. The lid unlocks via the motor, the illuminated pushbutton extinguishes
and in the display the symbol changes to the symbol .
10.2 Closing the lid
Do not put your fingers between lid and housing.
Do not bang the lid shut.
• Place the lid and slightly press it down at the tubular handle. The locking action is effected by motor. The button
lights up and the symbol in the display turns to the symbol .
11 Installation and removal of the rotor
Rotor installation:
Dirt particles between the motor shaft and rotor prevent the rotor from
having a perfect seat and cause it to run unsteadily.
• Clean the motor shaft (C) and the bore of the rotor (A) and then apply a thin coat
of grease to the motor shaft.
• Place the rotor vertically onto the motor shaft. The driver of the motor shaft (D)
must be in the groove of the rotor (B). The groove alignment is marked on the
rotor.
• Tighten the clamping nut of the rotor by turning it in the clockwise direction
using the key included in delivery.
• Check the rotor to make sure it is seated firmly.
To ensure a tight fit of the rotor, the nut of the rotor must be hand-tightened.
Removing the rotor:
• Loosen the clamping nut by turning it in the counter clockwise direction up to the
lifting pressure point. After overcoming the lifting pressure point, the rotor is
released from the cone of the motor shaft.
• Turn the clamping nut until the rotor can be lifted up from the motor shaft.

EN
16/61 Rev. 02 / 05.2022 AB5005EN_SA
12 Inserting and removing hangers into/from the rotor
For swing-out rotors, all rotor places must be occupied with the
same hangers.
Certain hangers are marked with the number of the rotor place.
These hangers may only be inserted in the corresponding rotor
place.
Hangers which are labelled with a set number, e.g. S001/4,
may only be used in a set.
B
A
C
Inserting hangers in the rotor:
• Check the rotor to make sure it is seated firmly.
• Grease the lifting lug (C) (Hettich lubricating grease, no. 4051).
• Insert hangers (A) into the rotor. While doing so, make sure that the
lifting lugs (C) are in the grooves (B) of the hangers.
• Push the hangers downward as far as they can go.
Removing hangers from the rotor:
• Pull the hangers (A) straight upward and out of the rotor.
13 Inserting and removing the adapters into/from the hangers
Inserting the adapters into the hangers:
• Insert the adapters (A) horizontally into the hangers (B).
Remove the adapters from the hangers:
• Remove the adapters (A) upward and out of the hangers (B).
B
A
B
A

EN
AB5005EN_SA Rev.02 / 05.2022 17/61
14 Loading the rotor
Standard centrifuge containers of glass will not stand RCF values exceeding 4000 (DIN 58970, pg. 2).
• Check the rotor for firm seating.
• With swing-out rotors all rotor positions must be lined with identical hangers. Certain hangers are marked with
the number of the rotor position. These hangers may only be used in the respective rotor position. Hangers that
are marked with a set number (e.g. S001/4) may only be used in the set.
• The rotors and hangers may only be loaded symmetrically. The centrifuge containers have to be distributed
evenly on all rotor positions. For authorised combinations see Chapter "Anhang/Appendix, Rotoren und
Zubehör/Rotors and accessories".
In the case of angle rotors all possible rotor positions must be loaded, see chapter "Anhang/Appendix, Rotoren
und Zubehör/Rotors and accessories".
Rotor is loaded symmetrically. Not permitted!
Rotor is loaded asymmetrically.
Rotor is evenly loaded Not permitted!
Rotor is not evenly loaded
• When using blood bags, the following must be observed:
If the hangers are not filled to the same weight, the differences can be compensated with balance weights.
See the chapter "Rotors and accessories" for available compensation weights.
If there are not enough blood bag systems available to fully load the rotor, empty hangers can be equipped with
compensating inserts. If necessary, fine adjustment is carried out with the tare weights supplied.
See the chapter "Rotors and accessories" for available compensation inserts.
• On certain hangers, the weight of the maximum load or the weight of the maximum load and the maximum
weight of the completely loaded hanger is specified. This weight may not be exceeded. In case of exception, see
chapter " Centrifugation of materials or mixtures of materials with a density higher than 1.2 kg/dm3". The weight
specification of the maximum load includes the total weight of the adapter, centrifuge container and contents.
• In containers with rubber inserts, the same number of rubber inserts must always be among the centrifuge
containers.
• The centrifuge containers may only be filled outside of the centrifuge.

EN
18/61 Rev. 02 / 05.2022 AB5005EN_SA
• The maximum filling quantity for the centrifuge containers specified by the manufacturer must not be exceeded.
In the case of angle rotors, the centrifuging
vessels may only be filled so far that no fluid
can be expelled from them while the centrifuge
is running.
Fluid
Centrifugal force
• When loading the angle rotors, no liquid may get into the angle rotors or centrifuging chamber.
• When loading the hangers and swing-out rotors and when swivelling out the hangers while the centrifuge is
running, no liquid may enter the hangers or the centrifuging chamber.
• In order to maintain the weight differences within the centrifuge container as marginal as possible, a consistent
fill level in the containers is to be heeded.
15 Closing biosafety systems
In order to guarantee that it is sealed, the lid to the biosafety system has to be firmly closed.
In order to prevent the packing ring from twisting when opening and closing the cover, the packing ring must
be lightly rubbed with a rubber care product.
For further details of available biosafety systems see chapter "Anhang/Appendix, Rotoren und Zubehör/Rotors
and accessories". If in doubt, you should obtain relevant information from the manufacturer.
Lid with clip lock
• Put the lid on the hanger and push down both clamps until they are underneath
the loops on the hanger.
• Fold down both clamps as far as they can go. The clamps have to lie flat against
the hanger.

EN
AB5005EN_SA Rev.02 / 05.2022 19/61
16 HettLiner packing instructions
16.1 Packing before centrifugation
Note: Make sure that the plastic insert cannot tip over when loading and unloading the inserts (use loading aid 4509).
• Insert the blood bag (a) into the insert
(b).
• Hold the blood bag at the connections
(c) and push the support plate (d) on
the outer side of the blood bag from
top to bottom into the insert
• Make sure that the lower edge of the
support plate rests as completely as
possible on the floor.
• Fold the support plate outwards and
push it down until the folded edge of
the support plate is level with the
liquid level of the blood bag.
• The position of the loop (e) must be
observed so that it can be reached
after centrifugation!
• The upper edge of the support plate
must not protrude too far from the
insert during centrifugation due of the
risk of jamming with the rotor arms!
• If available, fold empty satellite bag(s) and pack differently depending on the appropriate accessories and
filling volume of the blood bag.
It is a good idea to fold the satellite bags and pack them on the outside between the folded support plate
and the outer wall of the insert.
→Make sure that the silicone plate does not slip while doing this!
→If necessary, the silicone plate can be held by the loop when packing the satellite bag and thus held
against it
→The position of the loop must be checked afterwards!
• Place the connections over the support plate so that the valves cannot break.
Make sure the tubes do not protrude from the insert!
→Stow tube sections protruding over the edge of the insert between the folded down support plate and the
insert wall.
• Balance weights should be placed between the folded down support plate and the bucket wall if needed.
a
b
b
a
c
d
d
c
e
e

EN
20/61 Rev. 02 / 05.2022 AB5005EN_SA
16.2 Unpacking after centrifugation
• Pull the satellite bag out of the insert while holding the silicone plate in place with one hand.
• Slowly pull out the folded part of the support plate at the loop provided!
→Caution: Carefully return the support plate to its original shape!
→The folded part of the support plate can spring back and mix blood components.
• Remove the remaining blood bag from the insert either together with the support plate or after removing the
support plate!
