HiB Vanquish 50 47600 User manual

Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to them during installation to ensure that
your product is tted safely and that it retains its high quality nish.
Please retain this booklet for future reference.
Before drilling or cutting, ensure there are no hidden cables or pipes in the wall.
Vanquish 50, 60, 80 & 120 Cabinet
FI #02 015 R161114 Ver No. 1.0 Jan 2017
Vanquish 50
Art No. 47600
Vanquish 60 & 80
Art No. 47700 & 47800
Vanquish 120
Art No. 47900

2
holes with the supplied screws (two on
each side) See Fig. D.
7. Insert metal shelf supports in desired
position. Put glass shelf into shelf supports
and tighten the plastic grub screw whilst
holding the metal support. This will
securely clamp the shelf into position see
Fig.E.
8. If necessary, hinges can be adjusted to
reposition the door(s) see Fig.F.
9. Switch mains supply back on.
Please Note
This product can only be recessed tted into a wall. Before installing ensure you take note of
measurements of the recessed area and the side xing points inside the cabinet carcass (See g. A & D).
You may need to remove the door / doors to make it easier to t. This can be done by un-clipping the
hinges. (There is a release catch at the back of the hinge). DO NOT FIT SHELVES AT THIS STAGE.
Operation Instructions
This cabinet is tted with colour temperature
changing technology.
To turn illumination on, touch the sensor once.
To change the colour temperature, touch and
hold the sensor until desired colour is obtained.
The colour temp is then set until changed again.
Heated Pad is only on when mirror is illuminated.
Care Instructions
Do not use abrasives or solvents when cleaning
this product.
Wipe o all water spillages as soon as possible
using a soft, damp cloth.
Aercare Service
In the unlikely event that this product should fail
please contact HiB customer services, contact
detail shown on the back page.
Charging Socket(s)
Charger socket(s) are suitable for charging
and powering electric razors, trimmers and
toothbrushes. Some cabinets may contain
multiple charging sockets.
NB. On rst use of the charger socket, inserting the
plug may prove to be sti. Reasonable force may
be required to fully insert the plug. Make sure that
the cabinet is held rmly so that it is not pushed o
the wall. After a few uses, stiness will ease and the
socket will function as normal.
Electrical Safety Information
HiB recommends that all electrical bathroom
products should only be tted by a suitably
qualied, Part P registered electrician in
accordance with current IEE regulations.
Ensure mains power supply is switched o
before starting installation. Before drilling, ensure
there are no hidden cables or pipes in the wall.
Fixing Preparation
Before installation, ensure the construction of
the partition wall is suitable to accommodate for
the size and weight of a recessed cabinet.
The cabinet should be placed in a suitable
location, (according to the zonal diagram (Fig. 1)
on the back page).
Ensure the domestic electrical mains supply to
which the cabinet is being connected is turned
o.
1. Measure the dimension of the cabinet
carcass (but not the front aluminium fascia).
2. Using these dimensions, take a soft pencil
and mark the outline for the required
aperture in the wall. Take great care to
mark this accurately, straight and level.
3. Using an appropriate tool, cut or channel
out the aperture in the wall where the
cabinet will t (Fig. A).
4. If it is necessary, install supporting baton(s)
or noggin(s) around the recessed area (see
Fig. B) to which the cabinet can be secured.
These supports must be completely vertical
and parallel to the cabinet to prevent the
cabinet twisting when tted.
5. Connect the domestic mains supply
according to the wiring diagram (See Fig.
2) on the back page and manoeuvre the
cabinet into the wall aperture (See Fig. C).
6. Using a suitable screwdriver or drill, secure
the cabinet into the wall aperture, via two

hib.co.uk 3
Move door(s) up/down
Move door away/towards
the cabinet
Move door(s) left/right
(Fig. F) Door Adjustment
(Fig. A) (Fig. B)
(Fig. D)
(Fig. C)
(Fig. E)

©HiB Copyright: No part of this document may be reprinted or duplicated without HiB consent. All sizes and measurements are approximate, but we do try and
make sure they are as accurate as possible. In the interest of continuous product development, HiB reserves the right to alter specications as necessary. E & OE.
T: [phone] F: [phone] E: [email protected]o.uk hib.co.uk
Building 3, North London Business Park, Oakleigh Road South, New Southgate, London. N11 1GN
Wiring Diagram (Fig 2)
WEEE Compliance
Must not be mixed with general household waste.
This product is suitable for installation in zones: 2 &Outside Zone
All installations must comply with guidelines which are based on a zonal concept. The diagram above
illustrates this concept and must be followed to ensure the safe installation of electrical appliances in the
bathroom. These regulations apply to domestic installations only. Installations must be made in accordance
with the current IEE wiring regulations and relevant building regulations. HiB recommends that all electrical
bathroom products should only be tted by a suitably qualied, Part P registered electrician.
(Fig. 1)
live
earth
neutral
MAINS SUPPLY
LUMINAIRE
Live supply can be Red or Brown
Earth supply is Green and Yellow
Neutral supply can be Blue or Black
Live is Brown
Earth is Green and Yellow
Neutral is Blue
Electrical Safety Information
HiB recommends that all electrical bathroom products should only be tted by a suitably qualied, Part P
registered electrician in accordance with current IEE regulations. Ensure mains power supply is switched o
before starting installation. Before drilling, ensure there are no hidden cables or pipes in the wall.
