USER GUIDE:
1101 UHF RFID READER FOR
THE MOTOROLA MC70/75/75A
TECHNOLOGY
SOLUTIONSUK LTD

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 2
TERMS & CONDITIONS
© 2021 TSL. All rights reserved.
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from Technology Solutions (UK) Ltd. This includes electronic or mechanical means,
such as photocopying, recording, or information storage and retrieval systems. The material in this manual is
subject to change without notice.
Technology Solutions (UK) Ltd (TSL) reserves the right to make changes to any product to improve reliability,
function, or design. TSL does not assume any product liability arising out of, or in connection with, the application
or use of any product, circuit, or application described herein. No license is granted, either expressly or by
implication, estoppel, or otherwise under any patent right or patent, covering or relating to any combination,
system, apparatus, machine, material, method, or process in which TSL products might be used. An implied
license exists only for equipment, circuits, and subsystems contained in TSL products. TSL and the TSL logo are
registered trademarks of TSL. Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.
All software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on
a licensed basis. TSL grants to the user a non-transferable and non-exclusive license to use each software or
firmware program delivered hereunder (licensed program). Except as noted below, such license may not be
assigned, sublicensed, or otherwise transferred by the user without prior written consent of TSL. No right to
copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall
not modify, merge, or incorporate any form or portion of a licensed program with other program material, create
a derivative work from a licensed program, or use a licensed program in a network without written permission
from TSL. The user agrees to maintain TSL’s copyright notice on the licensed programs delivered hereunder, and
to include the same on any authorized copies it makes, in whole or in part. The user agrees not to decompile,
disassemble, decode, or reverse engineer any licensed program delivered to the user or any portion thereof.
TSL reserves the right to make changes to any software or product to improve reliability, function, or design.
TSL does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
Symbol is a registered trademark of Motorola Technologies, Inc.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 3
History
Version Date Modifications
1.0 28/04/2010 Document creation
1.1 28/04/2010 Added regulatory information
1.2 23/07/2010 Updated regulatory information
1.3 26/11/2010 Added improved read zone illustration, more regulatory updates.
1.4 17/11/2011 Changed from custom serial cable to Micro USB cable
1.5 01/06/2012 Changed ‘Charging/ActiveSync Connection’ image, expanded ‘LED status’
chart
CONTENT
Introduction 4
Parts of the 1101 UHF Reader 4
Attaching to an MC70/75 5
Detaching from an MC70/75 5
Battery Installation or Removal 6
Charging and ActiveSync Connection 7
Connecting the Charger Cable 7
Status LED 8
Reading Transponders 9
Antenna location and read direction 9
Holding the reader 9
Transponder orientation 10
Read and Write range 11
Software 11
Driver Installation 11
Reader Demonstration 11
Software Development 12
General Notes 12
Compatible peripherals 12
ActiveSync 12
Troubleshooting and Maintenance 13
Maintenance 13
Troubleshooting 13
Technical specifications 14
Summary of specifications 14
Regulatory Information 15
FCC 15
Industry Canada 15
Health and Safety Recommendations 16
Waste Electrical and Electronic Equipment (WEEE) 17
Warranty 17
About TSL 19
About 19
Contact 19
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 4
INTRODUCTION
Technology Solutions’ 1101 UHF Reader provides the Motorola MC70/75 with Radio Frequency Identification (RFID)
functionality. The unit attaches as a snap on to the MC70/75. The mechanical design of the unit allows it to be
quickly and easily removed, alternatively two screws may be used to make the installation semi-permanent.
The 1101 UHF reader is powered from its own internal battery and does not draw power from the MC70/75. It is
used with UHF transponders including the EPCGlobal Class 1 Generation 2 transponders.
PARTS OF THE 1101 UHF READER
FIGURE 1: Parts of the 1101 UHF Reader
MC70/75/75A mating connector
Status LED
Micro USB and
Charge connectors
Antenna located
on reverse of unit.
Latch locking
screw hole
Latch locking
screw hole
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 5
FIGURE 3: Detaching from an MC70/75
FIGURE 2: Attaching to an MC70/75
ATTACHING TO AN MC70/75
For semi-permanent installation fit M2×6mm pan head
Pozidriv screws into the latch locking screw holes.
DETACHING FROM AN MC70/75
Align the slots on the MC70/75
with the guides on the spring
clips of the 1101 UHF Reader.
Spring Clip
Slide the 1101 UHF Reader on to the
MC70/75 ensuring the MC70/75 aligns
with the MC70/75 mating connector on
the 1101 UHF Reader. The spring clips
will push out and then click in as the
MC70/75 locks in place.
Remove the latch locking screws if fitted.
Squeeze the spring clips together by
pressing on the latch locking screw holes.
Slide the 1101 UHF
Reader off the MC70/75.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 6
BATTERY INSTALLATION OR REMOVAL
FIGURE 4: 1101 UHF Reader Battery
The battery is located under the front cover of the UHF reader. To access the battery compartment:
●Remove the locking screw next to the status LED (if fitted)
●Apply a gentle pressure to the top of the cover either side of the TSL logo and push the cover away as shown
●The cover can then be slid off the reader
●The battery can then be removed
Ensure the battery is fully charged before first use.
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
Dispose of used batteries according to local regulations.
Push down and slide to remove cover.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 7
CHARGING AND ACTIVESYNC CONNECTION
FIGURE 5: Connecting the Charger Cable
The USB connection connects to a desktop computer to provide USB ActiveSync functionality to the MC70/75.
The power connector is compatible with the standard Motorola 5.4V chargers for the MC70/75. When in use
through the accessory both the 1101 UHF reader and the MC70/75 will be charging.
CONNECTING THE CHARGER CABLE
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 8
CHARGING AND ACTIVESYNC CONNECTION
STATUS LED
The status LED on the front of the 1101 UHF Reader provides an indication of the operating status of the 1101 UHF
Reader.
●Green LED indicates the reader is ready to talk to the software
●Red LED indicates charge status
●Amber LED occurs when both the green and red LEDs are lit simultaneously
LED colour and pattern Connection and Charge Status
Off Disconnected from software, not charging
Green continuous Connected to software, not charging.
Amber single flash and green pause Connected to software and charging. The reader
battery is less than 33% charged.
Amber double flash and green pause Connected to software and charging. The reader
battery is between 33% and 66% charged.
Amber triple flash and green pause Connected to software and charging. The reader
battery is between 66% and fully charged.
Amber continuous Connected to software. The reader battery is fully
charged.
Green/Amber continuous flash Connected to software. There is a charge error / battery
fault.
Red single flash and pause Disconnected from software and charging. The reader
battery is less than 33% charged.
Red double flash and pause Disconnected from software and charging. The reader
battery is between 33% and 66% charged.
Red triple flash and pause Disconnected from software and charging. The reader
battery is between 66% and fully charged.
Red continuous Disconnected from software. The reader battery is fully
charged.
Red continuous flash Disconnected from software. There is a charge error /
battery fault.
Note: On earlier versions of the 1101 UHF Reader charge status is not supported
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 9
READING TRANSPONDERS
FIGURE 6: Antenna location and read direction
RFID transponders can be read when they are in range of the antenna. The antenna is located on the back of the
1101 UHF Reader.
ANTENNA LOCATION AND READ DIRECTION
Antenna located behind this cover.
FIGURE 7: Correct read orientation
For best results the reader should be held so that the transponders are behind the reader as shown in Figure 7.
HOLDING THE READER
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 10
READING TRANSPOND
The 1101 UHF RFID reader has a circularly polarised antenna. This means that the alignment of the transponder
relative to the reader is unimportant. In many cases a transponder will only be sensitive along two of its three
axes. Read and write performance will be poor along its insensitive axis. Figure 8 shows the correct and incorrect
orientations for a typical transponder relative to the 1101 UHF reader.
TRANSPONDER ORIENTATION
FIGURE 8: Correct transponder orientation
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 11
READING TRANSPOND
The range at which a transponder can be read depends on the transponder type, size and location. Generally;
●larger transponders can be read at greater distances
●moving transponders closer to each other reduces read distance
●metal or water nearby reduces read range, unless a mount on metal transponder is used
●write range is between 50% and 90% of the read range for a given transponder.
READ AND WRITE RANGE
SOFTWARE
The drivers required for the 1101 UHF READER are deployed as part of any application written using Technology
Solution’s software development kit. The unit is automatically powered up when the serial port on the bottom of the
MC70/75 (COM1) is opened.
DRIVER INSTALLATION
Technology Solutions provide a demonstration application which can be used to explore the functionality of the
1101 UHF Reader and test the read range for a particular transponder. This application and full instructions are
available for download from the Technology Solutions website at
https://www.tsl.com/downloads/tsl-products/1101-downloads/
An example screenshot of the Demonstration software is shown in Figure 9.
READER DEMONSTRATION
FIGURE 9 : Demonstration software
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 12
SOFTWARE
To make full use of the functionality of the 1101 UHF Reader, a customised software application will be required.
There are two approaches that can be taken:
●For basic applications requiring minimal software development expertise the reader supports an ASCII
command mode. Simple, text based commands are sent to the reader and responses are returned as
text. This allows straightforward access to RFID tag functions such as inventory, read and write. Details
of the ASCII command mode are included on the Explorer Kit CD and are available for download from
https://www.tsl.com/downloads/tsl-products/1101-downloads/ . A simple Motorola Pocket Browser compatible
application which uses the ASCII command mode is included on the Explorer Kit CD.
●For more advanced application requiring full control and configuration of the reader a full managed code API
is provided on the Explorer Kit CD. This is supported with the source code for a sample application which
demonstrates the use of all the reader functionality.
SOFTWARE DEVELOPMENT
GENERAL NOTES
The 1101 UHF Reader is not compatible with other MC70/75 peripherals that attach to the MC70/75.
It is charged using a standard Motorola 5.4V power supply via the supplied ActiveSync and charge cable.
COMPATIBLE PERIPHERALS
The MC70/75 with 1101 UHF Reader attached can be used with ActiveSync, but the USB rather than the serial
connection must be used.
ACTIVESYNC
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 13
MAINTENANCE
TROUBLESHOOTING
For trouble-free service treat the 1101 UHF tt in the same way as you would the MC70/75 and observe the following
tips when using the 1101 UHF Reader:
●Do not store or use the 1101 UHF Reader in any location that is dusty, damp, or wet.
●Protect the 1101 UHF Reader from temperature extremes. Do not leave it on the dashboard of a car on a hot
day, and keep it away from heat sources.
TROUBLESHOOTING AND MAINTENANCE
Symptoms Possible cause Action
The Application on the MC70/75
cannot communicate with the
1101 UHF Reader.
The MC70/75 is not firmly seated
into the 1101 UHF Reader.
Remove and re-insert the MC70/75 from
the 1101 UHF Reader, ensuring it is
firmly seated.
The port has not been opened. Check that the Application has been
configured to use COM1.
The port is in use by another
application.
Close the other application and try
again.
The 1101 UHF Reader does not
read a particular transponder
The 1101 UHF Reader has been
configured to exclude some
transponders based on a mask
value.
Correct the mask value.
The transponder is out of range of
the 1101 UHF Reader.
Move the transponder closer to the
antenna.
The transponder has been
inventoried into a persistent
session.
Wait for the session persistence to
expire, use a different session or use a
different target flag.
MC70/75 battery does not charge The battery is faulty. Verify that other batteries charge
properly. If so, replace the faulty battery.
Ambient temperature is too warm. Move the unit to an area where the
ambient temperature is between 0°C
and 35°C.
The MC70/75 is not firmly seated
into the 1101 UHF Reader.
Remove and re-insert the MC70/75 from
the 1101 UHF Reader, ensuring it is
firmly seated.
ActiveSync cannot connect to the
MC70/75
ActiveSync is not correctly
configured on the PC or the
MC70/75.
Detach the 1101 UHF Reader from the
MC70/75 and try to ActiveSync directly
to the MC70/75. If this does not work
then consult the MC70/75 User Guide.
The MC70/75 is not firmly seated
into the 1101 UHF Reader.
Remove and re-insert the MC70/75 from
the 1101 UHF Reader, ensuring it is
firmly seated.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 14
The following table summarises the 1101 UHF Reader’s intended operating environment and technical hardware
specifications:
TECHNICAL SPECIFICATIONS
SUMMARY OF SPECIFICATIONS
Symptoms
Frequenc 865 – 868 MHz (ETSI version)
902 – 928 MHz (FCC version)
RF Power 10 - 800 mW (10dBm to 29dBm) (software controlled)
Antenna Circularly Polarised radiating from the back plane of the reader and host
terminal.
Read distance Up to 2m (6 feet) (tag/antenna dependent)
Supported UHF tags EPC Class 1 Generation 2 (ISO18000-6C)
Physical Characteristics
Dimensions (without host terminal) 87(w) × 135 max (l) × 42(d) – 3.43” x 5.31” x 1.65”
Weight 295g (10.4 oz)
Enclosure material GE Lexan Polycarbonate
Colour Grey
Material finish Sparked surface
Mechanical attachment to hand
scanner
Snap-on action with locking screws
Environmental
Operating Temperature -20°C to +60°C (-4°F to 140°F)
Storage Temperature -40°C to +60°C (-40°F to 140°F)
Humidity Up to 90% Relative humidity Non Condensing
Drop specification 1.3m (4.26ft) to concrete, 6 drops per 6 sides over operating temperature
Sealing Conformal coated electronics
Electrostatic discharge +/-15kV air discharge, +/-8kV direct discharge
Construction RoHS compliant
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 15
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference that may cause undesired operation.
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate
this equipment.
REGULATORY INFORMATION
FCC
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired operation of the
device.
INDUSTRY CANADA
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 16
Ergonomic Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury, follow the recommendations below.
Consult with your local Health & Safety Manager to ensure that you are adhering to your company’s safety
programs to prevent employee injury.
●Reduce or eliminate repetitive motion
●Maintain a natural position
●Reduce or eliminate excessive force
●Keep objects that are used frequently within easy reach Perform tasks at correct heights
●Reduce or eliminate vibration
●Reduce or eliminate direct pressure
●Provide adjustable workstations
●Provide adequate clearance
●Provide a suitable working environment
●Improve work procedures.
For vehicle installation and use
An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless
equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles (including
safety systems). Check with the manufacturer or its representative regarding your vehicle. You should also consult
the manufacturer of any equipment that has been added to your vehicle.
Power Supply
Use only Motorola-approved cradles, chargers and power supplies with the HF 1097 UHF Reader. Use of an
alternative power supply will invalidate any approval given to this device, void the warranty for the product and may
be dangerous.
HEALTH AND SAFETY RECOMMENDATIONS
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 17
For EU Customers: All products at the end of their life must be returned to TSL for recycling. For information on how
to return product please contact TSL.
WARRANTY
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
(WEEE)
(A) Warranty
TSL’s hardware Products are warranted against defects in workmanship and materials for a period of twelve (12) months
from the date of shipment, unless otherwise provided by TSL in writing, provided the Product remains unmodified and is
operated under normal and proper conditions. Warranty provisions and durations on software, integrated installed systems,
Product modified or designed to meet specific customer specifications (“Custom Products”), remanufactured products, and
reconditioned or upgraded products, shall be as provided in the applicable Product specification in effect at the time of
purchase or in the accompanying software license.
(B) Spare Parts
Spare parts (i.e. parts, components, or subassemblies sold by TSL for use in the service and maintenance of Products) are
warranted against defects in workmanship and materials for a period of thirty (30) days from the date of shipment. Spare parts
may be new or originate from returned units under the conditions set forth in subsection D below.
(C) Repair of TSL branded hardware
For repairs on TSL branded hardware Products under this Agreement, including repairs covered by warranty, the repair services
provided are warranted against defects in workmanship and materials on the repaired component of the Product for a period
of thirty (30) days from the shipment date of the repaired Product, or until the end of the original warranty period, whichever is
longer. Any such defects shall be notified to TSL in writing within 7 days of the same becoming apparent.
(D) Product Service
Products may be serviced or manufactured with parts, components, or subassemblies that originate from returned products and
that have been tested as meeting applicable specifications for equivalent new material and Products. The sole obligation of TSL
for defective hardware Products is limited to repair or replacement (at TSL’s option) on a “return to base (RTB)” basis with prior
TSL authorisation.
Customer is responsible for prompt shipment to TSL and assumes all costs and risks associated with this transportation; return
shipment to the Customer will be at TSL’s expense. Customer shall be responsible for return shipment charges for product
returned where TSL determines there is no defect (“No Defect Found”), or for product returned that TSL determines is not
eligible for warranty repair. No charge will be made to Buyer for replacement parts for warranty repairs. TSL is not responsible
for any damage to or loss of any software programs, data or removable data storage media, or the restoration or reinstallation of
any software programs or data other than the software, if any, installed by TSL during manufacture of the Product.
(E) Original Warranty Period
Except for the warranty applying solely to the repaired component arising from a repair service as provided in Section C above,
the aforementioned provisions do not extend the original warranty period of any Product that had either been repaired or
replaced by TSL.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 18
WARRANTY
(F) Warranty Provisions
The above warranty provisions shall not apply to any Product:
(i) which has been repaired, tampered with, altered or modified, except by TSL’s authorized service personnel;
(ii) in which the defects or damage to the Product result from normal wear and tear, misuse, negligence, improper storage, water
or other liquids, battery leakage, use of parts or accessories not approved or supplied by TSL, or failure to perform operator
handling and scheduled maintenance instructions supplied by TSL;
(iii) which has been subjected to unusual physical or electrical stress, abuse, or accident, or forces or exposure beyond normal
use within the specified operational and environmental parameters set forth in the applicable Product specification; nor shall the
above warranty provisions apply to any expendable or consumable items, such as batteries, supplied with the Product.
EXCEPT FOR THE WARRANTY OF TITLE AND THE EXPRESS WARRANTIES STATED ABOVE, TSL DISCLAIMS ALL
WARRANTIES ON PRODUCTS FURNISHED HEREUNDER INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR USE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED IN
DURATION TO THE LIMITED WARRANTY PERIOD. SOME STATES OR COUNTRIES DO NOT ALLOW A LIMITATION ON
HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR CONSUMER PRODUCTS. IN SUCH STATES OR COUNTRIES, FOR SUCH PRODUCTS, SOME EXCLUSIONS OR
LIMITATIONS OF THIS LIMITED WARRANTY MAY NOT APPLY.
The stated express warranties are in lieu of all obligations or liabilities on the part of TSL for damages, including but not limited
to, special, indirect or consequential damages arising out of or in connection with the use or performance of the Product or
service. TSL’s liability for damages to Buyer or others resulting from the use of any Product or service furnished hereunder shall
in no way exceed the purchase price of said Product or the fair market value of said service, except in instances of injury to
persons or property.
TSL is not responsible for any damages incurred during shipment if the approved shipping container is not used. Shipping the
units improperly can possibly void the warranty. If the original shipping container was not kept, contact your local distributor or
TSL to have another sent to you.
TSL shall not be responsible for any injury, damage or loss of whatever kind caused directly or indirectly by the goods whether
as a result of their manufacture, operation, use or otherwise and the customer shall indemnify TSL from any claim arising from
any loss suffered by any third party.
www,tsl.com

1101 UHF Reader User Guide V1.51Copyright © Technology Solutions (UK) Ltd 2021 19
ABOUT
ABOUT TSL®
CONTACT
ISO 9001: 2015
Technology Solutions UK Ltd (TSL®), part of HID Global, is a leading manufacturer of high performance mobile
RFID readers used to identify and track products, assets, data or personnel.
For over two decades, TSL®has delivered innovative data capture solutions to Fortune 500 companies around the
world using a global network of distributors and system integrators. Specialist in-house teams design all aspects of
the finished products and software ecosystems, including electronics, firmware, application development tools, RF
design and injection mould tooling.
TSL®is an ISO 9001:2015 certified company.
TECHNOLOGY
SOLUTIONSUK LTD
Address: Technology Solutions (UK) Ltd, Suite A, Loughborough Technology Centre, Epinal Way,
Loughborough, Leicestershire, LE11 3GE, United Kingdom.
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.tsl.com
Technology Solutions (UK) Ltd reserves the right to change its products, specifications and services at any time without notice.
HID Global powers the trusted identities of the world’s people, places and things. We make it possible
for people to transact safely, work productively and travel freely. Our trusted identity solutions give people
convenient access to physical and digital places and connect things that can be identified, verified and tracked
digitally. Millions of people around the world use HID products and services to navigate their everyday lives, and
billions of things are connected through HID technology. We work with governments, educational institutions,
hospitals, financial institutions, industrial businesses and some of the most innovative companies on the planet.
Headquartered in Austin, Texas, HID Global has over 4,000 employees worldwide and operates international offices
that support more than 100 countries. HID Global is an ASSA ABLOY Group brand.
For more information, visit www.hidglobal.com.
ABOUT HID GLOBAL
www,tsl.com
