HIKOKI CB12-ST2 User manual

Band Saw Stand
帶鋸機台架
Handling instructions
使用說明書
en
zh
en
zh
00Book_Band Saw Stand.indb 100Book_Band Saw Stand.indb 1 2021/10/22 13:15:232021/10/22 13:15:23

2
English
STANDARD ACCESSORIES
Contour table Slide cover
Used when carrying out
contour cutting work.
Used to prevent the band
saw blade from being
exposed during contour
cutting work.
One One
Slide cover holder Butterfly bolt
(5 mm)
Used to install the slide
cover and adjust its
position during work.
Used to install the slide
cover holder on the main
unit.
One One
Vise guide Hexagonal wrench
(4 mm)
Used to adjust the angle
of the band saw blade
and cut thin or small
diameter workpieces.
Used to adjust the lower
limit position of the band
saw blade.
One One
Hexagonal wrench (8 mm) Knob bolts
Bolt washers
Used to move vise (B)
and adjust the positions
of the hinges.
Used to install a band
saw on the band saw
stand.
One Two each
BAND SAW STAND SAFETY
WARNINGS
●Correctly install the band saw stand by following the
instructions provided in the manual.
●In order to prevent accidents, when installing or removing
the band saw stand, turn the switch of the rotary band
saw off. If your band saw has a power cord, remove the
power plug from the outlet. If your band saw is a cordless
model, remove the battery from the main unit.
●After installing the band saw on the band saw stand,
follow the instructions provided in the manual of the
rotary band saw.
NAMES OF PARTS
Stopper bolt
Screw hole for keeping the stopper bolt
Knob
Clutch
Vise (A)
Vise (B)
Hinge (B)
Hinge (A)
Wheel
Base
D6 knob bolt
Bolt washer
[Opposite side]
Hexagonal wrenches
(4 mm and 8 mm)
Spring stopper
Spring
Fig. 1
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
To reduce the risk of injury, user must read
instruction manual.
Warning
00Book_Band Saw Stand.indb 200Book_Band Saw Stand.indb 2 2021/10/22 13:15:232021/10/22 13:15:23

3
English
APPLICATIONS
Band saw stand especially designed for stationary
implementation of right-angle cutting, angle cutting, and
contour cutting work, for use with the following HiKOKI
band saw: CB3612DA
For details regarding the latest available band saw, check
our general catalogue and other information.
SPECIFICATIONS
Model CB12-ST2
Max. cutting
capacity* 90°
Round pipe Φ115 mm
Square pipe Width 100 mm x Height
100 mm
45°
Round pipe Φ50 mm
Square pipe Width 50 mm x Height
50 mm
Weight 14.5 kg
* Maximum cutting capacity possible when a rotary band
saw is installed
HOW TO USE
1. Installing the band saw stand and switch holder
(1) Move the lever switch to the OFF position, and remove
the battery from the main tool unit.
(2) When the stopper bolt is loosened, the hinges of the
band saw stand will fall over backward (toward the
wheels) due to the force of the spring.
While loosening the stopper bolt, hold the top of the
hinges so that they do not fall over backward. (Fig. 2)
Stopper bolt
Wheel
Fig. 2
(3) Align the hole in the side of pulley guard (A) with the D8
pin of hinge (A), and insert the D8 pin into the hole. (Fig. 3)
(4) One D6 knob bolt is provided on each of the front and
rear sides of hinge (B). Only tighten the one on the rear
side. (Fig. 3)
Hole
D6
knob bolt
Rear side of
the band saw
D8 pin Hinge (A)
Hinge (B)
Pulley guard
(A)
Fig. 3
NOTE
The switch holder needs to be installed in order to use
the band saw installed on the stand.
(5) While pressing the switch lock, pull the switch and fit the
switch holder into position.
This locks the switch in the ON position. (Fig. 4)
(6) Tighten the D6 knob bolt on the front side.
When the installation procedure has been correctly
carried out, the switch lock is held in the pressed
position. (Fig. 4)
Switch lock
Switch holder D6 knob bolt
Switch
Fig. 4
Switch holder
(standard
accessory
of CB3612DA)
00Book_Band Saw Stand.indb 300Book_Band Saw Stand.indb 3 2021/10/22 13:15:232021/10/22 13:15:23

4
English
(7) Check that the D6 knob bolt on the rear side is correctly
tightened, and that the main tool unit is securely
installed on the stand. (Fig. 5)
Rear side
of the
band saw
Front side
of the
band saw
Hinge (B)
Fig. 5
2. Operating the switch
After installing the band saw on the stand, check that the
switch can be correctly operated.
(1) Check that the band saw stand is correctly secured, and
that the lever switch is in the OFF position. (Fig. 6)
OFF
ON
Lever switch
Fig. 6
(2) Install the battery on the main tool unit.
(3) Check that the band saw blade is not touching anything,
then turn the lever switch ON and OFF to check that the
band saw operates correctly.
NOTE
The lever switch does not function unless the switch is
held in the ON position using the switch holder.
3. Adjusting the lower limit position of the band saw
blade
Adjust the positions of the base of the band saw stand
and the tip of the band saw blade. (Fig. 7)
(1) Remove the stopper bolt and screw it several turns into
the screw hole for keeping the stopper bolt.
(2) Slowly move the main tool unit down, and adjust the
position of the guide plate so that the tip of the band saw
blade stops approximately 2 mm below the top surface
of the base. (Use the 4-mm hexagonal wrench supplied
as a standard accessory.)
(3) After finishing the adjustment, firmly secure the guide
plate using two M6 screws.
2mm
Guide plate
Stopper bolt
Top surface of the base
Band saw blade
M6 screws
Fig. 7
4. Adjusting the perpendicularity of the band saw
blade
<Adjustment of the perpendicularity between vise (B) and
the band saw blade (Fig. 8)>
(1) Loosen the two vise (B) adjustment bolts using the 8-mm
hexagonal wrench supplied as a standard accessory.
Ensure that vise (A) is away from vise (B).
(2) Place the vise guide supplied as a standard accessory
as shown in the figure. Move the main tool unit down to
lightly press the vise guide against the side of the band
saw blade and the guide plate.
(3) Lightly press the vise guide so that it does not move, and
place vise (B) so that it comes in contact with the vise
guide.
Tighten the two vise (B) adjustment bolts to firmly secure
vise (B) in that position.
Vise guide Vise (B)
adjustment bolt
Vise (B)
Vise (A)
Band saw blade Guide plate
Fig. 8
NOTE
If a higher level of cutting precision is required, adjust the
vise position using a speed square.
00Book_Band Saw Stand.indb 400Book_Band Saw Stand.indb 4 2021/10/22 13:15:242021/10/22 13:15:24

5
English
<Adjustment of the perpendicularity between the top surface
of the base and the band saw blade>
(1) Apply the vise guide to vise (B), and lightly secure the
vise guide using vise (A). (Fig. 9)
Vise (B)
Vise (A) Vise guide
Fig. 9
(2) Loosen the two band saw adjustment bolts using
the 8-mm hexagonal wrench supplied as a standard
accessory.
Hold the front handle and move the main unit up and
down to adjust its angle so that a uniform amount of
clearance is created between the side of the vise guide
and the band saw blade. (Fig. 10)
(3) Tighten the two band saw adjustment bolts to firmly
secure hinge (B).
NOTE
If a higher level of cutting precision is required, adjust the
vise position using a speed square.
Hinge (A)
To p s u r f a c e
of the base
Band saw
blade
Band
saw blade
Side of the
vise guide
Band saw
adjustment bolts
Hinge (B)
Fig. 10
5. Setting the cutting load
In order to set the cutting load, lift and hold the main unit
at the upper limit position, then change the position of the
spring stopper. (Fig. 11)
When cutting thin wall steel pipes (with a wall thickness
of 2 mm or less), PVC, or plastic materials, set the cutting
load to "Light load" or "Lightest load".
NOTE
●When setting the cutting load, be sure to lift the main unit
to the upper limit position.
If the spring stopper is pressed in when the main unit is
in a low position, the force of the spring will be applied
in the opposite direction, preventing the main unit from
being able to be lifted to the upper limit position.
●Setting a lighter cutting load increases the length of time
required to cut workpieces, however, cutting precision
will be improved.
Pull out the spring stopper.
(Remove it from surface .) "Heavy load"
Insert it into hole ."Medium load"
Insert it into hole . "Light load"
Insert it into hole ."Lightest load"
A
Heavier
Lighter
Spring stopper
Pin
Surface
Hole
Hole
Hole
Fig. 11
6. Securing workpieces
Vise (A) of the band saw stand can be moved faster
when the clutch is released, and can be used to press
a workpiece when the clutch is applied. You can carry
out your work efficiently by appropriately moving the vise
faster and pressing it against workpieces.
(1) Place a workpiece on the top surface of the base, and
press it against vise (B).
(2) Release the clutch, and move vise (A) until it comes in
contact with the workpiece.
(3) Apply the clutch, and turn the knob clockwise to secure
the workpiece. (Fig. 12)
Vise (B)
Vise (A)
Workpiece
Clutch
Knob
Apply
Release
Tighten
Fig. 12
NOTE
If the clutch cannot be released, turn the knob
counterclockwise a little.
00Book_Band Saw Stand.indb 500Book_Band Saw Stand.indb 5 2021/10/22 13:15:242021/10/22 13:15:24

6
English
7. Cutting thin or small diameter workpieces
When cutting a thin or small diameter workpiece, place
the vise guide supplied as a standard accessory onto the
top of vise (B) to reduce the clearance between the band
saw blade and the vise guide. (Fig. 13)
When cutting a thin or small diameter workpiece, if the
clearance between the band saw blade and vise (B) is
large, the workpiece may be deformed or vibrate in a
swinging manner.
Vise (B)
Vise guide
Thin board to be cut
Fig. 13
8. Angle cutting (Fig. 14)
When you adjust the angle of vise (B), you can cut
workpieces at an angle between a right-angle and 45
degrees.
(1) Loosen the two vise (B) adjustment bolts that are used
to secure vise (B) using the 8-mm hexagonal wrench
supplied as a standard accessory.
(2) By checking with the angle scale, rotate vise (B) to orient
its workpiece side at the desired angle.
(3) After adjusting the angle, firmly tighten the two vise (B)
adjustment bolts to secure vise (B).
(4) When the angle cutting work is finished, return vise (B) to
a right-angle position.
(See "Adjustment of the perpendicularity between vise
(B) and the band saw blade".)
NOTE
In order to improve the precision of angle cutting, apply
an angle gauge to the side of the band saw blade and the
workpiece side of vise (B) when securing vise (B).
Vise (B)
Angle scale Vise (B)
adjustment bolt
Fig. 14
9. Contour cutting work
WARNING
Be sure to correctly install the protective cover, contour
table, and slide cover before use.
CAUTION
If the band saw blade is locked during the cutting
operation, immediately turn the switch offto stop the
operation.
<Installing the contour table (Fig. 15)>
(1) Lift the main unit to the upper limit position, then lower
it a little, and hold it in a position where the main unit is
perpendicular to the top surface of the base.
In this position, firmly tighten the stopper bolt of the hinge
to secure the main unit.
NOTE
If the stopper bolt is tightened although the main body
is not in a perpendicular orientation, the main unit may
wobble and cut the contour table.
(2) While placing the contour table on the guide plate, align
the groove with the band saw blade.
(3) Secure the contour table using vise (B).
Guide plate
Stopper bolt
Vise (A)
Vise (B)
Contour table
Groove
To p s u r f a c e
of the base
Band saw blade
Fig. 15
<Installing the slide cover (Fig. 16)>
(1) Remove the M8 bolt. As this bolt is also used to fasten
the bearing holder, be careful not to drop the bearing
holder.
(2) Insert the protrusion on the slide cover into the slotted
hole in pulley guard (B), and tighten the M8 bolt to secure
it.
(3) Correctly install the slide cover using the 5-mm butterfly
bolt. Before tightening the bolt, adjust the position of the
slide cover according to the height of the workpiece.
00Book_Band Saw Stand.indb 600Book_Band Saw Stand.indb 6 2021/10/22 13:15:252021/10/22 13:15:25

7
English
Protrusion
Pulley guard (B)
M8 bolt
Slide cover
Slide cover holder
Butterfly bolt
(
5 mm)
Fig. 16
<Contour cutting work (Fig. 17)>
(1) Turn the lever switch on.
(2) Hold the workpiece with both hands. Slowly slide it on the
contour table to the band saw blade to cut its contours.
(3) Press the workpiece against the band saw blade by
exerting a load that is not excessive to the point where
it warps the blade. Exercise care not to apply excessive
loads to the blade.
NOTE
Turn the lever switch offeach time you finish cutting
workpieces.
Workpiece Band saw blade
Contour table
Lever switch
OFF
ON
Fig. 17
10. Moving the band saw installed on the band saw
stand
When moving the band saw installed on the band saw
stand, move the main unit down to the lower limit position
as shown in the figure below. Tighten the stopper bolt so
that the main unit does not move up, then hold both ends
of the base. (Fig. 18-a)
The band saw stand has wheels, which enables you to
hold the front handle and lift the pulley guard (B) side to
move the band saw. (Fig. 18-b)
NOTE
Remove the band saw blade and battery even when you
move or store the band saw installed on the band saw
stand.
Stopper bolt
Fig. 18-a
Stopper bolt Wheel
Front handle
Fig. 18-b
00Book_Band Saw Stand.indb 700Book_Band Saw Stand.indb 7 2021/10/22 13:15:252021/10/22 13:15:25

8
中國語
標準附件
輪廓工作台 滑動護蓋
進行輪廓切割作業時
使用。
用於進行輪廓切割作
業時防止帶鋸條露出。
1 個1 個
滑動護蓋座 蝶形螺栓（5 mm）
用於安裝滑動護蓋及
作業期間調整其位置。
用於將滑動護蓋座安
裝在主體上。
1 個1 個
虎鉗導板 六角扳手（4 mm）
用於切割薄或小直徑
工件時調整帶鋸條角
度。
用於調整帶鋸條的下
限位置。
1 個1 枝
六角扳手（8 mm）旋鈕螺栓
螺栓墊圈
用於移動虎鉗 (B) 及調
整鉸鏈的位置。
用於將帶鋸機安裝在
帶鋸機台架上。
1 枝各 2 個
帶鋸機台架安全警告
●請按照說明書中的指示正確安裝帶鋸機台架。
●為了防止發生事故，安裝或拆卸帶鋸機台架時，
請關閉旋轉帶鋸機的開關。若您使用的是電源線
型帶鋸機，請從插座拔下電源插頭。若您使用的
是充電式帶鋸機，請從主體取出電池。
●將帶鋸機安裝到帶鋸機台架後，請按照旋轉帶鋸
機說明書中的指示進行操作。
各部位名稱
止動螺栓
固定止動螺栓的螺絲孔
旋鈕
離合器
虎鉗 (A)
虎鉗 (B)
鉸鏈(B)
鉸鏈
(A)
車輪
底座
D6旋鈕螺栓
螺栓墊圈
[相反側]
六角扳手
（4 mm和8 mm）
彈簧擋塞
彈簧
圖1
符號
警告
以下為使用於本機器的符號。請確保您在使用前
明白其意義。
使用前請詳讀使用說明書。
警告
00Book_Band Saw Stand.indb 800Book_Band Saw Stand.indb 8 2021/10/22 13:15:252021/10/22 13:15:25

9
中國語
用途
本帶鋸機台架專為進行固定型直角切割、角度切割
及輪廓切割作業而設計，其適用於以下 HiKOKI 帶鋸
機： CB3612DA
有關最新可用帶鋸機的詳細資料，請查閱本公司的
總目錄及其他資訊。
規格
型號 CB12-ST2
最大切割
能力*90°
圓管 Φ115 mm
方管 寬100 mm x 高100 mm
45°
圓管 Φ50 mm
方管 寬50 mm x 高50 mm
重量 14.5 kg
* 安裝旋轉帶鋸機後的最大切割能力
使用方法
1. 安裝帶鋸機台架及開關固定座
(1) 將撥桿開關移至 OFF 位置，然後從工具主體取出
電池。
(2) 鬆開止動螺栓時，帶鋸機台架的鉸鏈會因彈簧的
作用力而向後（往車輪方向）倒。
因此，鬆開止動螺栓時，請握緊鉸鏈頂端以免其
向後倒。（圖2）
止動螺栓
車輪
圖2
(3) 將皮帶輪護罩 (A) 側面的孔對準鉸鏈 (A) 的 D8 插
銷，然後將 D8 插銷插入孔中。（圖3）
(4) 鉸鏈 (B) 的前後兩側各有一個 D6 旋鈕螺栓。請只
鎖緊後側的那個螺栓。（圖3）
孔
D6
旋鈕螺栓
帶鋸機的
後側
D8 插銷 鉸鏈 (A)
鉸鏈 (B)
皮帶輪護罩
(A)
圖3
註
必須安裝開關固定座才能使用安裝在台架上的帶
鋸機。
(5) 按住開關鎖，同時扣動開關並將開關固定座安裝
到位。
即可將開關鎖入 ON 位置。（圖4）
(6) 鎖緊前側的 D6 旋鈕螺栓。
安裝程序正確完成後，開關鎖保持在按下位置。
（圖4）
開關鎖
開關固定座
D6 旋鈕螺栓
開關
圖4
開關固定座
（CB3612DA
的標準附件）
00Book_Band Saw Stand.indb 900Book_Band Saw Stand.indb 9 2021/10/22 13:15:262021/10/22 13:15:26

10
中國語
(7) 檢查後側的 D6 旋鈕螺栓是否正確鎖緊，且工具
主體是否牢固安裝在台架上。（圖5）
帶鋸機的
後側
帶鋸機的
前側
鉸鏈 (B)
圖5
2. 操作開關
帶鋸機安裝到台架上後，請檢查開關能否正常操
作。
(1) 檢查帶鋸機台架是否正確固定，且撥桿開關是否
處於 OFF 位置。（圖6）
OFF
ON
撥桿開關
圖6
(2) 將電池裝入工具主體。
(3) 確認帶鋸條沒有接觸到任何物品，然後 ON/OFF
撥桿開關，檢查帶鋸機是否正常運作。
註
除非使用開關固定座將開關保持在 ON 位置，否
則撥桿開關不起作用。
3. 調整帶鋸條的下限位置
調整帶鋸機台架底座及帶鋸條鋸尖的位置。
（圖7）
(1) 拆下止動螺栓，將其轉動數圈擰入固定止動螺栓
的螺絲孔。
(2) 緩慢向下移動工具主體，並調整導向板的位置，
使帶鋸條鋸尖停在底座頂面下方約 2 mm 處。
（使用隨附的標準附件 4-mm 六角扳手。）
(3) 調整完成後，用兩顆 M6 螺絲將導向板牢牢固
定。
2mm
導向板
止動螺栓
底座頂面
帶鋸條
M6 螺絲
圖7
4. 調整帶鋸條的垂直度
<調整虎鉗 (B) 與帶鋸條之間的垂直度（圖 8）>
(1) 使用隨附的標準附件 8-mm 六角扳手鬆開兩個虎
鉗(B) 調節螺栓。確保虎鉗 (A) 遠離虎鉗 (B)。
(2) 如圖所示放置隨附的標準附件虎鉗導板。向下移
動工具主體，將虎鉗導板對著帶鋸條的側面及導
向板輕輕按壓。
(3) 輕輕按壓虎鉗導板，使其保持不動，再放置虎鉗
(B)，使其緊貼虎鉗導板。
鎖緊兩個虎鉗 (B) 調節螺栓，將虎鉗 (B) 牢牢固
定在位。
虎鉗導板 虎鉗 (B)
調節螺栓
虎鉗 (B)
虎鉗 (A)
帶鋸條 導向板
圖8
註
如需更高級別的切割精度，請使用三角尺調整虎
鉗位置。
00Book_Band Saw Stand.indb 1000Book_Band Saw Stand.indb 10 2021/10/22 13:15:262021/10/22 13:15:26

11
中國語
<調整底座頂面與帶鋸條之間的垂直度>
(1) 沿著虎鉗 (B) 放置虎鉗導板，然後使用虎鉗 (A)
輕輕固定虎鉗導板。（圖 9）
虎鉗 (B)
虎鉗 (A) 虎鉗導板
圖9
(2) 使用隨附的標準附件 8-mm 六角扳手鬆開兩個帶
鋸機調節螺栓。
握住前握把，上下移動主體，調整其角度，使虎
鉗導板側面與帶鋸條之間產生的間隙量均勻一
致。（圖 10）
(3) 鎖緊兩個帶鋸機調節螺栓，以牢牢固定鉸鏈 (B)。
註
如需更高級別的切割精度，請使用三角尺調整虎
鉗位置。
鉸鏈 (A)
底座
頂面
帶鋸機條
帶鋸條
虎鉗導板的
側面
帶鋸機
調節螺栓
鉸鏈 (B)
圖10
5. 設定切割負荷
為了設定切割負荷，請先將主體提升到上限位置
並保持住，然後調整彈簧擋塞的位置。（圖 11）
當切割薄壁鋼管（壁厚為 2 mm 或以下）、PVC
或塑膠材料時，請將切割負荷設定為「輕負荷」
或「最輕負荷」。
註
●設定切割負荷時，請務必將主體提升到上限位
置。
如果在主體處於低位時按入彈簧擋塞，則彈簧的
作用力會向相反的方向施加，使主體無法提升到
上限位置。
●設定較輕的切割負荷會延長切割工件所需的時
間，但切割精度會提高。
拉出彈簧擋塞。
（從 面拆下。） 「重負荷」
將其插入孔 。 「中負荷」
將其插入孔 。 「輕負荷」
將其插入孔 。 「最輕負荷」
A
較重
較輕
彈簧擋塞
插銷
面
孔
孔
孔
圖11
6. 固定工件
帶鋸機台架的虎鉗 (A) 可在鬆開離合器時加快移
動，並可在壓緊離合器時壓住工件。以適當的速
度加快移動虎鉗並使其抵住工件可有效提高作業
效率。
(1) 將工件放在底座頂面，並將其抵住虎鉗 (B)。
(2) 鬆開離合器，移動虎鉗 (A) 直到觸及工件為止。
(3) 壓緊離合器，順時針轉動旋鈕以固定工件。
（圖 12）
虎鉗 (B)
虎鉗 (A)
工件
離合器
旋鈕
壓緊
鬆開
鎖緊
圖12
註
如果離合器無法鬆開，請逆時針略微轉動旋鈕。
00Book_Band Saw Stand.indb 1100Book_Band Saw Stand.indb 11 2021/10/22 13:15:272021/10/22 13:15:27

12
中國語
7. 切割薄或小直徑工件
切割薄或小直徑工件時，將隨附的標準附件虎鉗
導板放在虎鉗 (B) 的頂部，以縮小帶鋸條與虎鉗
導板之間的間隙。（圖 13）
切割薄或小直徑工件時，如果帶鋸條與虎鉗 (B) 之
間的間隙較大，則工件可能會變形或劇烈振動。
虎鉗 (B)
虎鉗導板
待切割的薄板
圖13
8. 角度切割（圖 14）
調整虎鉗 (B) 的角度，以便在直角與 45 度角之間
以任意角度切割工件。
(1) 使用隨附的標準附件 8-mm 六角扳手鬆開用於固
定虎鉗 (B) 的兩個虎鉗 (B) 調節螺栓。
(2) 使用角度尺進行檢查，轉動虎鉗 (B)，使工件側
定位在所需的角度。
(3) 調整角度後，用力鎖緊兩個虎鉗 (B) 調節螺栓以
固定虎鉗 (B)。
(4) 角度切割作業完成後，將虎鉗 (B) 返回到直角位
置。
（請參見「調整虎鉗 (B) 與帶鋸條之間的垂直
度」。）
註
為了提高角度切割的精度，固定虎鉗 (B) 時，將角
度尺貼放於帶鋸條的側面及虎鉗 (B) 的工件側。
虎鉗 (B)
角度尺 虎鉗 (B)
調節螺栓
圖14
9. 輪廓切割作業
警告
使用前請務必正確安裝防護罩、輪廓工作台及滑
動護蓋。
注意
如果切割作業中帶鋸條被鎖定，請立即關閉開關
停止操作。
<安裝輪廓工作台（圖 15）>
(1) 將主體提升到上限位置，然後略微降低一點，並
保持在主體與底座頂面呈垂直的位置。
在此位置，牢牢鎖緊鉸鏈的止動螺栓以固定主
體。
註
如果在主體未處於垂直方向時鎖緊止動螺栓，則
主體可能會擺動並鋸到輪廓工作台。
(2) 一邊將輪廓工作台放在導向板上，一邊對準凹槽
與帶鋸條。
(3) 使用虎鉗 (B) 固定輪廓工作台。
導向板
止動螺栓
虎鉗 (A)
虎鉗 (B)
輪廓工作台
凹槽
底座
頂面
帶鋸條
圖15
<安裝滑動護蓋（圖 16）>
(1) 拆下 M8 螺栓。由於此螺栓也用於緊固軸承座，
因此請小心不要掉落軸承座。
(2) 將滑動護蓋上的突起部插入皮帶輪護罩 (B) 的槽
孔，並鎖緊 M8 螺栓以固定。
(3) 使用 5-mm 蝶形螺栓正確安裝滑動護蓋。鎖緊螺
栓前，請根據工件高度調整滑動護蓋的位置。
00Book_Band Saw Stand.indb 1200Book_Band Saw Stand.indb 12 2021/10/22 13:15:272021/10/22 13:15:27

13
中國語
突起部
皮帶輪護罩 (B)
M8 螺栓
滑動護蓋
滑動護蓋座
蝶形螺栓
(5 mm)
圖16
<輪廓切割作業（圖 17）>
(1) 打開撥桿開關。
(2) 用雙手握住工件。在輪廓工作台上將工件緩慢滑
動靠近帶鋸條，進行輪廓切割。
(3) 將工件抵住帶鋸條，施加的負荷切勿過大，以免
鋸片彎曲。請謹慎操作，避免對鋸片施加過大負
荷。
註
每次完成切割工件後，應關閉撥桿開關。
工件 帶鋸條
輪廓工作台
撥桿開關
OFF
ON
圖17
10.搬移安裝在帶鋸機台架上的帶鋸機
搬移安裝在帶鋸機台架上的帶鋸機時，如下圖
所示將主體向下移動到下限位置。鎖緊止動螺
栓以免主體向上移動，然後握住底座的兩端。
（圖 18-a）
帶鋸機台架配有車輪，您可握住前握把，同時提
起皮帶輪護罩 (B) 側來搬移帶鋸機。（圖 18-b）
註
即使僅移動或存放安裝在帶鋸機台架上的帶鋸機
時，也應拆下帶鋸條及電池。
止動螺栓
圖18-a
止動螺栓 車輪
前握把
圖18-b
00Book_Band Saw Stand.indb 1300Book_Band Saw Stand.indb 13 2021/10/22 13:15:282021/10/22 13:15:28

14
00Book_Band Saw Stand.indb 1400Book_Band Saw Stand.indb 14 2021/10/22 13:15:282021/10/22 13:15:28

15
00Book_Band Saw Stand.indb 1500Book_Band Saw Stand.indb 15 2021/10/22 13:15:282021/10/22 13:15:28

201
Code No. C99147031 F
Printed in China
Shinagawa Intercity Tower A, 15-1, Konan 2-chome,
Minato-ku, Tokyo, Japan
00Book_Band Saw Stand.indb 1600Book_Band Saw Stand.indb 16 2021/10/22 13:15:282021/10/22 13:15:28
