Hill Laboratories Rath Mechanical User manual

R E F E R E N C E A N U A L
The Rath
Mechan cal
Treatment Table

Hill Laboratories has been making quality a family business since 1945.
Your new Rath echanical Table is built on an established Hill tradition
of innovation and value. Our reputation rests on the confidence that
your Hill Table will strengthen this legacy and provide you with solid,
reliable service for many years to come.
And welcome to the Hill Laboratories family
Congratulations!
IMPORTANT!
Your Hill Table or Chair has advanced electronics with critical
functions that are controlled by a circuit board.
Since electrical spikes, surges and undervoltage can be
detrimental to electronic components, we require, in order
to maintain your warranty, that you protect your table with
an automatic voltage regulator.
The APC LE1200 voltage regulator, rated at 1200 VA, is one
example of a device that provides a minimum level of
required protection.

Your Hill Laboratories Rath echanical Table has been thoroughly tested and
inspected before shipment. All parts are guaranteed against defect in materials
for one full year from date of purchase. During this period, any such defect will
be remedied by Hill Laboratories or by a factory-authorized repair service
without charge. Tables damaged by mishandling or accident
will be repaired at a reasonable charge.
All correspondence should be directed to your local dealer,
or when this is not possible, to Hill Laboratories directly.
We appreciate your business and your confidence in our product. Our aim is to
provide you with excellent service and satisfaction for many years to come.
President of Hill Laboratories Company
Table Serial Number_______________________________
The Hill Laboratories Guarantee
At Your Service

Ready for use
Your Rath echanical Table comes ready to plug into any 115 v outlet.
Adjustable Angle Front
For Flexion and Extension
Durable V nyl Upholstery
See Table Care page for cleaning and care details
Plast c Base
Cover
Encloses all
interior parts
Rocker Foot
Pedal
Adjusts height from either
side of the table
Foot Cush on
Slides to stabilize patients
Belt
Foot Pedal
Controls treatment angle
Protractor
easures treatment angle
Pat ent Hand
Control
IMPORTANT: This table should be used for positioning only and is not designed for continual motion techniques.
Table Rating
Lifts up to 400 lbs. Static Tested at 1000 lbs.
Height Range - 22"-35"
Standard Width - 24", optional 27" or 30"
Length Reclined - 6'1"
Table Base Skirting
Acrylic thermo-plastic
Foam
Ultra-Cell®for comfort and shape retention
Shipping Weight
Approximately 250 lbs
Electric Requirements
115 v~, 60 Hz., 5 A, 10 A, where specified -
230 v~, 50 Hz.
Note: Grounding reliability can only be achieved
when the equipment is connected to an equivalent
receptacle marked hospital only or hospital grade.
There is no E I concern related to the safe
operation of this table.
Transportation and Storage Conditions
Amb ent Temperature Range:
-30°C to +60°C (-22°F to 140°F)
Relat ve Hum d ty
0% to 90% (non-condensing)
Specifications
3

Table Care
Your Hill Table comes upholstered in a highly durable vinyl material. Its appearance is guarded by Prefixx™
brand protective finish. Your upholstery may be cleaned with the Hill Laboratories Vinyl Cleaner or any non-
abrasive household detergent without change to surface luster. Stubborn stains can be cleaned with most
common solvent cleaners such as naphtha (lighter fluid), rubbing alcohol (IPA type), toluene, Coleman
gas, turpentine (paint thinner), and nail polish remover (50/50 mixture of acetone and water) with no change
to surface luster or color. One hundred percent acetone can also be used for short periods but it is sug-
gested that it first be tested on an inconspicuous area of the table.
Caut on: These solvents are highly flammable; exercise proper care when cleaning with these materials and
do not use near open flame or intense heat. Wear rubber gloves during all cleaning activities. When clean-
ing other parts of your table (besides upholstery) use only nonabrasive household detergents and water.
Caut on: Be sure to unplug your table before performing any maintenance on the table.
Caut on: The table should be checked once a year to make sure all internal and external bolts are secure.
Caut on: The table should be in its lowest height position when not attended.
Caut on: In case of power outage, the table will rely on the generator back-up of the facility where the table
is installed for powering the table to its lowest position.
Caut on: The power cord shall be located to avoid objects being rolled over or placed on top of it and also to
avoid people tripping over it. Damaged cords should be replaced with another of hospital grade.
Caut on:
Grounding reliability can only be achieved when the equipment is connected to an
equivalent receptacle marked hospital only or hospital grade.
Symbols - Each of the symbols below are used n your product label ng. An explanat on of
each s below.
Clean ng Your Table
Caut ons and Symbol Explanat on
4
~
Attent on Symbol
consult accompanying
documents
Dangerous Voltage
Symbol
Type BF Appl ed
Part Symbol
Ground
Symbol
Alternat ng Current
Symbol

Wiring Diagram
