Hillrom Allen Advance Table User manual

D-720725
Version E
Enhancing outcomes for
patients and their caregivers.®
Advance Table
User Manual
Product No. A-71101-EU

2 Allen® Advance Table User Manual (D-720725 Ver E)
ENGLISH ....................................................................................7
中文简体 ..................................................................................70
FRANÇAIS .............................................................................136
DEUTSCH ...............................................................................203
ITALIANO...............................................................................270
ESPAÑOL...............................................................................337
OTHER LANGUAGES ............................................................400

Allen® Advance Table User Manual (D-720725 Ver E) 3
© 2014 Allen Medical Systems Inc. ALL RIGHTS RESERVED.
Manufacturer:
ALLEN MEDICAL SYSTEMS，INC.
100 DISCOVERY WAY
ACTON，MA 01720
800-433-5774（NORTH AMERICA）
[phone]（INTERNATIONAL）
Authorised Representative in EU:
HILL-ROM SAS
B.P. 14 - Z.I. DU TALHOUET
56330 PLUVIGNER
FRANCE
Tel. [phone]
No part of this text shall be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying, recording, or by
any information or retrieval system without prior written permission from
Allen Medical Systems, Inc. (Allen Medical).
The information in this manual is confidential and may not be disclosed to
third parties without the prior written consent of Allen Medical
This manual (D-720725) was originally released and supplied in English.
For a list of available translations, contact Allen Medical Technical
Support.
First Edition, March 2014
First Printing, 2014
Product may be covered by one or more patents. Please consult listing at
www.hill-rom.com/patents for any patent(s).
Mizuhosi® is a registered trademark of Mizuho Orthopedic Systems, Inc.
Velcro® is a registered trademark of Velcro Industries, BV.
Allen®, Bow®, C-Flex®, Easy Lock® are registered trademarks of Allen
Medical Systems, Inc.
Ultra Comfort™ is a trademark of Allen Medical Systems, Inc.
Quick View™ is a trademark of Hill-Rom Services, Inc.
The information contained in this manual is subject to change without
notice. Allen Medical makes no commitment to update or keep current, the
information contained in this manual.

4 Allen® Advance Table User Manual (D-720725 Ver E)
Allen Medical reserves the right to make changes without notice in design,
specifications, and models. The only warranty Allen Medical makes is the
express written warranty extended on the sale or rental of its products.
NOTE:
Replace this manual (D-720725) if it is damaged and/or can not be read.
To order additional copies of this manual (D-720725), contact
Allen Medical.
This manual was created from template D-FACT-7201.

Allen® Advance Table User Manual (D-720725 Ver E) 5
Table of Contents
INTENDED USE ......................................................................................... 7
SYMBOL IDENTIFICATION..................................................................... 8
DOCUMENT SYMBOLS .................................................................... 8
PRODUCT SYMBOLS ........................................................................ 8
SAFETY WARNINGS AND CAUTIONS.................................................14
Quick View™ FUNCTIONAL PARTS LIST.............................................17
View 1..................................................................................................17
View 2..................................................................................................18
CONTROLS AND INDICATORS .............................................................19
Instructions for Use .....................................................................................21
TURN THE UNIT ON AND OFF.......................................................21
Battery charge level.......................................................................22
Potential Equalization Conductor..................................................22
LOCKING AND UNLOCKING THE BRAKES ................................22
Manually Release the Brakes ........................................................23
Reset the Electronic Brakes after being Manually Released.........23
ADJUST THE LENGTH OF THE ALLEN ADVANCE TABLE ......23
INSTALL A PATIENT SUPPORT TOP.............................................24
Remove a Support Top and/or H-bracket......................................28
INSTALL THE PRONE SUPPORT SET (A-71300) ON THE
RAIL TOP............................................................................................28
PRE-USE CHECK ...............................................................................31
ADJUST THE HEIGHT OF THE ALLEN ADVANCE TABLE .......32
PUT THE ALLEN ADVANCE TABLE IN A
TRENDELENBURG POSITION ........................................................33
TILT THE SUPPORT TOP .................................................................34
LEVEL THE ALLEN ADVANCE TABLE AND THE
SUPPORT TOP....................................................................................35
ROTATE THE SUPPORT TOP 180°..................................................36
TRANSFER A PATIENT....................................................................41
ACCESS THE CERVICAL TRACTION ASSEMBLY......................42
SHUT DOWN THE ALLEN ADVANCE TABLE.............................44

6 Allen® Advance Table User Manual (D-720725 Ver E)
CLEAN AND DISINFECT ........................................................................45
CLEAN................................................................................................46
CLEAN DIFFICULT SPOTS..............................................................46
STEAM CLEAN..................................................................................46
DISINFECT.........................................................................................46
TROUBLESHOOTING..............................................................................46
THE ALLEN ADVANCE TABLE WILL NOT GO INTO
PENDANT CONTROL MODE FROM THE MANUAL
FLIP MODE.........................................................................................47
THE PENDANT CONTROL AND MANUAL FLIP
INDICATORS ARE FLASHING........................................................47
THE BRAKES LOCKED AND UNLOCKED INDICATORS
ARE FLASHING.................................................................................47
THE ALLEN ADVANCE TABLE “BEEPS” WHEN
A PENDANT CONTROL IS PRESSED.............................................47
SERVICE CALLS ......................................................................................48
PREVENTIVE MAINTENANCE..............................................................48
MAINTENANCE CHECKS................................................................48
STORAGE AND HANDLING...................................................................49
EXPECTED LIFE.......................................................................................49
DISCARD THE UNIT................................................................................49
PARTS REPLACEMENT ..........................................................................49
Pendant.................................................................................................50
FUSES .................................................................................................51
Accessories..................................................................................................53
SPECIFICATIONS.....................................................................................56

INTENDED USE
Allen® Advance Table User Manual (D-720725 Ver E) 7
INTENDED USE
The intended users of the Allen® Advance Table are healthcare employees
who have been trained to use the product, and who have the physical
strength and cognitive skills to operate and control the product. Follow
facility safety protocols if an intended user does not have the physical
strength or cognitive skills to operate and control the product safely. The
Allen Advance Table is intended to be used in an operating room
environment to support and position patients during surgical procedures.
Several types of specialty tops can be attached to the Allen Advance Table
to permit surgical access and 360° radiolucency for various types of surgical
operations. The patient can be secured into various operable positions from
the supine, prone, or lateral position. Electronic controls on the Allen
Advance Table pendant permit the adjustment of table height, angle, tilt,
and auxiliary function for the lateral top. The Allen Advance Table contains
electronic locking casters that permit the Allen Advance Table to be moved
and locked into position by use of an electronic control on the Allen
Advance Table pendant.
This manual provides the information required for normal operation of the
Allen Advance Table. Before you operate the Allen Advance Table, be sure
that you have read and understood in detail the contents of this manual. It is
important that you read and strictly obey the aspects of safety contained in
this manual. Any reference to a side of the Allen Advance Table is from the
patient’s view lying on an installed patient support top on his or her back.
NOTE:
When we discuss the installation of the Prone Support Set, any
position reference is with the patient lying face down on the patient
support top.
This manual includes the different features and options for the Allen
Advance Table, some of which may not apply to your unit. To identify the
model that you have, look at the model number label that is on the inside of
the head-end base, near the power outlet.

SYMBOL IDENTIFICATION
8 Allen® Advance Table User Manual (D-720725 Ver E)
SYMBOL IDENTIFICATION
DOCUMENT SYMBOLS
This manual contains different typefaces and symbols to make the content
easier to read and understand:
•Standard text—used for regular data.
•Boldface text—emphasises a word or phrase.
•Note:—sets apart special data or important instruction
clarification.
•WARNING or CAUTION
–A WARNING identifies situations or actions that may have an
effect on patient or user safety. To ignore a warning could
cause patient fall, patient injury, or user injury.
–A CAUTION identifies special procedures or precautions that
persons must obey to help prevent equipment damage.
PRODUCT SYMBOLS
Symbol
Description
Table Frame Symbols
Conforms to European Medical Device Directive
93/42/EEC. a
Medical electrical equipment evaluated in
accordance with UL60601-1, EN 60601-1,
IEC 60601-1, IEC 60601-2-46 and
IEC 60601-1-2.
Type B applied part.

SYMBOL IDENTIFICATION
Allen® Advance Table User Manual (D-720725 Ver E) 9
Symbol
Description
Degree of protection against the ingress of water.
Manufacturer.
Equipotential.
General WARNING symbol in accordance with
IEC 60601-1 (This symbol is black with a yellow
background. The yellow background indicates a
warning.)
Follow the Operating Instructions symbol in
accordance with IEC 60601-1. (This symbol is
black with a white background.)
Failure to Follow the Operating Instructions
could place the patient or operator at risk symbol
in accordance with IEC 60601-1. (This symbol is
white with a blue background. The blue
background indicates a mandatory action.)
Shows the maximum patient weight for the
Support Tops.
The Allen Advance Table is not suitable for use
in oxygen enriched environments or where there
is a flammable anesthetics mixture with air,
oxygen, or nitrous oxide.
Battery charge level indicator.

SYMBOL IDENTIFICATION
10 Allen® Advance Table User Manual (D-720725 Ver E)
Symbol
Description
Power indicator.
Identifies the emergency brake releases.
Shows that when the flip handle is in the lowered
position, the Allen Advance Table is in flip mode
(the top can be turned manually).
Shows that when the flip handle is in the raised
position, the Allen Advance Table can be
operated by the pendant.
Identifies the location of the cervical traction
assembly.
Pendant Symbols
Identifies the controls in the area as tilt controls.
This is not a control.

SYMBOL IDENTIFICATION
Allen® Advance Table User Manual (D-720725 Ver E) 11
Symbol
Description
Tilt Left control - turns a support top up to 25°
counterclockwise.
Tilt Right control - turns a support top up to 25°
clockwise.
Identifies the controls in the area as column
height controls. This is not a control.
Up control - raises both columns at the same
time.
Down control - lowers both columns at the same
time.
Reverse Trendelenburg control - lowers the head-
end column as it raises the foot-end column.
Trendelenburg control - raises the head-end
column as it lowers the foot-end column.
Identifies the controls in the area as brake
controls. This is not a control.

SYMBOL IDENTIFICATION
12 Allen® Advance Table User Manual (D-720725 Ver E)
Symbol
Description
Lock control - locks the brakes.
Unlock control - when pressed along with the
Key control, unlocks the brakes.
Key control - when pressed along with the unlock
control, unlocks the brakes.
Display Symbols
Tilt indicator area - shows how far the support top
is tilted to the left or right.
Tilt level indicator - when the indicator is green,
the patient is not tilted to the left or right.
Brake status indicators—the Locked indicator is
green when the brakes are locked; the Unlocked
indicator is yellow when the brakes are unlocked.
Pendant control indicator - green when the Allen
Advance Table is in pendant mode (the Allen
Advance Table can be operated using the pendant
controls).

SYMBOL IDENTIFICATION
Allen® Advance Table User Manual (D-720725 Ver E) 13
Symbol
Description
Manual flip indicator - yellow when the Allen
Advance Table is in flip mode (the top can be
turned manually).
Prone Support Setb
Identifies the chest pad.
Identifies the hip pads.
Identifies the right thigh pad.
Identifies the left thigh pad.
a. The CE mark was used for the first time in 2013.
b. The label shows the patient lying prone on the support set.

SAFETY WARNINGS AND CAUTIONS
14 Allen® Advance Table User Manual (D-720725 Ver E)
SAFETY WARNINGS AND CAUTIONS
WARNING:
Obey these safety instructions to help prevent patient fall,
injury, and/or equipment damage:
•Read and understand all warnings in this manual and on the unit
itself prior to use with a patient.
•This device should be operated by trained persons only.
•The procedures in this manual are only manufacturer’s
recommendations. The final responsibility for patient care with
respect to this device remains with the attending physician.
•No modification of this device is allowed.
•Patient support tops and accessories from Allen Medical are
designed to industry standard dimensions. Before you use products
that are not from Allen Medical, you must verify with the product
manufacturer that the product can be used safely with the Allen
Advance Table.
•Before you use Allen® Patient Support Tops with tables that are
not from Allen Medical, you must verify with the product
manufacturer that the product can be used safely with the support
top.
•There are no known contraindications for use of the Allen
Advance Table.
•Except for patient transfer, always use safety straps to help secure
the patient to the support top.
•Never remove a cross pin from a support top while a patient is on
the support top.
•Before each use of the unit, make sure that all parts are correctly
installed and that the unit operates correctly.
•If the unit has been dropped or damaged, before you use the unit,
make sure facility maintenance has examined the unit completely
and determined that it is safe to operate.
•To avoid the risk of electric shock, the unit must only be connected
to a supply mains with protective earth.
•The potential for electrical shock exists with electrical equipment.
Failure to follow facility protocols may cause death or serious
injury.

SAFETY WARNINGS AND CAUTIONS
Allen® Advance Table User Manual (D-720725 Ver E) 15
•If the Allen Advance Table is to be used near high-frequency
surgical equipment, cardiac defibrillators, and cardiac defibrillator-
monitors, refer to the product manufacturer’s instructions to make
sure the equipment will operate as intended.
•Incorrect use or handling of the power cord may cause damage to
the power cord. If damage has occurred to the power cord or any of
its components, remove the Allen Advance Table from service
immediately, and contact the applicable maintenance persons.
•Do not expose the unit to excessive moisture.
•Fluid spills on to the electronics can cause a hazard. If such a spill
occurs, unplug the unit and remove it from service. When fluid
spills occur outside that seen in normal use, immediately do as
follows:
a. Unplug the unit from its power source.
b. Remove the patient from the unit.
c. Clean the fluid spill from the unit.
d. Have maintenance examine the unit completely.
e. Do not put the unit back into service until it is completely dry,
tested, and determined to be safe to operate.
•Be aware of these pinch points on the Allen Advance Table:
–Between the caster and base skins
–Between an H-bracket and the column
–Between the head of the cross pin and the end cap during an
extreme tilt and Trendelenburg, or Reverse Trendelenburg
position
–Between the cross-pin drop lock and bowtie
–Between an H-bracket and the column during the removal of a
cross pin
•The unit is not intended for patient transport. However, if you must
use the unit to transport a patient, make sure that the unit is in its
lowest position and the patient is in a level position (not tilted).
•Before you transport the unit, make sure of these:
–The unit is in its lowest position.
–The power cord is disconnected from the facility power outlet
and stored on the unit.
–Accessories, supports, and any equipment that is to be
transported with the unit are within the perimeter of the unit
and secure on the unit.

SAFETY WARNINGS AND CAUTIONS
16 Allen® Advance Table User Manual (D-720725 Ver E)
•During transport, make sure to do these:
–Use caution so that the unit does not tip or overbalance.
–For inclines and thresholds, approach them as you move
forward or backward, rather than sideways.
–Push the unit safely; do not make sharp corners or turn the unit
at high speeds.
•Do not use tape on the Allen Advance Table. Adhesive residue
could affect the functions of the Allen Advance Table or the
support tops.
•Keep this manual available for future reference.

Quick View™ FUNCTIONAL PARTS LIST
Allen® Advance Table User Manual (D-720725 Ver E) 17
QUICK VIEW™ FUNCTIONAL PARTS LIST
VIEW 1
Item
Feature
Page
Item
Feature
Page
A
Flip handle
36
F
On/Off switch
21
B
Cervical traction
rope insertion
42
G
Power cord outlet
21
C
Patient support top
with pad
24
H
Pendant
20
D
Cross pin and H-
bracket storage
28
I
Pendant holder
44
E
Collapsible cross
tube
23

Quick View™ FUNCTIONAL PARTS LIST
18 Allen® Advance Table User Manual (D-720725 Ver E)
VIEW 2
Item
Feature
Page
Item
Feature
Page
J
Bowtie
24
O
Battery charge
level
22
K
Cross pin
24
P
Power indicator
21
L
H-bracket
24
Q
Emergency brake
release
23
M
Display
20
R
Pendant connector
50
N
Pendant cord holder
44
S
Cervical traction
release
42

CONTROLS AND INDICATORS
Allen® Advance Table User Manual (D-720725 Ver E) 19
CONTROLS AND INDICATORS
You will find the different controls and indicators for the Allen Advance
Table on the cross tube, on both columns, and on the pendant.
You will find these controls and indicators on the head-end base:
•Model number label
•Serial number label
•Plug outlet
•On/Off switch
•Equipotential ground point
•Manual brake release (red handle
on both columns)
•Power indicator—when on, the
Allen Advance Table is plugged
in.
•Battery charge level
•Manual flip handle—when
released, the flip feature can be
used.
•Cervical traction release—when
pressed, the traction assembly
moves out from the column.

CONTROLS AND INDICATORS
20 Allen® Advance Table User Manual (D-720725 Ver E)
You will find these controls on the pendant:
•Left/Right tilt —turns a support top
approximately 25° clockwise or
counterclockwise.
•Height adjust—raises or lowers the Allen
Advance Table columns. The height can be
adjusted from 67.3 cm to 127 cm (26.5” to
50”); measured from the support top to the
floor.
•Trendelenburg / Reverse Trendelenburg—raises
one column in relation to the opposite column.
•Electronic brake lock/unlock—locks and
unlocks the brakes.
You will find these important information indicators on the display:
•Tilt level indicator
(when the indicator
is green, the patient
is not tilted to the
left or right)
•Tilt indicator and tilt
indicator area
•Brakes locked and
unlocked indicators
•Pendant control
indicator
•Manual flip indicator
