Hioki LR5051-20 User manual

CLAMP LOGGER
July 2013 Revised edition 2 LR5051B980-02 13-07H
Instruction Manual
LR5051

Contents
i
Contents
Introduction ..............................................................................1
Verifying Package Contents....................................................3
Safety Information....................................................................5
Operating Precautions.............................................................6
Measurement Preparation to Data Analysis ..........................8
Chapter 1
Overview__________________________________ 13
1.1 Product Overview and Features .............................13
1.2 Part Names/Functions and Display Indicators .....14
1.3 Display Organization ...............................................16
Chapter 2
Measurement Preparations___________________ 19
2.1 Installing (or Replacing) the Battery ......................19
2.2 Connecting a Clamp Sensor ...................................22
2.3 Installing the PC Application Program ..................29
Chapter 3
Settings___________________________________ 35
3.1 Settings List .............................................................35
3.2 Making Settings on the Logger ..............................37
3.3 Making Settings from the LR5000 Utility Program 43
Chapter 4
Measurement and Analysis___________________ 51
4.1 Pre-Measurement Inspection .................................51
4.2 Installing the Logger ...............................................52
4.3 Starting and Stopping Recording ..........................53
4.4 Confirming Currently Measured Values and Data 
Recording .................................................................55
4.5 Automatically Importing (Saving) Recorded Data 
to a Computer, and Graph Display ........................55
1
2
3
4

Contents
ii
4.6 Manually Importing (Saving) Recorded Data to a 
Computer, and Graph Display ............................... 65
4.7 Displaying a Graph of Saved Recording Data ..... 68
4.8 Printing Recorded Data .......................................... 70
Chapter 5
Processing Recorded Data ___________________71
5.1 Scaling ..................................................................... 73
5.2 Calculating Electric Power ..................................... 74
5.3 Calculating Energy Cost ........................................ 75
5.4 Calculating Operating Rate .................................... 76
5.5 Integration ............................................................... 77
5.6 Calculating Dew-Point Temperature ..................... 78
5.7 Two-Data-Item Arithmetic Calculations ................ 79
5.8 Converting Over-Threshold Data Values .............. 80
Chapter 6
Organizing Data ____________________________81
6.1 Copying and Moving Data ...................................... 82
6.2 Deleting Data ........................................................... 83
6.3 Combining Data ...................................................... 84
6.4 Extracting Data ....................................................... 85
Chapter 7
Options Settings (LR5000 Utility Program) ______87
7.1 Changing the Saving Method for Imported Data . 88
7.2 Changing the Connection Monitoring Method, 
and Logger Settings Displays ............................... 89
Chapter 8
Specifications______________________________91
8.1 Measurement Specifications ................................. 91
8.2 Functional Specifications ...................................... 92
8.3 Miscellaneous ......................................................... 93
8.4 LR5091 Communication Adapter Specifications . 94

Contents
iii
Chapter 9
Maintenance and Service ____________________ 97
9.1 Cleaning ...................................................................97
9.2 Disposing of the Logger .........................................97
9.3 Troubleshooting ......................................................98
9.4 Error Displays ........................................................100
Appendix_________________________________ A 1
Appendix 1 About Recording Modes..............................A 1
Appendix 2 Recording Intervals and Maximum 
Recording Times..........................................A 2
Appendix 3 Battery Life Approximation.........................A 2
Appendix 4 Measurement Method ..................................A 3
Index _________________________________Index 1
4
5
6
7
8
9
Appendix
Index

Contents
iv

Introduction
1
Thank you for purchasing the HIOKI "Model LR5051 Clamp Logger." To obtain max-
imum performance from the instrument, please read this manual first, and keep it
handy for future reference.
Windows is a registered trademark of Microsoft Corporation in the United States and/
or other countries.
The screen of this instrument displays characters in the following manner.
Introduction
Registered Trade Marks
Notation
Indicates a prohibited action.
(p. ) Indicates the location of reference information.
Indicates quick references for operation and remedies for
troubleshooting.
*Indicates that descriptive information is provided below.
[ ] Menus, commands, dialogs, buttons in a dialog, and other
names on the screen and the buttons are indicated in
brackets.
SET
(Bold charac-
ters)
Bold characters within the text indicate operating button
labels.
Windows Unless otherwise specified, “Windows” represents Win-
dows XP, Windows Vista, or Windows 7.
Dialog Dialog box represents a Windows dialog box.

Introduction
2
We define measurement tolerances in terms of rdg. (reading) and dgt.
(digit) values, with the following meanings:
Accuracy
rdg.
(reading or displayed
value)
The value currently being measured and indicated
on the measuring instrument.
dgt.
(resolution)
The smallest displayable unit on a digital measur-
ing instrument, i.e., the input value that causes the
digital display to show a "1" as the least-significant
digit.
Mouse Operation
Click Press and quickly release the left button of the mouse.
Right-click Press and quickly release the right button of the mouse.
Double click Quickly click the left button of the mouse twice.
Drag While holding down the left button of the mouse, move the mouse and then release the left button to deposit the cho-
sen item in the desired position.
Activate Click on a window on the screen to activate that window.

Verifying Package Contents
3
When you receive the instrument, inspect it carefully to ensure that no damage
occurred during shipping. In particular, check the accessories, panel switches, and
connectors. If damage is evident, or if it fails to operate according to the specifica-
tions, contact your dealer or Hioki representative.
Quantities in parentheses ( ).
Verifying Package Contents
LR5051(1)
LR6 alkaline battery (2)
(Pre-installed in the logger.)
Accessories
See: Other specified options: "Options" (p.4)
Instruction Manual (1)
Operation Manual (1)

Verifying Package Contents
4
The following logger options are available separately. Even if purchased previously,
you may want to confirm that you have them at hand.
Use the original packing materials when transporting the instrument, if possible.
Pack the instrument so that it will not sustain damage during shipping, and include a
description of existing damage. We do not take any responsibility for damage incurred
during shipping.
Options
LR5092-20 Data Collector
(Includes LR5000 Utility Program* CD [PC ap-
plication software], LR6 alkaline battery x2, In-
struction manual, Operation manual, and USB
Cable)
9695-02 Clamp On Sensor
50 A AC load current
Note: Requires 9219 Connection
Cable
LR5091 Communication Adapter(1)
(Includes LR5000 Utility Program* CD [PC appli-
cation software] and USB Cable)
*:The latest version can be download-
ed from our web site.
CT6500 Clamp On Sensor
AC500 A AC load current
9669 Clamp On Sensor
1000 A AC load current
9675 Clamp On Leak Sensor
10A AC leakage current
Note: Displays up to 5.000 A with
the LR5051
See: LR5091 specification:(p.94)
Z5004 Magnetic Strap
9219 Connection Cable
9657-10 Clamp On Leak Sensor
10A AC leakage current
Note: Displays up to 5.000 A with
the LR5051
See: Method of mounting:
(p.52)
Transporting Precautions

Safety Information
5
This manual contains information and warnings essential for safe operation of the
instrument and for maintaining it in safe operating condition. Before using it, be
sure to carefully read the following safety precautions.
Markings on the logger have the following meanings.
Markings on the logger have the following meanings.
The following symbols in this manual indicate the relative importance of cautions and warnings.
Safety Information
This instrument is designed to comply with IEC 61010 Safety Stan-
dards, and has been thoroughly tested for safety prior to ship-
ment. However, mishandling during use could result i n injury or
death, as well a s damage to the instrument. However, using the
instrument in a way not described in this manual may negate the
provided safety features.
Be certain that you understand the instructions and precautions in
the manual before use. We disclaim any responsibility for acci-
dents or injuries not resulting directly from instrument defects.
Safety Symbols
In the manual, the symbol indicates particularly important infor-
mation that the user should read before using the instrument.
The symbol printed on the instrument indicates that the user
should refer to a corresponding topic in the manual (marked with the
symbol) before using the relevant function.
Indicates DC (Direct Current).
Symbols for Various Standards
WEEE marking:
This symbol indicates that the electrical and electronic appliance is
put on the EU market after August 13, 2005, and producers of the
Member States are required to display it on the appliance under Arti-
cle 11.2 of Directive 2002/96/EC (WEEE).
This symbol indicates that the product conforms to safety regu-
lations set out by the EC Directive.
Danger Levels
Indicates that incorrect operation presents an extreme hazard
that could result in serious injury or death to the user.
Indicates that incorrect operation presents a significant hazard
that could result in serious injury or death to the user.
Indicates that incorrect operation presents a possibility of
injury to the user or damage to the instrument.
Indicates advisory items related to performance or correct
operation of the instrument.

Operating Precautions
6
Follow these precautions to ensure safe operation and to obtain the full ben-
efits of the various functions.
• Operating temperature and humidity: 0 to 50C (32 to 122F), 80%RH or less
• Storage temperature and humidity: -10 to 60C (14F to 140F), 
80%RH or less (non-condensating)
• Operating environment: indoors
Operating Precautions
Installation Precautions
Avoid the following locations that could cause an accident or damage to the instru-
ment.
Exposed to direct
sunlight
Exposed to high tem-
perature
In the presence of
corrosive or explosive
gases
Exposed to liquids
Exposed to high
humidity or condensa-
tion
Exposed to strong
electromagnetic
fields
Near electromagnetic
radiators
Subject to vibration
Near induction heat-
ing systems
(e.g., high-frequency
induction heating sys-
tems and IH cooking
utensils)
Exposed to high lev-
els of particulate dust
Transporting and Handling
To avoid damage to the instrument and sensors, protect it from physical
shock when transporting and handling. Be especially careful to avoid
physical shock from dropping.

Operating Precautions
7
Before using the instrument the first time, verify that it operates normally to ensure
that the no damage occurred during storage or shipping. If you find any damage, con-
tact your dealer or Hioki representative.
CD Handling
• Always hold the disc by the edges, so as not to make fingerprints on
the disc or scratch the printing. Never touch the recorded side of the
disc. Do not place the disc directly on anything hard.
• Do not wet the disc with volatile alcohol or water, as there is a possibil-
ity of the label printing disappearing.
• To write on the disc label surface, use a spirit-based felt pen. Do not
use a ball-point pen or hard-tipped pen, because there is a danger of
scratching the surface and corrupting the data. Do not use adhesive
labels.
• Do not expose the disc directly to the sun's rays, or keep it in condi-
tions of high temperature or humidity, as there is a danger of warping,
with consequent loss of data.
• To remove dirt, dust, or fingerprints from the disc, wipe with a dry
cloth, or use a CD cleaner. Always wipe from the inside to the outside,
and do no wipe with circular movements. Never use abrasives or sol-
vent cleaners.
• Hioki shall not be held liable for any problems with a computer system
that arises from the use of this CD, or for any problem related to the
purchase of a Hioki product.
Preliminary Checks
Before using the instrument, make sure that the insulation on the
sensor cables is undamaged and that no bare conductors are
improperly exposed. Using the instrument in such conditions
could cause an electric shock, so contact your dealer or Hioki rep-
resentative for replacements.

Measurement Preparation to Data Analysis
8
The steps from measurement preparation to data analysis are illustrated with a typ-
ical measurement example.
Example case: Record factory current consumption at one-minute intervals for one
month, and store the data on a computer.
Quantities in parentheses ( ).
Measurement Preparation to Data Analysis
Required Items:
LR5051 (1) LR6 alkaline battery (2) CT6500 Clamp On Sensor (1)
LR5091 Communication Adapter (1)
(CD [PC application software] and 
USB Cable)
Computer (1)
Procedure:
1Install the battery in the logger.
See: "Installing (or Replacing) the Bat-
tery" (p.19)
2Connect the CT6500 Clamp On Sensor to
the logger.
See: "Connecting a Clamp Sensor"
(p.22)
1
2

Measurement Preparation to Data Analysis
9
3Install the LR5000 Utility Program on the
computer.
See: "Installing the PC Application Pro-
gram" (p.29)
4Select the recording interval for the logger
(in this case, 1 minute).
See: "Recording Interval Setting" (p.37)
(The setting can be made also from the
LR5000 Utility Program.) (p.46)
5Set the logger to the correct date and time
(in this case, 15 May 2010, 13:00).
See: "Real-Time Clock Setting" (p.38)
(With the LR5000 Utility Program, the log-
ger can be set to the computer time.)
(p.49)
6Set the stop method to [OFF].
(This setting provides one-time measurement:
recording stops when memory becomes full.)
See: "Stop Method Setting (for when
memory becomes full)" (p.39)
(The setting can be made also from the
LR5000 Utility Program.) (p.46)
5
4
3
6

Measurement Preparation to Data Analysis
10
7Set the recording mode to [OFF].
(This setting provides instantaneous mea-
surement.)
See: "Recording Mode Setting" (p.40)
(The setting can be made also from the
LR5000 Utility Program.) (p.46)
8Set the power save setting to [ON].
(The on (enabled) setting is recommended
for long-term recording.)
See: "Power Save Setting" (p.40)
(The setting can be made also from the
LR5000 Utility Program.) (p.45)
9Set the CH1 measurement range to
[6500 50.00 A].
See: "Selecting the Clamp Sensor
Model and Measurement Range"
(p.41)
(The model name of the clamp sensor is
displayed above the current range.)
Note: The CT6500 Clamp On Sensor is
displayed as [6500] on the screen.
10 Set the filter to [OFF].
See: "Filter Setting" (p.42)
11 Pre-measurement inspection (p.51)
12 Install the logger at the measurement
site in the factory.
See: "4.2" (p.52)
It can be wall-mounted.)
8
9
7
10

Measurement Preparation to Data Analysis
11
13 Hold REC/STOP on the logger for two
seconds to start recording.
See: "4.3" (p.53)
14 Press (+) and (-) on the logger to confirm
that the recording count is incrementing,
and that recording data (maximum and
minimum values) are displayed.
(Confirm that recording is actually occurring.)
See: "4.4" (p.55)
15 After a month, hold REC/STOP on the
logger again for two seconds to stop
recording.
See: "4.3" (p.53)
16 Retrieve the logger from the factory.
17 Import recorded data from the logger to
a connected computer. For analysis, dis-
play the data in a graph.
See: "4.5" (p.55)
The data is automatically saved when
imported to the computer. By default, it is
also automatically displayed in a graph.)
18 Print recorded data as needed.
See: "4.8" (p.70)
13
17
14

Measurement Preparation to Data Analysis
12

1.1 Product Overview and Features
13
3
1
Chapter 1 Overview
This instrument is a compact portable data logger for measuring, displaying, and
recording AC current.
Overview Chapter 1
1.1 Product Overview and Features
Browse and manage data with
LR5000 Utility Program on a PC.
The LR5000 Utility Program PC applica-
tion is very easy to install.
After installation, data management and
browsing is easy with auto-start, data dis-
play and saving.
Large display shows two
channels' data simulta-
neously
Measures AC current on two
channels.
• Data can be imported while recording.
• Records up to 60,000 measurements
• Data is preserved independently
of battery state.
• Recording continues (for approx.
30 s) during battery replacement
Advanced functions included
• Record statistical values (p.39), (p.46)
• Scaling (p.47), (p.73)
• Alarm display (p.48)
Measurement Sites
Analysis Site
Energy saving measurements in
houses, offices, factories, ware-
houses, etc.
Suitable for ESCO environmental
measurements.

1.2 Part Names/Functions and Display Indicators
14
1.2 Part Names/Functions and Display Indicators
IR Port (p.55)
Communicates
with the LR5091
Communication
Adapter or
LR5092-20 Data
Collector.
Front
LCD (p.15)
The display blanks after 30 seconds of oper-
ator inactivity(auto powersave). The display
reappears by pressing a button.
Whenthedisplayisvisible,itrefreshesabout
once per second.
Battery
Cover
(p.19)
SET button
Displays settings.
Back
Operating Buttons
Sensor Jacks (p.22)
Connect a clamp sensor.
Operating
Buttons
LR5091 Communication Adapter
IR Port (p.55)
Communicates with the logger.
USB Port (p.43)
Connect a USB cable here to communicate with a
computer. (Mini-B receptacle)
Stand/Strap Attachment Hole (p.52)
Attach the logger to a wall or other surface by
hanging it on a screw. (Supported screw head
dimensions: up to approx. 6.8 mm in diameter
and approx. 2.5 mm in thickness)
REC/STOP button
Hold for two seconds to start/stop recording.
From a setting display, switches to measurement display.
(-) button, (+) button
Changes Measurement display contents.
Changes setting values on the Settings display.
