Hioki IM3536-01 User manual
i
When measuring conductivity and per-
mittivity........................................................68
3.5 Judging Measurement Results ..... 69
Setting the judgment mode.........................70
Conguring comparator function set-
tings (judging measurement results
based on one judgment standard) ..............70
Conguring BIN function settings (judg-
ing measured values based on multiple
judgment standards) ...................................75
3.6 Setting Application Settings ......... 80
Range synchronization (Setting mea-
surement conditions for individual mea-
surement Ranges) ......................................80
Waveform averaging function (increas-
ing measurement precision or measure-
ment speed)................................................83
High-Z reject function (detecting contact
errors during 2-terminal measurement) ......85
Contact check function
(
detecting poor
contact with the sample during 4-termi-
nal measurement).......................................86
Memory function (saving measurement
results) ........................................................87
Number of effective digits of the mea-
surement value ...........................................88
LCD display auto-off (power-saving mode) 89
Key tones and judgment tones ...................90
Key-lock function (Disabling key operation)91
4 Using Continuous Mea-
surement Mode 93
4.1 Setting Which Panels to Use in
Continuous Measurement ............. 93
4.2 Performing Continuous Mea-
surement ......................................... 94
4.3 Checking Continuous Measure-
ment Results................................... 94
4.4 Changing the Display Tim-
ing Setting (When You Wish
to Shorten the Screen Update
Interval) ........................................... 95
4.5 Setting the LCD display auto-
off (When You Wish to save the
power) ............................................. 96
5 Error Correction 97
5.1 Setting the Cable Length (Cable
Length Correction)......................... 98
5.2 Open Correction............................. 99
Before performing open correction .............99
All correction .............................................100
Contents
Introduction................................................ 1
Verifying Package Contents ..................... 1
Measurement process............................... 6
Safety Information................................... 10
Operating Precautions............................ 12
1 Overview 17
1.1 Product Overview and Features ... 17
1.2 Names and Functions of Parts ..... 18
1.3 Screen Layout and Operation ....... 20
Screen transition diagram...........................20
Viewing measured values (Measure-
ment screen)...............................................22
Select the measurement mode (MODE
screen)........................................................24
Setting detailed settings such as mea-
surement conditions (SET screen) .............25
Checking measurement condition set-
tings information .........................................26
Conguring correction functionality (ADJ
screen)........................................................27
Conguring the instrument’s interfaces,
setting the time and date, and checking
the system (SYS screen) ............................28
Displaying and manipulating les on the
USB ash drive (FILE screen) ....................29
2 Measurement Prepara-
tions 31
2.1 Preparation Flowchart ................... 31
2.2 Pre-Operation Inspection .............. 33
2.3 Connecting the Power Cord.......... 34
2.4 Connecting the Measurement
Cables, Probes, or Fixture............. 35
2.5 Turning the Power On and Off ...... 36
2.6 Setting the Date and Time ............. 38
3 Performing Measure-
ments in LCR Mode 39
3.1 Setting Display Parameters........... 39
To perform DC measurement (DC resis-
tance measurement)...................................40
3.2 Viewing Measured Values.............. 41
3.3 Enlarging Display of Measure-
ment Values .................................... 42
3.4 Setting Measurement Condi-
tions (basic settings) ..................... 43
Required settings........................................44
User-congurable settings..........................55
Measurement and data acquisition timing ..66
IM3536A981-03
3
2
1
5
4
Ind.Appx.
10
9
8
7
6
Contents
ii
8 Using USB Flash Drive
(Saving and Loading
Data) 137
8.1 Inserting and Removing a USB
ash drive ..................................... 138
8.2 Checking the Contents of Files
on a USB ash drive .................... 139
8.3 Formatting a USB Flash Drive .... 140
8.4 Saving Measurement Data .......... 141
Saving Measurement Data in text.............141
Saving a copy of the screen .....................150
To specify the save folder .........................152
8.5 Saving Settings Data ................... 153
Saving instrument settings other than
panels .......................................................153
Save all instrument settings including
panels (ALL SAVE function)......................154
8.6 Loading Instrument Settings ...... 155
Loading settings les or panel les...........155
Loading settings les including panel
les (ALL LOAD function) .........................156
8.7 Checking the Contents of a File . 157
8.8 Deleting Files and Folders .......... 158
8.9 Creating Folders........................... 159
8.10 Displaying the USB Flash Drive
Information ................................... 160
9 External Control 161
9.1 External Input/Output Connec-
tor and Signals ............................. 162
Instrument connector and supported
connectors ................................................162
Instrument connector signal assignments 162
Input (IN) signal function details ...............167
BCD mode function details .......................168
Output signals when errors occur .............170
9.2 Example Measurement Timing
(Timing Charts)............................. 171
9.3 Internal Circuitry .......................... 176
Circuit diagrams........................................176
Electrical specications.............................178
Connection examples ...............................178
9.4 External I/O Settings .................... 180
Setting the delay time (from judgment
result output to EOM
―――
output) and judg-
ment result reset operation .......................181
Disabling the trigger input during mea-
surement and setting the trigger input
effective edge ...........................................182
Setting the E
________
OM output method and
output time ................................................183
Spot correction..........................................103
5.3 Short Correction........................... 105
Before performing open correction ...........105
All correction .............................................106
Spot correction..........................................107
5.4 If Open or Short Correction
Fails to Complete Normally......... 109
5.5 Disabling Open and Short Cor-
rection Values................................111
5.6 Load Correction (Correcting
Values to Match Reference Val-
ues).................................................112
Procedures for the load correction............ 113
To reset the correction condition settings . 119
When load correction fails to complete
normally .................................................... 119
Disabling load correction ..........................120
5.7 Correcting Measured Values
with a User-specied Correction
Coefcient (Correlation Correc-
tion) ............................................... 121
6 Saving and Loading
Measurement Condi-
tion and Correction
Value Data 123
6.1 Saving Measurement Condi-
tions and Correction Values
(Panel Save Function).................. 124
6.2 Loading Measurement Condi-
tions and Correction Values
(Panel Load Function) ................. 128
6.3 Changing a Panel Name .............. 129
6.4 Deleting a Panel ........................... 130
7 Setting the System 131
7.1 Setting the Interface (Controlling
the Instrument from a Computer)132
7.2 Checking the Version of the
Instrument..................................... 132
7.3 Testing the System (Self diag-
nosis)............................................. 133
Panel test..................................................133
Panel calibration .......................................134
Testing the screen display status and
LED status ................................................134
ROM/RAM test..........................................135
Testing EXT I/O input/output signals.........135
Ind.
10
9
8
7
6
5
4
13
12
11
Contents
iii
Outputting measured values (switching
to BCD mode) (LCR mode only)...............184
9.5 External control Q&A................... 185
9.6 Measurement Using a Computer 186
10 Specications 187
10.1 General Specications ................ 187
10.2 Environmental and Safety Spec-
ications ....................................... 192
10.3 Accessories and Options ............ 193
10.4 Function specications ............... 193
10.5 Interfaces ...................................... 205
10.6 Measurement Range and Accu-
racy................................................ 207
10.7 About Measurement Times and
Measurement Speed .................... 217
11 Maintenance and Ser-
vice 221
11.1 Calibration, Inspection, Repair,
and Cleaning................................. 221
Calibrations...............................................221
Inspection and Repair...............................221
Replaceable Parts and Operating Life-
times .........................................................221
Transporting the instrument......................222
Cleaning....................................................222
11.2 Troubleshooting ........................... 223
Before returning for repair.........................223
Initializing (System Reset) ........................228
Performing a full reset (If you are unable
to perform a system reset)........................229
11.3 Error Massage and Error Display 230
11.4 Discarding the Instrument........... 235
Appendix Appx.1
Appx. 1 Measurement Param-
eters and Calculation
Formula............................. Appx.1
Appx. 2 Measurement of High
Impedance Components . Appx.3
Appx. 3 Measurement of In-cir-
cuit Components ............. Appx.4
Appx. 4 Countermeasures
Against Incorporation of
External Noise.................. Appx.5
Countermeasures against incorporation
of noise from the power line.................Appx.5
Countermeasures against noise from
the measurement cables .....................Appx.6
Appx. 5 Supplying DC Bias........... Appx.6
How to supply a DC bias voltage.........Appx.7
How to supply a DC bias current .........Appx.8
Appx. 6 The Residual Charge
Protection Function......... Appx.9
Appx. 7 Series Equivalent Cir-
cuit Mode and Parallel
Equivalent Circuit Mode Appx.10
Appx. 8 Open Correction and
Short Correction .............Appx.11
Appx. 9 Attaching Rack-mount-
ing Hardware to the
Instrument ...................... Appx.12
Appx. 10 Dimensional Diagram .... Appx.14
Appx. 11Initial Settings Table ...... Appx.15
Appx. 12 Device Compliance
Statement ....................... Appx.22
Index Ind.1
Appx.
9
8
7
6
5
4
11
10
11
Ind.
3
12
1
Introduction
Thank you for purchasing the Hioki IM3536 LCR Meter. To obtain maximum performance from the
instrument, please read this manual rst, and keep it handy for future reference.
Target audience
This manual has been written for use by individuals who use the product in question or who teach
others to do so. It is assumed that the reader possesses basic electrical knowledge (equivalent to
that of someone who graduated from the electrical program at a technical high school).
Trademarks
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in
the United States and other countries.
Verifying Package Contents
When you receive the instrument, inspect it carefully to ensure that no damage occurred during
shipping. In particular, check the accessories, panel switch, button, and connectors. If damage is
evident, or if it fails to operate according to the specications, contact your authorized Hioki distribu-
tor or reseller.
Conrm that these contents are provided.
IM3536 LCR Meter ×1
Accessories
LCR Application Disc ×1
(Includes Communications Instruction Manual (PDF edition), ex-
planation of communications commands, USB driver, and sample
programs.)
The latest version can be downloaded from our web site
Instruction manual
(This document) ×1
Power Cord ×1
• Measurement cable and xture are not supplied with the instrument as standard equipment. You should
order them separately, according to requirements.
See “Options (reference: open and short correction states)” (p. 2).
• The instrument ships from the factory congured as described in”Appx. 11 Initial Settings Table” (p. Appx.15).
Precautions when transporting the instrument
Store the packaging in which the instrument was delivered, as you will need it when transporting
the instrument.
10
9
8
7
6
5
4
3
2
1
2
Verifying Package Contents
Options (reference: open and short correction states)
The following options are available for the instrument. Contact your authorized Hioki distributor or
reseller when ordering.
Probe type (cord length: 1 m) Open state during open
correction
Shorted state during short
correction
L2000 4-Terminal Probe
Measurable range: DC to 8 MHz
Maximum applied voltage:
±42 V peak
(AC+DC)
Maximum applied current: ±1 A peak
(AC+DC)
Measurement terminal hole diameter:
0.3 mm to 5 mm
Alligator-clip-type measurement cables.
These general-purpose dual-electrode
clips t a wide range of conductor thick-
nesses.
Width of the measurement
sample
Close the tips of the probes and
place the probes so that they are
as far apart as the width of the
measurement sample.
HPOT
LPOT
LCUR HCUR
Clamp the probe tips together with
the V mark facing up.
9140-10 4-Terminal Probe
Measurable range: DC to 200 kHz
Maximum applied voltage:
±42 V peak
(AC+DC)
Maximum applied current: ±1 A peak
(AC+DC)
Measurement terminal hole diameter:
0.3 mm to 5 mm
Width of the measurement
sample
Close the tips of the probes and
place the probes so that they are
as far apart as the width of the
measurement sample.
Clamp the probes on the short bar.
9500-10 4-Terminal Probe
Measurable range: DC to 200 kHz
Maximum applied voltage: DC±40 [42 V
peak (Measurement signal + bias volt-
age)]
Maximum applied current: 1 A peak
(Measurement signal + bias voltage)
Measurement terminal hole diameter:
0.3 mm to 2 mm
Rubber-sheathed alligator clip type
Red (High)
Black (Low)
Metal wire
Width of the
measurement
sample
Clamp a short piece of metal wire
with the HCUR and HPOT terminals
(red) and the LCUR and LPOT termi-
nals (black) of the probes so that
they are as far apart as the width
of the measurement sample.
Red (High)
Black (Low)
Metal wire
Clamp a short piece of metal wire
in the following probe terminal
order: HCUR, HPOT, LPOT, LCUR.
3
Verifying Package Contents
Probe type (cord length: 1 m) Open state during open
correction
Shorted state during short
correction
L2001 Pincher Probe*1
Measurable range: DC to 8 MHz
Maximum applied voltage: DC±30 V
Space between tip electrodes: 0 mm to
approx. 6 mm
Pincer type
Gradations on open
correction xture
Clamp the tip of the pincers at
the open correction xture gra-
dation (using the same value as
the length of the measurement
sample), taking care to insert the
pincers all the way.
(For sample 1005, the length is 1.0
mm.)
Close the tip of the pincers.
Test xture types Open state during open
correction
Shorted state during short
correction
9261-10 Test Fixture
Measurable range: DC to 8 MHz
Maximum applied voltage: DC±40 V
Measurement terminal hole diameter:
0.3 mm to 1.5 mm
Cord length: 1 m
Connect the 9261-10 and the
instrument with the connection
cable (do not clamp anything to
the xture).
Insert the short bar all the way
into the sample mounting area.
9262 Test Fixture*1
Measurable range: DC to 8 MHz
Maximum applied voltage: DC±40 V
Measurable sample dimensions:
Lead diameter of φ0.3 mm to φ2 mm
Lead pitch of 5 mm or more
This fixture is for measuring lead com-
ponents. (less than 10 mΩresidual re-
sistance after zero adjustment)
In contact
Turn the knob clockwise to tighten
the sample mounting area.
Insert the short bar all the way
into the sample mounting area.
*1: Although the test xture appears to use a four-terminal setup, two terminals provide contact with the sample
since HPOT and HCUR as well as LPOT and LCUR are connected inside the xture and probe.
10
9
8
7
6
5
4
3
2
1
4
Verifying Package Contents
Test xture types Open state during open
correction
Shorted state during short
correction
9263 SMD Test Fixture*1
Measurable range: DC to 8 MHz
Maximum applied voltage: DC±40 V
Measurable sample dimensions: Test
sample width of 1 mm to 10 mm
This fixture is for measuring chip com-
ponents. (less than 10 mΩresidual re-
sistance after zero adjustment)
Turn the knob counterclockwise to
open the high and low electrodes
(use the width of the measure-
ment sample as the open spac-
ing).
Turn the knob clockwise to tighten
the high and low electrodes.
9677 SMD Test Fixture*1
Measurable range: DC to 120 MHz
Maximum applied voltage: DC±40 V
Measurable sample dimensions: Test
sample width of 3.5±0.5 mm or less
Move the knob to open the high
and low electrodes (use the width
of the measurement sample as
the open spacing).
Move the knob to close the high
and low electrodes.
9699 SMD Test Fixture*1
ショート
オープン
Measurable range: DC to 120 MHz
Maximum applied voltage: ±42 V peak
(AC+DC)
Measurable sample dimensions: Test
sample width of 1 mm to 4 mm
Test sample height of 1.5 mm or less
This xture is for the lower electrode.
ショート
オープン
Turn both knobs counterclock-
wise to loosen them (do not place
anything in the sample mounting
area).
ショート
オープン
Position the included short bar
in the sample mounting area
and turn the knobs clockwise to
secure the measurement sample
in place.
*1: Although the test xture appears to use a four-terminal setup, two terminals provide contact with the sample
since HPOT and HCUR as well as LPOT and LCUR are connected inside the xture and probe.
5
Verifying Package Contents
Test xture types Open state during open
correction
Shorted state during short
correction
IM9100 SMD Test Fixture
Measurable range: DC to 8 MHz
Maximum applied voltage: DC±40 V
Maximum applied current: 0.15 A rms (±0.15
ADC)
Measurable sample dimensions:
JIS (EIA): L mm × W mm
0402 (01005) : 0.4 mm × 0.2 mm
0603 (0201) : 0.6 mm × 0.3 mm
1005 (0402) : 1.0 mm × 0.5 mm
For use with SMD components
1
2
Mount the open correction x-
ture for the 1005 in the test head
measurement area with a pair of
pincers.
12
3
1. Remove the template.
2. Mount the short correction
xture in the test head mea-
surement area, passing the
guide pins through the holes
on the xture.
3. Push the tip of the tip pin
gradually into the short cor-
rection xture.
DC Bias Unit Open state during open
correction
Shorted state during short
correction
9268-10 DC Bias Voltage Unit
Measurable range: 40 Hz to 8 MHz
Maximum applied voltage: DC±40 V
Connect the following items to the
9268-10:
• Measurement cables and xture
or probe (in the open correction
state)
• Bias application cable
• External DC bias power supply
(with the 0 V output setting on)
Connect the following items to the
9268-10:
• Measurement cables and xture
or probe (in the short correction
state)
• Bias application cable
• External DC bias power supply
(with the 0 V output setting on)
9269-10 DC Bias Current Unit
Measurable range: 40 Hz to 2 MHz
Maximum applied current: DC 2 A
Connect the following items to the
9269-10:
• Measurement cables and xture
or probe (in the open correction
state)
• Bias application cable
• External DC bias power supply
(setting off)
(Do not connect the bias applica-
tion cable.)
Connect the following items to the
9269-10:
• Measurement cables and xture
or probe (in the short correction
state)
• Bias application cable
• External DC bias power supply
(setting off)
(Do not connect the bias applica-
tion cable.)
Connection cords
9637 RS-232C Cable
9-pin to 9-pin cross type, Cord length: 1.8 m
9151-02 GP-IB Connector
Cable
Cord length: 2 m
10
9
8
7
6
5
4
3
2
1
6
Measurement process
Measurement process
This section uses AC measurement of a laminated ceramic capacitor as an example to provide an
overview of the instrument’s functionality.
Items to be prepared:
9263 SMD Test Fixture, Laminated ceramic capacity you want to measure
1
Inspect the instrument before measurement. (p. 33)
2
Connect the power cord to the instrument. (p. 34)
3
Turn on the power. (p. 36)
(A 60-minute warm-up period is necessary before performing the correction process de-
scribed in Step 9.)
4
Set the date and time. (p. 38)
5
Connect the 9263 SMD test xture to the measurement terminals.
• Overview of connections: p. 35
(The connection method varies with the probes and
xture being used. For more information, see each prod-
uct’s user manual.)
• Optional probes and xtures: p. 2
6
Set the measurement mode to LCR. (Default setting: LCR)
2
3
1
Use the CONTINUOUS setting if you wish to take continuous measurements under multiple sets of
conditions. (In LCR mode, you must rst set and save the measurement conditions.)
See “4 Using Continuous Measurement Mode” (p. 93).
7
Measurement process
7
Set the rst parameter to Cs and the third parameter to D. (p. 39)
Example: Set the rst parameter to Cs
1
3
2
When you wish to perform DC in addition to AC measurement, set the parameter to Rdc.: “To per-
form DC measurement (DC resistance measurement)” (p. 40)
8
Set the measurement conditions.
Press the SET key, select the BASIC tab, and congure the settings as desired. (The numbers under-
neath the buttons indicate the default settings.)
1
3
2
FREQ Measurement frequency: 1.0000 kHz
(p. 44)
(Required: congure based on the
measurement sample.)
AVG Average: OFF (p. 57)
(Optional: Set to ON when you wish to
prevent instability in the display value.)
RANGE Measurement range: AUTO (p. 45)
(Required: congure based on the
measurement sample.)
DC BIAS
DC bias: OFF (p. 60)
(Optional: Set to ON when you wish
to superimpose the DC voltage on the
measurement signal during capaci-
tance measurement.)
LEVEL
Measurement signal mode:
Open circuit voltage (V) mode
Measurement signal level: 1.000 V
(p. 49)
(Required: congure based on the
measurement sample.)
DELAY Trigger delay: 0.0000 s (p. 64)
(Optional: If the trigger synchronous
output function is enabled, set to a
large enough value that measurement
can stabilize.)
SPEED
Measurement speed: MED (p. 55)
(
Optional:
Change this setting when
you wish to perform measurement
more quickly or at a higher level of
precision.)
TRIG Trigger: INT (p. 63)
(Optional: Set to EXT when you wish to
input the trigger manually, using EXT I/O,
or using the interface.)
LIMIT Voltage and current limit: OFF
(p. 59)
(Optional: Set to ON when you wish
to limit the voltage or current that is
applied to the sample.)
SYNC Trigger synchronous output function:
OFF (p. 65)
(Optional: Change the setting when
you wish to apply the signal to the
sample during measurement only.)
10
9
8
7
6
5
4
3
2
1
8
Measurement process
• To save measurement conditions internally or load previously saved measurement conditions:
“6 Saving and Loading Measurement Condition and Correction Value Data” (p. 123)
• To perform DC (DC resistance) measurement: “3.4 Setting Measurement Conditions (basic set-
tings)” (p. 43)
9
Wait at least 60 minutes after turning on the instrument and then perform correction.
1. Press the ADJ key.
CABLE “5.1 Setting the Cable Length (Ca-
ble Length Correction)” (p. 98)
OPEN
“5.2 Open Correction” (p. 99)
SHORT
“5.3 Short Correction” (p. 105)
1
5
23 4
2. Set the cable length (for the 9263, use a setting of 0 m).
3. Place the 9263 SMD Test Fixture in the open state and perform open correction.
4. Place the 9263 SMD Test Fixture in the shorted state and perform short correction.
• To save measurement conditions internally or load previously saved measurement conditions: “6
Saving and Loading Measurement Condition and Correction Value Data” (p. 123)
• The open state and shorted state vary with the probe or xture being used. (p. 2)
For more information, see each component’s user manual.
10
Connect the test sample to the 9263 SMD test xture.
The method used to connect to the sample
varies with the probe or xture being used. See
each component’s user manual for details.
9
Measurement process
11
Check the measurement results. (p. 41)
• To enlarge the measured value display: p. 42
• To change the number of digits used to display
measured values: p. 88
• When you want to judge the measurement results:
To perform comparator measurement (p. 70), To
perform BIN measurement (p. 75)
• When you want to save the measurement results:
To save the desired number of measurement
data points (p. 87)
To save one measurement data point before the
save was performed to the USB ash drive in the
CSV format (p. 141)
An error message or error display will be shown:
Error massage
Reference Value: No measured value accuracy guarantee
Memory Full: Memory full
Hi Z: Hi Z reject error Error display
See “11.3 Error Massage and Error Display” (p. 230).
The following functionality is also available
Measuring conductivity and dielectric constant p. 68
Measuring at a high level of precision p. 56
Limiting instability of display values p. 57
Setting measurement conditions for each measurement range p. 80
Increasing the measurement precision or measurement speed p. 83
Detecting contact errors during two-terminal measurement p. 85
Detecting poor contact with the sample during four-terminal measurement p. 86
Changing the key tone or judgment tone p. 90
Disabling key operation (key lock function) p. 91
Performing measurement by outputting a signal from an external device
to the instrument p. 63, p. 161
Controlling the instrument by sending commands from a computer p. 132
Saving settings data to the USB ash drive p. 153
Loading settings data from the USB ash drive p. 155
10
9
8
7
6
5
4
3
2
1
10
Safety Information
Safety Information
This instrument is designed to conform to IEC 61010 Safety Standards, and has been thoroughly
tested for safety prior to shipment. However, using the instrument in a way not described in this
manual may negate the provided safety features.
Before using the instrument, be certain to carefully read the following safety notes.
DANGER
Mishandling during use could result in injury or death, as well as damage to the
instrument. Be certain that you understand the instructions and precautions in
the manual before use.
WARNING
With regard to the electricity supply, there are risks of electric shock, heat gen-
eration, re, and arc discharge due to short circuits. If persons unfamiliar with
electricity measuring instrument are to use the instrument, another person famil-
iar with such instruments must supervise operations.
Notation
In this manual, the risk seriousness and the hazard levels are classied as follows.
DANGER Indicates an imminently hazardous situation that will result in death or serious
injury to the operator.
WARNING Indicates a potentially hazardous situation that may result in death or serious
injury to the operator.
CAUTION Indicates a potentially hazardous situation that may result in minor or moderate
injury to the operator or damage to the instrument or malfunction.
IMPORTANT Indicates information related to the operation of the instrument or maintenance
tasks with which the operators must be fully familiar.
Indicates a high voltage hazard.
If a particular safety check is not performed or the instrument is mishandled,
this may give rise to a hazardous situation; the operator may receive an electric
shock, may get burnt or may even be fatally injured.
Indicates the prohibited action.
Indicates the action which must be performed.
*Additional information is presented below.
Bold Names and keys on the screen are indicated in boldface.
Windows Unless otherwise specied, “Windows” represent Windows 7, Windows 8 and
Windows 10.
11
Safety Information
Symbols on the instrument
Indicates cautions and hazards.
When the symbol is printed on the
instrument, refer to a corresponding
topic in the Instruction Manual.
Indicates a grounding terminal.
Indicates AC (Alternating Current).
Indicates the ON side of the power
switch.
Indicates the OFF side of the power
switch.
Symbols for Various Standards
Indicates the Waste Electrical and
Electronic Equipment Directive
(WEEE Directive) in EU member
states.
Indicates that the product conforms
to regulations set out by the EU
Directive.
Accuracy
We dene measurement tolerances in terms of f.s. (full scale), rdg. (reading) and dgt. (digit) values,
with the following meanings:
f.s. (maximum display value)
The maximum displayable value. This is usually the name of the currently selected range.
rdg. (reading or displayed value)
The value currently being measured and indicated on the measuring instrument.
dgt.
(resolution)
The smallest displayable unit on a digital measuring instrument, i.e., the input value that
causes the digital display to show a “1” as the least-signicant digit.
Measurement categories
To ensure safe operation of measuring instruments, IEC 61010 establishes safety standards for vari-
ous electrical environments, categorized as CAT II to CAT IV, and called measurement categories.
DANGER
•Using a measuring instrument in an environment designated with a higher-
numbered category than that for which the instrument is rated could result in a
severe accident, and must be carefully avoided.
•Never use a measuring product that lacks category labeling in a CAT II to CAT
IV measurement environment. Doing so could result in a serious accident.
CAT II: When directly measuring the electrical outlet receptacles of the primary electrical cir-
cuits in equipment connected to an AC electrical outlet by a power cord (portable tools,
household appliances, etc.)
CAT III:
When measuring the primary electrical circuits of heavy equipment (xed installations) con-
nected directly to the distribution panel, and feeders from the distribution panel to outlets
CAT IV: When measuring the circuit from the service drop to the service entrance, and to the
power meter and primary overcurrent protection device (distribution panel)
T
Outlet
CAT II
Internal wiring
Distribution panel
Service entrance
Service drop
CAT IV
Power meter
CAT III
Fixed Installation
10
9
8
7
6
5
4
3
2
1
12
Operating Precautions
Operating Precautions
Follow these precautions to ensure safe operation and to obtain the full benets of the various functions.
DANGER
If the probes, cords or the instrument is damaged, there is a risk of electric
shock. Before using the instrument, perform the following inspection.
•Before using the instrument, check that the coating of the probes or cords are
neither ripped nor torn and that no metal parts are exposed. Using the instru-
ment under such conditions could result in electric shock. Replace the probes
or cords with those specied by our company.
•Verify that the instrument operates normally to ensure that no damage occurred
during storage or shipping. If you nd any damage, contact your authorized
Hioki distributor or reseller.
Instrument Installation
Installation environment
WARNING
Installing the instrument in inappropriate locations may cause a malfunction of
instrument or may give rise to an accident. Avoid the following locations.
•Exposed to direct sunlight or high temperature
•Exposed to corrosive or combustible gases
•Exposed to a strong electromagnetic eld or electrostatic charge
•Near induction heating systems (such as high-frequency induction heating sys-
tems and IH cooking equipment)
•Susceptible to vibration
•Exposed to water, oil, chemicals, or solvents
•Exposed to high humidity or condensation
•Exposed to high quantities of dust particles
Installation instructions
CAUTION
• Do not place the device on an unstable table or an inclined place. Dropping or knock-
ing down the device can cause injury or damage to the device.
• Leave sufcient space around the instrument when positioning it. Failure to do so may
result in damage to the instrument or re.
• Install with the bottom surface facing downward.
• Vents must not be obstructed.
50 mm or more 50 mm or more 10 mm or more
Vents
Back
The instrument can be used with the stand (p. 18).
It can also be rack-mounted (p. Appx.12).
13
Operating Precautions
Shipping precautions
Hioki disclaims responsibility for any direct or indirect damages that may occur when this instrument
has been combined with other devices by a systems integrator prior to sale, or when it is resold.
Handling the Instrument
This instrument may cause interference if used in residential areas. Such use must be avoided un-
less the user takes special measures to reduce electromagnetic emissions to prevent interference
to the reception of radio and television broadcasts.
DANGER
To avoid electric shock, do not remove the instrument’s case. The internal com-
ponents of the instrument carry high voltages and may become very hot during
operation.
CAUTION
• Note that the instrument may be damaged if the applied voltage or current exceeds
the measurement range.
• Do not use excessive force on the touch panel, and do not use sharp objects that
could damage the touch screen.
• Do not apply heavy downward pressure with the stand extended. The stand could be
damaged.
• If the instrument exhibits abnormal operation or display during use, review the infor-
mation in “11.2 Troubleshooting” (p. 223) and “11.3 Error Massage and Error Dis-
play” (p. 230) before contacting your dealer or Hioki representative.
• To avoid damage to the instrument, protect it from physical shock when transporting
and handling. Be especially careful to avoid physical shock from dropping.
• After use, always turn OFF the power.
Before Turning Power On
WARNING
•Before turning the instrument on, make sure the supply voltage matches that
indicated on its power connector. Connection to an improper supply voltage
may damage the instrument and present an electrical hazard.
•To avoid electrical accidents and to maintain the safety specications of this
instrument, connect the power cord provided only to a 3-contact (two-conductor
+ ground) outlet.
•Be sure to ground the power cord. Failure to do so will cause the enclosure to
have a voltage equal to half the supply voltage, resulting in electric shock.
•
To avoid shock and short circuits, turn off all power before connecting probes or cords.
CAUTION
Do not connect the supply voltage improperly. Doing so may destroy the instrument’s
internal circuitry.
DC resistance measurement only
To suppress noise, the instrument needs to be set to match the frequency of the power source. Before
operating, set the instrument to the frequency of your commercial power. If the supply frequency is not set
properly, measurements will be unstable.
See “Line frequency (DC)” (p. 54).
10
9
8
7
6
5
4
3
2
1
14
Operating Precautions
Handling the cords, xtures, and probes
WARNING
If the insulation on a cord melts, the metal conductor may be exposed. Do not use
any cord whose metal conductor is exposed. Doing so could result in electric shock,
burns, or other hazard.
CAUTION
• To avoid breaking the cords or probes, do not bend or pull them.
• Avoid stepping on or pinching cords, which could damage the cord insulation.
• Keep in mind that, in some cases, conductors to be measured may be hot.
•
To avoid damage to the instrument, do not short-circuit the measurement terminals
and do not input voltage to the measurement terminals.
• For safety reasons, disconnect the power cord when the instrument is not used.
• To avoid damaging the power cord, grasp the plug, not the cord, when unplugging it
from the power outlet.
• To prevent damage to the BNC connector or junction, be sure to release the locking
mechanism, grip the head of the connector (not the cord), and pull it out.
• Put the protective cap back on the connector when not in use. If the protective cap is
not properly inserted, dust or other foreign matter may enter the connector and cause
damage.
IMPORTANT
• Use only the specied connection cords. Using a non-specied cable may result in incorrect
measurements due to poor connection or other reasons.
Before using a xture or the like, read the instruction manual supplied with the product to
be used.
Before Using the USB Flash Drive
CAUTION
•
Do not transport the instrument while a USB ash drive is connected. Damage could result.
• Inserting a USB ash drive upside down, backwards or in the wrong direction may
damage the USB ash drive and/or the instrument.
•
Some USB ash drives are susceptible to static electricity. Exercise care when using such
products because static electricity could damage the USB ash drive or cause malfunc-
tion of the instrument.
IMPORTANT
• USB ash drives have a limited usable lifetime. After long-term use, data reading and writing
will fail, at which time the USB ash drives must be replaced.
• When a USB ash drive is accessed, the color of the USB icon changes from blue to red. Do
not turn off the power of the instrument while the USB ash drive is being accessed. Also,
never remove the USB ash drive from the instrument. Doing so may result in the data in the
USB ash drive being lost.
• Hioki cannot recover data from damaged or faulty storage media resulting from abnormalities. We
are also unable to provide compensation for such data loss,regardless of the contents or cause
of the failure or damage. We recommend making a backup of all important data on a computer or
other storage devices..
15
Operating Precautions
With some USB ash drives, the instrument may not start up if power is turned on while the USB ash
drive is inserted. In such a case, turn power on rst, and then insert the USB ash drive. It is recom-
mended to try out operation with a USB ash drive before starting to use it for actual measurements.
Before Connecting EXT I/O
WARNING
•The ISO_5V pin of the EXT I/O connector is a 5V power output. Do not apply
external power to this pin.
To avoid electric shock or damage to the equipment, always observe the follow-
ing precautions when connecting to EXT I/O connectors.
•Always turn off the power to the instrument and to any devices to be connected
before making connections.
•Be careful to avoid exceeding the ratings of EXT I/O connectors. (p. 178)
•During operation, a wire becoming dislocated and contacting another conduc-
tive object can be serious hazard. Use screws to secure the external connec-
tors.
•Ensure that devices and systems to be connected to the EXT I/O terminals are
properly isolated.
CAUTION
To avoid damage to the instrument, observe the following cautions:
• Do not apply voltage or current to the EXT I/O terminals that exceeds their ratings.
• Do not short the ISO_5V and ISO_COM EXT I/O connectors.
See “Instrument connector signal assignments” (p. 162).
• When driving relays, be sure to install diodes to absorb counter-electromotive force.
Handling the LCR application disc
• Exercise care to keep the recorded side of discs free of dirt and scratches. When writing text on a
disc’s label, use a pen or marker with a soft tip.
• Keep discs inside a protective case and do not expose to direct sunlight, high temperature, or
high humidity.
• Hioki is not liable for any issues your computer system experiences in the course of using this
disc.
10
9
8
7
6
5
4
3
2
1
16
Operating Precautions
This manual suits for next models
1
Table of contents
Other Hioki Measuring Instrument manuals
Hioki
Hioki PW3365 User manual
Hioki
Hioki 8835-01 User manual
Hioki
Hioki PQ3198 User manual
Hioki
Hioki 8715-01 User manual
Hioki
Hioki Super megohm SM7110 User manual
Hioki
Hioki 3332 User manual
Hioki
Hioki PW6001 User manual
Hioki
Hioki CHT3548 User manual
Hioki
Hioki PW3390 Use and care manual
Hioki
Hioki LUX HiTESTER 3423 User manual
