Hioki 3126-01 User manual
Warranty
Warranty malfunctions occurring under conditions of normal use in
conformity with the Instruction Manual and Product Precautionary
Markings will be repaired free of charge. This warranty is valid for a
period of one (1) year from the date of purchase. Please contact the
distributor from which you purchased the product for further informa-
tion on warranty provisions.
Introduction
Thank you for purchasing the HIOKI 3126-01 PHASE DETECTOR.
To obtain maximum performance from the product, please read this
manual first, and keep it handy for future reference.
Initial Inspection
When you receive the product, inspect it carefully to ensure that no
damage occurred during shipping. If damage is evident, or if it fails to
operate according to the specifications, contact your dealer or Hioki
representative.
Preliminary Checks
• Before using the product the first time, verify that it operates nor-
mally to ensure that the no damage occurred during storage or ship-
ping. If you find any damage, contact your dealer or Hioki
representative.
• Before using the product, make sure that the insulation on the
cables and the protective tube of the fuse holder is undamaged and
that no bare conductors are improperly exposed. Using the product
in such conditions could cause an electric shock, so contact your
dealer or Hioki representative for repair.
Maintenance and Service
• To clean the product, wipe it gently with a soft cloth moistened with
water or mild detergent. Never use solvents such as benzene, alco-
hol, acetone, ether, ketones, thinners or gasoline, as they can
deform and discolor the case.
• To verify that the product operates normally,connect the tester to a
three-phase power supply that has a collect phase order and make
sure that the indicator dial rotates in the direction of the arrow.
• If the product seems to be malfunctioning, your dealer or Hioki rep-
resentative. Pack the product carefully so that it will not be damaged
during shipment, and include a detailed written description of the
problem. Hioki cannot be responsible for damage that occurs during
shipment.
Follow these precautions to ensure safe operation and to obtain the
full benefits of the various functions.
Safety Symbol
The following symbols in this manual indicate the relative importance
of cautions and warnings.
Indicates that incorrect operation presents an extreme haz-
ard that could result in serious injury or death to the user.
Indicates that incorrect operation presents a significant haz-
ard that could result in serious injury or death to the user.
Indicates that incorrect operation presents a possibility of
injury to the user or damage to the product
Advisory items related to performance or correct operation of
the product.
This manual contains information and warnings essential for safe
operation of the product and for maintaining it in safe operating condi-
tion. Before using the product, be sure to carefully read the following
safety notes.
• Continuous use for long periods of time may be dangerous. Be sure
to use the tester within the maximum permissible use times given
above.
• If the power voltage is unknown, be sure to check it first with a volt-
meter before connection the tester.
• This tester is designed to be used in the horizontal position (±15
°
).
Using it in other attitudes may prevent the dial from rotating, and
cause faulty readings.
The ABS case and all movable components are resistant to vibration
and impact, providing the strength needed for field application. And its
compact size and light weight provides superior portability. In addition,
the leads are color-coded to match the dial, making it easy to tell R, S
and T leads from each other.
Connect the tester to a three-phase circuit. If the circular dial rotates in
the direction of the arrow, the phase connection order is RST.
1. Open the fuse holder by turning one end counterclockwise.
2. Replace the fuse inside the fuse holder.
3. Close the fuse holder by pushing the ends back together, then turn-
ing one end clockwise.
0
3126-01
PHASE DETECTOR
Instruction Manual
September 2013 Revised edition 9 Printed in Japan
3126A980-09 13-09H
Inspection and Maintenance
Specifications
Voltage range 110 to 480 V
Permissible time limits 110 V: continuous
220 V: 30 minutes
480 V: 4 minutes
Frequency range 40 to 70 Hz
Using position Horizontal position ±15
°
Operating temperature
&humidity 0 to 40
°C (32 to 104°F)
,
70%RH or less (non-condensating)
Storage temperature
&humidity
-10 to 50°C (14 to 122°F),
70%RH or less
(non-condensating)
Dielectric strength 2000 VAC for 1 minute
(between circuit and product, at 50/60 Hz)
Insulation resistance 100 Mor more/500 VDC
(between circuit and product)
Connection cable
length
1.2 m (472.44“)
Accessories Carring case, Instruction manual, Protective
fuse (7012540 (made by SIBA Inc.), Rating
FF0.5 A/700 V non-arcing (6.35 dia. x 32
mm))
Dimensions and mass 70W x 95H x 55D mm (2.76”W x 3.74”H x
2.17”D)
280 g (9.9 oz.)
Safety
In the manual, the symbol indicates particularly impor-
tant information that the user should read before using the
product.
Usage Notes
The maximum rated working voltage is 480 VrmsAC. Attempting
to measure voltage in excess of the maximum rating could
destroy the product and result in personal injury or death.
• To avoid electric shock, do not allow the product to get wet,
and do not use it when your hands are wet.
• To avoid electric shock when measuring live lines, wear
appropriate protective gear, such as insulated rubber gloves,
boots and a safety helmet.
• Do not use the product where it may be exposed to corrosive
or combustible gases. The product may be damaged or cause
an explosion.
• To avoid electric shock, turn off the power before attaching a
clip, and then turn on the power to measure.
• Do not store or use the product where it could be exposed to direct
sunlight, high temperature or humidity, or condensation. Under
such conditions, the product may be damaged and insulation may
deteriorate so that it no longer meets specifications.
• To avoid damage to the product, protect it from vibration or shock
during transport and handling, and be especially careful to avoid
dropping.
Features
Measurement Procedure
Fuse Replacement
• To avoid electric shock when replacing the fuse, first discon-
nect the clip from the object to be measured.
• Replace the fuse only with one of the specified characteristics
and voltage and current ratings. Using a non-specified fuse or
shorting the fuse holder may cause a life-threatening hazard.
Fuse type: 7012540 (made by SIBA Inc.), Rating FF0.5 A/700 V
(non-arcing) 6.35 X 32 mm dia.
The leads on the clip side of the fuse holders do not rotate turn
independently of the fuse holders. To avoid damaging the leads, do
not turn the fuse holders unless the leads are free to turn with them.
Rotating dial
Indicator dial Three-phase
power supply
Red clip
White clip
Blue clip
Fuse holder
Fuse holder
Fuses are contained in the fuse holders.
Fuse holder (clip side)
Protective tube
Fuse
