HOMCOM 800-094V70 User manual

ASSEMBLY INSTRUCTION
INcsb032V01_UK
800-094V70
Digital Air Fryer
（220-240V 1700W 5.5L）
Manufacturer:Zhejiang Tianxi Kitchen Appliance Co.,Ltd
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

SAFETY INSTRUCTIONS
•Carefully and fully read the instruction manual prior to using the appliance and
carefully store the manual for future reference.
Caution! Avoid contact with hot surfaces within the appliance, when it is
switched on.
•Never cover the air inlet and outlet openings when using the appliance.
•Always placethe ingredients to be fried in the basket, to prevent them from
making contact with the heating elements.
•Never fill the appliancewith oil, this could causea fire hazard.
•Never submerge the appliance, cord or plug in water.
•Only use this appliance for the purposes describedin the instructionmanual.
•Only connect the appliance to alternate current, to a grounded wall socket, with a main
voltagethat corresponds with the information providedon theinformationplate of the
appliance.
•Keep the appliance out of reach of children. Childrendo not seethe dangers when
handlingelectrical appliances. Therefore, never allow childrento work with electrical
appliances without supervision. Keep theappliance andcord out of reach of children
younger than8 years of age.
•Theappliance canbe used by childrenof 8 years and older and persons with a limited
physical, sensory or mental capacity or lack of experience or knowledge, provided they
use theappliance under supervision or have been instructed about its safe use and
understandthe hazards involved.
•Childrenare not allowedto play with the appliance.
•Theappliance may not be cleanedor maintained by children, unless this is doneunder
supervision.
•Do not use the appliance if theplug, cord or appliance are damaged, or if the appliance
no longer functions properly or if it is damagedin any other way. If this is the case,
consult our technical service center. Never replace the plug or cord yourself. Repairs to
electrical appliances should only be performedby skilledpersons.
•In correct repairs could cause considerable hazards for the user.
Never use theappliance with parts that are not recommended
or supplied by themanufacturer.
•Never bend thepower cord sharply or allow it to runacross hot parts.
•Connect the appliance only to agrounded socket. Always check that the plug is
properly inserted in the socket.
•Do not pull the cord and/or appliance to remove the plug from the wallsocket. Never
touch theappliance with wet or moist hands.
•Never connect theappliance to an external timer or a separate remote control system,
in order to prevent hazardous situations.
•Never place the appliance near appliances that give off heat, such as ovens, gas
cookers, hotplates, etc. Keep the appliance away from walls or other objects that could
catch fire, such as curtains, towels (cottonor paper, etc.).
•Place the appliance on a sturdy, flat surface and make sure there is enough space

around it for sufficient ventilation. A minimum space of 10 cm is required between the
appliance and the walls. Place nothing on top of the appliance.
•Do not leave the appliance unsupervised when it is working.
•Caution! A lot of steam is released via the outlet openings during hot air frying. Keep
your hands and face away from the steam coming out of the outlet openings. Watch out
for the steam, when removing the pan.
•After use, the interior is very hot. Therefore avoid con tact with the interior.
•Always make sure the appliance is placed on an even, flat surface and is only used in
doors.
•This appliance is only intended for household use and not for use:
-in staff kitchens, shops, offices and other work environments.
-by guests of hotels, motels and other residential environments.
-in Bed & Breakfast type environments
-farms
•If the appliance is not being used or is being cleaned, switch off the appliance and
remove the plug from the socket.
•Allow the appliance to cool down for 30 minutes before storing or cleaning it
•Ensure that the ingredients being prepared in the appliance come out golden-brown
and not dark or brown. Remove burnt parts.
•In case of a breakdown, do not make repairs yourself; a blown safety device in the
appliance could indicate a defect that cannot be resolved by removing or replacing this
safety device. Only original parts should ever be used.
•This appliance is only suitable for household use. When the appliance is used for any
other use than intended, no claims for compensation can be made in case of any
defects and the warranty is invalidated.
OVERHEATING SAFETY SYSTEM
The hot air fryer has been provided with an overheatingsafety system. If the interior
temperature is too high, the appliance is switched off automatically by the safety system. In
that case, theappliance canno longer be used. Remove the plugfrom the socket, allow
the appliance to cool down andcontact the service center or your retailer.
AUTOMATIC DEACTIVATION
This appliance hasbeenprovided with atimer. Once the timer has counted down to 0, a
beep sound can be heard and the appliance switches off automatically. To switch off the
appliance manually, press the on and off key once to stop the frying process, and then
press theonand off key a secondtime to switch off thedisplay.
ELECTROMAGNETIC FIELDS (EMF)
This appliance complies with all requirements relating to electromagnetic fields (EMF).

PRODUCT DESCRIPTION
1.Operating panel
2.Basket
3.Basket handle
4.Pan
5.Air inlet openings
6.Heating element
2.Basket
3.Basket handle
4. Pan
7. Release button- basket
8. "+" and "-" keys for setting the temperature
9. Easy control menu button
10. Automatic menus
11. Standby and on-and-off key
12. "+"and "-" keys for setting the time
13.Display (temperature and preparation time)
14. Thermostat indicator

PRIOR TO FIRST USE
Before using the appliance for the first time, you should proceed as follows: carefully
unpack the hot air fryer and remove all packaging material and any promotional stickers.
Keep the packaging (plastic bags and cardboard) out of the reach of children. After
unpacking the appliance, check it for external damage that may have occurred during
transport. Place the hot air fryer on a sturdy, flat and heat-resistant surface.
The buttons used for opera ting the hot air fryer; are touch controls and an easy control
rotary knob. Carefully touch the touch controls with a finger to activate. Each time the touch
control is touched and the rotary knob is turned, you can hear a sound signal.
STANDBY
As soon as you insert the plug in the socket, the hot air fryer is in the standby position. The
standby key lights up.
In the following situations, the hot air fryer automatically switches to the standby position:
•when you insert the plug in the socket
•when the set time has elapsed
•when you press the standby key for 4 seconds
SWITCHING ON AND OFF
Switch on the hot air fryer with the standby key
•The hot air fryer only functions if the basket has been placed in the pan correctly.
•As soon as the set time has elapsed, the hot air fryer automatically switches to the
standby position: The fan does not continue to run in order to allow the hot air fryer to
cool down. After approximately 20 seconds, 5 beeps will sound and the thermostat
indicator is switched off.
•Attention: during cooling it is not possible to operate the display.
PRIOR TO FIRST USE
Check that the voltagecorresponds with what is statedon theinformationplate andinsert
the plugin agrounded socket. Theheatingelement is provided with a protective layer
that must be removedprior to first use. This is done by settingthe hot air fryer to the
maximum position for approximately 10 minutes without any food in theappliance. A little
smoke may be generated dueto the protective layer being burnt off the heating
element. Therefore ensure sufficient ventilation in theroom. After removingthe protective
layer you can switch off thehot air fryer.
Remove the plug from the socket. Allow the hot air fryer to cool down properly and clean
loose comp orients prior to actually using the hot air fryer. Clean the basket and pan with
warm water; a mild washing-up liquid and a soft sponge.
Tip: these components may also be cleaned in the dishwasher.
Clean the interior and exterior of the appliance with a damp cloth.

This fryer works with hot air. Do not fill the pan with oil or frying fat.
•Place the hot air fryer on a heat-resistant flat surface.
•Properly place the basket in the pan.
•Place the pan in the hot air fryer.
CAUTION! Properly place the pan in the hot air fryer; otherwise it will not function.
Do not fill the pan with oil or other liquids.
Place nothing on top of the appliance.
Do not place anything over the air inlet openings. This will disrupt the air
circulation and will have a negative effect on the frying result.
SETTING TEMPERATURE AND TIME
Use the +and -keys to set the temperature °C and the time MIN. The display changes
every 5 seconds if no key is operated.
HOTAIR FRYING
The hot air fryer can be used to prepare a wide range of dishes.
1. Check that the voltage corresponds with what is stated on the informationplate and
insert the plug in agrounded socket. Thefull display briefly lights up and thehot air fryer
is in thestandby position. The standby key lights up.
2. Carefully remove thepan from thehot air fryer by its handle.
3. Place the ingredients in thebasket. Caution: never exceed the recommended volume
and never fill the basket above the maximum, because in that case the foodcould
make contact with theheating element.
4. Properly slide the pan back in the hot air fryer. Never usethe pan without the basket.
If the pan is not properly placed in the hot air fryer, the appliance will not
function.
Caution: do not touch the pan during and shortly after use, as it gets very hot.
Only hold the pan by its handle.
5. Press thestandby key to switch on thehot air fryer. The display shows thepreset of
190°C and 15 minutes.
6. Select an automatic menu with the easy control menu buttonor set the time MIN (1 - 60
minutes) and temperature °C (80- 200°C) yourself using the accompanying +and -
keys.
Tip: add 3 minutes to the cookingtime when thehot air fryer is cold.
7. Then press the easy control menu buttonto switch on thehot air fryer.
•Thedisplay alter nates between theset time andset temperature.
•Thedisplay shows the remaining time. Time and temperature can be adjusted during
frying by pressingtheaccompanying +or -keys.
During hot air frying, the thermostat indicator flashes.
•Excess oildrippingfrom theingredients is collected in the pan.

8. Some ingredients must be shaken halfway the cooking time. Take the pan from the hot
air fryer by its handle and place it on a heat-resistant surface, such as a pan coaster.
Press the release button of the handle and lift the basket from the pan. Shake the
contents of the basket above the pan to prevent leaking and click back the basket in the
pan. When you remove the pan from the hot air fryer; the hot air frying process is
interrupted.
Caution: the display switches off completely. When you place the pan back in the hot
air fryer; the display switches on and hot air frying is resumed automatically.
9. Then slide back the pan in the hot air fryer to continue frying. When you place the pan
back in the hot air fryer; the display switches on and hot air frying is resumed
automatically.
10. As soon as the set time has elapsed, the hot air fryer automatically switches to the
standby position: The fan does continue to run order to allow the hot air fryer to cool
down. After approximately 20 seconds, 5 beeps will sound and the thermostat indicator
is switched off. Pull the pan from the hot air fryer by its handle and place it on a
heat-resistant surface, such as a pan coaster.
Check that the ingredients are cooked.
If the ingredients are not yet cooked, place the pan back in the hot air fryer; add a
number of extra minutes to the timer and then press the easy control menu button.
11. To remove small ingredients (such as fries), press the button of the handle and lift the
basket from the pan.
Do not hold the basket upside down while the pan is still attached. The excess fat
accumulated on the bottom of the pan will spread all over the ingredients.
After hot air frying, the pan and the ingredients are hot. Depending on the type of
ingredients, it is possible that steam comes out of the pan.
After hot air frying, the pan and the metal interior are very hot, avoid contact with
these components.
12. Empty the basket onto a dish or plate. In case of large ingredients, use tongs.
PAUSE
•Press the easy control menu butt on to pause the hot air frying process. Press the easy
control menu butt on once more to resume the hot air frying process.
•The hot air frying process is also paused when you remove the pan from the hot air
fryer.
Caution: the display switches off completely.
When you place the pan back in the hot air fryer; the display switches on and the hot air
frying process is resumed.

AUTOMATIC MENUS
Tur n the easy control menu butt on to select the following functions:
Preset Menu Set Temperature Set Time
Standard seng 190°C 15 minutes
Fries 200°C 12 minutes
Chicken 180°C 20 minutes
Steak 200°C 9 minutes
Fish 200°C 10 minutes
170°C 3 minutes
Frozen Snacks 200°C 12 minutes
Vegetables 150°C 16 minutes
Shrimps 200°C 8 minutes
Preheang 200°C 10 minutes
Quick 5 190°C 5 (5-30) minutes
The temperatures and times in the table are indications. Depending on size and weight, it may be necessary
to adjust temperature and time.
You can change the set temperature and time of the automatic menus by pressing the accompanying +and -
keys.
After selecting an automatic menu, press the easy control menu butt on to switch on the hot air fryer.
The time in the QUICK 5 menu can only be adjusted in steps of 5 minutes: 5-10-15-20-25-30 minutes.
baking

TIPS
•Smaller ingredients usually require a slightly shorter cooking time.
•A larger amount of ingredients only requires a little more time, and a smaller amount
requires a little less cooking time.
•Shaking smaller ingredients several times during the cooking time results in a better
and more even end result.
•Do not cook extremely fat ingredients such as sausages in the hot air fryer.
•Snacks that can be cooked in the oven, can also be cooked in the hot air fryer.
•The optimum amount for preparing crispy fries is 1500g. The maximum amount is
2000g.
•If necessary, use an oil spray to lightly oil the ingredients and make them even more
crispy.
•Use ready-made dough for a fast and simple preparation of filled snacks. Ready-made
dough cooks faster than home-made dough.
•Place a baking tin or oven dish in the basket if you want to make a cake or quiche, or if
you want to cook delicate or filled ingredients.
•The hot air fryer can also be used to reheat ingredients. For this, set the temperature to
150°C for 10 minutes.
•Add 3 minutes to the cooking time if the hot air fryer is still cold.
•As the turbo hot air tech no logy immediately reheats the air in the appliance, briefly
removing the pan from the hot air fryer does not have an effect on the end result.

CLEANING AND MAINTENANCE
Clean the hot air fryer after every use.
Before cleaning the hot air fryer, allow it to cool down fully.
Do not touch the metal interior in order to clean it, when frying has just been
completed.
When cleaning the pan and basket, do not use metal kitchenware or abrasive agents,
as these could damage the anti-stick coating.
1. Remove the plug from the socket and allow the hot air fryer to cool down fully.
Tip: remove the pan from the hot air fryer to allow the appliance to cool down faster.
2. Cleanthe exterior of the hot air fryer with a damp cloth.
3. Cleanthe pan and basket with hot water containing a little soap and a sponge. The
pan and basket may also be cleanedin the dishwasher.
A degreaser can be used to remove remaining dirt.
Tip: fill the pan with hot water and a little bit of washing-up liquid and allow it to soak for 10
minutes to remove persistent dirt.
4. Cleanthe interior of the appliance with hot water and a soft sponge.
5. Cleanthe heating element with a soft brush to remove any food residues. Be careful
with washing-up liquid. This could be left behind on the heating element and give a foreign
taste to the ingredients.
Never submerge the appliance, cord or plug in water or other liquids
Before storing the hot air fryer; allow it to cool down fully and remove the plug from the
socket. Check that all components are clean and dry. Store the hot air fryer in a clean and
dry location.

PROBLEMS AND SOLUTIONS
ProblemsPossible cause Solutions
The hot air fryer does
not funcon.
The plug is not in the socket. Insert the plug in an earthed socket.
The pan is not properly
placed in the appliance.
Properly slide the pan in the appliance
The ingredients are not
cooked.
The amount of ingredients in
the basket is too much.
Place smaller amounts of ingredients in
the basket. Smaller porons can be
fried more evenly.
The set temperature is too
low.
Set the hot air fryer to a higher
temperature.
The cooking me is too short. Set a Ionger me.
The ingredients are not
fried evenly.
Certain ingredients must be
shaken halfway the cooking
me.
Ingredients lying on top of one another
(such as fries), must be shaken halfway
the cooking me.
Fried snacks are not crispy
when they leave the hot
air fryer.
The snacks are not suitable for
ahot air fryer; but should be
fried in oil.
Use oven snacks or cover the snacks
with a lile oil for a more crispy result.
It is not possible to slide
the pan in the appliance
properly.
The basket is overfilled. Do not fill the basket above the
maximum, but observe the
recommended amounts.
The basket is not properly
aached in the pan.
Press the basket in the pan unl
you hear a click sound.
There is white smoke
coming from the
appliance.
You are cooking fay
ingredients.
When fay ingredients are being
cooked in the hot air fryer; it is possible
that a lot of fat drips in the pan. The fat
causes white smoke and the pan can
become hoer
than normal. This does not have an
effect
on the applianee or on the end result.
The pan sll contains fat
residues from a previous
preparaon.
Clean the pan aer every use. Fat
residues that become hot can cause
white smoke.
Fresh fries are not evenly
fried in the hot air fryer.
An unsuitable potato variety
has been used.
Use fresh potatoes that are a lile
floury when cooked.
The fries have not been
properly rinsed prior to frying.
Properly rinse the cut fries to remove
starch.

DISPOSAL OF ELECTRICAL APPLIANCES
- This symbol means that this product shall not be disposed of
with normal household waste.
- Follow your country’s rules for the separate collection of
electrical and electronic products. Correct disposal helps
prevent negative consequences for the environment and
human health.
