HOMCOM 800-164V70 User manual

1
INSTRUCTION MANUAL
IN221200235V01_UK
800-164V70
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
-FOR INDOOR HOUSEHOLD USE ONLY-
Air fryer

2
This appliance is not intended to be used in locations such as:
- Staff kitchen areas in shops, offices and other working environments.
- Farm houses.
- By clients in hotels, motels and other residential type environments.
- Bed and breakfast type environments.
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury to persons, including the following:
1. Read all instructions before using this product.
2. This appliance generates heat during use. Do not touch hot surfaces. Use handles or
knobs.
3. To protect against electric shock, do not immerse cord, plugs, or appliance in water or
other liquid.
4. This appliance is not intended for use by children or by persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge. Close supervision
is necessary when any appliance is used near small children. Keep the appliance and
cord out the reach of children.
5. Before cleaning, maintenance and when not in use, ensure the appliance is unplugged
and has cooled down. To disconnect, turn controls off, then unplug from the outlet by
grasping the plug – do not pull the cord.
6. Do not use any appliance with a damaged cord, plug or after the appliance
malfunctions. Do not attempt to replace or splice a damaged cord. Return the
appliance to the manufacturer (see warranty) for examination, repair or adjustment.
7. Using accessories not recommended by the manufacturer may cause injuries.
8. Do not use outdoors or for commercial purposes.
9. Do not let cord hang over the edge of tables or counters or touch hot surfaces.
10. Keep away from wet surfaces and heat sources, such as hot gas, electric burners and
heated ovens.
11. Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.
12. The heating base is subject to residual heat from the cooking cycle. Do not touch
heating base immediately after using. Allow to cool before handling.
13. Use caution when opening the lid during or after a cooking cycle. Steam can cause
burns.
14. Do not use appliance for anything other than its intended purpose. Improper use can
cause injuries or damage to property.
15. Intended for household use only. Ensure there is at least 6 inches (152mm) of space
between the wall and all sides of the appliance. Place the appliance on a dry, stable
and level surface.
16. If the appliance is tilted, the lid will not stay open on its own. Ensure the appliance is
upright before opening the lid.
17. Never use an external timer or separate remote control system to operate this
appliance.
18. WARNING: Spilled food can cause serious burns. Keep appliance and cord away
from children. Never drape cord over edge of counter and never use an outlet below
the counter.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS

3
INTRODUCTION
This air fryer provides an easy and healthy way of preparing your favourite ingredients.
By using hot rapid air circulation and a top grill, it is able to make numerous dishes. It
heats food in all directions, so most ingredients do not need oil.
TECHNICAL DATA:
-----Voltage:220-240V,~50/60Hz
-----Wattage:1350 Watts (1350W)
-----Capacity of pot: 6.5 Litre(6.5QT)
-----Adjustable temperature:0℃-200℃
----- Timer: 0-60 min
General description
Perspective
window
Button
Timer knob Temperature knob
Air inlet
Air outlet
Fig 2
Stirring shaft
Mixing
blade
Grill
Pot
Handle
Axis of
rotation

4
Important
Danger
Under guided supervision, this appliance can be used by children aged eight years and
above, provided they understand the potential risks and hazards. Under guided
supervision, this appliance can be used by persons with disabilities or persons without
experience, provided they understand the potential risks and hazards.
- Small children must not clean or maintain this appliance, unless they are older than eight
years and are under adult supervision.
- Keep the appliance and cord out the reach of small children.
- Never immerse the housing in water or rinse under a tap – it contains electrical
components and heating elements.
- Do not let water or other liquids enter the appliance to prevent electric shock.
- Always put the ingredients into the pot, so it doesn’t touch the heating elements.
- Do not cover the air inlet and the air outer openings while the appliance is operating.
- Do not fill the pot with oil as this may cause a fire hazard.
- Never touch the inside of the appliance while it is operating.
- Surfaces may be hot when the appliance is in use.
WARNING
- Check if the voltage indicated on the appliance matches the local mains voltage.
- If the plug, mains cord or other parts are damaged, do not use this appliance.
- Unauthorised persons must not replace or fix damaged cords.
- Keep the mains cord away from hot surfaces.
- Never plug in or use the appliance with wet hands.
- Do not place the appliance against the wall or other appliances. Ensure there is at least
10cm of space between the wall and all sides of the appliance.
Do not place anything on top of the appliance.
- Do not use the appliance for anything any other than the purpose described in this
manual.
- When in use, never leave the appliance unattended.
- During use, hot steam is released through the air outlet openings. Keep your hands and
face away from the steam and openings.
Be careful of hot steam and air when removing the pot.
- If you see dark smoke coming from the appliance, unplug it immediately. Wait for the
smoke to stop before removing the pot.
Caution
- Ensure the appliance in placed on a horizontal, even and stable surface.
- This appliance is designed for household use only. It is not suitable for staff kitchens,
farms, motels and other non-residential environments.
- If this appliance is used improperly or for professional or semi-professional purposes,
the warranty will be void. We could refuse any liability for damage caused.
- Unplug the appliance when not in use.
- Wait for 30 minutes before touching, so the appliance can cool down completely.
Automatic switch-off
The appliance has a timer and when it counts down to 0, it will ring and switch off
automatically. To switch off manually, turn the timer knob anticlockwise to 0.

5
Fig 3
Before first use
1. Remove all packaging materials.
2. Remove any stickers or labels from the appliance.
3. Thoroughly clean the grill and pot with hot water, washing-up liquid and a non-abrasive
sponge.
4. Wipe inside and outside of the appliance with a damp cloth.
NOTICES
1. Some countertop and table surfaces are not designed to withstand the prolonged heat
generated by certain appliances. Do not set the heated unit on a finished wood table.
2. During initial use of this appliance, slight smoke and/or odour may be detected. This is
normal and should go away after a few uses.
Fig 4
Fig 5 Fig 6
Preparing for use
1.Place the appliance on a stable, horizontal and even surface.
Do not place the appliance on non-heat-resistant surface.
2.Place the grill in the pot.
Do not fill the pot with oil or other liquids.
Do not put anything on top of the appliance – the airflow will be disrupted and
affects the hot air frying result.
3.The grill is installed in the pot first, then mixing blade is mounted on the shaft(Fig.5).
4.When food does not need to be mixed, it can be used directly without installing a mixed
blade

6
USING THE APPLIANCE
This oil-free appliance can prepare a large range of ingredients.
Hot air frying
1. Connect the mains plug into an earthed wall socket
2. Open the air fryer by pushing the button(Fig.3)
3. Carefully put the pot into the air fryer.(Fig. 4)
4. Put grill into the pot before put the ingredients into the grill. Insert the mixing blade if
the food need to be mixed.(Fig.5)
5. Close the cover after installing the fryer, Set the time and temperature needed by
turning the knob.
6. Once the temperature and time is confirmed, the red power light besides the knob will
lit up. The air fryer will begin cooking.
Caution: This product gets very hot – do not touch during and straight after use.
Only hold the appliance with the handle.
The pot and the ingredients are hot. Depending on the type of the ingredients in the
air fryer, steam may escape from the pot.
Fig 7
Settings
This table below will help select the basic settings for ingredients.
Note: As ingredients differ in origin, size, shape and brand, we cannot guarantee the best
setting for your ingredients.
The Rapid Air technology instantly reheats the air inside the appliance.
Put the pot briefly into the appliance when preheating.
To set time and temperature, refer to below Fig.7
Tips
- Smaller ingredients usually require a slightly shorter preparation time than larger
ingredients.
- A larger amount of ingredients require a slightly longer preparation time. A smaller
amount of ingredients require a slightly shorter preparation time.
- The mixing blade can help prevent unevenly fried ingredients.
- Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the air fryer
within a few minutes after you added the oil.
- Do not prepare extremely greasy ingredients, such as sausages.
- Snacks that can be prepared in an oven can also be cooked in the air fryer.
- The optimal amount for preparing crispy fries is 400 grams.

7
- Use premade dough to prepare filled snacks quickly and easily. Premade dough is
quicker to cook than homemade dough.
- For baking cakes, quiche or for frying fragile or filled ingredients, place a baking tin or
oven dish in the pot.
-℃ To reheat ingredients, set the temperature to 150 for up to 10 minutes.
Steak Wings Shrimp Fish Snacks Fries Bake Vegetab
les
180 180 180 180 200 200 160 160
Tempera
ture
o
0-200 C
Timer 1-60Min 16 15 12 18 20 25 17 30
Min-max
Amount(g) 100-800 100-800 100-800 100-800 100-800 100-800 100-800 100-800
Cleaning
Clean the appliance after every use.
Do not use metal kitchen utensils or abrasive cleaning materials to clean the pot and grill
– this may damage the non-stick coating.
1. Unplug the appliance and let it cool down completely.
Note: Remove the pot to let the air fryer cool down quickly.
2. Wipe the outside of the appliance with a damp cloth.
3. Clean the pot and grill using hot water, washing up liquid and a non-abrasive sponge.
You can use degreasing liquid to remove any remaining dirt.
Tip: If dirt is stuck to the grill or the bottom of the pot, fill the pot with hot water with some
washing-up liquid. Put the grill into the pot and let it soak for approximately 10 minutes.
4. Clean the inside of the appliance with hot water and a non-abrasive sponge.
5. Clean the heating element with a cleaning brush to remove any food residue.
Storage
1.Unplug the appliance and let it cool down.
2.Make sure all parts are clean and dry.
Environment
Do not throw away the appliance with the normal household waste when it is exhausted,
but hand it in at an official collection point for recycling. By doing this, you help to preserve
the environment
Guarantee and service
If you need service or information or if you have a problem, please contact your local
authorized service centre.

8
Troubleshooting
Problem Possible cause Solution
The air fryer does
not work.
The appliance is not
plugged in.
You have not set the
timer.
Put the mains plug in an earthed wall socket.
Set the timer key to the required preparation time
to switch on the appliance.
The ingredients
are not fried
properly.
The amount of
ingredients in the pot is
too big.
The set temperature is
too low.
The preparation time
is too short.
Put smaller batches of ingredients in the pot.
Smaller batches are fried more evenly.
Set the temperature key to the required
temperature setting (see section ‘settings’ in
chapter ‘Using the appliance’).
Set the timer to the required preparation time
(see section ‘Settings’ in chapter’ Using the
appliance’).
The ingredients
are fried unevenly
in the air fryer.
Certain types of
ingredients need to be
shaken halfway
through the preparation
time.
Ingredients that lie on top of or across each other
(e.g. fries) need to be shaken halfway through the
preparation time. See section ‘Settings’ in
chapter ‘Using the appliance’.
Fried snacks are
not crispy when
they come out of
the air fryer.
You used a type of
snacks meant to be
prepared in a
traditional deep fryer.
Use oven snacks or lightly brush some oil onto
the snacks for a crispier result.
I cannot slide the
pot into the
appliance properly.
There are too much
ingredients in the pot.
Do not fill the pot beyond the MAX indication.
The grill is not placed in
the pot correctly.
Push the pot down into the pot until you hear a
click.
White smoke
comes out of the
appliance.
You are preparing
greasy ingredients.
When you fry greasy ingredients in the air fryer, a
large amount of oil will leak into the pot. The oil
produces white smoke and the pot may heat up
more than usual. This does not affect the
appliance or the end result.
The pot still contains
grease residues from
previous use.
White smoke is caused by grease heating up in
the pot. make sure you clean the pot properly
after each use.
Fresh fries are
fried unevenly in
the air fryer.
You did not use the
right potato type.
You did not rinse the
potato sticks
properly before you
fried them.
Use fresh potatoes and make sure they stay
firm during frying.
Rinse the potato sticks properly to remove
starch from the outside of the sticks.
Fresh fries are
not crispy when
they come out
of the air fryer.
The crispiness of the
fries depends on the
amount of oil and
water in the fries.
Make sure you dry the potato sticks properly
before you add the oil.
Cut the potato sticks smaller for a crispier
result.
Add slightly more oil for a crispier result.

9
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your local
authority or retailer for recycling advise.
Correct Disposal of this product
If you have any questions, please contact our customer care center.
Our contact details are below:
0044-800-240-4004
[e-mail]
IMPORTER ADDRESS:
MH STAR UK LTD
Unit 27, Perivale Park,
Horsenden lane South
Perivale, UB6 7RH
MADE IN CHINA

10
