HOMCOM 820-257 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
INcjd070_UK_IT_ES_PT
820-257

1
Warning: risk of fire, electric shock, physical injuries and material
damage.
Before using this appliance,always follow the safety advice during
assembly, use and maintenance.
SAFETY ADVICE (Use)
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
- Children of less than 3 years should be kept away unless continuously
supervised.
Children aged from 3 years and less than 8 years shall only switch on/off
the appliance provided that it has been placed or installed in its intended
normal operating position and they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children aged from 3 years and less than 8 years
shall not plug in, regulate and clean the appliance or perform user
maintenance.
CAUTION - Some parts of this product can become very hot and
cause burns. Particular attention has to be given where children and
vulnerable people are present.
- If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
- CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cutout, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and off by the utility.
- WARNING: In order to avoid overheating, do not cover the heater
- The heater must not be located immediately below a socket-outlet.
- Means for disconnection having a contact separation in all poles must
be incorporated in the fixed wiring in accordance with the wiring rules.
- The heater must be installed at least 1.8 m above the floor.
- Means for disconnection having a contact separation in all poles must
be incorporated in the fixed wiring in accordance with the wiring rules.
- Do not use this heater in the immediate surroundings of a bath,a shower
or swimming pool.
EN

2
=Power
=Mode Section
=Heating on half power (1000W)
=Heating on full power (2000W)
P = Weekly programming
=Open window Mode
°C = Setting temperature
= swing
= Timer (Turn-on/Turn-off)
Stand-by mode
Installation:
The fan heater must be installed on a wall before operating. Don’t try to use it without
installation.
The installation sequence of the fan heater is as follows:
1. Find a space to install the fan heater (See Figure ).
2. Drill two holes of the dimension of the expansible tubes ¢ - 8 mm - in the wall (See
Figure ) - D= 394mm
3. Insert the expansible tubes into the holes and tighten them with the screws
provided firmly.
NOTE: Fasten the screws tightly. Do not fasten the screw into the expansible tube
thoroughly; the length of the bare parts should be 10 mm.
4. Mount the fan heater to the wall . Make sure the two holes located on the back of
the heater do aim at the above two screws, then push the heater backwards to the
wall, and then downwards till the unit is stable.
The controls:
ON-OFF
- Press the ON -OFF switch to switch the appliance ON (I) or OFF (O).
Regular function operation
Temperature setting and
ErP function Confirm
Weekly time & window
open detection operation
EN

3
Part 1 Regular function
FAN and HEATING (by control panel)
- Press the button to select one of the following mode
Stops by going into standby Fan without heating Heating on half power
(the fan stops 30 seconds
after the stand-by).
Heating on full power with swing Heating on full power
The default setting temperature is 23°C when the light °C is off
FAN and HEATING (ONLY by remote control)
- Press to switch on the appliance.
- Press to select one of the following modes :
Fan without heating Heating on half power
Heating on full power with swing Heating on full power
EN

4
- Press again to switch off the appliance.
Stops by going into standby
(the fan stops 30 seconds after the stand-by).
TEMPERATURE CONTROL (ONLY by remote control)
- Press to switch on the appliance.
- Press + or - to set the setting temperature from 10°C to 49°C
(the light °C is on). If room temperature
15°C, setting temperature 25°C, the display as the picture
- Press to cancel the temperature setting
(the light °C is off) and to choose the heating on half power ( ) or full power ( ).
The heater working on full power when the room temperature is 4°C lower than the
setting temperature.
.The heater working on half power when the room temperature is between 0° and 2°C
lower than the setting temperature.
The heater switches off when the room temperature is higher than the setting
temperature. the fan working 30 seconds to make inside cool to protect component,
then fan stop, the unit enter into standby.
.The heater switches on again when the room temperature falls 2°C below the setting
temperature.
TURN-ON, TURN-OFF (by control panel and remote control)
Turn-on in stand-by mode:
- Press to set the appointment turn-on time in 1-12 hours (the
light is on).
.The display automatically decreases 1 hour for each hour passed.
When the appointment power-on time arrived, the product will
automatically turns on. The default setting temperature is 23°C.
.If not setting the setting temperature and weekly program, the unit
will automatically turn-off after continuous-by.
For example to set appointment turn-on time to 8 hours
Turn-offinrunning mode
Press to set the appointment turn-on time in 1-12 hours (the light is on)
When the appointment power-off time arrived, the product will automatically turns off.
The default setting temperature is 23°C
For example to set appointment turn-off time to 8 hours
EN

5
SET SET
SET SET
5 seconds
Part 2 Weekly time and Window open detection
SET CURRENT TIME (ONLY by remote control)
- Press to switch on the appliance.
- Press SET to display the hour.
- Press + or - to set the current hour (00 to 23).
- Press SET again to display the minute.
- Press + or - to set the current minute (00 to 59).
- Press SET again to display the day of week.
- Press + or - to set the current day (d1= Monday,d2=Tuesday,d3=Wednesday,
d4 = Thursday, d5 = Friday, d - Press OK to confirm the setting).
For example, Wednesday 9:30 , Setting temperature = 25°C :
To check the current time and setting temperature, press SET again.
If main switch off or power cutoff , it need reset the time
.The current time must be set before any programming.
- Press to switch on the appliance.
1- Press P to enter into weekly program setting (the light P is on).
2- Press DAY to set the day of program activation (d1, d2,d7...),
3- Press EDIT to set the time period number (P1, P2,...P6),
4- Press TIME/ON to set the turn-on time (00, 01, 02...,24,)
Cannot set to minutes.
5- Press TIME/OFF toset theturn-offtime (00, 01, 02,..., 24)
Cannot set to minutes.TIME/OFF can not be less than TIME/ON.
6- Press + or - to set the setting temperature of this time period.
EN

6
PressP Day EDIT Time/On Time/Off OK
7- Press OK to confirm the setting.
8- Repeat steps 3 to 7 to set another time period number for the same day.
Up to 6 programs are available for each day of the week.
9- Repeat steps 2 to 8 to set the others days of the week.
- Press P to active the weekly program (the light P is on), or to disable it (the lightP
is off).
- After the above setting are completed and P program is work, pressDAY / EDIT
TIME/ON and TIME/OFF to check the setting time of each dayand time period.
.When the turn-on time is same as the turn-off time, the appliance is instand by
mode.
f the setting temperature is not set, the default setting temperature is 23°C. If room
temperature higher 23°C, the appliance is not switch on.
.Theweeklyprogramiserasedwhenthe switch is off.
For example: Setting Monday 1st period working time 7:00 to 13:00
- Press to disable the open window mode (the light is off).
The appliance will resume to previous working mode.
During open window mode, if the room temperature drops from about 5°C to 10°C
in less than 10 minutes, the appliance will stop working and enter into stand by
mode. Press again to switch on the appliance.
.If open-window mode and weekly timer program simultaneously, if the appliance
turn off in weekly time, the appliance is not turned on. If it already turn on in weekly
timer, the appliance working as the setting temperature under open-window mode.
For example: when window open detection function on, the weekly working time
already setting before: it's Monday morning A.M 9:00--10:00 , desired temperature
28 degree, the window open only working A.M 9:00--10:00 , the unit will cut off
when temperature reduce to 23°C or more lower . Other time, the unit not working,
just in standby.
SET OPEN WINDOW (ONLY by remote control)
- Press to switch on the appliance, heating for a
moment
until stability.
- Press to active the open window mode (the light
is on).
- Press + or - to set the setting temperature for the
open windows function.
EN

7
REMOTE CONTROL
The remote control requires 1 CR2025 3V lithium battery (not included)
Important: Follow the instructions of use and the recycle rules given on the
battery packaging.
1- Open the battery compartment by sliding the cover down.
2- Insert the battery into the compartment,
observing the polarity in the diagram (see below drawing).
3- Close the battery compartment.
NOTE: the remote control buttons perform the same functions as those on the
control panel on the unit.
Maintenance and cleaning
- Warning : Never use detergent, chemicaldamage plastic parts.
- WARNING : Let the appliance cool down completely before handling or
cleaning.
- To prevent risk of fire or electrocution inside the appliance.
- Clean the outside wall of the appliance by rubbing it gently with soft, damp
cloth, either with or without soap.
- Regularly clean the air inlet and outlet vents of the fan.
Environmental protection
This symbol is known as the ‘Crossed-out Wheelie Bin
Symbol’. When this symbol is marked on a product or battery, it means
that it shoul general household waste. Some chemicals contained
within electrical/electronic products or batteries can be harmful to
health and the environment. Only dispose of electrical/
electronic/battery items in se which cater for the recovery and
recycling of materials contained within. Your co-operation is vital to
ensure the success of these schemes and for the protection of the
environment.
Disposal of an exhausted batteries
To preserve natural resources, please batteries properly.
EN

8
Consult your local waste authority for information regarding available recycling
and /or disposal options.
Technical Specification
- Reference : 820-257
- Rating power : 2000W
- Power : 220-240V ~ 50Hz
- Class II
- Waterproof:IP22 Protected against 15 degree angle falling drops of water
(condensation).
