Home Styles 20 05186 0004 User manual

Hardware List
20 05186 0004
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Desk Hutch
Part List
IMPORTANT
B.
Side Panel
1 pc.
C.
Side Panel
1 pc.
D.
Middle Panel
1 pc.
E.
Middle Panel
1 pc.
F.
Shelf
2 pcs.
H.
Drawer
1 pc.
Tool(s) required for assembly: Phillips screwdriver
A.
Top
1 pc.
G.
Back Panel
1 pc.
I.
Drawer
1 pc.
Refer to the last page(s) of these instructions for drawer assembly.
Cam Lock
19 pcs. (+2 extra)
Cam Lock Screw
19 pcs. (+1 extra)
M4x32
Machine Screw
4 pcs.
Handle
2 pcs.
Cover
5 pcs. (+1 extra)
M3.5x25
Wood Screw
16 pcs. (+1 extra)

STEP 1
Insert Cam Lock Screws into
pre-drilled holes in Top (A), Side Panels (B), (C),
Middle Panels (D), (E) and Back Panel (G),
then tighten. (See Figure 1)
STEP 2
Attach Middle Panels (D) and (E)
to Back Panel (G) with Cam Locks. (See Figure 2)
Attach Shelves (F) to unit with Cam Locks.
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Assembly Instructions 2/6
Cam Lock Screw
A
B
C
D
E
G
Figure 1
Figure 2
GF
F
D
E
Cam Lock

Assembly Instructions 3/3
Assembly Instructions 3/6
STEP 3
Attach Side Panels (B) and (C) to unit with Cam Locks.
STEP 4
Turn unit to its upright position.
Attach Top (A) to unit with Cam Locks.
A
Cam Lock
Cam Lock
B
C

H4
Wood Screw
Assembly Instructions 4/6
H2.
Drawer Back
1 pc.
H3.
Drawer Side
2 pcs.
H4.
Drawer Bottom
1 pc.
STEP 5
Attach Drawer Sides (H3) to
Drawer Back (H2) with Wood Screws.
H2 H3
H3
STEP 6
Slide Drawer Bottom (H4) into groove.
Attach Drawer Front (H1) to unit with
Wood Screws.
Part List
Machine Screw
Handle
STEP 7
Attach Handle with Machine Screws.
Wood Screw
H1.
Drawer Front
1 pc.
H1
Drawer (H)

H4
Wood Screw
Assembly Instructions 5/6
STEP 8
Attach Drawer Sides (H3) to
Drawer Back (H2) with Wood Screws.
H2 H3
H3
STEP 9
Slide Drawer Bottom (H4) into groove.
Attach Drawer Front (I1) to unit with
Wood Screws.
Part List
Machine Screw
Handle
STEP 10
Attach Handle with Machine Screws.
Wood Screw
I1
Drawer (I)
H4.
Drawer Bottom
1 pc.
I1.
Drawer Front
1 pc.
H2.
Drawer Back
1 pc.
H3.
Drawer Side
2 pcs.

Assembly Instructions 3/3
Assembly Instructions 6/6
Figure 3
STEP 11
Cover Cam Locks with Covers. (See Figure 3)
Cover
H
I
STEP 12
Slide Drawers (H) and (I) into position.
Place Hutch onto Desk.

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
