Home Styles 20 05503 0016 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[e-mail], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver, Level
20 05503 0016
Student Desk
IMPORTANT
A.
Top
1 pc.
Refer to later page(s) of these
instructions for drawer assembly.
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Cam Lock Screw
13 pcs. (+1 extra)
Cam Lock
13 pcs. (+2 extra)
M3.5x25
Wood Screw
16 pcs. (+1 extra)
M6x32
Head Cap Bolt
9 pcs. (+1 extra)
Knob
2 pcs.
M4x25
Machine Screw
2 pcs.
B.
Base
1 pc.
C.
Back Panel
1 pc.
D.
Side Panel
1 pc.
E.
Middle Panel
1 pc.
F.
Side Panel
1 pc.
G.
Leg
4 pcs.
H.
Drawer
2 pcs.
Spring Washer
9 pcs. (+1 extra)
Flat Washer
9 pcs. (+1 extra)

Assembly Instructions 2/5
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.
A
F
D
Cam Lock Screw
STEP 1
Place Top (A) and Side Panels (D), (F)
on a soft cloth.
Insert Cam Lock Screws into
pre-drilled holes in Top (A) and
Side Panels (D), (F), then tighten.
(See Figure 1)
Figure 1
C
STEP 2
Attach Side Panels (D) and (F) to Back Panel (C) with Cam Locks.
(See Figure 2)
Cam Lock
Figure 2
D
F

Assembly Instructions 3/5
STEP 5
Attach Legs (G) to unit. G
STEP 3
Place Top (A) upside down on a soft cloth.
Attach unit and Middle Panel (E)
to Top (A) with Cam Locks.
Cam Lock
E
GG
Figure 3
G
A
B
Head Cap Bolt
STEP 4
Attach Base (B) to unit with Flat Washers,
Spring Washers and Head Cap Bolts.
(See Figure 3)
Spring Washer
Flat Washer

Part List
Assembly Instructions 4/5
H1.
Drawer Front
2 pcs.
H2.
Drawer Back
2 pcs.
H3.
Drawer Side
2 pcs.
H4.
Drawer Side
2 pcs.
H5.
Drawer Bottom
2 pcs.
Drawer (H)
STEP 6
Attach Drawer Sides (H3) and (H4)
to Drawer Front (H1) with Wood Screws.
H1
H3
H4
Wood Screw
STEP 7
Slide Drawer Bottom (H5) into groove.
Attach Drawer Back (H2) to unit
with Wood Screws.
Roller at back
H5
STEP 8
Attach Knob with Machine Screw.
Machine Screw
Knob
H2
Wood Screw

Assembly Instructions 5/5
H
H
STEP 9
Turn unit from Step 5 over to its’ upright position.
Level unit by adjusting the adjustable levelers on bottom of legs. (See Figure 4)
Note: Unit must be level to work properly.
Slide Drawers (H) into position.
Figure 4

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
Home Styles will provide replacements free of charge for missing or damaged hardware or parts within 30 days of
purchase. Digital images of the defective parts may be required. If the product was not purchased from an authorized
retail affiliate, Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled
items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at:
www.homestyles-furniture.com/customer-service/replacement-parts
Home Styles Customer Service: www.homestyles-furniture.com,
[e-mail], 888-680-7460, 877-831-0319
