Home Styles Bali Hai Bar Stool User manual

Part List
Bali Hai Bar Stool
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
Tools required for assembly : Phillips screwdriver
A.
Backrest
1 pc.
F.
Stretcher
2 pcs.
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
Head Cap Bolt
(long)
6 pcs.(+1 extra)
Wood Screw
6 pcs.(+1 extra)
Head Cap Bolt
(Short)
2 pcs.(+1 extra)
C.
Leg
1 pc.
88 5660 89
Key Wrench
1 pc.
B.
Seat
1 pc.
D.
Leg
1 pc.
E.
Stretcher
1 pc.
Cross Dowel
6 pcs.(+1 extra)
Head Cap Bolt
2 pcs.(+1 extra)
Small
Hex Wrench
1 pc.

B
A
F
E
Assembly Instructions
STEP 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.
Attach Stretcher (E) and (F) to
Side Frame (C) with Head Cap Bolts (long)
and Cross Dowels.
Attach Side Frame (D) to the unit
with Head Cap Bolts and Cross Dowels.
STEP 2
Attach Seat (B) to the
unit with Wood Screws.
Attach Backrest (A) to the
unit with Head Cap Bolts (short)
and Head Cap Bolts.
CD
F
Wood Screw
Head Cap Bolt
Head Cap Bolt (short)
Head Cap Bolt (long)
Cross Dowel

CARE INSTRUCTIONS
IMPORTANT – READ CAREFULLY
RETAIN THIS INFORMATION FOR FUTURE REFERENCE
Advisory Notes
• Periodic structural checks of this furniture should be undertaken. Do not use if
you have any doubts about its fitness for purpose.
• Care should be exercised so as not to trap fingers in any of the hinged parts
of this furniture.
• Alwaysuse on firm level ground, ensuring that all legs remain in contact with
the ground.
• Do not stand on a chair or sit or stand on anyother item.
• Do not let children play with this furniture.
• This furniture should be stored under cover during prolonged periods of
adverse weather (wet or cold) and also during the winter (ideally in a garden
shed or garage). Always clean and dry thoroughly before storage.
Care of Outdoor Wooden Furniture
PLEASE FOLLOW THESE CARE INSTRUCTIONS IN ORDER TO MAINTAIN
THE APPEARANCE AND LIFE OF THIS OUTDOOR WOODEN FURNITURE.
This furniture has been treated with linseed oil during manufacture and does not
require a further application before being placed outside. If the furniture is
intentionally left outside for a prolonged period of adverse weather (see advisory
notes) further finish must be applied. Please refer to the maintenance
instructions below for the application of linseed oil.
Due to the high density of certain hardwoods, fine surface cracks may occur over
time from weathering, but these won’t affect the structural integrity of the
furniture.
(Please see following page for further care instructions.)

Maintenance
In order to maintain the appearance of the wood, regular coatings of linseed oil
must be applied. The frequency will depend on the weather conditions
experienced.
1. Ensure that you refer to the manufacturers guidelines of the linseed oil that
you use.
2. Linseed oil is best applied with a clean cloth. Wipe the oil onto the wood
surface straight from the container.
3. Treat all surfaces of the furniture. Ensure that any hidden surfaces, such as
those exposed when the furniture is turned upside down, are adequately
treated. Particular care should be given to the end grain, to all joints and to
any crevices that may have been caused by damage.
4. Let the surface dry out. This can take between 4 and 12 hours depending on
weather conditions.
5. Repeat the above steps with at least 2 more coats of oil. Extra coats may
leave a semi-gloss sheen once the oil has dried out, but any excess oil can
be wiped off with a clean cloth.
CAUTION: DO NOT leave cloths used for applying linseed oil where they may
constitute a fire hazard, as they are liable to spontaneous combustion, i.e. self
igniting without warning. Immediately after use, saturate all cloths used for
applying linseed oil with water and dispose of safely outside the home.
Should you choose not to treat this furniture, then it will turn a greyish colour and
develop cracks. Light sanding can restore the original colour after which linseed
oil can be applied in accordance with the instructions above.
Tannin Exudation
Tannin is a naturally occurring substance in many wood species which may
exude from the surface of the wood. While normally harmless to touch, soil,
grass or other plants, this may stain the surface of hard areas such as patios or
decks.
To clean the Tannin marks it may be po ssible to use a proprietary cleaning
product or, alternatively, use a water-based wood restorer (typically containing
oxalic acid). It is important that any stains are removed within 1 to 2 days of them
occurring.
Care should be exercised to follow the manufacturer’s guidelines for the type of
cleaner used and that a test is carried out on a small area first to determine the
effectiveness of the chosen product. This is especially important on wooden
decking areas where the existing surface finish may be lifted due to the
application of the cleaning agent. If decking has become discolored from the
cleaning it can be restored with a suitable wood finish.

Part List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hardware List
Tools required for assembly : Phillips screwdriver
Head Cap Bolt
20 pcs.(+1 extra)
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
Wood Screw
4 pcs.(+1 extra)
Key Wrench
1 pc.
A.
Top
1 pc.
B.
Side Frame
1 pc.
C.
Side Frame
1 pc.
D.
Front Stretcher
1 pc.
F.
Front Frame
1 pc.
G.
Stretcher
1 pc.
H.
Shelf
4 pcs.
Bali Hai Bar Cabinet
88 5660 99
E.
Back Stretcher
1 pc.
Small
Hex Wrench
1 pc.

STEP 1 A
Wood Screw
STEP 2
Attach Shelves (H) to Side Frame (B) with
Head Cap Bolts.
Attach Front Frame (F) to unit with
Head Cap Bolts.
Attach Stretcher (G) to unit.
E
D
B
H
F
G
Head Cap Bolt
Assembly Instructions 2/3
Attach Front Stretcher (D) and Back Stretcher (E)
to Top (A) with Wood Screws.
H
H
H
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.

Assembly Instructions 3/3
STEP 3 C
STEP 4
Attach unit from Step 1 to the unit with
Head Cap Bolts.
Head Cap Bolt
Head Cap Bolt
Attach Side Panel (C) to unit with
Head Cap Bolts.

CARE INSTRUCTIONS
IMPORTANT – READ CAREFULLY
RETAIN THIS INFORMATION FOR FUTURE REFERENCE
Advisory Notes
• Periodic structural checks of this furniture should be undertaken. Do not use if
you have any doubts about its fitness for purpose.
• Care should be exercised so as not to trap fingers in any of the hinged parts
of this furniture.
• Alwaysuse on firm level ground, ensuring that all legs remain in contact with
the ground.
• Do not stand on a chair or sit or stand on anyother item.
• Do not let children play with this furniture.
• This furniture should be stored under cover during prolonged periods of
adverse weather (wet or cold) and also during the winter (ideally in a garden
shed or garage). Always clean and dry thoroughly before storage.
Care of Outdoor Wooden Furniture
PLEASE FOLLOW THESE CARE INSTRUCTIONS IN ORDER TO MAINTAIN
THE APPEARANCE AND LIFE OF THIS OUTDOOR WOODEN FURNITURE.
This furniture has been treated with linseed oil during manufacture and does not
require a further application before being placed outside. If the furniture is
intentionally left outside for a prolonged period of adverse weather (see advisory
notes) further finish must be applied. Please refer to the maintenance
instructions below for the application of linseed oil.
Due to the high density of certain hardwoods, fine surface cracks may occur over
time from weathering, but these won’t affect the structural integrity of the
furniture.
(Please see following page for further care instructions.)

Maintenance
In order to maintain the appearance of the wood, regular coatings of linseed oil
must be applied. The frequency will depend on the weather conditions
experienced.
1. Ensure that you refer to the manufacturers guidelines of the linseed oil that
you use.
2. Linseed oil is best applied with a clean cloth. Wipe the oil onto the wood
surface straight from the container.
3. Treat all surfaces of the furniture. Ensure that any hidden surfaces, such as
those exposed when the furniture is turned upside down, are adequately
treated. Particular care should be given to the end grain, to all joints and to
any crevices that may have been caused by damage.
4. Let the surface dry out. This can take between 4 and 12 hours depending on
weather conditions.
5. Repeat the above steps with at least 2 more coats of oil. Extra coats may
leave a semi-gloss sheen once the oil has dried out, but any excess oil can
be wiped off with a clean cloth.
CAUTION: DO NOT leave cloths used for applying linseed oil where they may
constitute a fire hazard, as they are liable to spontaneous combustion, i.e. self
igniting without warning. Immediately after use, saturate all cloths used for
applying linseed oil with water and dispose of safely outside the home.
Should you choose not to treat this furniture, then it will turn a greyish colour and
develop cracks. Light sanding can restore the original colour after which linseed
oil can be applied in accordance with the instructions above.
Tannin Exudation
Tannin is a naturally occurring substance in many wood species which may
exude from the surface of the wood. While normally harmless to touch, soil,
grass or other plants, this may stain the surface of hard areas such as patios or
decks.
To clean the Tannin marks it may be po ssible to use a proprietary cleaning
product or, alternatively, use a water-based wood restorer (typically containing
oxalic acid). It is important that any stains are removed within 1 to 2 days of them
occurring.
Care should be exercised to follow the manufacturer’s guidelines for the type of
cleaner used and that a test is carried out on a small area first to determine the
effectiveness of the chosen product. This is especially important on wooden
decking areas where the existing surface finish may be lifted due to the
application of the cleaning agent. If decking has become discolored from the
cleaning it can be restored with a suitable wood finish.
