Home Styles 5100-101 User manual

U.
Top
1 pc.
Part List
IMPORTANT
For assembly see instructions in 5100 Buffet carton.
Solid Wood Top
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460
5100 10- 1

Part List
Hardware List
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
Refer to later page(s) of these
instructions for drawer assembly.
A.
Side Panel
1 pc.
B.
Side Panel
1 pc.
E.
Back Panel
3 pcs.
C.
Middle Panel
1 pc.
D.
Middle Panel
1 pc.
F.
Back Upright
2 pcs.
G.
Back Rail
1 pc.
H.
Back Rail
1 pc.
I.
Front Rail
1 pc.
K.
Front Upright
2 pcs.
Q.
Shelf
2 pcs.
L.
Fixed Shelf
1 pc.
M.
Base
1 pc.
O.
Wine Grid
2 pcs.
P.
Wine Grid
2 pcs.
R.
Door
1 pc.
S.
Door
1 pc.
N.
Leg
2 pcs.
T.
Drawer
3 pcs.
IMPORTANT
5100 Top carton is also needed for assembly.
5100 00- 2
Buffet
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Cam Lock
14 pcs. (+2 extra)
Cross Dowel
8 pcs. (+1 extra)
Cam Lock Screw
14 pcs. (+1 extra)
M3.5x25
Wood Screw (long)
24 pcs. (+1 extra)
M3.5x13
Wood Screw (short)
12 pcs. (+1 extra)
Adjustable Pin
8 pcs. (+2 extra)
M3.5x16
Wood Screw
for Back Panel
12 pcs. (+1 extra)
Handle
3 pcs.
Knob
2 pcs.
M6x35
Head Cap Bolt
4 pcs. (+1 extra)
M6x50
Head Cap Bolt (long)
8 pcs. (+1 extra)
M4x25
Machine Screw
8 pcs.
J.
Front Rail
1 pc.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460

Assembly Instructions 2/8
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
The unit must be level to work properly. Use the included adjustable levelers to level.
Keep Hex Wrench as the bolts may need to be tightened in the future.
Cam Lock Screw
Figure 2
STEP 1
Insert Cam Lock Screws into pre-drilled holes
in Side Panels (A), (B) and Middle Panels (C), (D),
then tighten. (See Figure 1)
Cam Lock
STEP 2
Attach Middle Panels (C) and (D)
to Fixed Shelf (L) with Cam Locks.
(See Figure 2)
Figure 1
L
AB
CD
D
C

Assembly Instructions 3/8
STEP 4
Attach Back Rail (G) to unit with Cross Dowels
and Head Cap Bolts (long).
STEP 3
Attach Back Rail (H) to unit with Cross Dowels
and Head Cap Bolts (long). (See Figure 3)
Attach Back Uprights (F) to Back Rail (H).
Slide Back Panels (E) into position.
STEP 5
Attach Front Rail (J) to unit.
Attach Front Uprights (K) to unit.
Attach Front Rail (I) to unit.
Head Cap Bolt (long)
Cross Dowel
Figure 3
H
E
E
F
E
K
G
I
J
K
F
Cross Dowel
Head Cap Bolt (long)

Cam Lock
Assembly Instructions 4/8
STEP 6
Attach Side Panels (A) and (B)
to unit with Cam Locks.
STEP 7
Attach Base (M) to unit
with Cross Dowels and
Head Cap Bolts (long).
Attach Legs (N) to Base (M)
with Head Cap Bolts.
STEP 8
Place Top (U) upside down on a soft cloth.
Insert Cam Lock Screws into pre-drilled holes in
Top (U), then tighten.
Cam Lock Screw
Arrow label
B
A
Head Cap Bolt
Head Cap Bolt (long)
Cross Dowel
N
M
N
U

Assembly Instructions 5/8
Figure 4 Figure 5
Cam Lock
Adjustable Pin
STEP 10
Attach Top (U) to unit with Cam Locks.
Note: Arrow label indicates front of Top (U).
STEP 9
Turn unit to its upright position.
Insert Adjustable Pins into
side panels and middle panels
at desired level.
Place Shelves (Q) into position.
Attach Doors (R) and (S) to unit by
sliding door hinges into side panel
hinges. (See Figure 4)
Attach Knobs to Doors (R) and (S)
with Machine Screws. (See Figure 5)
Knob
Machine Screw
S
U
R
Q
Q

Assembly Instructions 6/8
STEP 13
Attach Handle with Machine Screws.
STEP 12
Slide Drawer Bottom (T5) into groove.
Attach Drawer Bottom (T5) to
unit with Wood Screws (short).
T1.
Drawer Front
3 pcs.
T2.
Drawer Back
3 pcs.
T5.
Drawer Bottom
3 pcs.
Drawer (T)
STEP 11
Attach Drawer Front (T1) and Drawer
Back (T2) to Drawer Side (T3)
with Wood Screws (long).
Attach Drawer Side (T4) to unit
with Wood Screws (long).
Roller at back
Wood Screw (long)
Bottom
Machine Screw
Handle
Part List
T3.
Drawer Side
3 pcs.
T4.
Drawer Side
3 pcs.
Wood Screw (short)
Bottom
Bottom
T5
T1
T2
T3
T4

Assembly Instructions 7/8
STEP 14
Slide Drawers (T) into position.
Slide Wine Grids (P) into
grooves in Fixed Shelf (L).
Slide Wine Grids (O) into unit.
STEP 15
Level unit by adjusting the adjustable
levelers on bottom of unit.
(See Figure 6)
Note: Unit must be level to proceed.
Insert Wood Screws for Back Panel
into pre-drilled holes in unit,
then tighten.
Note: Unit must be level before
tightening these screws.
Wood Screw for Back Panel
Figure 6
T
T
O
T
L
PP
O

Assembly Instructions 8/8
STEP 16
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
Pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on unit.
(See Figure 7)
Put tie end of Tipover Restraint into lock
end of Tipover Restraint and pull until tight.
Figure 7
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Drill 3/8” hole in wall
Top of unit
Hardware List
Tipover
Restraint

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
homestyles will provide replacements free of charge for missing or damaged parts within 30 days of purchase.
Digital images of the defective parts may be required. If the product was not purchased from an authorized retailer,
homestyles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor
are parts available for sale. Replacements for missing or damaged parts may be requested via contact info below.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460

Hardware List
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit
IMPORTANT
5100 0-3 2
Hutch
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Cam Lock
1 pcs. (+2 extra)8
Cam Lock Screw
1 pcs. (+1 extra)8
M x134
Wood Screw for Bracket
8 pcs. (+1 extra)
Adjustable Pin
12 1pcs. (+ extra)
M3.5x16
Wood Screw for Back Panel
12 pcs. (+1 extra)
Bracket
2 pcs.
M4x25
Machine Screw
2 pcs.
Knob
2 pcs.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460
Part List
A.
Top
1 pc.
F.
Back Rail
1 pc.
G.
Back Rail
1 pc.
I.
Fixed Shelf
1 pc.
H.
Front Rail
1 pc.
J.
Shelf
1 pc.
K.
Shelf
2 pcs.
D.
Back Panel
3 pcs.
E.
Back Upright
2 pcs.
N.
Door
1 pc.
O.
Door
1 pc.
C.
Side Panel
1 pc.
B.
Side Panel
1 pc.
L.
Middle Panel
1 pc.
M.
Middle Panel
1 pc.
Hutch

Cam Lock
Assembly Instructions 2/6
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the screws until each part is properly assembled.
STEP 2
Attach Back Rail ( ) to Side Panel (B)F
with Cam Lock. (See Figure 2)
Attach Back Uprights (E) to Back Rail ( ).F
Slide Back Panels (D) into position.
Attach Back Rail ( ) to unit with Cam Lock.G
STEP 1
Insert Cam Lock Screws into pre-drilled holes in
Top (A), Side Panels (B), (C) and Fixed Shelf (I),
then tighten. (See Figure 1)
Cam Lock Screw
Figure 2
Figure 1
I
E
BC
A
G
F
D
B
D
D
E

Assembly Instructions 3/6
Cam Lock
Cam Lock
Cam Lock
STEP 3
Attach Fixed Shelf (I) to unit
with Cam Locks.
STEP 4
Attach Middle Panels (L) and
(M) to unit with Cam Locks.
Attach Front Rail (H)
to unit with Cam Lock.
STEP 5
Attach Side Panel (C) to unit
with Cam Locks.
C
I
H
LM

Assembly Instructions 4/6
Cam Lock
Adjustable Pin
Knob
Machine Screw
STEP 7
Attach Top (A) to unit with Cam Locks.
STEP 6
Insert Adjustable Pins into
side panels and middle panels
at desired level.
Place Shelves (J) and (K)
into position.
Attach Doors (N) and (O) to unit by
sliding door hinges into side panel hinges.
(See Figure 3)
Attach Knobs to Doors (N) and (O)
with Machine Screws.
(See Figure 4)
Figure 3 Figure 4
J
A
O
K
K
N

Assembly Instructions 5/6
STEP 8
Insert Wood Screws for Back Panel
into pre-drilled holes in unit.
STEP 9
Attach Hutch to Buffet with Brackets by
inserting Wood Screws for Bracket into
pre-drilled holes, .then tighten
(See Figure 5)
Wood Screw for Bracket
Bracket
Wood Screw for Back Panel
Figure 5

Assembly Instructions /66
STEP 10
Place unit at desired location.
Drill a 3/8” hole in wall in-line with
Pre-drilled hole at top of unit.
Move unit.
Insert Anchor into the wall hole
and attach Bracket with Wall Screw.
Attach Bracket at pre-drilled hole
at top of unit with Wood Screw.
Move unit back into place.
Slide Tipover Restraint through
Bracket on wall and Bracket on unit.
(See Figure )6
Put tie end of Tipover Restraint into lock
end of Tipover Restraint and pull until tight.
Figure 6
IMPORTANT
To help reduce the risk of the unit tipping over, the Tipover Restraint must be installed following these instructions exactly.
Anchor
1 pc. (+1 extra)
Bracket
2 pcs. (+1 extra)
Tipover Restraint
1 pc. (+1 extra)
M3.5x40
Wall Screw
1 pc. (+1 extra)
M3.5x16
Wood Screw
1 pc. (+1 extra)
Wood Screw
Wall Screw
Bracket
on wall
Anchor in wall
3/8” wall hole
Pre-drilled hole
at top of unit
Tie end
Lock end
Bracket at
top of unit
Hardware List
Tipover
Restraint
Drill 3/8” hole in wall
Top of unit

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
homestyles will provide replacements free of charge for missing or damaged parts within 30 days of purchase.
Digital images of the defective parts may be required. If the product was not purchased from an authorized retailer,
homestyles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor
are parts available for sale. Replacements for missing or damaged parts may be requested via contact info below.
styles Customer Service: www.homestylesfurniture.com,home
[email protected], 888-680-7460
