Home Styles 88 4512 95 User manual

Hardware List
Part List
Home Styles Customer Service: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Tool(s) required for assembly: Phillips screwdriver
IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Adjustable Pin
8 pcs. (+1 extra)
M4x25
Machine Screw
5 pcs.
A.
Top
1 pc.
B.
Side Panel
1 pc.
C.
Side Panel
1 pc.
E.
Back Panel
3 pcs.
D.
Middle Panel
1 pc.
H.
Back Stretcher
1 pc.
M.
Side Rack
1 pc.
N.
Side Rack
1 pc.
P.
Rack
1 pc.
O.
Base Rack
1 pc.
J.
Base
1 pc.
K.
Arm
2 pcs.
Drawer
Pull Handle
5 pcs.
G.
Back Stretcher
1 pc.
L.
Towel Bar
1 pc.
M3x16
Wood Screw
for Magnet
4 pcs. (+1 extra)
M3.5x25
Wood Screw (long)
24 pcs.(+1 extra)
M3.5x16
Wood Screw (short)
24 pcs. (+1 extra)
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
M6x12
Head Cap Bolt
for Caster
16 pcs. (+1 extra)
M6x25
Head Cap Bolt
4 pcs. (+1 extra)
M6x38
Head Cap Bolt (long)
4 pcs. (+1 extra)
S.
Shelf
2 pcs.
Q.
Door
1 pc.
R.
Door
1 pc.
T.
Drawer
3 pcs.
I.
Front Piece
2 pcs.
Magnet
2 pcs.
F.
Back Upright
2 pcs.
88 4512 95
Kitchen Cart
Refer to later page(s) of these
instructions for drawer assembly.
Caster
2 Locking
2 Non-Locking
4 pcs.

Assembly Instructions 2/6
Figure 3
B
C
STEP 1
Attach Magnets to Top by inserting Wood Screws for Magnet into
pre-drilled holes. (See Figure 1)
STEP 2
Attach Arms (K) to Side Panel (B) with Head Cap Bolts. (See Figure 2)
Assemble Side Racks (M), (N), Base Rack (O) and Rack (P), then attach to Side Panel (C) with
Head Cap Bolts. (See Figure 3)
Wood Screw for Magnet
Magnet
Head Cap Bolt
K
Head Cap Bolt
Figure 2
M
A
K
KB
NP
O
C
Figure 1
IMPORTANT
Use a soft cloth between these parts and the floor.
Do not use power tools above 8 volts to assemble.
Do not tighten all the bolts until each part is properly assembled.
Keep Hex Wrench in a safe place as the bolts may need to be tightened up in the future.

Assembly Instructions 3/6
H
C
EE
FF
G
B
E
Figure 6
Figure 4
Figure 5
Locking Caster
Non-Locking Caster
Head Cap Bolt for Caster
J
‘Arrow’ sticker at front
STEP 3
Attach Back Stretcher (G) to Side Panel (B), then flip the locks.
(See Figures 4 and 5)
Attach Back Uprights (F) to unit, then slide Back Panels (E) into position.
Attach Back Stretcher (H) and Side Panel (C) to unit, then flip the locks.
STEP 4
Attach Casters underneath Base (J) with Head Cap Bolts for Caster, with Locking Casters at front.
(See Figure 6)
Note: ‘Arrow’ sticker indicates front of Base (J).

Wood Screw
(short)
STEP 6
Turn the unit to its’ upright position.
Slide Towel Bar (L) into place.
Attach Front Pieces (I) and Middle Panel (D) to unit, then flip the locks.
Insert Wood Screws (short) into pre-drilled holes of Back Stretchers (G) and (H) and tighten.
D
L
I
I
H
G
Assembly Instructions 4/6
Head Cap Bolt (long)
‘Arrow’ sticker at front STEP 5
Attach unit from Step 4 to unit from
Step 3 with Head Cap Bolts (long),
then flip the locks.

Part List
Assembly Instructions 5/6
T2.
Drawer Back
3 pcs.
T5.
Drawer Bottom
3 pcs.
T1.
Drawer Front
3 pcs.
T3.
Drawer Side
3 pcs.
T4.
Drawer Side
3 pcs.
T1
T2
T3
T4
T5
STEP 9
Attach Knob with Machine Screw.
STEP 8
Slide Drawer Bottom (T5) into the grooves
of Drawer Sides (T3) and (T4) until it meets
Drawer Front (T1).
Attach Drawer Bottom (T5) to unit with
Wood Screws (short).
Drawer (T)
STEP 7
Attach Drawer Front (T1) and Drawer
Back (T2) to Drawer Side (T3) with
Wood Screws (long).
Attach Drawer Side (T4) to unit with
Wood Screws (long).
Roller at back
T1
T2
T3
T4
Bottom
Wood Screw (long)
Wood Screw (short)
Machine Screw
Knob

STEP 10
Insert Adjustable Pins into side panel and middle panel at desired level.
Place Shelves (S) into position.
Attach Doors (Q) and (R) by sliding door lift hinges into side panel
lift hinges. (See Figure 7)
Assemble Pull Handles to Doors with Machine Screws. (See Figure 8)
Attach Top (A) to unit, then flip the locks.
Slide Drawers (T) into position.
Adjustable Pin
Assembly Instructions 6/6
Figure 8
Figure 7
Q
A
S
S
R
T
T
T

NEVER
use glass cleaners on
finished furniture. Ammonia
chemically attacks the finish.
allow liquids to remain on furniture.
Absorption causes parts to warp
and split and finishes to delaminate.
NEVER
CARE INSTRUCTIONS
Do not use rubber
based placemats.
PREVENT
DISCOLORING
Do not use commercial
waxes and polishes.
PREVENT
YELLOWING
Do not place hot
objects on surface.
PREVENT
FINISH DAMAGE
Do not write
directly on surface.
PREVENT
MARKING
Do not use power tools
above 8 volts to assemble.
PREVENT
CRACKING
Do not place
in direct sunlight.
PREVENT
FADING
with a soft cloth moistened
in lukewarm soap and water.
Buff with a dry clean cloth.
CLEAN
