Home Styles 88564949 C User manual

BASE UNIT PART LIST
HARDWARE LIST
Hex Wrench
1 pc. Wood Plug
8 pcs. (+1 Extra)
Wood Screw
(for Spring Support)
8 pcs.(+1 Extra)
Head Cap Bolt
(long)
8 pcs.(+1 Extra)
Thai Patent Pending Numbers 081316
A.
Seat
1 pc.
B.
Side Panel
1 pc.
C.
Side Panel
1 pc.
F.
Base
1 pc.
D.
Front Panel
1 pc.
E.
Back Panel
1 pc.
Cross Dowel
8 pcs.(+2 Extra) Spring Support
2 pcs.
Head Cap Bolt
(short)
4 pcs.(+ 1 Extra)
88564949 C
Hall Tree Storage Bench
Dear Our Valuable Customers,
Please follow our assembly instructions in every step,
we guarantee that you will get the perfect merchandise.
Thank you so much for purchasing our quality products.
Tools Required For Assembly : Philips screwdriver

Assembly Instructions
IMPORTANT
Do not tighten up all the screws until each part is properly assembled.
You should keep Hex Wrench in the safe place as you may need to tighten up
the Head Cap Bolts in the future.
STEP 1
STEP 2
STEP 3
D
E
C
Attach the Seat (A) to the assembled unit
with Head Cap Bolts (short).
Put the Base (F) into the storage.
B
E
Insert Cross Dowels into the
holes of Front Panel (D) and
Back Panel (E).
Attach the Side Panel (B) and (C)
to the Front Panel and Back Panel
with Head Cap Bolts.
Cross Dowel
Assembly
A
Turn over the Seat (A).
Attach Spring Support to the
Seat (A) with Wood Screws.
Spring Support Assembly A
F
STEP 4
Cover all holes with
Wood Plugs
Cross Dowel
Cross Dowel
Head Cap Bolt
(long)
Head Cap Bolt
(long)
Head Cap Bolt
(short)
Wood Screw

TOP UNIT PART LIST
L.
Back Stretcher
2 pcs.
J.
Upper
Back Frame
1 pc.
I.
Side Panel
1 pc.
G.
Top
1 pc.
H.
Side Panel
1 pc.
K.
Lower
Back Frame
1 pc.
N.
Arm
1 pc.
M.
Arm
1 pc.
88564949 C
Hall Tree Storage Bench
Hex Wrench
1 pc.
Head Cap Bolt
(short)
4 pcs.(+1 Extra)
Wood Screw
8 pcs.
(+1 Extra)
Wood Plug
12 pcs.
(+1 Extra)
Hook
4 pcs.
HARDWARE LIST
Head Cap Bolt
(long)
20 pcs.(+1 Extra)
Thai Patent Pending Numbers 081316
Dear Our Valuable Customers,
Please follow our assembly instructions in every step,
we guarantee that you will get the perfect merchandise.
Thank you so much for purchasing our quality products.
Tools Required For Assembly : Philips screwdriver

Assembly Instructions 2/3
IMPORTANT
Do not tighten up all the screws until each part is properly assembled.
You should keep Hex Wrench in the safe place as you may need to tighten up
the Head Cap Bolts in the future.
STEP 1
STEP 2
Attach the Hooks to the Upper Back Frame (J)
with Wood Screws.
STEP 3
L
L
K
J
J
Assemble the Back Stretcher (L),
Upper Back Frame (J) and Lower Back Frame (K).
Hutch and Base Unit
Assembly
Hook
Assembly
Attach the Side Frame (H) and (I)
to the assembled unit with Head Cap Bolts.
H
I
Head Cap Bolt (long)
Head Cap Bolt (long)

Assembly Instructions 3/3
STEP 4
Attach the Top (G) to the Side Panel (H) and (I) with Head Cap Bolts as shown.
Attach the Arm (M) and (N) to the Side Panels with Head Cap Bolts.
STEP 5
M
N
G
H
I
Place the Top Unit on the Base Unit.
Tighten up all the Head Cap Bolts.
STEP 6
Cover all holes with
Wood Plugs
Head Cap Bolt (long)
Head Cap Bolt (long)
Head Cap Bolt (short)
Head Cap Bolt (short)
