Hardware List
C.
Side Frame
2 pcs.
B.
Stretcher
2 pcs.
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Cabinet
1 pc.
88 5050 22
Modern Craftsman
Console Table
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
Part List
D.
Shelf
1 pc.
Head Cap Bolt
8 pcs. (+1 extra)
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Flat Washer
8 pcs. (+1 extra )
Spring Washer
8 pcs. (+1 extra )
Tools required for assembly : Phillips screwdriver
Wood Screw
6 pcs. (+1 extra)

Assembly Instructions 2/3
STEP 1
Assemble Stretchers (B),
Base (D) to Side Frame (C)
with Head Cap Bolts,
Spring Washers and
Flat Washers.
(See figure 1)
STEP 2
Flat Washer
Spring Washer
Head Cap Bolt
Figure 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.
B
B
C
C
D
Remove the drawers,
then place Cabinet (A)
upside down on a soft cloth.
A

Assembly Instructions 3/3
STEP 3
Attach unit onto Cabinet (A)
with Wood Screws.
Wood Screw
A
STEP 4
Turn the unit over to its’ upright position.
Remove the Pull Handles that are
installed on the inside of the drawers and
re-install them on the outside of the drawer.
(See figure 2)
Slide the drawers into position.
Figure 2
