Home Styles Monarch User manual

Part List
For assembly see instructions in carton 88 5008 612
Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Level
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
88 5008 611
Monarch Buffet
A.
Top
1 pc.

Part List
Hardware List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Cam Lock Screw
18 pcs.(+1 extra)
88 5008 612
Monarch Buffet
Also need Part in carton 88 5008 611
Head Cap Bolt
(long)
18 pcs. (+1 extra)
Hex Wrench
1 pc.
Wood Screw (short)
for Drawer Base Part
8 pcs. (+1 extra)
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Level
Home Styles Consumer Assistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
(Knock-Down Construction, please refer
to the last page of these instructions
for steps to assemble drawers)
S.
Drawer
2 pcs.
L.
Front Rail
1 pc.
B.
Front Post
1 pc.
C.
Front Post
1 pc.
D.
Side Panel
1 pc.
E.
Side Panel
1 pc.
F.
Middle Panel
1 pc.
G.
Support
Runner
1 pc.
H.
Support
Runner
1 pc.
M.
Back Rail
2 pcs.
K.
Front Rail
1 pc.
J.
Front Rail
1 pc.
Q.
Back Post
2 pcs.
R.
Back Panel
3 pcs.
O.
Door
1 pc.
P.
Door
1 pc.
N.
Bottom
1 pc.
I.
Shelf
4 pcs.
Knob
4 pcs.
Head Cap Bolt
(short)
8 pcs. (+1 extra)
Machine Screw
4 pcs.
Wood Screw (long)
for Drawer Side Part
16 pcs. (+1 extra)
Wood Screw
4 pcs. (+1 extra)
Flat Washer
4 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+1 extra)
Wood Screw (short)
for Back Panel
12 pcs. (+1 extra)
Cam Lock
18 pcs.(+1 extra)
Steel Connector
4 pcs.

Assembly Instructions 2/5
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* After assembly, item must be level to work properly. Use the included adjustable levelers to level.
* Use a soft cloth between these parts and the floor.
Figure 1
Head Cap Bolt (short)
DE
C
L
K
B
J
Figure 2
STEP 1
Insert Cam Lock
Screws into the
pre-drilled holes of
Front Post (B), (C)
and Side Panels (D), (E)
and Front Rail (J), (K) and (L).
(see Figure 1)
Attach Steel Connectors to
Side Panel (D) and (E) with
Head Cap Bolts (short).
STEP 2
Attach Front Post (B) to
Side Panel (D) and Front
Post (C) to Side Panel (E)
with Cam Locks and Head
Cap Bolts (long).
(see Figure 2)
Attach Support Runner (G)
to Side Panel (D) and
Support Runner (H) to
Side Panel (E) with
Head Cap Bolts (long).
DE
H
G
Head Cap Bolt
(long)
Cam Lock
Steel Connector
Head Cap Bolt
(long)
B
C

Assembly Instructions 3/5
Figure 4
Figure 3
M
R
R
R
Q
Q
E
M
L
Cam Lock
Head Cap Bolt
(long)
Flat Washer
Wood Screw
JK
FSTEP 4
Attach Middle Panel (F) to the unit
with Wood Screws and Flat Washers.
(see Figure 4)
Attach Front Rail (J), (K) and (L) to the
unit using Cam Locks.
Attach Side Panel Unit (E) to the unit
with Cam Locks and Head Cap Bolts
(long).
STEP 3
Attach Bottom (N) to Side Panel Unit (D) with
Head Cap Bolts (long).
Attach Back Rail (M) to unit using a Cam Lock.
(see Figure 3)
Attach Back Posts (Q) to Back Rail (M) and
slide Back Panels (R) into place.
Attach Back Rail (M) to the unit using a Cam Lock.
N
D
Cam Lock
Head Cap Bolt
(long)

Assembly Instructions 4/5
Figure 8
O
Figure 7
Turn the unit to its’ upright position.
Place Top (A) onto unit and
attach with Head Cap Bolts
(long).
Insert Adjustable Pins into
side panels and middle
panel. Place Shelves (I) into
position.
Slide Drawers (S) into position.
Attach Doors (O) and (P) to the
side panels by sliding the door
lift hinges into the side panel lift hinges.
(see Figure 5)
Assemble Pull Handles to Door (O) and (P) with
Machine Screws. (see Figure 6)
STEP 5
STEP 6
Insert 12X Wood Screws from
the back of the unit. (see Figure 7)
Note: Please make sure unit is
level before tightening these
screws.
To level the unit, adjust the adjustable
levelers on the bottom of unit.
(see Figure 8)
Figure 6
Figure 5
S
A
P
I
S
Wood Screw
(short) for
Back Panel
Head Cap Bolt
(long)
Adjustable Pin
II
I

N2
Figure 2
MAKE SURE ROLLER
IS ON THE BACK
S2
S3
S6
S5
S5
S1
Figure 3 Figure 5
Insert wood screws (4X)
into the pre-drilled holes in S5
and tighten. (see Figure 3)
short
Insert S6 into grooves in S1 and
S2. (see Figure 2)
STEP 5
STEP 3
STEP 4
Tighten all screws used in drawer assembly.
Assemble Pull Handle with
machine screws. (see Figure 4)
Assembly Instructions 5/5
Part List
S1.
Front Part
2 pcs.
S6.
Divider
4 pcs.
S2.
Back Part
2 pcs.
S3.
Side Part
2 pcs.
S4.
Side Part
2 pcs.
Drawer (S)
Attach S1 to S3 and S4, using
a and
wood screws ,
tighten halfway.
Attach S2 to S3 and S4 using
wood screws ,
tighten halfway. (see Figure 1)
Phillips screwdriver
(4X)
(4X)
long
long
S4
S3 S1
S2
Figure 1
STEP 1 N3
S4
S1
S2
S3
S5.
Base Part
2 pcs.
Slide S5 into the grooves in S3
and S4. Be sure to push S5 all
the way forward so it meets S1.
(see Figure 2)
STEP 2
S4
S6
Figure 4
S1
S2
