HON Ceres Task Guide

Ceres Task – Seat Assembly Replacement Instructions
Items Required:
1 – New Seat Upholstered Assembly:
Applicable Part No’s: 92 -9740XX, 92F9740XX, 92-9738XX, 92F9738XX, 92L9739XX
1 – 3/16” Allen Wrench or Equivalent (5/32” Allen may also beused)
1. Place Ceres Task chair on elevated surface and locate seat removal opening in bottom
of lower control assembly (See Figure 1 below).
3/16” Allen
Wrench
Figure 1
Page 1
56-0124 Rev. A
The HON Company
200 Oak Street
Muscatine, IA 52761
800-833-3964
hon.com

2. Adjust the seat depth until the seat assembly is positioned at its most forward
position (See Figure 2 below).
3. While holding the seat slide lever upward, take the 3/16” Allen wrench and push up
into the seat removal opening until the wrench hits the seat assembly lock tab . (Note:
The 3/16” Allen wrench pushes the seat assembly lock tab out of the lock slot on the
control assembly.) See Figure 3 below:
Figure 2
Page 2
56-0124 Rev. A
The HON Company
200 Oak Street
Muscatine, IA 52761
800-833-3964
hon.com

4. While holding the seat slide lever upward and continuing to push the Allen wrench
upward on the seat assembly lock tab, pull the seat forward until the seat assembly
disengages with the control assembly on the Ceres chair. Make sure to push the lock
tab upward enough to disengage from the control (Note: the lock tab should only
need to be pushed slightly upward to disengage the seat assembly from the control).
5. Take the replacement seat assembly and center the seat assembly on the four control
posts as indicated below in Figure 4 (next page):
6. While holding seat slide lever upward, push the seat assembly forward until you hear
a ‘click’ or ‘popping’ sound. This sound indicates that the seat assembly lock tab has
engaged the control assembly.
Figure 3
Seat Removal
Opening on Control
Seat Slide Lever
Page 3
56-0124 Rev. A
The HON Company
200 Oak Street
Muscatine, IA 52761
800-833-3964
hon.com

Figure 4
Page 4
56-0124 Rev. A
The HON Company
200 Oak Street
Muscatine, IA 52761
800-833-3964
hon.com
© 2011 The HON Company
H4010 (01/11)
