Honeywell Home HVC0001 User manual

Owner’s Guide
Guide du propriétaire
Guía del usuario
HVC0001 / HVC0002
Programmable Bath Fan Control
Contrôleur de ventilateur programmable
Controlador de ventilador programable
400-305-000-B (69-2316EFS-03).book Page 1 Monday, September 28, 2009 11:06 AM
69-2316EFS-05
Home

Read and save these instructions.
À lire et conserver en lieu sûr.
Estas instrucciones deben leerse y conservarse
400-305-000-B (69-2316EFS-03).book Page 2 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
ENGLISH
Overview
About your programmable bath
fan control......................................... 2
Quick reference................................ 3
Installation
2-wire installation.............................. 4
4-wire installation.............................. 5
Setup
Ventilation Mode parameters............ 6
Time and date .................................. 7
Backlight mode................................. 8
Daylight saving time ......................... 9
Modes of Operation
Ventilation mode .............................10
Customized cycle mode..................12
Daily On/Off mode ..........................14
Manual mode ..................................16
Countdown mode ............................ 17
Appendices
Product specifications.....................18
Customer assistance ......................19
5-year limited warranty ...................20
Table of contents
400-305-000-B (69-2316EFS-03).book Page 1 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
2
ENGLISH
The bath fan control has been designed to control a single-speed bath fan. To suit your lifestyle, it can
be programmed in any of the following modes of operation:
• Ventilation Mode (see page 10)
• Customized Cycle Mode (see page 12)
• Daily On/Off Mode (see page 14)
• Manual Mode (see page 16)
Unlike the four programmable modes mentioned above, the Countdown Mode can easily be
activated by simply pressing a button (see page 17). In this mode, the fan is on until the end of the
programmed countdown time when the controller returns to the programmed mode.
This controller cannot be used with a load lower than 0.1 A or higher than 2.5 A.
The controller can be used to control a bath fan’s built-in light or a separate light
fixture connected to the bath fan control circuit. However, the light cannot be
independently controlled and will turn On or Off at the same time as the fan.
About your programmable bath fan control
400-305-000-B (69-2316EFS-03).book Page 2 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
3
ENGLISH
Quick reference
The LED illuminates
when the bath fan is On.
Press the Main Button to turn the
bath fan On or Off. (Press for 3
seconds to enter the setup menus.)
Press either button to place in
Countdown Mode. Then press the
left button to decrease the
countdown time or the right button
to increase the time.
Setup menu
Clock
The bath fan is On The bath fan is Off
Programmable modes
Countdown time
If the controller is also used to control
lights, pull out this safety tab before
replacing the light bulb. Push back in
after the light bulb is replaced.
Countdown Mode
(see page 17)
400-305-000-B (69-2316EFS-03).book Page 3 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
4
ENGLISH
nCut power at the main electrical panel to avoid electric shock.
oRemove the existing switch if applicable.
pInstall the bath fan controller.
qApply power at the circuit breaker.
2-wire installation
black
white
black (LINE)
black (LOAD)
green (GND)
120
VAC
black
white
For installation in wet locations, protect the circuit
with a ground fault circuit interrupter (GFCI).
400-305-000-B (69-2316EFS-03).book Page 4 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
5
ENGLISH
nCut power at the main electrical panel to avoid electric shock.
oRemove the existing switch if applicable.
pInstall the bath fan controller.
qApply power at the circuit breaker.
4-wire installation
120
VAC
black
white
black
white black (LINE)
black (LOAD)
green (GND)
For installation in wet locations, protect the circuit
with a ground fault circuit interrupter (GFCI).
400-305-000-B (69-2316EFS-03).book Page 5 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
6
ENGLISH
At first power-up, you will be prompted to set the following parameters:
Set the Ventilation Mode parameters
Select Units
(US /Metric)
Set Fan Capacity ***
(CFM or LPS)
ASHRAE 62.2
Pass/Fail ****
Set Floor Size **
(Sq. ft or Sq. M)
Set no. of
Bedrooms *
Normal
Display
* No. of bedrooms (1, 2, ..., 6)
** Floor space (1000, 1100, ..., 5000 sq. ft. or 100, 110, ..., 500 m2)
*** Fan capacity (30, 40, ..., 200 CFM or 15, 20, ..., 100 LPS)
**** The controller shows whether you pass or fail ASHRAE
Standard 62.2 for ventilation and the percentage of time the fan
will run every hour. If the controller indicates Fail; this usually
means the fan capacity is insufficient for your house.
If you press the main button for 3 seconds or do
not press any button for 60 seconds, the
controller will go to normal display. If the
parameters are not set, you will again be
prompted the next time the controller is powered
up, for example, after a power outage. The
parameters can be set at any time (see page 10).
400-305-000-B (69-2316EFS-03).book Page 6 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
7
ENGLISH
Set the time and date
Set Hour Set Minutes
Set Year Set Month Set Day
Select 24H or 12H
The time flashes on the screen when it is
not yet set or after a power outage of
more than 4 hours. To set the clock,
press the main button for 3 seconds to
display the setup menu and proceed as
shown.
Press the main button for 3 seconds at
any time (or do not press any button for
60 seconds) to save any changes you
have made and exit the setup menu.
400-305-000-B (69-2316EFS-03).book Page 7 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
8
ENGLISH
The controller provides 3 backlight modes. Depending on the mode selected, the screen behaves as
follows:
•Scrn Off: The screen is not lit (the backlight is off).
•Scrn On HI: The screen is lit at high intensity.
•Scrn On LO: The screen is lit at low intensity (default mode).
When you press any button, the screen is lit at high intensity for 8 seconds.
Set the Backlight mode
Set Backlight
(2 times)
(2 times)
Press the main but-
ton for 3 seconds at
any time (or do not
press any button for
60 seconds) to save
any changes you
have made and exit
the setup menu.
To set the backlight
mode, press the
main button for 3
seconds to display
the setup menu and
proceed as shown:
400-305-000-B (69-2316EFS-03).book Page 8 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
9
ENGLISH
When Automatic Daylight Savings Time changeover is enabled (DST On), the controller automatically
switches to daylight savings time (summer time) at 2:00 am on the second Sunday of March and back to
standard time (winter time) at 2:00 am on the first Sunday of November. This function is enabled by
default.
Set the Automatic Daylight Savings Time Changeover
Set Daylight
Saving Time
(2 times) (2 times)
To set the Automatic
Daylight Savings Time
Changeover, press the
main button for 3
seconds to display the
setup menu and
proceed as shown:
Press the main but-
ton for 3 seconds at
any time (or do not
press any button for
60 seconds) to save
any changes you
have made and exit
the setup menu.
400-305-000-B (69-2316EFS-03).book Page 9 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
10
ENGLISH
Press the main button for 3 seconds at any time (or do not press any button for 60 seconds) to save any changes you have
made and exit the setup menu.
Ventilation Mode
Select Units
(US /Metric)
Set Fan Capacity
(CFM or LPS) ASHRAE 62.2
Pass/Fail
Set Floor Size
(Sq. ft or Sq. M)
Set no. of
Bedrooms
Press simultaneously
In Ventilation Mode, the controller sets the fan On/Off time to meet ASHRAE Standard 62.2 for
ventilation based on total floor space, number of bedrooms and fan capacity. In this mode, the
fan operates on a 60-minute cycle. For example, if the fan is On for 20 minutes, it will be Off for
40 minutes. To set the Ventilation Mode parameters, press the main button for 3 seconds to
display the setup menu and proceed as shown.
400-305-000-B (69-2316EFS-03).book Page 10 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
11
ENGLISH
To place the controller in Ventilation Mode, proceed as shown:
Temporary override
Press the main button to temporarily turn the fan On or Off. For example, if you press the
main button to turn the fan On during the idle period, the fan will remain On until the
beginning of the next idle period or until you press the main button again.
Ventilation Mode (cont’d)
Select
Ventilation Mode
Ventilation Mode
Normal Display
(3 sec.) (3 sec.)
400-305-000-B (69-2316EFS-03).book Page 11 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
12
ENGLISH
In Customized Cycle Mode, you set the amount of time the fan is On (Run Period) or Off (Idle Period).
Each period can be set between 10 minutes and 120 minutes in increments of 5 minutes. The controller
will cycle between the two periods. For example, if you set the Run Period to 10 minutes and the Idle
Period to 20 minutes, you have established a cycle of 30 minutes. During every cycle, the fan will turn On
for 10 minutes and Off for 20 minutes.
Press the main button for 3 seconds at any time (or do not press any button for 60 seconds) to save any
changes you have made and exit the setup menu.
Customized Cycle Mode
Set Run Period Set Idle Perio
d
(3 times)
The Run Period and Idle Period
are available only if the controller
is in Customized Cycle Mode
(see opposite page). To set the
periods, press the main button for
3 seconds to display the setup
menu and proceed as shown:
400-305-000-B (69-2316EFS-03).book Page 12 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
13
ENGLISH
To place the controller in Customized Cycle Mode, proceed as shown:
Temporary override
Press the main button to temporarily turn the fan On or Off. For example, if you press the
main button to turn the fan On during the idle period, the fan will remain On until the
beginning of the next idle period or until you press the main button again.
Customized Cycle Mode (cont’d)
Select Customized
Cycle Mode
Customized Cycle Mode
Normal Display
(3 sec.) (3 sec.)
400-305-000-B (69-2316EFS-03).book Page 13 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
14
ENGLISH
In Daily On/Off Mode, the fan turns On and Off once a day according to the programmed On Time
and Off Time.
Press the main button for 3 seconds at any time (or do not press any button for 60 seconds) to
save any changes you have made and exit the setup menu.
Daily On/Off Mode
Set On Time Set Off Time
(3 times)
The On Time and Off Time
are available only if the
controller is in Daily On/Off
Mode (see opposite page).
To set the On Time and Off
Time, press the main
button for 3 seconds to
display the setup menu
and proceed as shown:
400-305-000-B (69-2316EFS-03).book Page 14 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
15
ENGLISH
To place the controller in Daily On/Off Mode, proceed as shown:
Temporary override
Press the main button to temporarily turn the fan On or Off. For example, if you press the
main button to turn the fan On, it will remain On until the programmed Off time or until you
press the main button again.
Daily On/Off Mode (cont’d)
Select Daily
On/Off Mode
Daily On/Off Mode
Normal Display
(3 sec.) (3 sec.)
400-305-000-B (69-2316EFS-03).book Page 15 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
16
ENGLISH
In Manual Mode, the controller operates like a regular switch. In this mode, simply press the
main button to turn the fan On or Off.
To place the controller in Manual Mode, proceed as shown:
Manual Mode
Select
Manual Mode
Normal Display Manual Mode
(3 sec.) (3 sec.)
400-305-000-B (69-2316EFS-03).book Page 16 Monday, September 28, 2009 11:06 AM

HVC0001/HVC0002
17
ENGLISH
Place the controller in Countdown Mode to run the fan for 10-60 minutes. The fan turns On when the
controller is in this mode. At the end of the countdown time, the controller returns to its programmed mode
and the fan turns Off. (NOTE: The fan might stay On if the controller has been set to turn the fan On at
that given time in the programmed mode.)
You can cancel the Countdown Mode and return to the programmed mode at any time by pressing the
main button.
To place the controller in Countdown Mode, proceed as shown:
Countdown Mode
After
5 sec.
Set Countdown
Time (minutes) *
Countdown Mode
is activated
At end of Countdown Mode
Normal Display _+
* Press the left or right button once
to use the same countdown time
as the one used the last time.
Press the left (-) or right (+) button
more than once to decrease or
increase the countdown time (in
increments of 5 minutes).
400-305-000-B (69-2316EFS-03).book Page 17 Monday, September 28, 2009 11:06 AM

Owner’s Guide 400-305-000-EFS
18
ENGLISH
HVC0001:white
HVC0002: biscuit
Voltage: 120 VAC - 15%, + 10%
Frequency: 60 Hz ± 5%
Minimum Load: 0.1 A (12 W)
Maximum Load: 2.5 A (300 W)
Minimum Power Factor:0.60
Operating Temperature Range: -15°C to 50°C (5°F to 122°F)
Storage Temperature Range: -40°C to 60°C (-40°F to 140°F)
Product Specifications
400-305-000-B (69-2316EFS-03).book Page 18 Monday, September 28, 2009 11:06 AM
