Honeywell CS10XE Series User manual

SWING
SPEED
POWER
TIMER
124
0.5 H L
M
COOL
Model / Modelo / Modèle: CS10XE
Power rating / Potencia / Puissance nominale: 102W
Voltage rating / Tensión / Tension nominale: 120V ~ 60Hz
For product inquiries or support / Para consultas del producto o soporte /
Pour les questions sur les produits ou pour du soutien:
www.honeywellaircoolers.com
Portable Evaporative Air Cooler
for Indoor Use
Evaporativo Portátil Enfriador De Aire
para uso En El Interior
Portatif Évaporatif Refroidisseur D'air
pour Usage Intérieur
OWNER’S MANUAL
Read and save these instructions before use
MANUAL DEL PROPIETARIO
Lea y guarde estas instrucciones antes de usar la unidad
MANUEL DU PROPRIÉTAIRE
Lire et conserver ces instructions avant utilisation
Customer Support / Atención al cliente / Soutien au client:
1-800-474-2147
Made in China
Hecho en China
Fabriqué en Chine

1
2
3
QUICK START GUIDE
Fill with water and plug into a standard
power outlet.
Place near an open door or window.
Note : Evaporative air cooler requires cross ventilation.
Turn ON and enjoy the cooling breeze.
Note: Start with LOW speed and gradually increase
to higher speed for optimum cooling performance.
Note: Please make sure the household power voltage
matches the product specifications.

SECTION PAGE
1. THANK YOU .........................................................................................................
2. USER TIPS ...........................................................................................................
3. SAFETY ................................................................................................................
4. PARTS DESCRIPTION ........................................................................................
5. USE & OPERATION .............................................................................................
6. CLEANING & MAINTENANCE .............................................................................
7. TROUBLESHOOTING GUIDE .............................................................................
8. TECHNICAL SPECIFICATIONS ...........................................................................
9. ELECTRICAL WIRING DIAGRAM ........................................................................
2
3
5
7
8
Filling with Water ................................................................................................
Function Buttons .................................................................................................
Remote Control ................................................................................................... 13
Control Panel ................................................................................................... 8
9
Low Water Alarm Function ................................................................................. 11
12
14
16
18
18
10. SERVICE AND WARRANTY ................................................................................. 19
INDEX
1
Read all instructions carefully before setting up and operating the unit, and please keep
this instruction manual for future reference. This manual is designed to provide you with
important information needed to setup, operate, maintain, and troubleshoot your cooler.
Failure to follow these instructions may damage and/or impair its operation and void the
warranty.

2
THANK YOU
Congratulations on your purchase of this versatile Honeywell Evaporative Air Cooler.
For optimum cooling from your cooler, fill the water tank to maximum level and load
ice inside the ice compartment before you turn on your air cooler.
Cooler Location - Indoors (Important - Please Read!)
Place the cooler in front of an open door or window. Ensure that there is adequate
cross - ventilation in the room by leaving a door or window open opposite the cooler.
Following these guidelines will ensure your cooler will work as effectively as possible.
Not an Air Conditioner (Important - Please Read!)
The evaporative air cooler is not an air conditioner as it does not use a compressor
or refrigerant gas. It should not be expected to cool as efficiently as a refrigerated air
conditioner.

3
USER TIPS
Energy Efficient, No Compressor
Honeywell Evaporative Air Coolers are built to maximize energy efficiency and keep
costs low. Warm air is drawn into the cooler through a dust and odor-reducing carbon
filter and enters the Honeycomb Cooling Media. Water pumped from the tank pours
over the honeycomb media. As the warm air passes through the media, the water
absorbs the heat, naturally cooling and humidifying the air. A fan propels the cooled air
out into the room. This no-compressor system cools naturally, efficiently and inexpen-
sively.
Pump
Water
Honeycomb Cooling Media
Evaporative Air Cooling Mechanism
Warm and
dry air
Cool and
humid air

4
USER TIPS
The recommended maximum relative humidity level is 60% or
less, which allows a noticeable temperature decrease. The
temperature decrease will be greater in drier climates because
higher evaporation occurs when the humidity is low.
The evaporative air cooler should not be used in enclosed
spaces. It must be kept level and there must be water in the
water tank. The room should have doors and windows opened
to allow free air flow. The evaporative air cooler works best
when placed near an open window, so that outside air is drawn
into the evaporative air cooler, circulates in the room, then
exits via the door. The maximum cooling effect is felt when a
person is in the flow of air coming out of the evaporative air
cooler.
The evaporative air cooler can also be used to humidify dry
air during cool weather. To be used for humidification the
windows and doors should be closed to allow the humidified
air to accumulate.
When the product is used for the first time the Honeycomb Cooling Media will have an
odor which will dissipate in a few hours or so of initial use.
Room with open windows & door
(RECOMMENDED)
Room with closed windows & door
(NOT-RECOMMENDED)
NOTE

120V AC 60Hz
SHOCK HAZARD
WATER LEVEL INDICATOR
5
SAFETY
READ AND SAVE THESE INSTRUCTIONS:
When using electrical appliances, basic safety precautions should always be followed:
Your cooler runs on 120 Volt AC, 60 Hz current. Check the
household voltage to ensure it matches the appliance's rate
specification.
Before operating the product remove it from its packaging
and check that it is in good condition.
DO NOT operate any product with a damaged cord or plug.
We recommend not using an extension cord with this
appliance.
DO NOT run power cord under carpeting, or cover it with
rugs or runners. Keep the cord away from areas where it
may be tripped over.
Always unplug the product before refilling the water tank.
Always unplug the appliance from the power source before
cleaning, servicing or relocating the unit.
Remove the power cord from the electrical receptacle by
grasping and pulling on the power cord plug-end only, never
pull the cord.
DO NOT use the product in areas where gasoline, paint or
other flammable goods and objects are stored.
When using the COOL setting, check the water tank to
ensure that it is full. Operation of this cooler on the COOL
setting with an empty tank may result in damage to the
water pump.
WARNING: To reduce the risk of fire or electric shock, do
not use this appliance with any solid state speed control
device.
•
•
•
•
•
•
•
•
•
•

SWING
SPEED
POWER
COOL
TIMER
H
124
0.5
L
M
FLOOR LEVEL
6
SAFETY
DO NOT attempt to repair or adjust any electrical or
mechanical functions of the cooler, as this may void the
warranty.
DO NOT cover the air inlet or outlet on the appliance as this
may cause motor damage.
DO NOT insert or allow objects to enter any ventilation or
exhaust opening as this may damage the product and could
cause electrical shock or fire.
DO NOT operate with the Honeycomb Cooling Media
removed as this will overload and damage the motor.
DO NOT leave the operating appliance unattended for any
extended period of time.
DO NOT let children play with this appliance, packaging or
plastic bags.
If the unit is damaged or it malfunctions, do not continue to
operate it. Refer to the troubleshooting section and seek
professional advice.
Place the unit on a level floor.
This product is not intended for use in wet or damp
locations.
DO NOT use in bathrooms. Never locate the product where
it may fall into a bathtub or other water container.
Store in a dry area when not in use.
This appliance is not intended for use by persons (including
children or elderly) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning
the use of the appliance by a person responsible for their
safety.
Always grip the side handles to move the cooler.
•
•
•
•
•
•
•
•
•
•
•
•
•

SWING
SPEED
POWER
COOL
TIMER
124
0.5 H L
M
1 Display Screen
2 Control Panel
3 Louvers
4 Front Grill
5 Front Castors
6 Handle
7 Remote Control
8 Honeycomb Cooling Media
9 Rear Grill
10 Water Fill Tray
11 Water Tank
12 Rear Wheels
13 Carbon Filter
14 Water Level Indicator
15 Water Tank Lock Clip
16 Power Cord & Plug
PARTS DESCRIPTION
7
12
16
11
10
9
813
6
7
1
2
3
4
14
15
5
ACCESSORIES:
Remote Control with 1pc CR2032 (1 x 3V) coin type battery.

CONTROL PANEL
USE & OPERATION
Icons on LED
Cool
Low speed
Medium speed
High speed
Swing
Time delay set
124
0.5 H L
M
SWING
SPEED
POWER
COOL
TIMER
Power ON / OFF
124
0.5
H L
M
8

FUNCTION BUTTONS
POWER
Press the POWER button to turn the unit on. To turn the unit
off, press the button again. The cooler will start automatically at
medium speed. After a few seconds the speed will switch to low.
USE & OPERATION
SPEED
Press the SPEED button repeatedly to change the speed
between H - M - L. The indicator light will show the selected
speed:
High (H) Medium (M) Low (L) H L
M
1
2
4
0.5
TIMER
Press the TIMER button until the indicator light moves to your
desired time setting. Once the set time has passed, the unit
will automatically shut off. The Timer function allows you to
program the unit for up to 7.5 hours of use.
9

USE & OPERATION
UP-DOWN AIR FLOW
To adjust the vertical direction of air flow, adjust the horizontal
louvers located behind the front grill manually.
SWING
Press the SWING button. The indicator light will come on
and the louvers will begin to move from right to left
automatically. Manually adjust the horizontal louvers to
change vertical airflow.
LOUVER MOVEMENT
COOL
When the COOL function is not activated while the unit is
ON, the unit functions as a normal fan without the
evaporative cooling function.
10

USE & OPERATION
LOW WATER ALARM FUNCTION
The unit is equipped with a low water sensor. When water in the tank is below the
minimum level, you will hear 10 beeps and the COOL LED indicator will flash
continuously. At the same time the power to the pump inside the unit will be cut off
to protect the life of the pump.
To disengage the alarm function, turn off and unplug the unit from the power
outlet. Fill the tank with water above the minimum level.
To turn off the Low Water Alarm and continue to use the unit as a normal fan,
without evaporative cooling function, turn the unit off, then on again. If the [COOL
is pressed again without filling the tank with water, the Low Water Alarm will
activate again.
11

USE & OPERATION
REMOTE CONTROL
Power: On / Off
Speed: Low / Medium / High
Cool: Controls cooling
Swing: Controls the motion of the louvers
Timer: Controls timer function for automatic shut off
12
NOTE
•
•
•
•
•
•
•
•
•
•
The remote control for your air cooler already has its battery installed.
The remote control requires a CR2032(1 x 3V) coin type or equivalent battery for
replacement.
Open the battery compartment at the back of the remote control and insert ta CR2032(1 x 3V)
coin type or equivalent battery. Care must be taken to insert the batteries according to the correct
polarity (+ / –) markings shown inside the battery compartment.
Always point the remote control signal transmitter towards the unit when operating.
Make sure that the signal path is not obstructed.
Remove the batteries if the unit is not going to be used for an extended period of time.
Do not drop the remote control.
Do not mix different types of batteries such as alkaline, carbon-zinc, or rechargeable batteries.
Do not mix old and new batteries.
Exhausted batteries are to be removed from the product.

USE & OPERATION
FILLING WITH WATER
Open the Water Fill Tray located at the back of the unit. The
water tank of the unit holds up to 2.6 Gallons of water.
CAUTION
The Water Level display window is located on thefrontof the
unit. Refill the water tankwhen water level is low. Do not fill
water above the Max water level mark. Check water level in
the tank before running theCOOLfunction. Please be sure
water in the tank is always above the minimum water level
mark. Running theunit withinadequate watermay cause pump
failure.If ice is available you may add ice in the top compartment
to enhance the cooling performance.
Unplug from power when refilling.
Water Level Indicator
13
Water Fill Tray

CLEANING & MAINTENANCE
Detached Water Tank
Before cleaning the unit, switch it to the OFF position and
remove the plug from the power socket.
To clean the outside, use a damp cloth to remove dirt and
dust.
Never use corrosive elements or any chemicals to clean
this product.
When the product is not in use, store the unit in a dry place
out of direct sunlight.
•
•
•
•
•
•
•
•
•
•
Turn the power OFF and disconnect the air cooler from the
power supply.
Move the unit to a location where it can be drained. Remove
the cap from the drainage tube and allow the tank to empty
(see parts description on page 7).
Once the tank is empty, unlock the latches on both sides
and lift off the cooler top section as shown in the figure and
place it vertically on the floor. Be careful not to bend the
water pickup tube that hangs below the unit.
Refill the water tank with clean water and drain it completely.
Clean the water tank with detergent or a damp cloth and
rinse it thoroughly.
Place the unit top carefully on the tank and lock the latches.
Refill the water tank with clean water, up to the maximum level.
The air cooler is now ready to be used. This cleaning
process should be repeated weekly to maintain the integrity
of the unit and to remove particles filtered from the air.
CLEANING & DRAINING THE WATER TANK:
WARNING
Water Pick Up Tube
14

CLEANING & MAINTENANCE
CLEANING THE CARBON FILTER AND HONEYCOMB
Honeycomb
Cooling Media Carbon Filter
The appliance is supplied with Carbon Filter & Honeycomb
Cooling Media.
Always keep the Carbon Filter clean. You can wash the
Carbon Filter at least twice a year or whenever you feel
necessary.
The Carbon Filter and Honeycomb Cooling Media are located
inside the back panel. Open the back panel by pulling out the
back grill to clean or replace the Carbon Filter or Honeycomb
Cooling Media. It is recommended that the Carbon Filter and
Honeycomb Cooling Media be replaced every year, depending
on use and environment.
Draining the water reservoir and refilling with fresh water at
least once a week will greatly reduce mineral deposits in the
pads and help to extend the life of Honeycomb Cooling Media.
Do not run the unit in COOL mode with stale water in the tank.
You must empty the water tank and refill with fresh water,
especially if the tank has not been cleaned in a long time.
The cleaning frequency for the Honeycomb media depends
on local air and water conditions. In areas where the mineral
content of water is high, mineral deposits may build up on the
Honeycomb Cooling Media and restrict air flow. Draining the
water reservoir and refilling with fresh water at least once a
week will help reduce mineral deposits. If mineral deposits
remain on the Honeycomb media, the media should be removed
and washed under fresh water. The media should be cleaned
every two months or sooner, depending on your needs.
For best results allow the Honeycomb Cooling Media to dry
after each use by turning off the cool function 15 minutes
before turning the unit off.
•
•
•
•
•
•
•
15

16
TROUBLESHOOTING GUIDE
No discharge of air Cord is not plugged in.
Power is not ON.
Not Cooling / Unit is
making noise
Pump is not turned ON.
Refill water tank.
Odors When the Cooler is new.
If the Cooler has been used.
Contact Customer Service
Center.
PROBLEM POSSIBLE CAUSE SOLUTION
Make sure power cord is
plugged in and the supply
switch is ON.
Turn the unit ON by pressing
button on the control panel or
remote control.
Turn on COOL function from
remote or control panel.
When the unit is used for the
first time, the Honeycomb
Cooling Media will have an
odor, which will dissipate
within a few hours of initial use.
There may be an algae issue.
Replace the Honeycomb
Cooling Media.
Low or no water in tank, when
COOL is selected.
Damaged Pump or Calcium
deposits on blower.
Customer Support: 1-800-474-2147

17
TROUBLESHOOTING GUIDE
The unit does not respond Remote control batteries.
Damaged Control Panel
on unit.
PROBLEM POSSIBLE CAUSE SOLUTION
Check batteries. Replace if
needed. Try to operate using
the control panel.
Try to activate the unit with the
Remote Control. If the unit
responds, then the Control
Panel on the unit may be
experiencing problems -
contact the Customer Service
Center.
If neither the Remote Control
or the Control Panel is
working, contact the Customer
Service Center.
Customer Support: 1-800-474-2147

MODEL NO. CS10XE
120V
60Hz
102 Watts
2.6 Gallons
Honeycomb
13.5 (W) x 15.7(D) x31.5(H) inch
18.5 lbs
Voltage
Frequency 0.85A
Ampere
Wattage
Water Tank Capacity
Cooling Media
Product Dimension
Net Weight
TECHNICAL SPECIFICATIONS
ELECTRICAL WIRING DIAGRAM
120VAC 60Hz
18
