Honeywell MM14CCS User manual

Email: [email protected]
Web: www.honeywellportableac.com
EN Portable Air Conditioner
User Manual
Read and save these instructions before use
FR Climatiseur portatif
Mode d’emploi
Lire ces consignes avant l’utilisation de l’appareil
et les conserver
NL Portable Air Conditioner
Gebruikers handleiding
Lees en bewaar deze instructies voor gebruik
DE Mobile Klimaanlage
Gebrauchsanleitung
Lesen Sie die Gebrauchsanleitung vor dem
ersten Gebrauch
Model / Modèle / Modell: MM14CCS

This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
•
•
•
EN
WARNING / AVERTISSEMENT / WAARSCHUWING / WARNHINWEIS
Cet appareil peut être utilisé par des enfants âgés de 8 ans et
plus, ainsi que des personnes ayants des capacités réduites
au niveau physique, sensoriel ou mental, ou un manque d’ex-
périence et de connaissances si ils ont été supervisés ou
instruits à propos de l’utilisation de l’appareil de manière sûre
et s’ils ont compris les risques encourus.
Les enfants de devront pas jouer avec l’appareil.
Le nettoyage ou la maintenance ne devra pas être effectuée
par des enfants, sauf si ces derniers sont âgés de plus de 8
ans et s’ils sont supervisés.
•
•
•
FR

Dieses Gerät darf von Kindern über 8 Jahre, sowie von Per-
sonen mit reduzierten körperlichen, sinnlichen oder geistigen
Fähigkeiten oder ohne Erfahrung und Wissen benutzt werden,
sofern sie unter Aufsicht sind, oder mit den entsprechenden
Anleitungen zum sicheren Gebrauch des Geräts und der
Gefahrenerkennung vertraut gemacht worden sind.
Kinder dürfen mit dem Gerät nicht spielen.
Die Reinigungs- und Wartungsarbeiten sollten nicht von Kin-
dern ausgeführt werden, außer sie sind älter als 8 Jahre und
werden dabei beaufsichtigt.
•
•
•
DE
Dit apparaat kan worden gebruikt door kinderen van 8 jaar en
ouder en personen met verminderde lichamelijke, zintuiglijke
of verstandelijke vermogens of gebrek aan ervaring en kennis
als ze onder toezicht staan of instructie over het gebruik van
het apparaat op een veilige manier en het begrijpen van de
eventuele gevaren.
Kinderen mogen niet met het apparaat spelen.
Reiniging en onderhoud mogen niet door kinderen worden
gedaan zonder toezicht.
•
•
•
NL
WARNING / AVERTISSEMENT / WAARSCHUWING / WARNHINWEIS

USER TIPS
THANK YOU
Congratulations on your purchase of this versatile Honeywell Portable Air Conditioner.
Honeywell Portable Air Conditioners are ideal for spot cooling. The compressor, condenser and
evaporator are housed in a compact unit. The air is filtered, dehumidified and cooled while a flexible air
outlet hose sends heat outside. The air conditioner includes a window venting kit.
No permanent installation is needed. The unit is easy to move from room to room and offers a truly
flexible air conditioning solution.
Auto Evaporation System - The unit automatically evaporates the condensate through the air
outlet hose. There is no need to empty the drainage tank except in very humid conditions.
Read and follow the instructions carefully.
•
•
Follow installation instructions to set up the unit.
Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.
Important:
Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.
Manually adjust the air vent located at the top of the unit to adjust the direction of air flow.
USER TIPS
To ensure optimal efficiency of the product, keep doors and windows closed when it is used as an air
conditioner or dehumidifier. If the product is being used with the fan function only, an open window could
improve air circulation.
Cooling and Dehumidifying Operation Fan Operation
EN 1

READ AND SAVE THESE INSTRUCTIONS
Improper handling can cause serious damage to the appliance.
WARNING:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DO NOT operate the unit with a damaged plug or loose wall outlet. If the power cord is damaged, it
must be replaced by the manufacturer or an authorized service agent.
DO NOT cover the air intake and exhaust when in use.
This appliance is not intended for use by children. Children should be supervised and should not play
on or around the appliance.
DO NOT place objects on or sit on the unit.
Always turn off and unplug the unit when cleaning or servicing.
If service is needed contact an authorized service agent.
Unplug the unit when stored or not in use.
DO NOT run the power cord under carpeting and rugs.
Use caution to prevent tripping on cord.
DO NOT use in areas where gasoline, paint or other flammable goods are stored.
Basic safety precautions should always be followed when using electrical appliances.
This appliance has been manufactured for use in domestic environments and should not be used for
other purposes.
Only use the installation kit provided to install this unit. DO NOT attempt to extend the exhaust hose or
install this unit using other methods other than that provided in this manual. Improper installation could
void any existing warranties.
DO NOT use an extension cord with this unit.
SAFETY
PARTS DESCRIPTION
5) Air Filter
6) Back Grill
7) Exhaust Hose Connector
8) Power Supply Cord
9) Remote Control
10) Lower Drain Plug with
Plastic Cap
(Air Conditioning Mode)
11) Upper Drain Plug
(De-humidifier Mode)
1) Control Panel
(Incl. Signal Receptor)
2) Air Outlet
3) Handle
4) Casters
EN 2
12) Air inlet filter
1
2
5
6
11
4
3
12
7
9
8
10
5
6
11
7
8
1010

It is important that the installation instructions below are followed for successful installation of this
portable air conditioner. Please call Customer Support if you have any difficulties or queries regarding
these installation procedures.
1.
2.
3.
4.
Drill a hole in an outside wall or through a window pane. Respect the height and dimensions of the
hole given in Fig. 2 and Fig. 3.
Insert & secure the Flange Fixture into the newly drilled hole.
Fix one end of the Plastic Hose into the Flange Fixture that was secured on the wall.
Fix the other end of the Plastic Hose onto the Hose Connector and then onto the rear Exhaust outlet
of the unit (See Fig. 3).
INSTALLATION
1.
2.
3.
4.
5.
Flange Fixture......................................
Hose Connector..................................
Hole Cover..........................................
Plastic Hose........................................
Exhaust Nozzle....................................
Installation kit:
1 Piece
2 Pieces
1 Piece
1 Piece
1 Piece
Through a Drilled Hole in the Wall or Window
If required, your Portable Air Conditioner can be installed semi-permanently.
NOTE: When the unit is not in use, remove the Plastic Hose from the Flange Fixture on the wall and use
the included Hole Cover to cover the hole on the wall.
Fig.1 Fig.2
12 4.9”
5 mm
In the
wooden
kickboard
of a french
window
In the wall: we
recommend you to
insulate the section
of wall using suitable
insulation materials.
In
the
window
panel
Fig.3
1. Install the plastic hose with exhaust nozzle and hose connector on both sides. Ensure proper fit on
both ends.
Through an Open Window
Connect the plastic hose to the rear exhaust
outlet on the back of the unit. Push-in until it is
locked in place.
Extend the plastic hose through an open
window and close the window as far as possible
trapping the Exhaust Nozzle (as shown below).
2. 3.
11.8” 11.8”
30 cm
1
45
x 1
x 2 x 1
x 1
x 1
23
x 1
MIN. 36 cm / 14”
MAX. 102 cm / 40”
30 cm
EN 3
Through a Drilled Hole in the Wall or Window
If required, your Portable Air Conditioner can be installed semi-permanently.
If required, your Portable Air Conditioner can be installed semi-permanently.
window and close the window as far as possible
trapping the Exhaust Nozzle (as shown below).
11.8”
11.8”
30 cm
30 cm

•Cooling Mode
The unit works as an air conditioner. Adjust fan speed and air temperature to suit your desired comfort
level. Temperature setting range is 16°C- 32°C (61°F- 89°F).
INSTALLATION (CONTINUED)
IMPORTANT:
•The length of the exhaust hose is determined by the product specifications. Do not replace or
lengthen it as this could cause the unit to malfunction.
WARNING: Any warranties included with this product will be voided if an extra extension hose is added
to the originally provided installation kit or if the installation is performed differently than the manufactur-
er's instructions, without proper consultation. Please contact Customer Support for help with installation
procedures if needed.
RECOMMENDEDNOT RECOMMENDED
•
•
•
The supplied exhaust hose has a diameter of 5 inches (12.7cm) and can be extended from 12 inches
to 47 inches (30cm to 120cm).
Do not bend (to the extent shown below) the exhaust hose. A bent hose will block exhaust air and
cause the unit to malfunction or shut-off.
Make sure the back of the unit is at least 50 cm / 20 inches away from the wall. Do not place the unit
in front of curtains or drapes as this could obstruct the airflow.
USE & OPERATION
TOUCH SCREEN CONTROL PANEL
POWER CONTROL
The Power Control turns the unit on and off. When
the unit is plugged in, this button lights up indicating
it is in a Standby Mode ready to be switched on
anytime.
MODE CONTROL
3 settings: Cool, Dehumidify, Fan.
A light will indicate which setting is currently
being used.
(1) Timer Control
(4) Mode Control
(2) Fan Speed Control
(5) Power Control / Standby Mode
(3) Timer / Temperature Set Controls
(6) Warning Light (when flashing)
50 cm / 20”
MIN. 36 cm / 14”
MAX. 102 cm / 40”
EN 4
MIN 35.6 cm
(1) (2) (3) (3) (4) (5) & (6)
50 cm / 20”
MIN. 36 cm / 14”
MAX. 102 cm / 40”

•
•
Dehumidifying Mode
Air is dehumidified as it passes through the unit, without being in full cooling mode. If room tempera-
ture is higher than 25°C (77°F) fan speed can be adjusted; otherwise fan speed is preset to LOW.
Note: If the unit will be used mainly as a dehumidifier, do not connect the exhaust hose and let the
warm air return in the room. Continuous drainage is then necessary and more efficient (refer to
Continuous Draining).
Fan Mode
For air circulation without air conditioner cooling.
USE & OPERATION (CONTINUED)
FAN SPEED CONTROL
3 settings: High, Medium and Low.
TIMER CONTROL
While the unit is turned on, press the timer button then press the ▼or ▲to select the number of hours
you would like the unit to continue to run. The unit will turn off automatically.
AUTO TURN OFF:
While unit is running, press the press the ▼or ▲button to select the number of hours you want the unit
to run in air conditioning mode.
AUTO TURN ON:
When unit is in a standby mode (plugged in with power light on), then press the ▼or ▲button to select
the number of hours until you want the unit to automatically start running.
TEMPERATURE / TIMER SET CONTROLS
WARNING LIGHT
Condensed water may accumulate in the unit. If the internal tank becomes full, the Power Control light
will flash and the unit will not operate until the unit has been drained (refer Water Condensation
Drainage).
After switching the air conditioner off, you must wait 3 minutes before switching it back on
again.
•
•
•
Used for adjusting the timer and thermostat.
The default display is room temperature.
In cooling mode, when ▼ or ▲button is pressed, the set temperature is displayed and may be
adjusted. After 10 seconds the display will revert back to room temperature. Temperature is only
adjustable in cool mode. The time is adjustable between 1~24 hours.
Note: By pressing both ▼/ ▲set buttons at the same time, the display will toggle between Celsius
and Fahrenheit.
FUNCTION BUTTONS (CONTINUED)
EN 5

REMOTE CONTROL
The functions work the same as the portable air conditioner's Touch Screen Control Panel.
All key functions can be accessed from the remote control.
USE & OPERATION (CONTINUED)
•
•
•
Used for adjusting the timer and temperature.
When ▼or ▲key is pressed in cool mode, the
set temperature is displayed and may be
adjusted. After 10 seconds the display will
revert back to room temperature.
Timer setting is available from 1-24 hours by
pressing the key ▼or ▲
Press this button to change the operation mode
in the order of:
ON / OFF
• HIGH • MEDIUM • LOW
In running mode: Auto switch off
In stand-by mode: Auto switch on
Press ▼or ▲button to adjust the
time setting for 1 hour intervals.
Temperature / Timer Set
Mode Control
Power Control
Fan Speed Control
Timer Control
Battery Installation: Remove the cover on the back of the remote control and insert two AAA batteries
with + and - pointing in the proper direction according to the polarity markings.
Use only two AAA or IEC R03 1.5V batteries.
Remove the batteries if the remote control is not in use for a month or longer.
All batteries should be replaced at the same time, do not mix with old batteries.
Properly dispose of used batteries.
•
•
•
•
•
Note:
Caution:
Cool Dehumidify
Fan
EN 6

CLEANING & MAINTENANCE
Appliance Maintenance:
Air Filter Maintenance:
The air filter should be cleaned every two weeks. Clean it as follows:
1.
2.
Turn off the appliance before disconnecting the power supply.
Always clean the appliance with a soft dry cloth.
1.
2.
Turn off the appliance and remove the air filter .
Rinse it in lukewarm water. After cleaning, dry in a shaded and cool place, then reinstall.
End of Season Storage & Maintenance:
If the appliance will not be used for a long time:
1.
2.
3.
4.
5.
6.
7.
8.
Be sure to drain the left-over water condensation. Remove the lower drain plug and use a
shallow pan to collect the water (make sure to replace the drain plug when finished).
To dry excess moisture, run the unit in Fan only mode for 30 minutes before storing.
Turn off and unplug the air conditioner from the power supply.
Remove the air filter and clean with water. Dry the air filter and then reinstall onto the unit.
Disconnecting the Window Installation Kit:
Cover the air conditioner with a cloth/ plastic bag before storage, to protect from dust and scratches
collecting on the surface of the unit.
It is recommended to coil the power cord and store it away from the floor to ensure the cord is
protected from bents and creases.
Store the air conditioner in a cool, dry place, away from direct sunlight.
Remove the Plastic Hose from the unit by pulling away from the unit at the same time.
Remove the Window Bracket, Window Bracket Panel Adapter and Hose Connector.
It is recommended to store the Window Kit parts in a bag together with the Remote Control and
placing them together with the air conditioner unit.
If needed, you can clean the Window Kit with a damp cloth and water before storing. Make sure all
parts of the Window Kit are dry before storage.
•
•
•
•
EN 7
