Honeywell Pro-Watch 7000 User manual

Install Guide
Pro-Watch 7000
Two-Reader Module
PW7K1R2

Copyright© 2020 Honeywell. All rights reserved.
All product and brand names are the service marks, trademarks, registered trademarks, or registered service marks of their
respective owners. Printed in the United States of America. Honeywell reserves the right to change any information in this
document at any time without prior notice.
Pro-Watch® is a trademark of Honeywell, Inc.
Ordering Information
Please contact your local Honeywell representative or visit us on the web at www.honeywellintegrated.com for information
about ordering.
Feedback
Honeywell appreciates your comments about this manual. Please visit us on the web at www.honeywellintegrated.com to
post your comments.
Discover | Customer Portal
Self-Service Product Support and Learning Management System
https://honeywelldiscovertraining.com/login/discover/default.asp
YouTube | Honeywell Help and Support
https://www.youtube.com/channel/UCBEL6ouNV_LN5lEpYRujMTg/featured

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 i
TABLE OF CONTENTS
Notices......................................................................................................................................... iii
Warnings and Cautions........................................................................................................ iii
Disclaimer....................................................................................................................................v
Limited Warranty ......................................................................................................................v
Confidentiality ......................................................................................................................... vi
Compliance ............................................................................................................................... vi
CE and WEEE Marking ......................................................................................................... vi
Unpacking Procedure .......................................................................................................... vii
Shipping Instructions .......................................................................................................... vii
Chapter 1 - Reader Module ............................................................................. 9
Description........................................................................................................................................ 9
Specifications......................................................................................................................... 10
Setup ................................................................................................................................................ 11
Setting Jumpers.................................................................................................................... 11
Setting DIP Switches........................................................................................................... 11
LED Operation.............................................................................................................................. 12
Power................................................................................................................................................ 13
Communications......................................................................................................................... 13
Wiring............................................................................................................................................... 14
Reader Wiring......................................................................................................................... 17
Input Wiring ............................................................................................................................ 17
Control Output Wiring ........................................................................................................ 18
Mounting Options....................................................................................................................... 19
Installing the Module................................................................................................................. 19

ii PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Appendix A - Programming Sheet............................................................... 21

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 iii
Notices
Warnings and Cautions
Wiring methods shall be in accordance with the National Electrical Code (ANSI/
NFPA70), Canadian Electrical Code, Part I (CSA C22.1) Safety Standard for Electri-
cal Installations, local codes, and the authorities having jurisdiction.
Warning:
Before connecting the device to the power supply, verify that the output voltage is within
specifications of the power supply.
Not Evaluated by UL for fire, life safety, or burglary applications.
Do not apply power to the system until after the installation has been completed. Personal
injury or death could occur, and the equipment could be damaged beyond repair, if this
precaution is not observed!
Warning: Fire Safety and Liability Notice
Never connect card readers to any critical entry, exit door, barrier, elevator, or gate without
providing an alternative exit in accordance with all fire and life safety codes pertinent to the
installation. These fire and safety codes vary from city to city and you must get approval from
local fire officials whenever using an electronic product to control a door or other barrier. Use of
egress buttons, for example, may be illegal in some cities. In most applications, single action
exit without prior knowledge of what to do is a life safety requirement. Always make certain that
any required approvals are obtained in writing. DO NOT ACCEPT VERBAL APPROVALS,
BECAUSE THEY ARE NOT VALID.
Honeywell never recommends using the PW-7000 or related products for use as a primary
warning or monitoring system. Primary warning or monitoring systems should always meet
local fire and safety code requirements. The installer must also test the system on a regular
basis by instructing the end user in appropriate daily testing procedures. Failure to test a
system regularly could make the installer liable for damages to the end user if a problem
occurs.

iv PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Note: See the Remote Enclosure Installation manuals for PW5K2ENC1/PW5K2ENC2 or
PW5K1ENC3 for installation instructions.
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Note: This document and the data in it shall not be duplicated, used, or disclosed to others
for procurement or manufacture, except as authorized by and with the written
permission of, Honeywell, Inc. The information contained in this document or in the
product itself is considered the exclusive property and trade secrets of Honeywell,
Inc. Copyright laws of the United States protect all information in this document or in
the software product itself.
Note: Any use of this product is subject to the terms and acceptance of the Honeywell, Inc.
Software Agreement. Please request a copy from Honeywell, Inc., and review the
agreement carefully.
Warning:
EARTH GROUND all enclosures for proper installation.
Warning:
Use suppressors on all door strikes. Use S-4 suppressors for installation. Honeywell
recommends only DC strikes.
Caution:
IF ANY DAMAGE TO THE SHIPMENT IS NOTICED, A CLAIM MUST BE FILED WITH THE
COMMERCIAL CARRIER RESPONSIBLE.
Caution:
Electrostatic discharge can damage CMOS integrated circuits and modules.
To prevent damage, always follow these procedures:
Use static shield packaging and containers to transport all electronic components,
including completed reader assemblies.
Handle all ESD sensitive components at an approved static controlled workstation. These
workstations consist of a desk mat, a floor mat, and an ESD wrist strap. Workstations are
available from various vendors.

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 v
Disclaimer
Product Liability; Mutual Indemnification
In the event that a Customer receives a claim that a Product or any component
thereof has caused personal injury or damage to property of others, Customer
shall immediately notify Honeywell in writing of all such claims. Honeywell shall
defend or settle such claims and shall indemnify and hold Customer harmless for
any costs or damages including reasonable attorneys' fees which Customer may
be required to pay as a result of the defective Product or the negligence of Honey-
well, its agents, or its employees.
Customer shall hold harmless and indemnify Honeywell from and against all
claims, demands, losses, and liability arising out of damage to property or injury to
persons occasioned by or in connection with the acts or omissions of Customer
and its agents and employees, and from and against all claims, demands, losses,
and liability for costs of fees, including reasonable attorneys' fees, in connection
therewith.
Limited Warranty
All Products sold or licensed by Honeywell include a warranty registration card
which must be completed and returned to Honeywell by or on behalf of the end
user in order for Honeywell to provide warranty service, repair, credit or exchange.
All warranty work shall be handled through Customer which shall notify Honeywell
and apply for a Return Merchandise Authorization (RMA) number prior to returning
any Product for service, repair, credit or exchange. NewWatch warrants that its
Products shall be free from defects in materials and workmanship for a period of
two years from date of shipment of the Product to Customer. The warranty on Ter-
minals, Printers, Communications Products and Upgrade kits is 90 days from date
of shipment.
Satisfaction of this warranty shall be limited to repair or replacement of Products
which are defective or defective under normal use. Honeywell’s warranty shall not
extend to any Product which, upon examination, is determined to be defective as a
result of misuse, improper storage, incorrect installation, operation or mainte-
nance, alteration, modification, accident or unusual deterioration of the Product
due to physical environments in excess of the limits set forth in Product manuals.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THIS PROVISION. THIS
WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS,
IMPLIED OR STATUTORY, INCLUDING IMPLIED WARRANTIES OF MERCHANT-
ABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. NO REPRESENTATION
OR WARRANTY OF THE DISTRIBUTOR SHALL EXTEND THE LIABILITY OR
RESPONSIBILITY OF THE MANUFACTURER BEYOND THE TERMS OF THIS PRO-
VISION. IN NO EVENT SHALL HONEYWELL BE LIABLE FOR ANY RE-PROCURE-
MENT COSTS, LOSS OF PROFITS, LOSS OF USE, INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES TO ANY PERSON RESULTING FROM THE USE OF NEW-
WATCH’S PRODUCTS.

vi PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Confidentiality
All software, drawings, diagrams, specifications, catalogs, literature, manuals and
other materials furnished by Honeywell relating to the design, use and service of
the Products shall remain confidential and shall constitute proprietary rights of
Honeywell and Customer agrees to treat such information as confidential. Cus-
tomer shall acquire no rights in the design of the Products or the related materials
except to use such information solely for the purpose of and only during the time it
sells the Products.
Customer shall not copy the design of any of the Products or use or cause to be
used any Product design or related materials for its own benefit or for the benefit of
any other party. The covenants contained in this section shall remain effective
throughout the term of this Agreement and thereafter unless specifically waived by
Honeywell in writing.
Compliance
To obtain applicable EU compliance Declaration of Conformities for this product,
please refer to our website, https://www.security.honeywell.com/All-Categories/
access-control-systems/control-panels-hardware. For any additional information
regarding the compliance of this product to any EU-specific requirements, please
contact:
Honeywell Security & Communications
Honeywell Security - Quality Assurance Dept., Newhouse Industrial Estate Mother-
well
Lanarkshire ML1 5SB Scotland
United Kingdom
Tel: [phone]
Email: [e-mail]
CE and WEEE Marking
Description of the used symbol.
CE -Standard -Logo. This product complies with
the harmonized Regulation of the EU
WEEE symbol.It indicates this product is to be
recycling and not been thrown in the dustbin

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 vii
Unpacking Procedure
All containers should be opened and unpacked carefully in order to prevent dam-
age to the contents.
The following steps are used to unpack equipment in preparation for installation:
Step 1. Open the container and remove the unit(s) and all packing material.
Retain the container and all packing materials. They may be used again
for reshipment of the equipment, if needed.
Step 2. Inspect the contents for shortage. If items are missing items, contact the
order entry department at 800-323-4576.
Step 3. Visually check contents. If damage is discovered, perform the following:
If shipping caused damage to the unit, a claim must be filed with the commercial
carrier.
If any other defect is apparent, call for a return authorization.
Shipping Instructions
To ship equipment back to Honeywell, Inc.:
Step 1. Contact the customer service department at 800-323-4576 before
returning equipment. When you call please have available:
• A description of the problem or reason you are returning the equipment.
• Your original purchase order number, invoice number and if the unit is still
under warranty.
• A new purchase order number if the unit is not under warranty
Caution:
If any damage to the shipment is noticed before unpacking, a claim must be filed with the
commercial carrier.

viii PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Step 2. From the customer service department, obtain the Return Authorization
Number (RMA).
Step 3. Show the RMA number on all packages shipped. Packages which are not
marked with an RMA number will be refused at the factory and returned
to you COD.
Step 4. Carefully pack the equipment for shipment. Use the original packing
material whenever possible.
This page is intentionally left blank

CHAPTER
1
PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 9
READER MODULE
Description
The PW-7000Two-Reader Module provides support for up to two access control
doors by providing connections for Wiegand or Clock/Data type readers, super-
vised inputs, and relay outputs. You can either mount the board in a rack or open
flat. If you rack-mount the board, only one edge is accessible for wiring; however, a
flat mount increases the amount of available I/O slightly but significantly
decreases the number of boards that can be mounted in one enclosure.
The I/O terminals are organized to support two doors. Starting at the bottom of the
rack-mount side of the board, the first connector provides power to the board. The
next connector provides communication with the Intelligent Controller (PW7K1IC
or PW6K1IC). The next set of terminals connects reader 1. The next set of terminals
connects the I/O typically associated with reader 1, namely the Door Status and
REX status inputs and the Door Lock and Lock Status relay outputs. Continuing up
this edge the next two connectors provide the reader and associated I/O terminals
for reader 0. The last connector on the rack-mount edge provides terminals for two
additional general-purpose inputs.
When the board is mounted flat, two additional relay outputs and two additional
general-purpose inputs are available along with two dedicated inputs for cabinet
tamper and power fault detection on the opposite edge of the board.
The reader interface accepts a Wiegand signal of Data 1 and Data 0 or a Clock and
Data signal and provides 5VDC or 12VDC reader power, a tri-stated LED control
and buzzer control. Two of the six form-C relay outputs are sized for the inductive
load of door locks and the other four are designed to handle dry-circuit signals. All
of the inputs are capable of four-state supervision except the two dedicated inputs.
Communication to the control panel is accomplished via an RS-485 interface. This
board requires 12VDC input power.
When communication to the control panel is lost, this board can grant access
based on facility code only. General purpose outputs will retain the setting at the
time communication was lost. Up to eight facility codes may be active in each
PW7K1R2 or PW6K1R2. Keypad input must follow the reader input format and is in
place of or multiplexed with the reader data.

10 PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Specifications
The Two-Reader Module is for use in low voltage, class 2 circuits only.
Primary power:
• 12VDC + 10%, 650mA maximum with 5V readers, 300 mA max. excluding
readers
Relay contacts:
• Relays 0 and 2 outputs, Form-C, 5A @ 30VDC, resistive
• Relays 1, 3, 4, and 5 outputs, Form-C, 2A @ 30VDC, resistive
Inputs:
• 8 supervised, End of Line resistors 1k ohm ± 1% tolerance
• 2 unsupervised dedicated inputs
Reader interface:
Communication:
Wire requirements:
Mechanical:
Environment:
Reader power 5VDC(5 - 6.2) 300mA max. each or 12VDC (pass-through),
300mA max. each
Reader LED output TTL compatible, high > 3V, low < 0.5V, 5mA source/sink max.
Reader buzzer output Open collector, 5VDC open circuit max. 10mA sink max.
Reader data inputs TTL compatible inputs
RS-485 9,600 to 38,400 bps
Power 1 twisted pair, 18AWG
RS-485 24AWG, 4,000 feet (1,200 m) max., 2-twisted pair with shield
(120 ohms, 23pf) (Belden 9842 or equiv.)
Inputs 1 twisted pair per input, 30 ohms max.
Outputs As required for the load
Readers 6 conductors, 18AWG, 500 feet (150m) max. shield and drain
Dimension 5.5" (140mm) W x 9" (229mm) L x 1" (25mm) H
Weight 12 oz. (340g) nominal
Temperature 0°C to +49°C, operating, -55°C to +85°C, storage
Humidity 0% to 85% RHNC

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 11
Setup
Setting Jumpers
Table 1: Jumper Settings
Setting DIP Switches
Table 2: DIP Switch Settings
Jumper Setting Default Selected
J1 OFF * Port 1 RS-485 EOL terminator is not active
ON Port 1 RS-485 EOL terminator is active
J2 OFF Reader 0 Power Terminal provides 5 VDC
ON * Reader 0 Power Terminal provides 12 VDC
J3 OFF Reader 1 Power Terminal provides 5 VDC
ON * Reader 1 Power Terminal provides 12 VDC
S8 S7 S6 S5 S4 S3 S2 S1 Selection
OFF OFF OFF OFF OFF ADDRESS 0
OFF OFF OFF OFF ON ADDRESS 1*
OFF OFF OFF ON OFF ADDRESS 2
OFF OFF OFF ON ON ADDRESS 3
OFF OFF ON OFF OFF ADDRESS 4
OFF OFF ON OFF ON ADDRESS 5
OFF OFF ON ON OFF ADDRESS 6
OFF OFF ON ON ON ADDRESS 7
OFF ON OFF OFF OFF ADDRESS 8
OFF ON OFF OFF ON ADDRESS 9
OFF ON OFF ON OFF ADDRESS 10
OFF ON OFF ON ON ADDRESS 11
OFF ON ON OFF OFF ADDRESS 12
OFF ON ON OFF ON ADDRESS 13
OFF ON ON ON OFF ADDRESS 14
OFF ON ON ON ON ADDRESS 15
ON OFF OFF OFF OFF ADDRESS 16
ON OFF OFF OFF ON ADDRESS 17
ON OFF OFF ON OFF ADDRESS 18
ON OFF OFF ON ON ADDRESS 19
ON OFF ON OFF OFF ADDRESS 20
ON OFF ON OFF ON ADDRESS 21
ON OFF ON ON OFF ADDRESS 22
ON OFF ON ON ON ADDRESS 23
ON ON OFF OFF OFF ADDRESS 24

12 PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
* = Default
LED Operation
The Two-Reader Module uses two onboard LEDs (D1 and D2) to provide status
information during the power-up sequence as well as during normal operation. The
Two-Reader Module also uses two onboard LEDs (D3 and D4) to indicate reader
activity.
Table 3: Onboard LEDs
In addition to the status LEDs, there are six additional relay status LEDs and eight
input status LEDs on board. The input LEDs flash when there is a fault associated
with the input. When any relay or input is energized or ON, its corresponding status
LED becomes ON also. The LED remains ON for as long as the relay is energized.
The assignment for each relay status LED is shown in the following table.
ON ON OFF OFF ON ADDRESS 25
ON ON OFF ON OFF ADDRESS 26
ON ON OFF ON ON ADDRESS 27
ON ON ON OFF OFF ADDRESS 28
ON ON ON OFF ON ADDRESS 29
ON ON ON ON OFF ADDRESS 30
ON ON ON ON ON ADDRESS 31
OFF OFF Reserved
OFF ON 9,600 BPS
ON OFF 19,200 BPS
ON ON 38,400 BPS*
OFF Not Used*
S8 S7 S6 S5 S4 S3 S2 S1 Selection
Mode LED
D1
LED
D2 Description
Power-up
sequence
ON OFF Start power-up, hardware setup.
OFF ON Testing RAM.
ON ON Testing ROM and completing initialization.
FLASH ON LED D1 flashes four times after power-up is completed.
Normal Opera-
tion
FLASH This is the processor heartbeat LED. It flashes once every second. A short ON
time (~20% duty cycle) indicates the board is offline or has lost serial
communication with the Controller board. A long ON time (~80% duty cycle)
indicates the board is online and communicating with the Controller board.
FLASH Flash when there is activity on its Serial Port.

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 13
Table 4: Additional PW7000 Two-Reader Module LEDs
Power
The Two-Reader Module accepts 12VDC with an operating range of 10 to 14VDC
and consumes 300 mA of current without readers. Locate power source as close to
this board as possible. Connect power with minimum of 18AWG wire.The input volt-
age is regulated to 5VDC.The regulated voltage or the 12VDC (pass through) is
available for powering the readers. The selection is made via jumpers and is avail-
able at both reader connectors.
Note: POLARITY for 12VDC power is important. Make sure the +12 VDC is connected to the
terminal labeled +12V and the return is connected to the terminal labeled GND.
Communications
The Two-Reader Module communicates to the host controller via an RS-485 inter-
face. The interface allows for multi-drop communication of up to 4,000 feet (1,200
m) total per port. Use two twisted pair (minimum 24AWG) with shield for communi-
cation. The default speed of this port is 38.4Kbps but it can be downgraded to
19.2Kbps or 9.6Kbps if the line conditions or receiving equipment require it (see
Table 1: Jumper Settings (page 11) for jumper settings and Table 2: DIP Switch
Settings (page 11) for DIP switch settings).
For wiring to an RS-485 port:
LED number Description
D3 Reader 0 activity
D4 Reader 1 activity
D5 Input 0
D6 Input 1
D7 Input 2
D8 Input 3
D9 Input 4
D10 Input 5
D11 Input 6
D12 Input 7
D13 Tamper
D14 Power
D15 Relay 0 status
D16 Relay 3 status
D17 Relay 2 status
D18 Relay 4 status
D19 Relay 1 status
D20 Relay 5 status

14 PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1
Step 1. TR+ is the plus side of the transmit and receive differential signal.
Step 2. TR- is the negative side of the transmit and receive differential signal.
Step 3. GND is the signal ground.The wiring for this signal is required and NOT
optional. This signal must NOT be connected to chassis GND.
Step 4. Use 24 AWG low capacitance, two twisted-pair, shielded cable (Belden
9842 or equivalent).
Note: For RS-485 Communication Connections, twist the blue pair together and use as the
common; use the orange pair as your data pair, observing polarity. Connect the
external drain shield to the appropriate earth ground on one end.
Step 5. When daisy-chaining RS-485 ports together, connect the TR+ wires from
the upstream and downstream boards to the TR+ terminal. Likewise,
connect the TR- wires from the upstream and downstream boards to the
TR- terminal.
By factory default J1 is set open. If this board is the last board on the RS-485 bus,
install jumper J1 across both pins (closed). Closing J1 provides the bus termina-
tion required.
Wiring
This section presents information on reader wiring, input wiring, and control out-
put wiring. The following figure shows the PW-7000 board and identifies its termi-
nal block pin assignments.

PW-7000 Two-Reader Module Installation Guide, Document 800-25676V1 15
Figure 1: PW-7000 Two-Reader Module Wiring: Connectors 1-7
Note: See LED Operation (see page 12) for descriptions of LEDs D1-D20.
DIP SWITCHES
ON
OFF
87654321
TWO READER BOARD Short
together*
Power
RS-485
EOL
EOL
Door Status
Switch
Typical Connection
Egress
Push-Button
Switch
RED
BLACK
BLACK
RED
WHITE
GREEN
S-4
Suppressor
S-4
Suppressor
Door Lock
Door Lock
Separate
Power
Supply
Separate
Power
Supply
-
VDC
+
-
VDC
+
KP-13
Weigand
Keypad
Proximity
Reader
Chassis GND
Inside Panel
Chassis GND
Inside Panel
Voltage is selected by
Jumper J2 On Board
Voltage is selected by
