Honeywell CIU 888 Instruction sheet

$*6
Configuration Manual
Release R210

Table of Contents
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 3
$*6
TABLE OF CONTENTS
Table of contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Purpose of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Target audience of this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
CHAPTER 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1 When to use CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.1.1 CIU 888 and Service Tool Compatibility Matrix . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Recommended workflows to commission CIU 888 . . . . . . . . . . . . . . . . . . . . 1-2
1.2.1 Commissioning a CIU 888 Standalone system . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2.2 Commissioning a CIU 888 Redundant system . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.2.3 Updating Non Redundant CIU 888 Configuration . . . . . . . . . . . . . . . . . . . . . 1-5
1.2.4 Updating Redundant CIU 888s Configuration . . . . . . . . . . . . . . . . . . . . . . . . 1-6
CHAPTER 2 Installing CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1 Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Installing CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2.1 Installing CIU 888 Service Tool on the new machine. . . . . . . . . . . . . . . . . . . 2-2
2.2.2 Upgrade the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2.2.3 Side by Side Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.3 Post-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2.3.1 Add User’s to “Local Engineers” Window Group . . . . . . . . . . . . . . . . . . . . . 2-13
2.3.2 Importing old site databases using CIU 888 Service Tool R210 . . . . . . . . . 2-13
2.4 CIU 888 Service Tool License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.5 Uninstalling CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
CHAPTER 3 Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.1 CIU 888 Web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.1 Changing the settings of Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.2 Changing the settings of Google Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
3.1.3 To Allow Pop-ups for file download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
3.1.4 Launching the CIU 888 Web interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
3.2 Configuring a site using CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . 3-23
3.2.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
3.2.2 Launching CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
3.2.3 Creating a new site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
3.2.4 Ensite pro database import option. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
3.2.5 CIU 888 Node Properties/Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-28
3.2.6 Configuring a Field port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
3.2.7 Configuring a Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-37

Table of Contents
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 4
$*6
3.2.8 Product configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-50
3.2.9 Product configuration Export and Import . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
3.2.10 Configuring a GPU Data Input or Modbus Data Input or TRL/2 Data Input. 3-64
3.2.11 Configuring a Host port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-84
3.2.12 Configuring User defined Modbus map . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-86
3.2.13 Configuring Ethernet Host port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-93
3.2.14 Configuring Modbus map for TCP/IP ports . . . . . . . . . . . . . . . . . . . . . . . . 3-103
3.3 Sending Configuration to CIU 888. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-108
3.4 Generating INI Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-109
3.5 Verifying Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-110
3.6 Importing an existing site configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-111
3.6.1 Recommended actions if importing from prior to R150.1 Databases . . . . 3-111
3.7 Opening an existing site configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-115
CHAPTER 4 Commissioning of a Standalone System Setup . . . . . . . . . . . . . . . . . . . . 4-1
4.1 Requirements for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Running the initial setup of the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2.1 Logging on to the CIU 888 and changing the initial password . . . . . . . . . . . 4-2
4.2.2 Verifying the CIU 888 license . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3 Setting up the site configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4.3.1 Configuration procedure in CIU 888 Service Tool . . . . . . . . . . . . . . . . . . . . . 4-5
4.4 Sending the site configuration to the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.5 Generating INI files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.6 Starting Entis Pro and loading the updated INI files in Entis Pro. . . . . . . . . . 4-7
4.7 Loading the CIU site database in ENTIS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.8 OPCUA Certificate Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.8.1 OPCUA Self-Signed Certificate Management . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.8.2 OPCUA CA-Signed Certificate Management . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.9 Self Signed Certificate Management with ENTIS . . . . . . . . . . . . . . . . . . . . 4-15
4.10 Verifying the working of the system setup . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
4.11 Sealing the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
CHAPTER 5 Commissioning of a Redundant System Setup . . . . . . . . . . . . . . . . . . . . 5-1
5.1 Requirements for commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2 Running the initial setup of the primary CIU 888 . . . . . . . . . . . . . . . . . . . . . . 5-3
5.3 Setting up the site configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.4 Sending the site configuration to the primary CIU 888 . . . . . . . . . . . . . . . . . 5-3
5.5 Commissioning of the secondary CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.6 Generating INI files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5.7 Loading the CIU site database in ENTIS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5.8 Starting Entis Pro and loading the INI files in Entis Pro. . . . . . . . . . . . . . . . . 5-6
5.9 OPCUA Certificate Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Table of Contents
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 5
$*6
5.10 Self Signed Certificate Management with ENTIS. . . . . . . . . . . . . . . . . . . . . . 5-6
5.11 Procedure for communication between ENTIS and CIU 888 . . . . . . . . . . . . 5-6
5.12 Verifying the working of the system setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5.13 Sealing the CIU 888s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
CHAPTER 6 Updating CIU 888 Site configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.1 Requirements for updating the non redundant CIU 888 site configuration . . 6-1
6.2 Requirements for updating the redundant CIU 888 site configuration. . . . . . 6-2
6.3 Implementing the required changes in the site configuration . . . . . . . . . . . . 6-2
6.4 Sending the site configuration to the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.5 Generating the INI files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.6 Starting Entis Pro and reloading INI files in Entis Pro . . . . . . . . . . . . . . . . . . 6-3
6.6.1 Using Entis as a host. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.7 Verifying the working of the CIU 888 system setup . . . . . . . . . . . . . . . . . . . . 6-3
6.8 Sealing the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6.9 Special Operating Procedure to perform configuration updates on redundant
CIU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.9.1 Updating configuration for Restart parameters . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.9.2 Updating configuration for Non-Restart parameters . . . . . . . . . . . . . . . . . . . 6-6
CHAPTER 7 General CIU 888 Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.1 (Re)starting and shutting down the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.1.1 Starting the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
7.1.2 Restarting the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
7.1.3 Shutting down the CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
7.2 W&M lock key switch and Configuration lock key switch . . . . . . . . . . . . . . . 7-4
7.2.1 W&M lock key switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
7.2.2 Configuration lock key switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
APPENDIX A Data Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.1 Engineering units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.2 Data presentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.2.1 Decimal and thousand separators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
A.2.2 Time stamped data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
A.2.3 Date and time presentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
A.3 List of entities not needing restart after a change . . . . . . . . . . . . . . . . . . . . .A-6
APPENDIX B Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
B.4 Scanning Philosophy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
B.5 Configured Foreground scan items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
B.6 Configured Background scan items. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-9
B.7 Command scan items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
B.8 Service Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
B.9 Priority Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-10
APPENDIX C Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-13

Table of Contents
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 6
$*6
C.10 Sync Link and database synchronization . . . . . . . . . . . . . . . . . . . . . . . . . .C-13
C.11 Supported redundant CIU 888 topologies of deployment . . . . . . . . . . . . . .C-14
C.11.1 RS-232 host port redundancy with redundant CIU 888s and host port
redundancy on demand of host system. . . . . . . . . . . . . . . . . . . . . . . . . . . .C-14
C.11.2 RS-232 host port redundancy with redundant CIU 888s and data
synchronization between host systems . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-15
C.11.3 Modbus TCP host port redundancy with redundant CIU 888s and data
synchronization between host systems . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-16
C.11.4 OPC UA TCP host port redundancy with redundant CIU 888s and data
synchronization between host systems . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-18
C.12 Redundant CIU 888-Experion PKS Integration . . . . . . . . . . . . . . . . . . . . . .C-20
C.12.1 Configuring CIU 888 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-20
C.12.2 Configuring Experion PKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-22
C.12.3 Configure Modbus Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C-26
C.12.4 Configure Points for CIU 888 parameters: . . . . . . . . . . . . . . . . . . . . . . . . .C-29
APPENDIX D Tank Capacity Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .D-31
APPENDIX E Density table format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E-34
APPENDIX F CTL table format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F-36
APPENDIX G Concentration table format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G-38
APPENDIX H Creation of new Modbus field device / TRL/2 Field Device configuration
file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-41
H.13 Device Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-41
H.14 Device engineering units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-41
H.15 Valid Register Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-42
H.16 Modbus Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-42
H.17 Custom Value Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-48
H.18 Supported Modbus Data types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-50
H.19 Supported Device Engineering Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .H-52
APPENDIX I List of Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I-55

Preface
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 i
$*6
PREFACE
General
Commissioning is the first step after the installation of the CIU 888.
During commissioning, the CIU 888 site configuration is created and
site elements such as CIU, field ports, tanks, GPU data inputs, Modbus
data inputs, TRL/2 data input, and host ports are configured.
When the site is in operation and there are changes, for example a
gauge is added or an additional host system is connected, these
changes need to be implemented, and the CIU 888 needs to be
updated with the new site configuration.
Purpose of this manual
The purpose of this manual is to provide information about the
commissioning and configuration of the CIU 888.For the migration of an
existing CIU 880 Prime/Plus site configuration to the CIU 888, See
chapter 3.2.4 "Ensite pro database import option".
Target audience of this manual
This manual is primarily intended for service technicians who are
responsible for commissioning and configuration of the CIU 888.

Preface
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 ii
$*6
This page is intentionally left blank

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 1
$*6
CHAPTER 1 INTRODUCTION
The CIU 888 Service Tool is used for commissioning and configuration
of the CIU 888. The CIU 888 Service Tool is typically installed on a PC/
laptop running Windows 10, which in turn is connected to the CIU 888
via the Service port located at the front of the CIU 888 or VPN port
located at the back of the CIU 888.
CIU 888 Service Tool replaces Ensite Pro as the configuration tool for
CIU 888. The CIU 888 Service Tool provides the Ensite Pro
configuration options with the following improvements:
Support for a maximum of 80 tanks.
Support for a maximum of 6 field ports.
Support for a maximum of 6 host ports.
Support for gauge engineering units.
Support for configuring a maximum of 4 host ports for GPU
emulation and Modbus Emulation
Support for Modbus field scan.
Support for TRL/2 field scan.
Support for servicing of Rex gauges.
Support for Modbus TCP/IP on host ethernet ports.
Support for OPC UA TCP on host ethernet ports.
Support for Wireless field device scan on field ethernet port.
NOTE: CIU 888 Service Tool can be released independent of CIU 888 firmware, hence
the CIU 888 Service Tool has its own release number independent of CIU 888
firmware release number.
1.1 When to use CIU 888 Service Tool
From CIU 888 R103 release, CIU 888 Service Tool is being introduced
to configure CIU 888.
Until R103 release, Ensite Pro, Ensite Pro to CIU 888 Migration Tool,
and Web interface are used during commissioning/configuration of the
CIU 888.
The Migration tool is used for uploading the site configuration to the CIU
888 and for updating the INI files generated from Entis Pro. INI files are
configuration files for Entis Pro. Migration tool needs to update the INI
files before the files can be loaded to the Entis Pro tank inventory
system.

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 2
$*6
The applicable configuration tools and scenarios to configure CIU 888
are mentioned in the following table.
NOTE: For Ensite pro database See chapter 3.2.4 "Ensite pro database import
option".
1.1.1 CIU 888 and Service Tool Compatibility Matrix
1.2 Recommended workflows to commission CIU 888
This section gives details on how to commission a CIU 888 (both
redundant and non-redundant), and how to update the site configuration
details of an existing CIU 888.
Use Ensite Pro + Migration tool + Web
interface Use CIU 888 Service Tool
Supported scenarios:
 CIU 880 being replaced by CIU 888,
except 4 plus host ports in redundant
non cross hot standby configuration.
 Earlier units of CIU 888 being
replaced with new units of CIU 888.
Supported scenarios:
 CIU 880 being replaced by CIU 888
with 4 plus host ports in redundant
non cross hot standby configuration
(new configuration).
 New sites being commissioned for
CIU 888.
CIU880 Migrations through Ensite
Pro database import
CIU 888 Version Service Tool Version
R103.1/R103.2 Service Tool R101.1
R120.1 Service Tool R120.1
R120.2 Service Tool R120.2
R130.1 Service Tool R130.1
R140 Service Tool R140
R150 Service Tool R150
R160 Service Tool R160
R161 Service Tool R161
R162 Service Tool R162
R210 Service Tool R210

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 3
$*6
1.2.1 Commissioning a CIU 888 Standalone system
FIGURE 1-1 Commissioning a Standalone System Setup
Notes: 1. Step 3 can be done offline without connection to CIU 888 and is
independent of step 1 and 2.
2. Steps 5 and 6 are required only when Entis Pro is a host connecting to
CIU 888.
c
h
a
p
t
c
h
a
p
t
e
c
h
a
p
t
e
c
h
a
p
t
c
h
a
p
t
c
h
a
p
t
e
c
h
a
p
t
chapter 4.2.1
"
L
o
g
g
Commissioning of a CIU 888 Redundant System Setup
Verify the license
of primary CIU 888
1
2
ŽŶĮŐƵƌĞ the site
ƵƐŝŶŐ/hϴϴϴ
Service Tool
Send
the site
ĐŽŶĮŐƵƌĂƟŽŶ
to primary CIU 888
35
46
>ŽŐŽŶƚŽƚŚĞ
primary CIU 888
ĂŶĚĐŚĂŶŐĞ
the password
Generate the
INI FIles, start the
ŶƟƐWƌŽĂŶĚůŽĂĚ
ƚŚĞ/E/ĮůĞƐ
Seal the CIU 888,
ĐŽŵŵŝƐƐŝŽŶŝŶŐ
completed
ƐƵĐĐĞƐƐĨƵůůLJ
CIU 888
Service Tool
CIU 888 Service Tool
to be installed on the
WC/Laptop
WC/Laptop to be connected to
primary CIU 888 ƵsinŐethernet
cable via service port located at the
front of CIU 888
Note: W&M lock key switch and
the ConĮŐƵraƟon lock key switch of
primary CIU 888 & secondary CIU 888
mƵst be in ‘Ƶnlocked’ posiƟon
Commission
the secondary
CIU 888
Verify the CIU 888
ƐLJƐƚĞŵƐĞƚƵƉŝƐ
ǁŽƌŬŝŶŐƉƌŽƉĞƌůLJ
8
7
ŶĚLJŽƵĂƌĞĚŽŶĞ

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 4
$*6
1.2.2 Commissioning a CIU 888 Redundant system
FIGURE 1-2 Commissioning of a Redundant System Setup
Notes: 1. Step 3 can be done offline without connection to CIU 888 and is
independent of step 1 and 2.
2. Step 6 is required only when Entis Pro is a host connecting to CIU 888.
c
h
a
p
t
e
c
h
a
p
t
e
c
h
a
p
t
e
c
h
a
p
t
c
h
a
p
t
e
c
h
a
p
t
e
c
h
a
p
t
c
h
a
p
t
e
Commissioning of a CIU 888 Redundant System Setup
Verify the license
of primary CIU 888
1
2
ŽŶĮŐƵƌĞ the site
ƵƐŝŶŐ/hϴϴϴ
Service Tool
Send
the site
ĐŽŶĮŐƵƌĂƟŽŶ
to primary CIU 888
35
46
>ŽŐŽŶƚŽƚŚĞ
primary CIU 888
ĂŶĚĐŚĂŶŐĞ
the password
Generate the
INI FIles, start the
ŶƟƐWƌŽĂŶĚůŽĂĚ
ƚŚĞ/E/ĮůĞƐ
Seal the CIU 888,
ĐŽŵŵŝƐƐŝŽŶŝŶŐ
completed
ƐƵĐĐĞƐƐĨƵůůLJ
CIU 888
Service Tool
CIU 888 Service Tool
to be installed on the
WC/Laptop
WC/Laptop to be connected to
primary CIU 888 ƵsinŐethernet
cable via service port located at the
front of CIU 888
Note: W&M lock key switch and
the ConĮŐƵraƟon lock key switch of
primary CIU 888 & secondary CIU 888
mƵst be in ‘Ƶnlocked’ posiƟon
Commission
the secondary
CIU 888
Verify the CIU 888
ƐLJƐƚĞŵƐĞƚƵƉŝƐ
ǁŽƌŬŝŶŐƉƌŽƉĞƌůLJ
8
7
ŶĚLJŽƵĂƌĞĚŽŶĞ

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 5
$*6
1.2.3 Updating Non Redundant CIU 888 Configuration
FIGURE 1-3 Updating Non redundant CIU 888 Configuration
NOTE: Steps 3 and 4 are required only when Entis Pro is a host connecting to
CIU 888.

Introduction
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 1 - 6
$*6
1.2.4 Updating Redundant CIU 888s Configuration
FIGURE 1-4 Updating Redundant CIU 888s Configuration
Notes: 1. Steps 3 and 4 are required only when Entis Pro is a host connecting to
CIU 888.
2. Primary CIU 888 & Secondary CIU 888 must be in sync.
3. Entis pro should be shut down before sending the site configuration to
CIU 888.
4. Updates can be sent only to primary CIU 888 and not to secondary CIU
888.

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 1
$*6
CHAPTER 2 INSTALLING CIU 888 SERVICE TOOL
2.1 Prerequisites
The PC/laptop must meet the following requirements to install the CIU
888 Service Tool:
Windows 10 Enterprise 64 bit or Windows 10 LTSB 64 bit
Microsoft .NET Framework 4.0 or higher
NOTE: Microsoft .NET Framework 4.0 is installed automatically during the installation
of Windows 7 or Windows 10.
Minimum 4 GB RAM
Microsoft Internet Explorer 10.x or 11.x or Google Chrome (version
66 or above).

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 2
$*6
2.2 Installing CIU 888 Service Tool
2.2.1 Installing CIU 888 Service Tool on the new machine
1. Right-click on Setup file and then click Run as administrator.
The welcome to installShield Wizard appears:.
2. Click Next.
The License Agreement window appears:
3. Read all license agreement and select “I accept the terms in the
license agreement” .
4. Click Next.

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 3
$*6
The Ready to Install the Program window appears:
5. Click Install.
6. The Installing Honeywell CIU 888 Service Tool R210 installation
progress status window appears:

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 4
$*6
7. The InstallShield Wizard Completed window appears after
successfull installation:
NOTE: The "Local Engineers" group will be created by default and the current user will
be added to the "Local Engineers" group.
8. Click Finish to close the wizard.
9. The message box appears to logoff and login the machine.
NOTE: If the local engineers group is already existing in the machine and if the current
user is already associated with the local engineers group, the message box
may not appear to logoff and login the machine.
10.Click Yes for installation changes to be effective.

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 5
$*6
2.2.2 Upgrade the Installer
1. Right-click on Setup file and then click Run as administrator.
The welcome to installShield Wizard appears:.
2. Click Next.
The License Agreement window appears:
3. Read all license agreement and select “I accept the terms in the
license agreement”.
4. Click Next.

Installing CIU 888 Service Tool
Part No.: 4417584_Rev12 Configuration Manual
CIU 888 2 - 6
$*6
The Select Installation Option window appaers:
5. Select Upgrade the existing CIU 888 Service Tool to uninstall the
previous version and install the new version.
The dialogue box appears to give message on the selected option.
6. Click Yes.
NOTE: This option removes the previous installation and then installs the new service
tool.
