Honeywell SmartLine ST700 User manual

Honeywell Process Solutions
FOUNDATION Fieldbus
ST 700 Pressure Transmitter
User's Guide
34-ST-25-48
Revision 2.0
July 2014

Page ii FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Copyrights, Notices and Trademarks
© Copyright 2014 by Honeywell, Inc.
Revision 2, July 2014
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as
may be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information
and specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International
Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1860 W. Rose Garden Lane
Phoenix, AZ 85027 USA

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page iii
About This Document
This guide provides the details of programming Honeywell ST 700 SmartLine Pressure
Transmitters for applications involving FOUNDATION Fieldbus protocol. For installation, wiring,
and maintenance information, refer to the ST 700 SmartLine Pressure Transmitter User Manual.
The configuration of your transmitter depends on the mode of operation and the options selected for
it with respect to operating controls, displays and mechanical installation.
An ST 700 FF pressure transmitter can be digitally integrated with one of two systems:
•Experion PKS, you need to supplement the information in this document with the data and
procedures in the Experion PDF Collection.
Release Information
Document Name/ID
ST 700 Pressure Transmitter User's Guide - 34-ST-25-48
Release
Number Publication Date
First Release 1.0 February 2013
2.0 July 2014
References
The following list identifies all documents that may be sources of reference for material discussed
in this publication.
ST 700 SmartLine Pressure Transmitter User Manual, # 34-ST-25-44
SmartLine Pressure Transmitter Quick Start Installation Guide, # 34-ST-25-36
ST 800 & ST 700 SmartLine Pressure Transmitter w/ HART Comms Safety Manual, # 34-ST-25-37
ST 700 Series HART/DE Option User Manual, Document # 34-ST-25-47

Page iv FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Patent Notice
The Honeywell ST 700 SmartLine Pressure Transmitter family is covered by one or more of the
following U. S. Patents: 5,485,753; 5,811,690; 6,041,659; 6,055,633; 7,786,878; 8,073,098; and
other patents pending.
Support and Contact Information
For Europe, Asia Pacific, North and South America contact details, see back page or refer to the
appropriate Honeywell Solution Support web site:
Honeywell Corporate www.honeywellprocess.com
Honeywell Process Solutions www.honeywellprocess.com/pressue-transmitters/
Training Classes http://www.automationccollege.com
Telephone and Email Contacts
Area Organization Phone Number
United States
and Canada Honeywell Inc. 1-800-343-0228 Customer Service
1-800-423-9883Global Technical Support
Global Email
Support Honeywell Process Solutions [e-mail]

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page v
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special
consideration.
TIP: Identifies advice or hints for the user, often in terms of
performing a task.
REFERENCE -EXTERNAL: Identifies an additional source of
information outside of the bookset.
REFERENCE - INTERNAL: Identifies an additional source of
information within the bookset.
CAUTION
Indicates a situation which, if not avoided, may result in equipment
or work (data) on the system being damaged or lost, or may result in
the inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used
to alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING: Indicates a potentially hazardous situation, which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or
60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which
equipment may be sensitive. Observe precautions for handling
electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the
protective earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as
noise immunity improvement. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance
with national local electrical code requirements.

Page vi FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Symbol Definition
Earth Ground:Functional earth connection. NOTE: This
connection shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.
Chassis Ground: Identifies a connection to the chassis or frame of
the equipment shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page vii
Terms and Acronyms
Term Definition
Alarm The detection of a block leaving a particular state and when it returns back to
that state.
Analog Input (function
block) One of the standard function blocks define by the Foundation Fieldbus
AP Absolute Pressure
Application A software program that interacts with blocks, events and objects. One
application may interface with other applications or contain more than one
application.
AWG American Wire Gauge
Block A logical software unit that makes up one named copy of a block and the
associated parameters its block type specifies. It can be a resource block,
transducer block or a function block.
Configuration (of a
system or device) A step in system design: selecting functional units, assigning their locations and identifiers, and defining their interconnections.
Device A physical entity capable of performing one or more specific functions.
Examples include transmitters, actuators, controllers, operator interfaces.
Device Description Description of FBAPs within a device. Files that describe the software objects
in a device, such as function blocks and parameters. The DD binary are
created by passing DD source files through a standard tool called a tokenizer.
Device Description
Language A standardized programming language (similar to C) used to write device description source files.
Device Tag The Physical Device Tag of the device as specified in the Foundation Fieldbus
specifications.
DP Differential Pressure
EEPROM Electrically Erasable Programmable Read Only Memory
EMI Electromagnetic Interference
Event An instantaneous occurrence that is significant to scheduling block execution
and to the operational (event) view of the application.
Field Device A fieldbus-compatible device that contains and executes function blocks.
Foundation Fieldbus Communications protocol for a digital, serial, two-way system which
interconnects industrial field equipment such as sensors, actuators and
controllers.
FTA Field Termination Assembly
Function Block An executable software object that performs a specific task, such as
measurement or control, with inputs and outputs that connect to other function
blocks in a standard way.
Function Block
Application Process The part of the device software that executes the blocks (function, transducer, or resource blocks).
GP Gauge Pressure
HP High Pressure (also, High Pressure side of a Differential Pressure Transmitter)

Page viii FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Term Definition
Hz Hertz
inH2O Inches of Water
LGP In-Line Gauge Pressure
Link Active Scheduler A device which is responsible for keeping a link operational. The LAS executes
the link schedule, circulates tokens, distributes time messages and probes for
new devices.
LP Low Pressure (also, Low Pressure side of a Differential Pressure Transmitter)
LRL Lower Range Limit
LRV Lower Range Value
Macrocycle The least common multiple of all the loop times on a given link.
mAdc Milliamperes Direct Current
Manufacturer's Signal
Processing A term used to describe signal processing in a device that is not defined by FF specifications.
mmHg Millimeters of Mercury
mV Millivolts
Network Management A part of the software and configuration data in a Foundation Fieldbus device
that handles the management of the network.
Network Management
Agent Part of the device software that operates on network management objects.
Network Management
Information Base A collection of objects and parameters comprising configuration, performance and fault-related information for the communication system of a device.
Nm Newton. Meters
NPT National Pipe Thread
NVM Non-Volatile Memory
Object Dictionary Definitions and descriptions of network visible objects of a device. There are
various object dictionaries within a device. The dictionaries contain objects and
their associated parameters which support the application in which they are
contained.
Objects Entities within the FBAP, such as blocks, alert objects, trend objects,
parameters, display lists, etc.
P Pressure
Pa Measured static pressure in PV4 algorithm
Parameters A value or variable which resides in block objects
Pc Absolute critical pressure of the gas
Pd Static pressure at downstream point
Pdp Measured differential pressure in Pascals in PV4 algorithm
Pf Absolute pressure of flowing gas
PM Process Manger

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page ix
Term Definition
Pr Reduced pressure
Proportional Integral
Derivative control A standard control algorithm. Also refers to a PID function block.
PSI Pounds per Square Inch
PSIA Pounds per Square Inch Absolute
Pu Static pressure at upstream point
PV Process Variable
PWA Printed Wiring Assembly
RFI Radio Frequency Interference
RTD Resistance Temperature Detector
Stack The software component that implement the Foundation Fieldbus
communications protocol specifications, including FMS, FAS, DLL, SM and
NM.
Status A coded value that qualifies dynamic variables (parameters) in function blocks.
This value is usually passed along with the value from block to block. Status is
fully defined in the FF FBAP specifications.
STIM Pressure Transmitter Interface Module
STIMV IOP Pressure Transmitter Interface Multivariable Input / Output Processor
System Management Provides services that coordinate the operation of various devices in a
distributed fieldbus system.
System Management
Agent Part of the device software that operates on system management objects.
System Management
Information Base A collection of objects and parameters comprising configuration and operational information used for control of system management operations.
TAC Technical Assistance Center
Trim Point A selected reference point at which a measurement is calibrated.
URL Upper Range Limit
URV Upper Range Value
US Universal Station
Vac Volts Alternating Current
Vdc Volts Direct Current
Virtual
Communication
Reference
A defined communication endpoint. Fieldbus communications can primarily
only take place along an active communications "path" that consists of two
VCR endpoints.
Virtual Field Device A logical grouping of "user layer" functions. Function blocks are grouped into a
VFD, and system and network management are grouped into a VFD.
For example, to establish communications between a transducer block and a
function block, a VCR must be defined at the transducer block and a VCR
must be defined at the function block.

Page x FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Contents
COPYRIGHTS, NOTICES AND TRADEMARKS....................................II
1. INTRODUCTION............................................................................1
1.1 About the ST 700 FF Pressure Transmitter...................................................1
1.2 ST 700 major assembly and electronic housing components....................2
1.3 Features of the transmitter.............................................................................3
2. GETTING STARTED......................................................................5
2.1 Verifying the installation.................................................................................5
Verifying transmitter installation tasks................................................................................... 5
2.2 Verifying communication with the transmitter.............................................6
Identify the transmitter........................................................................................................... 6
2.3 Establishing communication with host systems .........................................7
Device Description (DD)........................................................................................................ 7
Enhanced Device Description (EDD) .................................................................................... 7
Device Type Manager (DTM)................................................................................................ 7
3. ST 700 FF PRESSURE TRANSMITTER CONFIGURATION........8
3.1 Importing the ST 700 FF Device Description (DD) files ...............................8
Importing the DD to Experion PKS........................................................................................ 8
3.2 Configuring the function block application process .................................12
About the Function Block Application Process (FBAP) ....................................................... 12
Block Alarms....................................................................................................................... 12
Process Alarms................................................................................................................... 14
3.3 Resource block..............................................................................................15
Configuring the Resource block .......................................................................................... 15
RESTART ........................................................................................................................... 15
Execution ............................................................................................................................ 16
CYCLE TYPE...................................................................................................................... 16
MEMORY............................................................................................................................ 16
MAX NOTIFY ...................................................................................................................... 16
FEATURES......................................................................................................................... 16
Reports................................................................................................................................ 16
SOFT W LOCK and HARD W LOCK .................................................................................. 17
Field Diagnostics................................................................................................................. 18
Parameter List..................................................................................................................... 21
3.4 Pressure Transducer block ..........................................................................25
Execution ............................................................................................................................ 25
Level Calculation................................................................................................................. 27
Calibration........................................................................................................................... 28
Sensors............................................................................................................................... 29
Parameter List..................................................................................................................... 30

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page xi
3.5 Diagnostic Transducer block .......................................................................33
Execution ............................................................................................................................ 33
Sensor................................................................................................................................. 33
Sensor General Diagnostics................................................................................................ 34
Device Diagnostics.............................................................................................................. 34
Time in Service.................................................................................................................... 35
Power Cycle Track.............................................................................................................. 35
Parameter List..................................................................................................................... 36
3.6 LCD Transducer block ..................................................................................38
Execution ............................................................................................................................ 38
Parameters List ................................................................................................................... 41
3.7 Flow Transducer block..................................................................................43
Execution ............................................................................................................................ 43
Configuration....................................................................................................................... 44
Parameter List..................................................................................................................... 44
Attributes............................................................................................................................. 45
3.8 Analog Input block ........................................................................................46
Execution ............................................................................................................................ 46
Parameters List ................................................................................................................... 49
Attributes............................................................................................................................. 52
3.9 Proportional Integral Derivative (PID) block with auto tune......................53
Execution ............................................................................................................................ 54
Auto tuning.......................................................................................................................... 57
Auto tuning procedure......................................................................................................... 57
Parameter list...................................................................................................................... 58
Attributes............................................................................................................................. 62
3.10 Input Selector block...................................................................................63
Execution ............................................................................................................................ 63
Parameters List ................................................................................................................... 65
Attributes............................................................................................................................. 67
3.11 Integrator block..........................................................................................68
Execution ............................................................................................................................ 68
Parameters List ................................................................................................................... 74
Attributes............................................................................................................................. 76
3.12 Arithmetic block.........................................................................................77
Execution ............................................................................................................................ 77
Attributes............................................................................................................................. 82
3.13 Signal Characterizer block........................................................................83
Execution ............................................................................................................................ 83
Parameter list...................................................................................................................... 85
Attributes............................................................................................................................. 86
3.14 Configuring the transmitter using Field Device Manager (FDM) system86
4. ST 700 FF PRESSURE TRANSMITTER OPERATION............... 87
4.1 Operational considerations..........................................................................87
LAS Capability..................................................................................................................... 87
Special Non-volatile parameters and NVM Wear-out.......................................................... 87
Mode Restricted Writes to Parameters................................................................................ 87
4.2 Configuration of the transmitter using Handheld (HH)..............................88
4.3 Performing block instantiation.....................................................................89
About block instantiation ..................................................................................................... 89
Block instantiation using Experion PKS............................................................................... 89

Page xii FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
5. ST 700 FF PRESSURE TRANSMITTER MAINTENANCE..........91
5.1 Replacing the Local Display and Electronic Assembly.............................91
5.2 Downloading the firmware............................................................................91
About firmware download feature........................................................................................ 91
Class 3 ................................................................................................................................ 91
Recommendations .............................................................................................................. 92
Downloading the File........................................................................................................... 92
6. ST 700 FF PRESSURE TRANSMITTER TROUBLESHOOTING 94
6.1 Troubleshooting overview............................................................................94
Device status and faults ...................................................................................................... 94
6.2 Troubleshooting the transmitter..................................................................95
Device not visible on the network........................................................................................ 95
Incorrect or non-compatible tools........................................................................................ 96
6.3 Troubleshooting blocks................................................................................97
Non-functioning blocks........................................................................................................ 97
Troubleshooting block configuration errors ......................................................................... 97
Troubleshooting the Resource block................................................................................... 97
Troubleshooting the Pressure Transducer block................................................................. 98
Troubleshooting the Diagnostics Transducer block............................................................. 99
Troubleshooting the Flow Transducer block...................................................................... 100
Troubleshooting the LCD Transducer block...................................................................... 101
Troubleshooting the Analog Input (AI) block ..................................................................... 102
Troubleshooting the Proportional Integral Derivative (PID) block...................................... 103
Troubleshooting the Input Selector block .......................................................................... 104
Troubleshooting the Integrator block................................................................................. 105
Troubleshooting the Arithmetic block ................................................................................ 106
Troubleshooting the Signal Characterizer block................................................................ 107
Resolving the block configuration errors ........................................................................... 108
6.4 Device Diagnostics......................................................................................110
ST 700 FF pressure transmitter memory........................................................................... 110
Performing diagnostics in the background ........................................................................ 110
BLOCK_ERR parameter ................................................................................................... 110
Background Diagnostics Execution, BLOCK_TEST parameter ........................................ 111
Transmitter Diagnostics..................................................................................................... 111
Function Block Faults........................................................................................................ 112
6.5 Understanding simulation mode................................................................116
About simulation mode jumper.......................................................................................... 116
Setting simulation jumper.................................................................................................. 116
Enabling simulation mode ................................................................................................. 117
Simulation mode truth table............................................................................................... 117
Setting Al block mode........................................................................................................ 117
6.6 Understanding write protection .................................................................118
SALES AND SERVICE......................................................................119

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page xiii
Tables
Table 1: Transmitter installation verification tasks.............................................5
Table 2: Transmitter parameters.......................................................................6
Table 3: Bit mapping of the BLOCK_ERR.......................................................12
Table 4: Priority for Alarms..............................................................................14
Table 5: Diagnostic Definitions........................................................................18
Table 6: Resource block parameters...............................................................21
Table 7: Pressure Transducer block parameters.............................................30
Table 8: Diagnostic Transducer block parameters ..........................................36
Table 9 LCD parameters.................................................................................39
Table 10: LCD Transducer block parameters..................................................41
Table 11: Flow Transducer block parameters .................................................44
Table 12: Analog Input block parameters........................................................49
Table 13: PID Tuning parameters ...................................................................56
Table 14: PID block parameters......................................................................58
Table 15: Input Selector block parameters......................................................65
Table 16: Integrator block parameters.............................................................74
Table 17: Arithmetic block parameters............................................................80
Table 18: Signal Characterizer block parameters............................................85
Table 19: Resource block ...............................................................................97
Table 20: Pressure Transducer block..............................................................98
Table 21: Diagnostics Transducer block .........................................................99
Table 22: Flow Transducer block ..................................................................100
Table 23: LCD Transducer block...................................................................101
Table 24: Analog Input block.........................................................................102
Table 25: PID block.......................................................................................103
Table 26: Input Selector block.......................................................................104
Table 27: Integrator block .............................................................................105
Table 28: Arithmetic block.............................................................................106
Table 29: Signal Characterizer block.............................................................107
Table 30: Resolving block configuration errors..............................................108
Table 31: Diagnostics....................................................................................110
Table 32: Identifying Critical and Non-critical Function block faults ...............112
Table 33: Summary of Function blocks Non-critical Faults............................114
Table 34: Summary of Function blocks Critical Faults...................................115
Table 35: Setting the Simulation Jumper.......................................................117
Table 36: Simulation Mode Truth Table ........................................................117
Table 37: Write lock ......................................................................................118

Page xiv FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
Figures
Figure 1: ST 700 Major assemblies..................................................................2
Figure 2: Electronic Housing components ........................................................2
Figure 3: Pressure Transducer Block .............................................................25
Figure 4: LCD Transducer Block ....................................................................38
Figure 5: Flow Transducer Block....................................................................43
Figure 6: Analog Input Block ..........................................................................46
Figure 7: Analog Input Block Schematic Diagram...........................................47
Figure 8: PID block.........................................................................................53
Figure 9: PID block schematic diagram..........................................................53
Figure 10: Input Selector block.......................................................................63
Figure 11: Input Selector schematic diagram.................................................. 64
Figure 12: Integrator Block.............................................................................68
Figure 13: Two Rate Inputs............................................................................69
Figure 14: Arithmetic block.............................................................................77
Figure 15: Arithmetic schematic diagram........................................................78
Figure 16: Signal Characterizer Block ............................................................83
Figure 17: Signal characterizer curve.............................................................84
Figure 18: Connecting the transmitter to the handheld ................................... 88
Figure 19: Simulation Jumper Location on Transducer Board...................... 116

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page 1
1. Introduction
1.1 About the ST 700 FF Pressure Transmitter
The newly designed Honeywell ST 700 is a smart pressure transmitter that has a wide
range of additional features along with supporting the FOUNDATIONTM Fieldbus (FF)
communication protocol. The ST 700 pressure transmitter with FF protocol provides a
FOUNDATIONTM Fieldbus interface to operate in a compatible distributed Fieldbus
system. The transmitter includes FOUNDATIONTM Fieldbus electronics for operating in a
31.25 Kbit/s Fieldbus network and can interoperate with any FOUNDATIONTM Fieldbus
registered device.
The STD700 is a high performance pressure transmitter featuring Piezo-resistive sensor
technology. By combining differential pressure sensing with on-chip static and temperature
compensation, the STD700 offers high accuracy and stability over a wide range of
application pressures and temperatures. The STG700 and STA700 are high performance
pressure transmitters featuring Piezo-resistive sensor technology combining pressure
sensing with on-chip temperature compensation capabilities providing high accuracy,
stability and performance over a wide range of application pressures and temperatures.
The SmartLine family is also fully tested and compliant with Experion ® PKS providing
the highest level of compatibility assurance and integration capabilities. The ST 700 easily
meets the most demanding application needs for pressure measurement applications. This
transmitter is used in the process automation industry for sensing and transmitting pressure
over intelligent communication networks.
The transmitter comes in a variety of models for measurement applications involving one
of these basic types of pressure:
•Differential Pressure (DP)
•Gauge Pressure (GP)
•Absolute Pressure (AP)

Page 2 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
1.2 ST 700 major assembly and electronic housing components
The following illustrations depict the major assembly and electronic housing components.
Figure 1: ST 700 Major assemblies
Figure 2: Electronic Housing components

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page 3
1.3 Features of the transmitter
The transmitter is a configurable intelligent field device that acts as a pressure sensor, and
is capable of performing control algorithms on process variables. The core functionalities
of the field device include:
•Process Variable (PV) measurement
•Function Block Application Process (FBAP)
•Device diagnostics
The ST 700 features standard fieldbus function blocks with manufacturer-specific additions
for enhanced operation. The transmitter can function as a Link Active Scheduler (LAS) in a
Fieldbus network.
It supports the following features:
•Link-master capability
•Supports the following standard function blocks apart from the Resource and
Transducer blocks.
−Analog Input block
−Input Selector block
−Integrator block
−Signal Characterizer block
−PID with auto tune block
−Arithmetic block
•Function block instantiation is supported by the following blocks
−Analog Input block
−Input Selector block
−Signal Characterizer block
•Supports the following Transducer blocks
−Pressure Transducer block
−LCD Transducer block
−Diagnostic Transducer block
−Flow Transducer block
•Supports class 3 type firmware download through commercial hosts.
DD and EDDL Features
The ST 700 supports DD and EDD file formats, and the data is displayed using the EDDL
features in the form of menus, graphs, charts, and pictures.

Page 4 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0

Revision 2.0 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Page 5
2. Getting started
2.1 Verifying the installation
Verifying transmitter installation tasks
After the transmitter is installed and powered up, you can verify communication between
the transmitter and the field devices on the network. Table 1 outlines the steps for
identifying and checking the transmitter on a Fieldbus network.
Table 1: Transmitter installation verification tasks
Task Description Comment
Verify device location Check that the device is installed in the
correct physical location.
Verify device ID Match the device ID with the physical
location.
The device serial number is the PROM ID
which is stamped on the transmitter
housing nameplate.
Verify connection with
host computer to
device
On the operator interface, check and
make sure communications are
established with the device on the
Fieldbus network.
Verify or assign Device
Tag and address Check that the Device Tag and node address are set. If not, assign the Device
Tag and the correct node address.
The Device Tag and address can be set
and viewed using the Fieldbus device
configurator application. Use a Device Tag
name (up to 16 characters) that does not
contain spaces.
Configure device Using a Fieldbus configuration program,
create a function block application as part
of the device configuration and process
control strategy.
Verify device operation Bring the network online, verify operation,
tune loops, and so on.

Page 6 FOUNDATION Fieldbus ST 700 Pressure Transmitter User's Guide Revision 2.0
2.2 Verifying communication with the transmitter
On the operator interface, establish communication with the device on the Fieldbus network.
If the device is not visible on the network, verify that the device has been installed properly.
Identify the transmitter
Verify the Device ID of the transmitter by checking the device parameters. The parameters
contain the following information:
•Transmitter type (pressure transmitter, temperature transmitter, and flow transmitter)
•Device Tag (tag description of the transmitter)
•Sensor serial number
•Firmware revision level (revision level of the firmware elements)
Check the transmitter parameters listed in Table 2 and note down the values to identify the
transmitter.
ATTENTION
It is recommended to verify the correct version of the Device Description file is
present on the host computer. (Refer to the document on the diskette shipped
with the transmitter.) This helps in getting the correct parameter names and its
corresponding descriptions, while viewing the device parameters.
Table 2: Transmitter parameters
Parameter To verify
Resource block
DEV_TYPE
That the transmitter is of the proper
device type.
For all the ST 700 type pressure
transmitters, the value is 0003.
Device Tag
(Physical device tag name of the transmitter)
The Device Tag is correct.
Device Tag name __________________
ATTENTION
The Device Tag name can be set and viewed
using the Fieldbus device configurator application.
Use a device tag name (up to sixteent characters)
that does not contain spaces.
Transducer Block
SENSOR_SN
Sensor serial # ________________
The SENSOR_SN value, when viewed
as a hexadecimal number, is the same
number as the first sixteen digits of the
PROM ID stamped on the transmitter
housing nameplate.
ATTENTION
Note that the eight digit serial number in the SENSOR_SN parameter does
not display the last two digits of the PROM ID stamped on the nameplate of
the transmitter housing. The Device ID contains the full 10-digit PROM ID.
