Hewlett-Packard Storage Processor (SP)
Installation Guide
Hewlett-Packard SPs are customer installable and replaceable. Areplacement SP must be the same type as the SP being
replaced.
The locations ofthe SPs in the 30-slot disk arrays are shown in Figure 1.
.
Figure 1.
Installan SP by performing the following steps. Place a check in the appropriate oas the step is completed.
Step 1: Observe antistatic precautions
An SP is shipped with an ESD kit containing:
–ESDwriststrap
– ESDconductive sheet
oGround the ESDwrist strap to the metaledge above the
rear retaining screws and fasten the strap to your wrist.
Step 2: Prepare to install the SP
oRemove the replacement SP from its shipping carton
and place it on a suitable antistatic work surface or the
ESD conductive sheet.
Arraypower can be left on during SP removal and
replacement.
oRemove the failed SP.
oRemove the memory modules from the failed SP.
oInsert memorymodules in the SIMMconnectors on the
SP to be installed.
See the 2EMOVALAND2EPLACEMENT chapter in the
(EWLETT0ACKARD(IGH!VAILABILITY&IBRE#HANNEL
$ISK!RRAY5SER'UIDE for more information about
SIMMremoval and replacement.
SP-A SP-B
Rear view, top of the disk array

Step 3: Install the SP
oInstall the SP as shown in Figure 2. oIf the array is operating, the SP activates automatically
when it is installed in the array.
Figure 2.
Ejector
Ejector
A. Engage the edge of the SP in the board guides, and
slide it into the chassis until the ejectors engage with
the chassis edge.
B. Press both ejectors until they lock and the SP seats completely
into the chassis.
Manual Part Number
A3662-90001 E0897 Copyright © 1997 Hewlett-Packard Company
*PA3662-96001*
A3662-96001
