HP F885 User manual

1
About this Guide
The content in this document is for information purpose and is subject to change
without prior notice. We have made every effort to ensure that this User Guide is
accurate and complete.
However, no liability is assumed for any errors or omissions that may have
occurred.
The manufacturer reserves the right to change the technical specifications or
accessories without prior notice.
Battery Warning
 Never dismantle, crush, or pierce the battery, or allow the battery to
short circuit. Do not expose battery being placed in high temperature
environment, if battery leaks or bulges, stop continue to use.
 Always charge using the system. Risk of explosion if battery is replaced by an
incorrect type.
 Keep the battery out of reach of children.
 Batteries may explode if exposed to open fire. Never dispose of batteries in a
fire.
 Never replace the battery on your own; have the dealer do it for you.
 Disposed of used batteries observing local regulations.
Notes on Installation
1. Please measure the front windshield viewing area, make sure not to block
driver's front view, install the camcorder below the rearview mirror (the
central, higher right position of the front windshield). And we recommend that
the sky and the land occupied by the screen 50%, fix the car holder and then
adjust the camcorder so that the lane is aligned with the screen. Proper
installation enables the camcorder to maximize the efficiency.
2. Make sure that the lens is within the wiping range of the windscreen wiper to
ensure a clear view even when it rains.
3. Do not touch the lens with your fingers. Finger grease may be left on the lens
and will result in unclear videos or pictures. Clean the lens on a regular basis.
4. Do not install the camcorder on a tinted window. Doing so may damage the
tint film.
5. Make sure that the installation position is not hindered by the tinted window.
6. This product is suitable for light windshield or light color heat resistant film
windows , it will affect video quality if install it on the dark windows or dark
heat resistant film windows.
7. Use the products of the attached power charger only, please do not use other
brand power charger, in order to avoid equipment burn or cause the battery
explosion.
For more operation details please refer to CD-ROM.

2
Caution
 Due to local laws and vehicles safety considerations, do not operate the
camcorder while driving.
 Set up time and date accurately before you use this camcorder.
 The firmware function in the camcorder is for reference only, drivers are
advised to exercise discretion based on actual road conditions.
 This product is used only for non commercial use, within the maximum limits
permitted by applicable law. We do not take any responsibilities for the loss of
use of the product.
 This camcorder gets warm when in use; this is normal.
 Improper use or operation of the product may result in damage of the product
or its accessories and void the warranty.
 HP Inc. is NOT responsible for the loss of any data/content during operation.
1Introduction
Thank you for purchasing this advanced Car Camcorder. This product is specifically
designed for real time video recording when driving. It also supports a HP rear
camera. You might ask distributor for further information.
1.1 Package Contents
The package contains the following items. In case there is any missing or damaged
item, contact your dealer immediately.
Car Camcorder Bracket CD ROM
Quick Start Guide Car Adapter
Before you start using the product it is assumed that you agree to
the above statement.

3
1.2 Product Overview
No. Item
No. Item
1 LED Indicator
9 Wide Angle Lens
2 LCD Color Screen
10 Memory Card Slot
3 Menu / Back Button ( / )
11 Microphone
4 Playback / Up Button ( / )
12 Power Switch
5 Snapshot / Down Button ( /
)
13 Power Connector Port
6 Emergency Recording / Confirm
Button ( /
OK
)
14 HDMI Connector Port
7 Switch Camera Button ( )
15 Micro USB Connector Port
8 Speaker
16 Bracket Socket
Note:
Please press the button (3~7) according to the diagram notice shown on screen.
3
4
5
6
7
1
2
9
8
12
13
14
10
11
16
15

4
2Getting Started
2.1 Storage Media
2.1.1 Insert the Memory Card
Insert memory card with the pins facing forward and the screen of the
camcorder facing forward too, see the picture as below:
Also, insert the SD card into the camcorder until the lock can be smoothly
slid. Card will be protruding in normal use, and damage may occur if
pressed too hard. Please read the instructions carefully on the screen
layer.
2.1.2 Remove the Memory Card
If the camcorder is power on, please power off first and wait for the
procedure of switching off the camcorder completed before removing
the memory card.
Note:
1. Do not remove or insert the memory card when the camcorder is turned on. This
may damage the memory card.
2. Support SDHC class 10 and memory storage 16GB or above (support up to 32GB).
3. Please format the micro SD cards before the initial use. The formatted file type for
this camcorder is FAT32 file.

5
2.2 Installing in Vehicles
2.2.1 Mount the Camcorder to
Windshield
1. Push the bracket into bracket slot on top of
camcorder until a click sound is heard.
2. Connect the power cable then power on to enter
preview screen and confirm the field of view.
Then clean the surface of the windshield with
alcohol to ensure that the adhesion surface is
clean.
3. Remove the protective layer on the bottom of
the bracket.
4. Release the lever of the bracket, install the
bracket onto the windshield, then lock the
lever to complete the installation.
5. Make sure the bracket is firmly installed onto
the windshield.
Note:
1. Do not install the camcorder on a tinted window. Doing so may damage the tint film.
2. This product is suitable for light windshield or light color heat resistant film
windows, it will affect video quality if install it on the dark windows or dark
heat resistant film windows.
3. Remove the protective layer on the bottom of the bracket.
2.2.2 Adjust the Camcorder
1. Loosen the knob to swivel the camcorder
vertically or horizontally.
2. Then tighten the knob to make sure the
camcorder is securely locked in place.
Knob
1
2

6
2.3 Connecting to Power
Use only the attached power connector for activating the camcorder and
charging the built in battery.
1. Connect one end of power connector to power connector port on the
camcorder. USB port input: DC 5V / 1.0A.
2. Plug the other end of the car adapter to the cigarette lighter socket of
your vehicle. Once the vehicle engine is started, the camcorder
automatically turns on. Car charger input: DC 12 / 24V.
Note:
Please measure front windshield viewing area, so as not to block the driver's field of
view, and install the camcorder under the driving mirror (upper central of the front
windshield). And we recommend that the sky and the land occupied by 50% in the
recording screen, please adjust the camcorder so that the alignment icon is aligning
the driving lane. Proper installation enables the camcorder to maximize the efficiency.
2.4 Initial Settings
Before using the camcorder, we recommend you setup the correct Date
and Time.
Note:
Please note that if you press the button during recording, the system will stop
recording and enter OSD menu. Make sure the recording is already stopped then
continue operating the menu.

7
3Using the Car Camcorder
3.1 Automatic Record
If the camcorder is connected to the vehicle power supply and slide the
power switch, once start the car engine, the camcorder will automatically
power on and start recording.
Recording will automatically stop when the engine is switched off.
Note:
1. Some vehicle power supply would not turn on / off automatically with the car engine
start, if the camcorder cannot automatically power on/off with the car engine,
please manually connect the power supply with the vehicle power, and then power
on, or manually power off the camcorder and then release the connector with the
car power supply.
2. It can be configured to save a video file for every 1 or 3 minutes of recording.
3. All the videos and photos are saved in the memory card, if memory card is full, loop
recording will be generally overwrite the oldest video file.
3.1.1 Emergency Recording
To start the Emergency Recording, do the following:
1. During Video Recording, press the
OK
button to enter emergency
recording mode, the
“Emergency” message will be
shown immediately on the upper
left corner of the screen, and the
recorded file will be protected.
2. The emergency video recording length is same as the recording
interval setting. When the emergency recording length reaches the
setting, the system will return to the general recording mode.
Note:
1. The emergency recording file is created as a new file, which will be protected to
avoid being overwritten by normal loop recording. A memory card can save up to 20
emergency video files if record interval time is 1 minute, and save up to 10
emergency video files if record interval time is set as 3 minutes.
2. The notice message of “Emergency files are full” will pop up on the screen when
the emergency recording folder is full, and the later emergency files will be saved in
the Normal Video folder which will be over written if memory is full. Thus, if you
want to keep newest emergency video file, please manually delete the oldest files
in the emergency video folder to release more capacity.

8
3.2 Picture in Video
You can also use this camcorder to take snapshots of the current scene.
1. In recording status, press
to capture recording screen
shots from the front lens.
2. When the icon shows in
the central of screen, it means
the screenshots is completed.
Note:
1. The screen shots image resolution quality is depending on the video resolution
setting.
2. The definition of picture in video by this product, the picture resolution is limited by
the speed of the target object and changes in ambient lighting. The photograph
function is better used for taking still pictures in accident scenes or when the car is
stopped to wait for a traffic light.
3. It is available only for the front camera if user wants to take pictures during
recording.

9
3.3 Driving Safety
Menu option Description
Parking Mode To monitor the vehicle when it is parked, you can activate
Vibration Detection or Motion and Collision Detection.
Collision
Detection
If Collision Detection is activated, this camcorder starts
emergency recording once it detects any collision.
Driver Fatigue
Alert
When Driver Fatigue Alert is enabled, audible alert and
screen message will be activated 1 hour after the
camcorder is powered on, with a repetition every 30
minutes.
Headlight
Warning
When Headlight Warning is activated, camcorder will issue
an audible alert and screen message reminding that
insufficient brightness is sensed on the recording face.
FCMD
If FCMD function is enabled, the camcorder will determine
it from front car about 3 ~ 4 meters. When the front object
moves about 3 ~ 5 seconds and the car did not start to
drive forward, the camcorder will issue audible alert and
screen message.
Note:
1. The Driving Safety function is limited to triggering no more than two alarms at the
same time. If a voice and alert message have been triggered, any other alarm will
be ignored until either of the two is settled.
2. The detections of FCMD may be inaccurate when used in rain, at night or in
environments of insufficient lighting. Drivers are advised to exercise discretion
based on actual road conditions.
The following driving safety function is for reference only.
Drivers are advised to exercise discretion based on actual road
conditions.

10
3.4 File Playback
3.4.1 Playing Videos
Playback video record files as follows:
1. Press the button to enter
the OSD menu.
2. Press the / button to
select File Playback, and then
press the
OK
button for
entering function menu.
3. Press the / button to
select Video / Parking Mode /
Emergency, and then press the
OK
button for entering menu.
4. Press / button to browse video files, select the video file
and then press
OK
button to enter Playback Mode. If
thumbnail shows
D
icon, it indicates that the file is dual lens
recording. In the playback mode, you can use button to
switch the front and rear lens recording file. (Rear Camera is not
included in standard package. Please contact distributor for further
information.)
5. Press the repetitively to return recording screen.

11
3.5 Deleting Files
To delete file(s), do the following:
1. Press the button to enter
the OSD menu.
2. Press the / button to
select File Deletion, and then
press the
OK
button for
entering function menu.
3. Press the / button to
select Video / Parking Mode /
Emergency / Picture, and then
press the
OK
button for
entering menu.
•Delete One:
- Press the /
button to select Delete
One, and then press the
OK
button to enter
the menu.
- Press / button
to browse files , select the
files you want to delete
and then press
OK
button to enter the menu.
- Press the / button to select item, and then press
the
OK
/ button to confirm or cancel the selection.
•Delete All:
- Press the / button to select Delete All, and then
press the
OK
button to enter the menu.
- Press the / button to select item, and then press
the
OK
/ button to confirm or cancel the selection.
4. Press the repetitively to return recording screen.
Note:
1. Only front camera thumbnails will be display in Menu, if you choose to delete the file
has the
D
icon, and then the files records with rear lens will be deleted. (Rear
Camera is not included in standard package. Please contact distributor for further
information.)
2. Deleted files cannot be recovered. Ensure the files have already backup before
deletion.

12
4Specifications
Item Description
Image Sensor 1/3” CMOS sensor
Effective Pixels 2688 (H) x 1520 (V)
Storage Media Support SDHC class 10 and 16GB micro SD card (up to 32GB)
LCD Display 3.0" TFT LCD color screen
Lens Wide Angle Fixed Focus lens F1.8, f=2.94mm
Focus Range 1.5m~Infinity
Movie Clip
Resolution: 2K HD@30 (1440P 30fps) / FHD@60 (1080P 60fps) /
FHD HDR (1080P HDR 30fps) / FHD@30 (1080P 30fps) / HD@120
(720P 120fps)
Format: MOV
Still Image Resolution: 4M (2688 x 1520)
Format: JPEG
Shutter Electronic shutter
Auto: 1/120 ~1/2000 sec.
G Sensor 3 Axis G Force sensor
ISO Auto
White Balance Auto
Microphone Yes
Speaker Yes
Interface Mini USB; Micro USB; Mini D Type HDMI
Battery Built in 470mAh Li polymer rechargeable
Operating
Temperature 0° ~ 60° C
Operating Humidity
20 ~ 70% RH
Storage Temperature
20° ~ 70° C
Dimensions 89 x 28.5 x 53 mm
Weight Approx. 86g (without memory card)

1
有關本手冊
有關本手冊有關本手冊
有關本手冊
本文件之內容只供參考，並得以隨時變更不需要事先通知。本公司已盡全力確
保本使用者手冊正確與完整。但有任何錯誤或遺漏概不負責。製造廠保留不需
事先通知，逕自變更技術規格或配件之權利。
電池注意事項
電池注意事項電池注意事項
電池注意事項
 嚴禁拆解、撞擊、穿刺、擠壓電池，或使電池短路。請勿將電池放置於
高溫環境中，若電池出現漏液或鼓脹，請勿繼續使用。
 請務必使用本系統進行充電。未正確處理電池或更換不正確之電池型式
會有引發爆炸的風險。
 請將電池放在孩童拿不到的地方。
 電池接觸明火可能會引起爆炸，請勿將電池丟棄到火中。
 嚴禁自行更換電池
嚴禁自行更換電池嚴禁自行更換電池
嚴禁自行更換電池，
，，
，欲更換電池
欲更換電池欲更換電池
欲更換電池請洽經銷商
請洽經銷商請洽經銷商
請洽經銷商。
。。
。
 請根據當地法規妥善處理使用過的電池。
安裝須知
安裝須知安裝須知
安裝須知
1. 請衡量前擋風玻璃的可視面積，以不遮擋駕駛前方的視野為原則，將本
設備安裝在汽車後視鏡的正下方 (前擋風玻璃中央偏上方的位置)。並建
議天空與地面佔據錄影畫面各 50%，固定托架後再調整設備使車道對齊
圖示與行駛車道對齊。正確的安裝可使設備發揮最大功效。
2. 確定鏡頭是在擋風玻璃雨刷的範圍內，確保視野良好，即使雨天依然清
晰。
3. 不要用手指碰觸鏡頭。手指上的油垢可能會留在鏡頭上，導致影片或照
片不清楚。請定期清潔鏡頭。
4. 請勿將本設備安裝在深色車窗上，否則將使隔熱紙受損。
5. 安裝設備之前請確認安裝位置不會受有色車窗阻礙。
6. 本產品僅適用於淺色擋風玻璃或貼附淺色隔熱紙的車窗，若使用深色車
窗或車窗貼附有色隔熱紙，將影響錄影成像的效果。
7. 本設備僅適用產品隨附之電源連接器，請勿使用其他廠牌以免設備燒毀
或導致電池爆炸。
欲瞭解更多的操作訊息
欲瞭解更多的操作訊息欲瞭解更多的操作訊息
欲瞭解更多的操作訊息，
，，
，請參閱
請參閱請參閱
請參閱 CD-ROM。
。。
。

2
安全
安全安全
安全注意
注意注意
注意事項
事項事項
事項
 使用者須遵守當地法律並以行車安全為優先考量，請勿於行車中操作本
設備。
 使用設備前請先確認日期與時間已設定完成。
 本設備內建的韌體功能僅供使用者參考，道路駕駛請依實際路況作判
斷。
 本產品僅供使用於非商業用途，適用法律允許的最大限度內。本公司對
於使用本產品所造成的損失不承擔任何責任。
 本設備在使用時會略微變熱，純屬正常現象不代表故障。
 不正確地使用本產品或操作不當導致設備或配件損壞，您的保固將會無
效。
 HP Inc.對於操作中任何資料／內容的損失概不負責。
1導論
導論導論
導論
謝謝惠顧此套先進的行車記錄器。本產品專用於行車時之即時錄影。本機種支
援惠普高清後置鏡頭，可洽經銷商選購，保障您的行車安全。
1.1 包裝
包裝包裝
包裝內容
內容內容
內容
以下為包裝內容物。若有任何遺漏或損壞項目，請立即聯絡您的經銷商。
行車記錄器 托架 光碟
快速使用手冊 電源連接器
開始使用本
開始使用本開始使用本
開始使用本產品
產品產品
產品視為同意以上聲明事項
視為同意以上聲明事項視為同意以上聲明事項
視為同意以上聲明事項。
。。
。

3
1.2 產
產產
產品概要
品概要品概要
品概要
編號
編號編號
編號
項目
項目項目
項目
編號
編號編號
編號
項目
項目項目
項目
1 LED 指示燈
9 廣角鏡頭
2 LCD 彩色螢幕
10 記憶卡插槽
3 目錄 / 返回按鍵 ( / )
11 麥克風
4 播放 / 向上按鍵 ( / )
12 電源開關
5 影片截圖 / 向下按鍵 ( /
)
13 電源連接埠
6 緊急錄影 / 確認按鍵 ( /
OK
)
14 HDMI 連接埠
7 鏡頭切換按鍵 ( )
15 Micro USB 連接埠
8 揚聲器
16 托架插孔
註
註註
註：
：：
：
使用設備時請依據螢幕顯示的圖示，操作相應的按鍵 (3~7 。
3
4
5
6
7
1
2
9
8
12
13
14
10
11
16
15

4
2開始
開始開始
開始
2.1 使用儲存媒體
使用儲存媒體使用儲存媒體
使用儲存媒體
2.1.1 插入記憶卡
插入記憶卡插入記憶卡
插入記憶卡
將記憶卡之金色接腳面朝前，以及設備螢幕面朝前，如圖示插入記憶
卡:
輕輕地將記憶卡插入卡槽直到開關可以輕易地滑動。正常使用上，記
憶卡會稍微突出相機本身。為預防卡片損毀，請勿重壓卡片進卡槽中。
請務必詳讀並遵循螢幕保護貼上步驟使用本產品。
2.1.2 取出記憶卡
取出記憶卡取出記憶卡
取出記憶卡
若設備在開機狀態請先關閉電源，並等待設備完成關機程序後再取出
記憶卡。
註
註註
註：
：：
：
1. 設備在開機狀態時，不要取出或插入記憶卡，以免損壞記憶卡。
2. 限使用 SDHC 速度等級 10 以上，且記憶體容量 16GB 以上的 micro SD 卡
(最高支援 32GB 。
3. 使用前請先格式化 micro SD 卡。

5
2.2 安裝於車內
安裝於車內安裝於車內
安裝於車內
2.2.1 固定設備在
固定設備在固定設備在
固定設備在擋風玻璃上
擋風玻璃上擋風玻璃上
擋風玻璃上
1. 將托架卡榫推入設備上方的托架插孔中，直
到聽到咔嗒聲固定。
2. 連接電源連接器並開啟設備電源預覽錄影畫
面，確認錄影範圍之後再以酒精清潔擋風玻
璃的表面，確保黏著表面乾淨無污。
3. 撕除托架底部的透明保護膜。
4. 開啟托架的壓力閥，將托架按壓於擋風玻
璃上，使托架的吸盤與擋風玻璃緊密貼
合，再關閉壓力閥以固定托架。
5. 確認托架已牢牢吸附於擋風玻璃。
註
註註
註：
：：
：
1. 請勿將本設備安裝在深色車窗上，否則將使隔熱紙受損。
2. 本產品僅適用於淺色擋風玻璃或貼附淺色隔熱紙的車窗，若使用深色車窗或車
窗貼附有色隔熱紙，將影響錄影成像的效果。
3. 使用設備前請先將鏡頭保護膜撕除。
2.2.2 調整設備
調整設備調整設備
調整設備
1. 鬆開旋鈕，將設備垂直或水平方向調
整。
2. 鎖緊旋鈕，並確認設備已牢牢固定。
1
2
旋鈕
旋鈕旋鈕
旋鈕

6
2.3 連接電源
連接電源連接電源
連接電源
限使用產品隨附之電源連接器啟動設備與充電。
1. 將電源連接器的一端連接到設備的電源連接埠。電源連接埠輸入
直流電壓 5V / 1.0A。
2. 將電源連接器的另一端插接汽車內的香煙點火器插孔。汽車引擎
一旦發動，設備即自動開機。車充輸入直流電壓 12 / 24V。
註
註註
註：
：：
：
請衡量前擋風玻璃的可視面積，以不遮擋駕駛前方的視野為原則，將本設備安裝
在汽車後視鏡的正下方 (前擋風玻璃中央偏上方的位置 。並建議天空與地面佔據
錄影畫面各 50%，固定托架後再調整設備使車道對齊圖示與行駛車道對齊。正確
的安裝可使設備發揮最大功效。
2.4 首次設定
首次設定首次設定
首次設定
在使用設備之前，我們建議先設定正確的日期與時間
日期與時間日期與時間
日期與時間。
註
註註
註：
：：
：
請注意若在錄影期間按 按鍵，系統將會停止錄影並進入 OSD 目錄。請先確
認錄影可以中止再操作目錄選單。

7
3使用行車記錄器
使用行車記錄器使用行車記錄器
使用行車記錄器
3.1 自動
自動自動
自動錄影
錄影錄影
錄影
首次操作請確認設備處於開機狀態並連接車用電源，汽車引擎一旦發
動設備將自動開機並啟動錄影。
當引擎熄火時設備會自動停止錄影。
註
註註
註：
：：
：
1. 某些汽車的車用電源並不會隨著汽車引擎的發動 / 熄火而自動開啟 / 關閉電
源，若設備無法隨汽車引擎自動開啟與關閉電源時，請以手動方式將電源連接
器與車用電源連接，再開啟設備電源，或是以手動方式關閉設備的電源，再將
電源連接器從車用電源卸除。
2. 可設定每個影片檔案錄影的時長為 1 或 3 分鐘。
3. 設備會儲存影片或照片於記憶卡中，若記憶卡空間已滿時，循環錄影會將一般
錄影中最舊的檔案覆蓋掉。
3.1.1 緊急錄影
緊急錄影緊急錄影
緊急錄影
啟動緊急錄影，其方式如下：
1. 在錄影期間按
OK
按鍵將會
進入緊急錄影模式
緊急錄影模式緊急錄影模式
緊急錄影模式，並於螢幕左
上角顯示 " 緊急錄影
緊急錄影緊急錄影
緊急錄影 " 的字樣。
在緊急錄影模式中錄製的影片會
被保護起來。
2. 緊急錄影的時長同錄影間隔的設定。當緊急錄影達設定的時
間，系統會回復到一般的錄影模式。
註
註註
註：
：：
：
1. 緊急錄影的檔案會另外儲存成受保護的檔案，避免檔案被循環錄影所覆蓋。若
錄影間隔設定為 1 分鐘，記憶卡可儲存約 20 組緊急錄影的檔案；若錄影間
隔設定為 3 分鐘，記憶卡可儲存約 10 組緊急錄影的檔案。
2. 當緊急錄影檔案已滿，螢幕會出現 "
緊急錄影檔案已滿
" 的警示，在此之後以
緊急錄影錄製下來的檔案都會被儲存為一般錄影 (若記憶卡空間已滿時，循環
錄影會將一般錄影中最舊的檔案覆蓋掉 。因此如欲留存較新的緊急錄影檔案，
請於系統發出警示時以手動的方式刪除舊有的緊急錄影檔案。
