HP MSR20-20 User manual

Models
HP MSR20-20 Router JF283A
HP MSR20-21 Router JD663B
HP MSR20-40 Router JF228A
Key features
Converged routing, switching, voice, and security
Embedded encryption, firewall, and security features
Modular WAN/LAN interface options
Unified wired and wireless
Single pane-of-glass management
Product overview
The HP MSR20 router series is a component of the HP FlexBranch solution, which is part of the HP FlexNetwork architecture. It features
a modular design that delivers unmatched flexibility for small branch offices and small to medium-sized businesses while reducing
complexity, simplifying management, and increasing control. MSR20 series routers provide a full-featured, resilient routing platform,
including IPv6 and MPLS, up to 180 Kpps forwarding capacity, and 100 Mbps encryption. These products offer lasting investment
protection, and help reduce capital and operating expenses. MSR20 series routers provide an agile, flexible network infrastructure that
offers the ability to quickly adapt to changing business requirements while delivering integrated, concurrent services on a single, easy-
to-manage platform.
Features and benefits
Quality of Service (QoS)
Traffic policing : supports Committed Access Rate (CAR) and line rate
Congestion management : supports FIFO, PQ, CQ, WFQ, CBQ, and RTPQ
Congestion avoidance : Weighted Random Early Detection (WRED)/Random Early Detection (RED)
Other QoS technologies : support traffic shaping, FR QoS, MPLS QoS, and MP QoS/LFI
Management
Industry-standard CLI with a hierarchical structure : reduces training time and expenses, and increases productivity in
multivendor installations
Management security : multiple privilege levels with password protection restrict access to critical configuration commands;
ACLs provide telnet and SNMP access; local and remote syslog capabilities allow logging of all access
SNMPv1, v2, and v3 : provide complete support of SNMP; provide full support of industry-standard Management Information
Base (MIB) plus private extensions; SNMPv3 supports increased security using encryption
Remote monitoring (RMON): uses standard SNMP to monitor essential network functions; supports events, alarm, history, and
statistics group plus a private alarm extension group
FTP, TFTP, and SFTP support : FTP allows bidirectional transfers over a TCP/IP network and is used for configuration updates;
Trivial FTP is a simpler method using User Datagram Protocol (UDP)
Debug and sampler utility : supports ping and traceroute for both IPv4 and IPv6
Network Time Protocol (NTP): synchronizes timekeeping among distributed time servers and clients; keeps timekeeping
consistent among all clock-dependent devices within the network so that the devices can provide diverse applications based on
QuickSpecs
HP MSR20 Series
Overview
DA - 13813 North America — Version 13 — November 22, 2013 Page 1

the consistent time
Info center : provides a central information center for system and network information; aggregates all logs, traps, and
debugging information generated by the system and maintains them in order of severity; outputs the network information to
multiple channels based on user-defined rules
Management interface control : provides management access through modem port and terminal interface; provides access
through terminal interface, telnet, or SSH
Network Quality Analyzer (NQA): analyzes network performance and service quality by sending test packets, and provides
network performance and service quality parameters such as jitter, TCP, or FTP connection delays; allows network manager to
determine overall network performance and diagnose and locate network congestion points or failures
Connectivity
High-density port connectivity : provides up to 4 interface module slots and up to 18 Fast Ethernet ports
Multiple WAN interfaces : provide a traditional link with E1, T1, ADSL, ADSL2, ADSL2+, G.SHDSL, ATM, Serial, and ISDN/AM
backup; provide high-density Ethernet access with WAN Fast Ethernet/Gigabit Ethernet and LAN 4- and 9-port Fast Ethernet;
provide mobility access with 802.11b/g/n Wi-Fi and 3G
Packet storm protection : protects against broadcast, multicast, or unicast storms with user-defined thresholds
Loopback : supports internal loopback testing for maintenance purposes and an increase in availability; loopback detection
protects against incorrect cabling or network configurations and can be enabled on a per-port or per-VLAN basis for added
flexibility
Flexible port selection : provides a combination of fiber and copper interface modules, 100/1000BASE-X auto-speed selection,
and 10/100/1000BASE-T auto-speed detection plus auto duplex and MDI/MDI-X
3G access support : provides 3G wireless access for primary or backup connectivity via a 3G SIC module certified on various
cellular networks; optional carrier 3G USB modems available
Performance
Powerful encryption capacity : includes embedded hardware encryption accelerator to improve encryption performance
Flexible chassis selection : offers a choice of three routers, meeting different requirements on enterprise branches
Excellent forwarding performance : provides forwarding performance up to 180 Kpps; meets current and future bandwidth-
intensive application demands of enterprise businesses
Resiliency and high availability
Backup Center : acts as a part of the management and backup function to provide backup for device interfaces; delivers
reliability by switching traffic over to a backup interface when the primary one fails
Virtual Router Redundancy Protocol (VRRP): allows groups of two routers to dynamically back each other up to create highly
available routed environments; supports VRRP load balancing
Layer 2 switching
Spanning Tree Protocol (STP)
fully supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and IEEE
802.1s Multiple Spanning Tree Protocol (MSTP)
Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping : effectively control
and manage the flooding of multicast packets in a Layer 2 network
Port mirroring : duplicates port traffic (ingress and egress) to a local or remote monitoring port
VLANs : support up to 4,094 ports or IEEE 802.1Q-based VLANs
sFlow : allows traffic sampling
Layer 3 services
QuickSpecs
HP MSR20 Series
Overview
DA - 13813 North America — Version 13 — November 22, 2013 Page 2

Address Resolution Protocol (ARP): determines the MAC address of another IP host in the same subnet; supports static ARPs;
gratuitous ARP allows detection of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when
subnets are separated by a Layer 2 network
User Datagram Protocol (UDP) helper : redirects UDP broadcasts to specific IP subnets to prevent server spoofing
Dynamic Host Configuration Protocol (DHCP): simplifies the management of large IP networks and supports client and server;
DHCP Relay enables DHCP operation across subnets
Layer 3 routing
Static IPv4 routing
provides simple, manually configured IPv4 routing
Routing Information Protocol (RIP)
uses a distance vector algorithm with UDP packets for route determination; supports RIPv1 and RIPv2 routing; includes loop
protection
Open Shortest Path First (OSPF)
Interior Gateway Protocol (IGP) uses link-state protocol for faster convergence; supports ECMP, NSSA, and MD5 authentication
for increased security and graceful restart for faster failure recovery
Border Gateway Protocol 4 (BGP-4)
Exterior Gateway Protocol (EGP) with path vector protocol uses TCP for enhanced reliability for the route discovery process,
reduces bandwidth consumption by advertising only incremental updates, and supports extensive policies for increased
flexibility, as well as scales to very large networks
Intermediate system to intermediate system (IS-IS)
Interior Gateway Protocol (IGP) uses path vector protocol, which is defined by the ISO organization for IS-IS routing and
extended by IETF RFC 1195 to operate in both TCP/IP and the OSI reference model (Integrated IS-IS)
Static IPv6 routing
provides simple, manually configured IPv6 routing
Dual IP stack
maintains separate stacks for IPv4 and IPv6 to ease the transition from an IPv4-only network to an IPv6-only network design
Routing Information Protocol next generation (RIPng)
extends RIPv2 to support IPv6 addressing
OSPFv3
provides OSPF support for IPv6
BGP+
extends BGP-4 to support Multiprotocol BGP (MBGP), including support for IPv6 addressing
IS-IS for IPv6
extends IS-IS to support IPv6 addressing
IPv6 tunneling
is an important element for the transition from IPv4 to IPv6; allows IPv6 packets to traverse IPv4-only networks by
encapsulating the IPv6 packet into a standard IPv4 packet; supports manually configured, 6to4, and Intra-Site Automatic Tunnel
Addressing Protocol (ISATAP) tunnels
Multiprotocol Label Switching (MPLS)
uses BGP to advertise routes across Label Switched Paths (LSPs), but uses simple labels to forward packets from any Layer 2 or
Layer 3 protocol, thus reducing complexity and increasing performance; supports graceful restart for reduced failure impact;
supports LSP tunneling and multilevel stacks
Multiprotocol Label Switching (MPLS) Layer 3 VPN
allows Layer 3 VPNs across a provider network; uses Multiprotocol BGP (MP-BGP) to establish private routes for increased
security; supports RFC 2547bis multiple autonomous system VPNs for added flexibility; supports IPv6 MPLS VPN
Multiprotocol Label Switching (MPLS) Layer 2 VPN
establishes simple Layer 2 point-to-point VPNs across a provider network using only MPLS Label Distribution Protocol (LDP);
QuickSpecs
HP MSR20 Series
Overview
DA - 13813 North America — Version 13 — November 22, 2013 Page 3

requires no routing and therefore decreases complexity, increases performance, and allows VPNs of non-routable protocols;
uses no routing information for increased security; supports Circuit Cross Connect (CCC), Static Virtual Circuits (SVCs), Martini
draft, and Kompella-draft technologies
Policy routing
allows custom filters for increased performance and security; supports ACLs, IP prefix, AS paths, community lists, and aggregate
policies
Security
Access control list (ACL): supports powerful ACLs for both IPv4 and IPv6; ACLs are used for filtering traffic to prevent
unauthorized users from accessing the network, or for controlling network traffic to save resources; rules can either deny or
permit traffic to be forwarded; rules can be based on a Layer 2 header or a Layer 3 protocol header; rules can be set to operate
on specific dates or times
Terminal Access Controller Access-Control System (TACACS+)
is an authentication tool using TCP with encryption of the full authentication request that provides additional security
Unicast Reverse Path Forwarding (URPF): allows normal packets to be forwarded correctly, but discards the attaching packet
due to lack of reverse path route or incorrect inbound interface; prevents source spoofing and distributed attacks
Network login : authentication of multiple users per port
RADIUS : eases security access administration by using a user/password authentication server
Network address translation (NAT): supports one-to-one NAT, many-to-many NAT, and NAT control, enabling NAT-PT to
support multiple connections; supports blacklist in NAT/NAT-PT, a limit on the number of connections, session logs, and multi-
instances
Secure Shell (SSHv2): uses external servers to securely login into a remote device; with authentication and encryption, it
protects against IP spoofing and plain text password interception; increases the security of SFTP transfers
IPSec VPN : supports DES, 3DES, and AES 128/192/256 encryption, and MD5 and SHA-1 authentication
DVPN (Dynamic Virtual Private Network): collects, maintains, and distributes dynamic public addresses through the VPN Address
Management (VAM) protocol, making VPN establishment available between enterprise branches that use dynamic addresses to
access the public network; compared to traditional VPN technologies, DVPN technology is more flexible and has richer features,
such as NAT traversal of DVPN packets, AAA identity authentication, IPSec protection of data packets, and multiple VPN domains
Convergence
Internet Group Management Protocol (IGMP): is used by IP hosts to establish and maintain multicast groups; supports IGMPv1,
v2, and v3; utilizes Any-Source Multicast (ASM) or Source-Specific Multicast (SSM) to manage IPv4 multicast networks
Protocol Independent Multicast (PIM): is used for IPv4 and IPv6 multicast applications; supports PIM Dense Mode (PIM-DM),
Sparse Mode (PIM-SM), and Source-Specific Mode (PIM-SSM)
Multicast Source Discovery Protocol (MSDP): is used for inter-domain multicast applications, allowing multiple PIM-SM
domains to interoperate
Multicast Border Gateway Protocol (MBGP): allows multicast traffic to be forwarded across BGP networks and kept separate
from unicast traffic
Integration
Embedded NetStream : local and global server load-balancing module improves traffic distribution using powerful scheduling
algorithms, including Layer 4 to 7 services; monitors the health status of servers and firewalls
Embedded VPN firewall : provides enhanced stateful packet inspection and filtering; delivers advanced VPN services with Triple
DES (3DES) and Advanced Encryption Standard (AES) encryption at high performance and low latency, Web content filtering, and
application prioritization and enhancement
Additional information
QuickSpecs
HP MSR20 Series
Overview
DA - 13813 North America — Version 13 — November 22, 2013 Page 4

OPEX savings : are delivered through the use of a common operating system that simplifies and streamlines deployment,
management, and training, thereby cutting costs as well as reducing the chance for human errors associated with having to
manage multiple operating systems across different platforms and network layers
High reliability : provides a state-of-the-art unified code base
Faster time to market : engineering efficiencies allow new and custom features to be brought rapidly to the market with better
initial and ongoing stability
Green initiative support : provides support for RoHS and WEEE regulations
Product architecture
Ideal multiservice platform
provides WAN router, Ethernet switch, wireless LAN, 3G WAN, firewall, VPN, and SIP/voice gateway all in one box
High-density voice interfaces
provide flexible analog and digital voice interface options for easy integration within a wide range of deployments
USB interface
uses USB memory disk to download and upload configuration files; supports an external USB 3G modem for a 3G WAN uplink
SIP trunk
the SIP trunk link can carry multiple concurrent calls; the carrier authenticates only the link, rather than carrying each SIP call on
the link
Embedded service modules for security and voice
embedded Voice Co-Processing Modules (VCPMs) and Voice Processing Modules (VPMs) accommodate digital signal processor
(DSP) modules for voice packet processing; embedded hardware encryption modules, Standard Network Data Encryption (SNDE)
cards, and Advanced Network Data Encryption (ANDE) cards do not occupy I/O slots
Warranty and support
1-year warranty : with advance replacement and delivery (available in most countries)
Electronic and telephone support : limited electronic and telephone support is available from HP; to reach our support centers,
refer to: www.hp.com/networking/contact-support ; for details on the duration of support provided with your product purchase,
refer to: www.hp.com/networking/warrantysummary
Software releases : to find software for your product, refer to: www.hp.com/networking/support ; for details on the software
releases available with your product purchase, refer to: www.hp.com/networking/warrantysummary
QuickSpecs
HP MSR20 Series
Overview
DA - 13813 North America — Version 13 — November 22, 2013 Page 5

Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
HP MSR20-20 Router JF283A
2 - SIC module slots
1 - ESM Slot
0 - VCPM slots
0 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
See Configuration
Note:1, 9
Russian Reduced Encryption JF283AA59
See Configuration
Note:2
HP MSR20-21 Router JD663B
8 - RJ45 LAN ports
2 - SIC module slots
1 - ESM Slot
0 - VCPM slots
0 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
See Configuration
Note:1, 9
Russian Reduced Encryption JD663BA59
See Configuration
Note:2
HP MSR20-40 Router JF228A
4 - SIC Module slots
2 - ESM Slot
1 - VCPM slots
2 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
See Configuration
Note:1, 9
Russian Reduced Encryption JF228AA59
See Configuration
Note:2
Configuration Rules:
Note 1 AC Power Supply included
Note 2 If this product is ordered with the A59 option, then the #A59 must replace the existing localization.
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 6

Note 9 Localization required. (See Localization Menu)
CTO Models
CTO Solution Sku
HP MSR CTO Router Solution JG500A
SSP trigger sku See Configuration
Note:10
CTO Base Sku
HP MSR20-20 Router JF283A
2 - SIC module slots
1 - ESM Slot
0 - VCPM slots
0 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
AC Power Supply included
See Configuration
Note:1, 2, 11
HP MSR20-21 Router JD663B
2 - SIC module slots
1 - ESM Slot
0 - VCPM slots
0 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
AC Power Supply included
See Configuration
Note:1, 2, 11
HP MSR20-40 Router JF228A
4 - SIC Module slots
2 - ESM Slot
1 - VCPM slots
2 - VPM slot
256MB DDR SDRAM included
1 - Compact Flash Slot
AC Power Supply included
See Configuration
Note:1, 2, 11
Configuration Rules:
Note 1 If this Switch is selected integrated to the CTO Switch Solution, Then a Minimum of 1 factory integrated accessory
must be ordered and integrated to CTO chassis. See Menu below, option must have a #0D1 to be integrated to the
CTO Chassis.
Note 2 Localization required. (See Localization Menu)
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 7

Note 10 This HPN CTO switch cannot be factory racked. (Future Release)
Note 11 If the Router Chassis is to be Box Level Factory Integrated (CTO), Then the #0D1 is required on the Router Chassis
and integrated to the JG500A - HP MSR CTO Enablement. (Min 1/Max 1 Router per SSP)
Internal Power Supplies
Internal Power Supplies included
Modules
SIC Modules
HP MSR 4-port 10/100 SIC Module JD573B
None See Configuration
Note:1
HP MSR 9-port 10/100 DSIC Module JD574B
See Configuration
Note:2, 3, 15, 16
HP MSR 1-port 10/100 SIC Module JD545B
None See Configuration
Note:1
HP 1-port 100Mbt SFP SIC Router Module JF280A
min=0 \ max=1 SFP Transceivers See Configuration
Note:1, 4
HP MSR 1-port 10/100/1000 SIC Module JD572A
min=0 \ max=1 SFP Transceivers See Configuration
Note:1, 5
HP MSR 2-port FXO SIC Module JD558A
None
HP MSR 1-port FXO SIC Module JD559A
None
HP MSR 2-port FXS SIC Module JD560A
None
HP MSR 1-port FXS SIC Module JD561A
None
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 8

HP MSR 1-port E1-Voice SIC Module JD575A
min=0 \ max=1 E1 Cable See Configuration
Note:3, 6, 11
HP MSR 1-port T1-Voice SIC Module JD576A
min=0 \ max=1 E1 Cable See Configuration
Note:3, 7
HP 2p ISDN-S/T Voice Interface SIC Mod JF821A
None See Configuration
Note:3
HP MSR 2FXS + 1FXO Voice Intfc SIC Mod JD632A
None See Configuration
Note:3
HP MSR 1-port Fractional E1 SIC Module JD634B
min=0 \ max=1 E1 Cable See Configuration
Note:3, 6 11
HP MSR 1-port Fractional SIC Module JD538A
min=0 \ max=1 T1 Cable See Configuration
Note:3, 7
HP MSR 2-port Fractional E1 SIC Module JF842A
min=0 \ max=2 Cable See Configuration
Note:3, 12
HP MSR 1-port Enhanced Serial SIC Mod JD557A
min=0 \ max=1 Cable See Configuration
Note:3, 8
HP A-MSR 1-port ADSL over POTS SIC Module JD537A
None See Configuration
Note:1
HP MSR 1-port ISDN-S/T SIC Module JD571A
None See Configuration
Note:3
HP A-MSR 8-port Async Serial SIC Module JF281A
Must select 1 8AS Communication Cable (min=1 \ max=1 cable) See Configuration
Note:3, 9
HP 802.11b/g/n Wireless AP SIC Module JF819A
None See Configuration
Note:1
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 9

HP MSR 802.11b/g/n Wless AP SIC Mod (NA) JG211A
None See Configuration
Note:1
HP MSR 1p 8-wire G.SHDSL (RJ45) DSIC Mod JG191A
None See Configuration
Note:1, 2
HP MSR 1-port ADSL over ISDN SIC Module JG056B
None See Configuration
Note:1
HP MSR 16-port Async Serial SIC Module JG186A
Must select 4 HP X260 mini D-28/4-RJ45 0.3m Rtr Cables (min=4 \ max=4 cables) See Configuration
Note:3,10
HP A-MSR 4-port FXS/1-port FXO DSIC Mod JG189A
None See Configuration
Note:1, 2
HP A-MSR HSPA/WCDMA SIC Module JG187A
None See Configuration
Note:1
HP MSR 1-port E1/CE1/PRI SIC Module JF253B
None
Configuration Rules:
Note 1 This module max = 2 on JF228A - HP A-MSR20-40 Router
Note 2 This Module takes up two slots.
Note 3 This module is only supported on JF228A - HP MSR20-40 Router
Note 4 The following Transceivers install into this Module: (Use #0D1 if router is CTO) - if applicable
HP X110 100M SFP LC LH40 Transceiver JD090A
HP X110 100M SFP LC LH80 Transceiver JD091A
HP X110 100M SFP LC FX Transceiver JD102B
HP X110 100M SFP LC LX Transceiver JD120B
Note 5 The following Transceivers install into this Module: (Use #0D1 if router is CTO) - if applicable
HP X125 1G SFP LC LH70 Transceiver JD063B
HP X120 1G SFP LC LH40 1550nm Transceiver JD062A
HP X125 1G SFP LC LH40 1310nm Transceiver JD061A
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 10

HP X120 1G SFP LC BX 10-U Transceiver JD098B
HP X120 1G SFP LC BX 10-D Transceiver JD099B
HP X120 1G SFP LC LH100 Transceiver JD103A
HP X120 1G SFP LC SX Transceiver JD118B
HP X120 1G SFP LC LX Transceiver JD119B
Note 6 The following E1 Cables install into this Module:
HP X260 E1 (2) BNC 75 ohm 3m Rtr Cable JD175A
HP X260 E1 BNC 20m Router Cable JD514A
HP X260 E1/2 BNC 75 ohm 40m Router Cable JD516A
Note 7 The following T1 Cables install into this Module:
T1 Cable RJ45/RJ45-3m JD518A
Note 8 The following Cables install into this Module:
V.24 Serial Port Cable, DTE, 3m JD519A
V.24 Serial Port Cable, DCE, 3m JD521A
V.35 Serial Port Cable, DTE, 3m JD523A
V.35 Serial Port Cable, DCE, 3m JD525A
X.21 Serial Port Cable, DTE, 3m JD527A
X.21 Serial Port Cable, DCE, 3m JD529A
RS449 Serial Port Cable, DTE, 3m JF825A
RS449 Serial Port Cable, DCE, 3m JF826A
RS530 Serial Port Cable, DTE, 3m JF827A
RS530 Serial Port Cable, DCE, 3m JF828A
Note 9 If this module is selected Then 1 JD642A - HP X260 SIC-8AS RJ45 0.28m Router Cable is required.
Note 10 If this module is selected Then 4 - JG263A HP X260 mini D-28/4-RJ45 0.3m Rtr Cable are required to be on the same
order.
Note 11 The following E1 Cables install into this Module:
HP X260 E1 RJ45 3m Router Cable JD509A
HP X260 E1 RJ45 20m Router Cable JD517A
Note 12 The following 2E1 Cables install into this Module:
HP X260 2E1 BNC 3m Router Cable JD643A
Note 15 If JF228A is selected, Then the maximum for this module = 2
Note 16 This module is not supported on the JF283A or JD663B.
ESM Modules
HP MSR Encryption Accelerator Adv Mod JD608A
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 11

HP MSR Std Encryption Accelerator Mod JD609A
Voice Co-Processing Modules
HP MSR Voice Co-processor Module JD610A
Voice Processing Modules
HP MSR 32-channel Voice Processor Module JD598A
See Configuration
Note:2, 3
HP MSR 24-channel Voice Processor Module JD599A
See Configuration
Note:2, 3
HP MSR 16-channel Voice Processor Module JD600A
See Configuration
Note:2, 3
HP MSR 8-channel Voice Processor Module JD601A
See Configuration
Note:2, 3
Transceivers
SFP Transceivers
HP X115 100M SFP LC FX Transceiver JD102B
HP X110 100M SFP LC LH40 Transceiver JD120B
HP X110 100M SFP LC LH80 Transceiver JD091A
HP X120 1G SFP LC SX Transceiver JD118B
HP X120 1G SFP LC LX Transceiver JD119B
HP X120 1G SFP LC LH40 1550nm XCVR JD062A
HP X110 100M SFP LC LH40 Transceiver JD090A
HP X125 1G SFP LC LH40 1310nm XCVR JD061A
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 12

HP X125 1G SFP LC LH70 Transceiver JD063B
HP X120 1G SFP LC BX 10-D Transceiver JD099B
HP X120 1G SFP LC BX 10-U Transceiver JD098B
HP X120 1G SFP LC LH100 Transceiver JD103A
Cables
HP X260 mini D-28/4-RJ45 0.3m Rtr Cable JG263A
HP X200 V.24 DTE 3m Serial Port Cable JD519A
HP X200 V.24 DCE 3m Serial Port Cable JD521A
HP X200 V.35 DTE 3m Serial Port Cable JD523A
HP X200 V.35 DCE 3m Serial Port Cable JD525A
HP X200 X.21 DTE 3m Serial Port Cable JD527A
HP X200 X.21 DCE 3m Serial Port Cable JD529A
HP X260 RS449 3m DTE Serial Port Cable JF825A
HP X260 RS449 3m DCE Serial Port Cable JF826A
HP X260 RS530 3m DTE Serial Port Cable JF827A
HP X260 RS530 3m DCE Serial Port Cable JF828A
HP X260 Auxiliary Router Cable JD508A
HP X260 E1 RJ45 3m Router Cable JD509A
HP X260 E1 RJ45 20m Router Cable JD517A
HP X260 E1 (2) BNC 75 ohm 3m Rtr Cable JD175A
HP X260 E1 BNC 20m Router Cable JD514A
HP X260 E1/2 BNC 75 ohm 40m Router Cable JD516A
HP X260 E1 RJ45 BNC 75-120 ohm Conversion Router Cable JD511A
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 13

HP X260 2E1 BNC 3m Router Cable JD643A
HP X260 T1 Router Cable JD518A
HP X260 T1 Voice Router Cable JD535A
HP X260 SIC-8AS RJ45 0.28m Router Cable JD642A
Remarks:
The following cable is used for RJ45 BNC Conversion -
HP X260 E1 RJ45 BNC 75-120 ohm Conversion Router Cable JD511A
The following Connector is used to extend E1/T1 Cables:
HP X500 T1/E1 Voice RJ45 Interface Connector JD535A
Router Options
Compact Flash cards
System (std 0 // max 1) User Selection (min 0 // max 1)
HP X600 1G Compact Flash Card JC684A
See Configuration
Note:1
HP X600 512M Compact Flash Card JC685A
See Configuration
Note:1
HP X600 256M Compact Flash Card JC686A
See Configuration
Note:1
Configuration Rules:
Note 1 These CF Cards are supported on the following routers only:
HP MSR20-20 Router JF283A
HP MSR20-21 Router JD663B
HP MSR20-40 Router JF228A
QuickSpecs
HP MSR20 Series
Configuration
DA - 13813 North America — Version 13 — November 22, 2013 Page 14

HP MSR20-20 Router (JF283A)
Ports 2 SIC slots
2 RJ-45 autosensing 10/100 WAN ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX);
Duplex: half or full
Physical characteristics Dimensions 14.17(w) x 11.3(d) x 1.74(h) in (36 x 28.71 x 4.42 cm) (1U height)
Weight 7.5 lb (3.4 kg)
Memory and processor Processor RISC @ 400 MHz, 256 MB compact flash, 256 MB SDRAM
Mounting Desktop or can be mounted in a standard 19-in. rack when used with the optional rack-mount kit.
Performance Throughput 180 Kpps (64-byte packets)
Routing table size 10000 entries (IPv4), 10000 entries (IPv6)
Environment Operating temperature 32ºF to 104ºF (0ºC to 40ºC)
Operating relative
humidity
5% to 90%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 158ºF (-40ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 90%, noncondensing
Electrical characteristics Maximum heat
dissipation
184 BTU/hr (194.12 kJ/hr)
Voltage 100-120/200-240 VAC
Maximum power rating 54 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety UL 60950-1; AS/NZS 60950; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser
Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1-03; EN 60950-1/A11; FDA 21 CFR Subchapter J
Emissions EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR 22 Class A;
EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A; EN
55024:1998+ A1:2001 + A2:2003; EN 61000-4-11:2004; EN 61000-4-8:2001
Telecom FCC part 68; CS-03
Management IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager; Telnet;
RMON1; FTP; IEEE 802.3 Ethernet MIB
Notes The HP 3G Wireless GSM/WCDMA WAN SIC Module (JF820A) is not approved for use in the same chassis as a
Wi-Fi interface (802.11b/g, 802.11b/g/n, etc.) in the European Union.
Services 3-year, parts only, global next-day advance exchange (UW075E)
3-year, 4-hour onsite, 13x5 coverage for hardware (UW076E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UW006E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UW009E)
3-year, 24x7 SW phone support, software updates (UW012E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR554E)
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 15

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR555E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support
(HR556E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW077E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW007E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW010E)
4-year, 24x7 SW phone support, software updates (UW013E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW078E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW008E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW011E)
5-year, 24x7 SW phone support, software updates (UW014E)
3 Yr 6 hr Call-to-Repair Onsite (UW079E)
4 Yr 6 hr Call-to-Repair Onsite (UW080E)
5 Yr 6 hr Call-to-Repair Onsite (UW081E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR558E)
1-year, 24x7 software phone support, software updates (HR557E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP MSR20-21 Router (JD663B)
Ports 2 SIC slots
2 RJ-45 autosensing 10/100 WAN ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX);
Duplex: half or full
8 RJ-45 autosensing 10/100 LAN ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX);
Duplex: half or full
Physical characteristics Dimensions 14.17(w) x 11.3(d) x 1.74(h) in (36 x 28.71 x 4.42 cm) (1U height)
Weight 7.5 lb (3.4 kg)
Memory and processor Processor RISC @ 400 MHz, 256 MB compact flash, 256 MB SDRAM
Mounting Desktop or can be mounted in a standard 19-in. rack when used with the optional rack-mount kit.
Performance Throughput 180 Kpps (64-byte packets)
Routing table size 10000 entries (IPv4), 10000 entries (IPv6)
Environment Operating temperature 32ºF to 104ºF (0ºC to 40ºC)
Operating relative
humidity
5% to 90%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 158ºF (-40ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 90%, noncondensing
Electrical characteristics Maximum heat
dissipation
184 BTU/hr (194.12 kJ/hr)
Voltage 100-120/200-240 VAC
Maximum power rating 54 W
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 16

Frequency 50/60 Hz
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety UL 60950-1; AS/NZS 60950; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser
Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1-03; EN 60950-1/A11; FDA 21 CFR Subchapter J
Emissions EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR 22 Class A;
EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A; EN
55024:1998+ A1:2001 + A2:2003; EN 61000-4-11:2004; EN 61000-4-8:2001
Telecom FCC part 68; CS-03
Management IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager; Telnet;
RMON1; FTP; IEEE 802.3 Ethernet MIB
Notes The HP 3G Wireless GSM/WCDMA WAN SIC Module (JF820A) is not approved for use in the same chassis as a
Wi-Fi interface (802.11b/g, 802.11b/g/n, etc.) in the European Union.
Services 3-year, parts only, global next-day advance exchange (UW075E)
3-year, 4-hour onsite, 13x5 coverage for hardware (UW076E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UW006E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UW009E)
3-year, 24x7 SW phone support, software updates (UW012E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW077E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW007E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW010E)
4-year, 24x7 SW phone support, software updates (UW013E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW078E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW008E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW011E)
5-year, 24x7 SW phone support, software updates (UW014E)
3 Yr 6 hr Call-to-Repair Onsite (UW079E)
4 Yr 6 hr Call-to-Repair Onsite (UW080E)
5 Yr 6 hr Call-to-Repair Onsite (UW081E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP MSR20-40 Router (JF228A)
Ports 4 SIC slots
2 RJ-45 autosensing 10/100 WAN ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX);
Duplex: half or full
Physical characteristics Dimensions 14.17(w) x 11.3(d) x 1.74(h) in (36 x 28.71 x 4.42 cm) (1U height)
Weight 11.9 lb (5.4 kg)
Memory and processor Processor RISC @ 400 MHz, 256 MB compact flash, 256 MB SDRAM
Mounting Mounts in an EIA standard 19-in. rack
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 17

Performance Throughput 180 Kpps (64-byte packets)
Routing table size 10000 entries (IPv4), 10000 entries (IPv6)
Environment Operating temperature 32ºF to 104ºF (0ºC to 40ºC)
Operating relative
humidity
5% to 90%, noncondensing
Nonoperating/Storage
temperature
-40ºF to 158ºF (-40ºC to 70ºC)
Nonoperating/Storage
relative humidity
5% to 90%, noncondensing
Electrical characteristics Maximum heat
dissipation
341 BTU/hr (359.76 kJ/hr)
Voltage 100-120/200-240 VAC
Maximum power rating 100 W
Frequency 50/60 Hz
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers
provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
Emissions EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR 22 Class A;
EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A; EN
55024:1998+ A1:2001 + A2:2003; EN 61000-4-11:2004; EN 61000-4-8:2001
Telecom FCC part 68; CS-03
Management IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager; Telnet;
RMON1; FTP; IEEE 802.3 Ethernet MIB
Notes The HP 3G Wireless GSM/WCDMA WAN SIC Module (JF820A) is not approved for use in the same chassis as a
Wi-Fi interface (802.11b/g, 802.11b/g/n, etc.) in the European Union.
Services 3-year, parts only, global next-day advance exchange (UW075E)
3-year, 4-hour onsite, 13x5 coverage for hardware (UW076E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UW006E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UW009E)
3-year, 24x7 SW phone support, software updates (UW012E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR554E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR555E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support
(HR556E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UW077E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UW007E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW010E)
4-year, 24x7 SW phone support, software updates (UW013E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UW078E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UW008E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UW011E)
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 18

5-year, 24x7 SW phone support, software updates (UW014E)
3 Yr 6 hr Call-to-Repair Onsite (UW079E)
4 Yr 6 hr Call-to-Repair Onsite (UW080E)
5 Yr 6 hr Call-to-Repair Onsite (UW081E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR558E)
1-year, 24x7 software phone support, software updates (HR557E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
Standards and protocols
(applies to all products in
series)
BGP
RFC 1163 Border Gateway Protocol (BGP)
RFC 1267 Border Gateway Protocol 3 (BGP-3)
RFC 1657 Definitions of Managed Objects for
BGPv4
RFC 1771 BGPv4
RFC 1772 Application of the BGP
RFC 1773 Experience with the BGP-4 Protocol
RFC 1774 BGP-4 Protocol Analysis
RFC 1965 BGP4 confederations
RFC 1997 BGP Communities Attribute
RFC 1998 PPP Gandalf FZA Compression Protocol
RFC 2385 BGP Session Protection via TCP MD5
RFC 2439 BGP Route Flap Damping
Denial of service protection
CPU DoS Protection
Rate Limiting by ACLs
Device management
RFC 1305 NTPv3
RFC 1945 Hypertext Transfer Protocol -- HTTP/1.0
RFC 2271 FrameWork
RFC 2452 MIB for TCP6
RFC 2454 MIB for UDP6
General protocols
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1w Rapid Reconfiguration of Spanning Tree
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
RFC 791 IP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 855 Telnet Option Specification
RFC 3214 LSP Modification Using CR-LDP
RFC 3215 LDP State Machine
RFC 3246 Expedited Forwarding PHB
RFC 3268 Advanced Encryption Standard (AES)
Ciphersuites for Transport Layer Security (TLS)
RFC 3277 IS-IS Transient Blackhole Avoidance
RFC 3279 Algorithms and Identifiers for the Internet
X.509 Public Key Infrastructure Certificate and
Certificate Revocation List (CRL) Profile
RFC 3280 Internet X.509 Public Key Infrastructure
Certificate and Certificate Revocation List (CRL)
Profile
RFC 3392 Support BGP capabilities advertisement
RFC 3479 Fault Tolerance for the Label Distribution
Protocol (LDP)
RFC 3564 Requirements for Support of
Differentiated Services-aware MPLS Traffic
Engineering
RFC 3602 The AES-CBC Cipher Algorithm and Its Use
with IPsec
RFC 3706 A Traffic-Based Method of Detecting Dead
Internet Key Exchange (IKE) Peers
RFC 3784 ISIS TE support
RFC 3786 Extending the Number of IS-IS LSP
Fragments Beyond the 256 Limit
RFC 3811 Definitions of Textual Conventions (TCs)
for Multiprotocol Label Switching (MPLS)
Management
RFC 3812 Multiprotocol Label Switching (MPLS)
Traffic Engineering (TE) Management Information
Base (MIB)
RFC 3847 Restart signaling for IS-IS
FRF.1.2 PVC User-to-Network Interface (UNI)
Implementation Agreement - July 2000
FRF.11.1 Voice over Frame Relay Implementation
Agreement - May 1997 - Annex J added March 1999
FRF.12 Frame Relay Fragmentation Implementation
Agreement - December 1997
FRF.16.1 Multilink Frame Relay UNI/NNI
Implementation Agreement - May 2002
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 19

RFC 856 TELNET
RFC 858 Telnet Suppress Go Ahead Option
RFC 894 IP over Ethernet
RFC 925 Multi-LAN Address Resolution
RFC 950 Internet Standard Subnetting Procedure
RFC 959 File Transfer Protocol (FTP)
RFC 1006 ISO transport services on top of the TCP:
Version 3
RFC 1027 Proxy ARP
RFC 1034 Domain Concepts and Facilities
RFC 1035 Domain Implementation and Specification
RFC 1042 IP Datagrams
RFC 1058 RIPv1
RFC 1071 Computing the Internet Checksum
RFC 1091 Telnet Terminal-Type Option
RFC 1122 Host Requirements
RFC 1141 Incremental updating of the Internet
checksum
RFC 1142 OSI IS-IS Intra-domain Routing Protocol
RFC 1144 Compressing TCP/IP headers for low-
speed serial links
RFC 1195 OSI ISIS for IP and Dual Environments
RFC 1256 ICMP Router Discovery Protocol (IRDP)
RFC 1293 Inverse Address Resolution Protocol
RFC 1315 Management Information Base for Frame
Relay DTEs
RFC 1332 The PPP Internet Protocol Control
Protocol (IPCP)
RFC 1333 PPP Link Quality Monitoring
RFC 1334 PPP Authentication Protocols (PAP)
RFC 1349 Type of Service
RFC 1350 TFTP Protocol (revision 2)
RFC 1377 The PPP OSI Network Layer Control
Protocol (OSINLCP)
RFC 1381 SNMP MIB Extension for X.25 LAPB
RFC 1471 The Definitions of Managed Objects for the
Link Control Protocol of the Point-to-Point Protocol
RFC 1472 The Definitions of Managed Objects for the
Security Protocols of the Point-to-Point Protocol
RFC 1490 Multiprotocol Interconnect over Frame
Relay
RFC 1519 CIDR
RFC 1534 DHCP/BOOTP Interoperation
RFC 1542 Clarifications and Extensions for the
Bootstrap Protocol
RFC 1552 The PPP Internetworking Packet Exchange
Control Protocol (IPXCP)
RFC 1577 Classical IP and ARP over ATM
RFC 1613 Cisco Systems X.25 over TCP (XOT)
RFC 1624 Incremental Internet Checksum
RFC 1631 NAT
FRF.2.2 Frame Relay Network-to-Network Interface
(NNI) Implementation Agreement - March 2002
FRF.20 Frame Relay IP Header Compression
Implementation Agreement - June 2001
FRF.3.2 Frame Relay Multiprotocol Encapsulation
Implementation Agreement - April 2000
FRF.7 Frame Relay PVC Multicast Service and
Protocol Description - October 1994
FRF.9 Data Compression Over Frame Relay
Implementation Agreement - January 1996
IP multicast
RFC 1112 IGMP
RFC 2236 IGMPv2
RFC 2283 Multiprotocol Extensions for BGP-4
RFC 2362 PIM Sparse Mode
RFC 2934 Protocol Independent Multicast MIB for
IPv4
RFC 3376 IGMPv3
IPv6
RFC 1981 IPv6 Path MTU Discovery
RFC 2080 RIPng for IPv6
RFC 2292 Advanced Sockets API for IPv6
RFC 2461 IPv6 Neighbor Discovery
RFC 2462 IPv6 Stateless Address Auto-configuration
RFC 2463 ICMPv6
RFC 2464 Transmission of IPv6 over Ethernet
Networks
RFC 2472 IP Version 6 over PPP
RFC 2473 Generic Packet Tunneling in IPv6
RFC 2529 Transmission of IPv6 Packets over IPv4
RFC 2545 Use of MP-BGP-4 for IPv6
RFC 2553 Basic Socket Interface Extensions for IPv6
RFC 2740 OSPFv3 for IPv6
RFC 2893 Transition Mechanisms for IPv6 Hosts
and Routers
RFC 3056 Connection of IPv6 Domains via IPv4
Clouds
RFC 3513 IPv6 Addressing Architecture
RFC 3596 DNS Extension for IPv6
MIBs
RFC 1213 MIB II
RFC 1229 Interface MIB Extensions
RFC 1286 Bridge MIB
RFC 1493 Bridge MIB
RFC 1573 SNMP MIB II
RFC 1724 RIPv2 MIB
RFC 1757 Remote Network Monitoring MIB
RFC 1850 OSPFv2 MIB
QuickSpecs
HP MSR20 Series
Technical Specifications
DA - 13813 North America — Version 13 — November 22, 2013 Page 20
